Kensington 70-watt AC/DC Power Adapter User manual

Notebook AC/DC Power Adapter
Portable 70-Watt AC/DC Power Supply
User Manual
Notebook AC/DC Power Adapter • 1
READ FIRST!

Notebook AC/DC Power Adapter • 2
Congratulations!
Your new Kensington Notebook AC/DC Power Adapter is a highly efficient
power adapter for notebook computers. With the Notebook AC/DC Power
Adapter, you have the flexibility of powering and charging your notebook from
acigarette lighter or airline EmPower® outlet.
The Notebook AC/DC Power Adapter powers and charges both the newest, high
wattage notebooks and older legacy computers. And it is compatible with the
following connections:
•Any 100–120 volt or 200–240 volt 50/60Hz AC wall outlet.
• 12 volt, negative-grounded, DC cigarette lighter.
• Airline in-seat power system.
The Kensington Notebook AC/DC Power Adapter delivers the correct amount of
power to each device through patented, interchangeable adapter tips. Refer to
the included Compatibility Chart to determine which tip you need for your
device. We have included several notebook tips in this package. You may also
purchase additional tips to power and charge other devices such as PDAs,
mobile phones, digital cameras, DVD players, and printers.
Please read this short manual to learn valuable information about the proper
use and installation of your new Notebook AC/DC Power Adapter. Register your
new Notebook AC/DC Power Adapter on line at www.kensington.com/register

Features
The Notebook AC/DC Power Adapter offers many features:
1. Compatible with most major notebook brands.
2. Provides up to 70 watts of safe, efficient power.
3. Safety features include: over voltage, temperature and short
circuit protection.
Notebook AC/DC Power Adapter • 3

Notebook AC/DC Power Adapter • 4
Important: Safety Precautions
The following safety precautions will reduce risk of fire, electric shock, or injury:
• Read all instructions in this user manual carefully before using the Adapter.
• Follow all warnings and instructions marked on the product.
• Before cleaning, remove the Adapter from electrical source. Never use liquid
or aerosol cleaners. Clean the unit with a lightly damp cloth.
• Do not block the grooves located on the case. The grooves are designed to
protect the unit from overheating. Never place the Adapter in a built-in
installation, or on a surface such as a bed, sofa, or rug.
• The Adapter must be operated from the type of power source indicated on
the label. If you are not sure which type of power source you have, consult
your dealer or local power company.
•Plug the Adapter directly into a wall outlet or power strip. This product may
become damaged or may not function properly if used in a plug adapter.
• Place power cable so that it won’t be stepped on or tripped over.
•If this device malfunctions, return it to the dealer from which it was
purchased. It is not user serviceable.
•Do not disassemble this product; doing so may expose you to high voltages
or other risks. Incorrect re-assembly may cause electric shock the next time
the device is used.
•Avoid exposing the Adapter to extreme temperatures. Such as from a
radiator, stove, car, or other heat source.

• Unplug the Adapter and contact Technical Support if any of the
following occur:
-The plastic case is damaged, or is opening at the seam.
-The product has been exposed to water.
-The product displays a change in performance, or does not operate
normally when the operating instructions are followed.
Notebook AC/DC Power Adapter • 5

Technical Specifications
Unit dimensions: 14 cm L x 8 cm W x 1.6 cm H
Weight: 170g
AC wall socket input cable: 17cm
DC auto/air input cable: 46cm
DC power output cable: 25cm
Input voltage: 100–120/200–240 volt 50/60Hz AC
12 to 16 volts DC
Output voltage: 0 to 24-volt DC
Output current: 3.5 Amps maximum
Output power: Up to 70 watts
Contents
• 70-watt AC/DC Power Adapter
• Adapter tips
•Adapter input and output cables
• User Manual
• Compatibility Chart
This adapter has a shorter input cable that connects to a cigarette lighter
socket. The longer cable connects to your device.
Notebook AC/DC Power Adapter • 6

