Kensence CAT-HDMI-70CT User manual

CAT-HDMI-70CT/CR-P
Transmitter & Receiver
Operation Manual
Kensence (shenzhen)Technology Development CO.,Ltd
Version：V1.01.01
Oct.2016

Contents
1. Product Introduction....................................................................................................................... 1
2. Main Functions................................................................................................................................ 1
3. Specification.................................................................................................................................. 1
4. Equipment operation and function description..............................................................................1
5 Troubleshooting................................................................................................................................4
Frequent Asked Questions.......................................................................................................... 4
6. Package List......................................................................................................................................5
7.Version And Manufacture Information............................................................................................ 5
To protect the equipment and operating personnel from electrostatic discharge, you
should check and ensure it is properly grounded before powering on. Please
observe the following before you install, operate or perform maintenance.
Safety Reminder

Ensure equipment is properly grounded
Please use single-phase three wire system AC 220V power supply, and ensure all transmission
system is properly grounded.
For the safety of operating personnel and the equipment, please turn off all power supplies and
remove the plug before moving or performing physical task. Turn off main power switch on rainy days
or when not in use for a long period of time.
Please do not obstruct cable being plugged on the equipment, it should be properly tied and
managed.
To avoid damaging the equipment, please turn off power supply before plugging or removing power
cable from equipment.
When equipment in operation, it will dissipate heat. Please keep the working environment at
normal temperature by providing good ventilation, so as not to damage equipment or cause
malfunction.
Do not store the equipment under extreme cold or hot environment. Chemical or liquid in the
vicinity of the equipment should not be exposed.
Non professionals without authorized, do not attempt to open the box, or repair.

1
1. Product Introduction
KENSENCE’s new CAT-HDMI-70CT-P & CAT-HDMI-70CR-P is an economic and practical transmission equipment, remotely
transmit full high resolution of HDMI signal via category cable at 70m.
With this enhanced model ends with the “P”, meaning that only required a single power supply from either the transmitter or
at the receiver end.
CAT-HDMI-70CT-P & CAT-HDMI-70CR-P comprises of two parts, a transmitter and a receiver, CAT-HDMI-70CT-P transmitter,
converts the HDMI signal into a single cable transmission. CAT-HDMI-70CR-P, the receiver, manages and converts the high-definition
network signal back to HDMI signal.
2. Main Functions
signal transmission through the network;
Support RS232, IR signal Bi-directional communication;
Supports POC ;
Supports HDMI1.3a，HDCP1.2，DVI1.0 protocol ;
Support signal transmission distance of 70 meters, to support on-site transmission effect adjustment;
support a variety of color space, support for video conversion and frequency doubling function;
Supports common resolutions in various input signal formats, supports common signal formats for VESA and HDTV;
3. Specification
Model
CAT-HDMI/DVI-70CT-P
CAT-HDMI/DVI-70CR-P
input
HDMI/DVI signal input
70M cat signal input
output
70M cat signal output
HDMI/DVI signal output
Color space
Support RGB444，YUV color space
resolution
800x600, 1024x768, 1280x720, 1280x800, 1280x1024, 1360x768, 1366x768,
1440x900, 1440x1050, 1600x1200, 1680x1050, 1680×1050,
1920x1080, 1920x1200
Transmit
distance
70M
Input voltage
DC 12-24V
Dimension
102x79x25mm
Operating
temperature
-10℃- 50℃
Weight
About 0.5KG
Storage
temperature
-25℃- 55℃
Power
consumption
≤10W
≤10W
4. Equipment operation and function description
Note: Please use the following installation sequence, if not properly followed by the installation sequence, the device may not work
or not working properly.

2
4.1 Operating sequence instructions:
1.Connect the signal source transmitter transmitter;
2.Use cable to connect transmitter and receiver.
3.Connect the display device at the transmitter output;
4.Power the device (DC12-24V);
4.2 Device panel description
Figure 4.2.1 CAT-HDMI-70CT-P transmitter front and rear panel
1,RS232 and IR signal port
2,HDMI signal input port
3, power connector
4, RJ45 port (network signal output)

3
Figure 4.2.2 CAT-HDMI-70CR-P Receiver Front and Rear Panels
1,RS232 and IR signal port
2,HDMI signal output port
3, power connector
4, RJ45 port (network signal output)
Figure 4.2.3 CAT-DVI-70CT-P transmitter front and rear panel
1, Power connector
2,RJ45 port (network signal output)

4
3, RS232 and R port
4,DVI signal input port
Figure 4.2.4 CAT-DVI-70CR-P Receiver Front and Rear Panels
1, Power interface
2,RJ45 port (network signal output)
1、RS232 and IR signal output
2、DVI signal output
4.3 Indicator light description
POWER: power indicator light, turn on the power after the light
MODE: device operating status indicator, blinking indicates that the device is operating normally
LINK: HDbaseT signal connection indicator, the device with a cable connected to a constant light
HDCP:HDCP: signal output indicator, blinking signal output is normal
5 Troubleshooting
Frequent Asked Questions
a. Network port indicator does not light up
Solution:

5
-Please check power adaptor or signal cable for loose connection. Turn off the equipment and wait for 5 seconds before
restarting. This is because the product contains a high speed DDR, that will take about 5 seconds to completely reboot.
b. Network port indicator keep flashing
Solution:
-Please check if the signal and display cable is connected properly. We recommend the use of CAT6, 568B standard cable and
distance not exceeding more than 180m.
c. Display appear “snowflakes” or “mosaic”
Solution:
-Please verify the signal source if it’s HDCP compliant as most Bluray DVD will verify this part. Check if the display supports HDCP.
Change the source resolutions to match the equipment supported resolutions.
6. Package List
Please check package before using this product. Do contact us if the product is found faulty or not intact.
7.Version And Manufacture Information
Description of version（Document number：DOC-0001#）
Date
Version
number
Description
2016-10
V1.01.01
First version
SN
Name
Quantity
Unit
1
extender
1
set
2
Power adapter DC 12-24V
1
pcs
3
Certificate
1
pcs
4
Warranty card
1
pcs
5
Instruction Manual
1
pcs

6
Contact us
Kensence (shenzhen) Technology Development
Address : Rm301-310 Tangtou blvd ,shixin community ,shiyan Town , Baoan District , shenzhen ,China 518108
Fax : [phone]
Website : www.kensence.com
Mail : Serv[email protected]