Using your Kensington Notebook AC/DC Power Adapter
Once connected, your battery will automatically charge regardless of whether
your computer is turned on or off.
NOTE: We recommend that you use the Kensington Notebook AC/DC Power
Adapter only with notebook batteries that meet or exceed the original
manufacturer's specifications.
CAUTION: Like the power adapter that came with your notebook, the Kensington
Notebook AC/DC Power Adapter may get warm to the touch during use. This is
normal. Avoid placing the Kensington Notebook AC/DC Power Adapter in direct
sunlight or next to heat sensitive materials.
Selecting the Proper Tip
Make sure you select the right tip for your notebook by reviewing the included
Compatibility Chart.
WARNING: Choosing the wrong tip may damage your computer or cause it
to malfunction.
After you have selected the tip that matches your notebook you’re ready to
get connected.
WARNING: Each AC plug only functions correctly with its designated power source.
The US plug (110/120V) will work when connected to a 110/120V AC power source;
the other plug styles are designed for use with particular 220/240V AC power
sources. Using the wrong plug will cause the Kensington Notebook AC/DC Power
Adapter to malfunction and may render the plug unusable.
Notebook AC/DC Power Adapter • 7

Notebook AC/DC Power Adapter • 8
Getting Connected
1. Connect the correct tip to the adapter output cord.
2. Insert the adapter output cord into the device’s power socket.
3. Follow the instructions on the following pages to connect to a cigarette
lighter or airline in-seat power outlet.
AC Wall Socket Connection
Use the AC wall socket connection anywhere a 100–120 volt or 200–240 volt
50/60Hz AC power source is available.
1. Connect the power tip to the adapter output cable and your notebook
computer, if you haven’t done so already.
2. Connect the AC wall socket input cable to the adapter.
3. Plug the AC connector into a wall outlet or power strip.
When the adapter has power, its status light glows green. Your devices’ battery
is now charging. Your device is now powered.

Auto Connection
The Notebook AC/DC Power Adapter’s auto connector can be used in any
vehicle with a 12-volt DC cigarette lighter socket, such as a car, truck, boat, or an
plane equipped with this type of power socket.
CAUTION: To prevent power interruption and any negative effects on the device
or its software, don’t start your vehicle’s engine while the adapter is connected
to the device.
1. Remove the vehicle’s cigarette lighter from its socket.
WARNING: Acigarette lighter could be hot and burn your skin or flammable
materials. Allow the lighter to cool completely before storing it.
2. Insert your adapter’s auto connector into the cigarette lighter socket.
3. If power to the cigarette lighter socket is not already on, remove the adapter
from the socket and start the vehicle’s engine. Then repeat step 2. The
adapter’s status light glows green when powered.
4. Connect the appropriate tip to the adapter output cable and plug it into your
notebook computer.
The device’s battery will start to charge. Turn on and use your device.
Notebook AC/DC Power Adapter • 9

Air Connection
Use the air connector when travelling with an airline that provides a compatible
in-seat power system.
Some airlines, including American Airlines, provide a 12-volt DC cigarette socket
instead of a special air connection. On these airlines, use the auto connection.
Compatibility between the adapter and an airline in-seat power system
depends upon the airline and the manufacturer’s power specifications for
your device.
1. Remove the auto connector to reveal the air connector: hold the tab at the
base of the connectors to slide the auto connector off.
2. Insert the adapter’s air connector into the in-seat power socket, usually
found on the arm of your seat or under the seat. The adapter’s status light
glows green when powered.
3. Connect the appropriate tip to the adapter output cable and plug it into the
notebook computer.
The device’s battery will start to charge. Turn on and use your device.
Notebook AC/DC Power Adapter • 10
Hold this tab and slide
the auto connector off
auto connector air connector

Technical Support
Technical support is available to all registered users of Kensington products.
There is no charge for technical support except long distance charges where
applicable. Technical Support Contact information can be found on the last
page of this manual.
Technical Support Tips
You may find the answer to your problem in the Frequently Asked Questions
(FAQ) section of the Support area on the Kensington Web site:
www.kensington.com.
• Call from a phone where you have access to your computer.
• Be prepared to provide the following information
-Name, address, and telephone number
- The name of the Kensington product
- Make and model of your computer
-Your system software and version
- Symptoms of the problem and what led to them
Notebook AC/DC Power Adapter • 11

Notebook AC/DC Power Adapter • 12
2-Year Limited Warranty
KENSINGTON TECHNOLOGY GROUP ("KENSINGTON") warrants this PRODUCT against
defects in material and workmanship under normal use and service for two years from the
original date of purchase. KENSINGTON, at its option, shall repair or replace the defective
unit covered by this warranty. Please retain the dated sales receipt as evidence of the date
of purchase. You will need it for any warranty service. In order to keep this warranty in
effect, the produc tmust have been handled and used as prescribed in the instructions
accompanying this warranty. This warranty does not cover any damage due to accident,
misuse, abuse, or negligence.
DISCLAIMER OF WARRANTY
The limited warranty described herein is your sole remedy. To the extent permitted by law,
Kensington disclaims all other implied or express warranties including all warranties of
merchantability and/or fitness for a particular purpose.
LIMITATION OF LIABILITY
Except to the extent of repairing or replacing the power inverter as expressly stated in the
limited warranty described herein, Kensington shall not be liable for any damages, whether
direct, indirect, incidental, special, consequential, exemplary, or otherwise, including lost
revenues, lost profits, loss of use of software, loss or recovery of data, rental of replacement
equipment, downtime, damage to property, and third-party claims, arising out of any
theory of recovery, including statutory, contract or tort. Notwithstanding the term of any
limited or implied warranty, or in the event that any limited warranty fails of its essential
purpose, in no event will Kensington’s entire liability exceed the purchase price of this
product. Some states and provinces do not allow the exclusion or limitation of incidental or
consequential damages so the above limitations or exclusions may not apply to you. This
limited warranty gives you specific legal rights, and you may also have other rights which
vary from state to state and province to province.

Federal Communications Commission Radio Frequency
Interference Statement
Note: The Kensington Notebook AC/DC Power Adapter model nos. 33234 & 33335 have
been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
MODIFICATIONS: Modifications not expressly approved by Kensington may void the user’s
authority to operate the device under FCC regulations and must not be made.
SHIELDED CABLES: In order to meet FCC requirements, all connections to equipment using
aKensington input device should be made using only the shielded cable provided.
Declaration of Conformity Compliance Statement for the Kensington
Notebook AC/DC Power Adapter
The Kensington Notebook AC/DC Power Adapter model nos. 33234 & 33335 comply with
Part 15 of the FCC Rules. Operation is subject to two conditions: (1) This device may not
cause harmful interference, and, (2) this device must accept any interference received,
including interference that may cause undesired operation. As defined in Section 2.909 of
the FCC Rules, the responsible party for this device is Kensington Technology Group,
333 Twin Dolphin Drive, Sixth Floor, Redwood Shores, CA 94065, USA, [phone].
Notebook AC/DC Power Adapter • 13

Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
Notebook AC/DC Power Adapter • 14

Contacting Kensington
Troubleshooting information and answers to frequently asked questions
are available 24 hours a day on the Kensington Web site at
www.kensington.com.
Support by Telephone
Technical Support is available by telephone.
Please visit www.kensington.com for hours.
Notebook AC/DC Power Adapter • 15
901-1779-00 / 901-1780-00
This manual is copyright © 2005 Kensington Technology Group, a division of ACCO Brands, Inc. Any unauthorised
copying, duplicating, or other reproduction of the contents hereof is prohibited without written consent from
Kensington Technology Group. All rights reserved. 1/05 Kensington is a registered trademark of ACCO World
Corporation. Registration of the Kensington trademark is pending in several international locations. All other
registered and unregistered trademarks are the sole property of their respective owners. Protected under US Patent
5,347,211. Other US and Foreign Patents Pending
Kensington Technology Group
333 Twin Dolphin Drive
Sixth Floor
Redwood Shores, CA 94065, USA
Kensington Europe
Oxford House, Oxford Road,
Aylesbury, Bucks, HP21 8SZ
United Kingdom www.kensington.com
Austria 01 790 855 701
Belgium 02 275 0684
Canada 1-800-268-3447
Denmark 35 25 87 62
Finland 09 2290 6004
France 01 7020 0041
Germany 0211 6579 1159
Ireland 01 601 1163
Italy 02 4827 1154
Mexico 001 880 535 4242
The Netherlands 053 482 9868
Norway 22 70 82 01
Spain 91 66 2 3833
Sweden 08 5792 9009
Switzerland 07 730 3830
United Kingdom 0207 949 0119
Portugal 800 831 438
International Toll [phone]

SmartTip Compatibility Chart • 1
SmartTip™Compatibility Chart
The Kensington 70 Watt Power Adapter delivers the correct amount of power to each
digital device through patented, interchangeable tips called SmartTip.™ SmartTips are
required and sold separately. See www.kensington.com for more information on which
SmartTips are needed for your digital devices. Purchasing additional SmartTips allow
you to power and charge your digital devices such as notebooks, iPods, MP3 music
players, cell phones, DVD players, PDAs, etc.
To simultaneously power and charge your notebook and other digital devices use our
Dual Charging Cable for Kensington Power Adapters—sold separately.
CAUTION: Using the incorrect SmartTip could result in a risk of fire, injury to
persons, or damage to personal property.
WARNING: Do not force the SmartTip into your digital device, it can damage the
Power adapter and the digital device.
• SmartTips are uniquely designed. If a tip does not fit in the appropriate socket, this
indicates that a mismatch has occurred. Please refer to the SmartTip compatibility
chart at
www.kensington.com to select the correct tip for your digital device.
• Notebook models change frequently. Please visit
www.kensington.com for the
latest compatibility information.
If your compatible notebook tip is available and not in the pack we will send it to you free
of charge, limit one tip perroduct purchase - visit www.eupowercenter.kensington.com
Compatibility Promise

Acer N14 Aspire 2000WLCi, 2000WLMi
Travelmate 200, 505 to 508 series, 600 series, 8000 series, C110Ti, C300
Apple N16 iBook (Firewire), (Vintage—original), 12.1 in >500MHz, 14.1 in >500MHz, G3
PowerBook G3, 2000 Wall Street Kanga, G3 Lombard, G3 series, Lombard Bronze
N23 iBook G4 (12 inch Display), G4 (14 inch display),
PowerBook G4 12 inch, G4 15 inch, G4 17 inch, Titanium G4
Averatec N3 3100 series, 3200 series, 5100 series
Compaq N3 Evo N115 series, N160 series, N180 series
Presario 1000 series, 1200 series, 1400 series, 1600 Series, 1700 Series, 1800 Series,
2700 Series, 700 Series, 800 series
N8 Armada 100, 1100, 1120, 1125, 1130, 4100 series, 4200 series
LTE 5000, LTE 5080, LTE 5100, LTE 5150, LTE 5180, LTE 5200, LTE 5230, LTE 5250, LTE 5280, LTE
5300, LTE 5380, LTE 5400, LTE 5480, LTE 6000
N9 Armada E500, E500s, E700, M300, M700, V300
Evo N110 series, N150 series, N200 series, N400c, N410c, N600c, N610c, N620c,
N800c, N800v
nc4000, nc6000, nc8000, nw8000
Presario 2200 Series, 2800 Series, 2900 series, 300 Series, M2000 series, V2000 series,
X1000 Series, X1300 series, X1400 series
Prosignia 150, 170, 190
Tablet TC-1000, TC-1100
Dell N11 Latitude LT
N3 Inspiron 200N, 250N, 3000, 3000 D, 3000 M233ST/XT, 3200, 3500, 7000, 7000 D400LT
N4 Latitude XP Series: 100cx, 4100C, 4100D, 4100T, 450c, 450x, 475c, 475D
2 • SmartTip Compatibility Chart

Dell N5 Inspiron 2500 12.1 inch disp, 2500 14 in display, 2500 15 in display, 2600, 2650,
3700, 3800, 4000, 4100, 4150, 5000, 5000e, 7500, 8000, 8100 14 inch display,
8100 15 in display
Latitude C400, C410, C500, C510, C540, C600, C610, C800, CP Series, CPi series,
CPt Series, CPx Series, CS/CSx Series, LM, X200, XPI Series
E-machine N3 Eslate 400K, 450K
Fujitsu- N15 FMV-BIBLO LOOX S80B, S80B/W, S80C, S80C/W, T50E, T50E/W, T70E, T93B, T93B/W,
Siemens T93C, T93C/W
FMV-BIBLO FLX2H, MG12B, MG12B/C, MG12B/M, MG12C, MG12C/M, MG12D, MG13D,
MG17D/A, MG50E, MG55E, MG70E, MG70E/ST, MG75E, MR16B, NB14B, NB14B/R, NB15B,
NB15B/S, NB15B/T, NB16B, NB16B/M, NB16C, NB16C/ST, NB16C/T, NB16C/V, NB16CA,
NB16CR, NB18B, NB18C, NB18C/T, NB18D, NB18D/D, NB18D/F, NB18D/L, NB18D/V, NB19D,
NB19D/D, NB70E, NB70E/T, NH24C, NH24D, NH26C, NH28D, NH50E, NH70E, NH90E/T, NU,
RS18D, RS18D/D, RS18D/ST, RS18D/T, RS50E/T, RS55E/T
Lifebook 200 Series, 400 Series, 500 Series, 600 Series, 700 Series, 900 Series, B112, B142,
B2, B2130, B2131, B2545, B2562, B2562 w/high cap main battery, B2562 w/main battery,
B2566, B2566 w/high cap main battery, B2566 w/main battery, B2610, B2620, B2630,
C340, C350, C352, C353, C360, C4120, C4235, C5130, C5235, C6177, C6320, C6330, C6525,
C6535, C6537, C6547, C6556, C6557, C6577, C6581, C6591, C6611, C6631, C6651 14.1 in. display,
C6651 15 in. display, C7631, C7651 14 in. display, C7651 15 in. display, C7661 14 in. display,
C7661 15 in. display, Celsius Mobile H, E2010, E330, E340, E342, E350, E351, E360, E362, E370,
E380, E5140, E5320, E5520, E6150, E6520, E6530, E6540, E6541, E6550, E6555, E6556, E6557,
E6570, E6571, E6575, E6595, L440, L470, S2010, S4510, S4542, S5582, S6010, S6110, S6120,
S6120D, T3010D
LifeBook Stylistic 3400, 3500, LT C-500, LT P-600, ST4110, ST4110P, ST4120, ST4120P
LifeBook ST4121
SmartTip Compatibility Chart • 3

Fujitsu- N3 LifeBook A1010, A4170, A4177, A4178, A4187, A4190, Amilo L, C2010, C2110, C2111,
Siemens C2210, E4010, E4010D, E6624, E6634, E6644, E6654, E6664, E7010, E7110, P1000, P1032,
P1035, P1120, P2000, P2040, P2046, P2110, P2120, P5010, P5010D
Gateway N12 200X, 200XL, Solo 200ARC
Solo 200ARC
N3 400SD4, 450ROG, 450SX4, 600YG2, 600YGR, M1200, M305, M305X, M500
Solo 1100, 1150, 1150 CL, 1150 CS, 1200, 1400, 1400ls, 1400se, 1450 LS, 1450 SE, 200, 2000,
2100 series, 2150 series, 2200 series, 2300 series, 2500 Series, 2550 series,
3100 Series, 3150 Series, 4520GZ, 4525GZ, 5100 Series, 5150 Series, 5300 Series,
5350 Series, 600 series, 9100 Series, 9150 series, 9300 Series, 9500, 9550 series
Tablets Tablet PC, Tablet PC Deluxe
HP N3 Omnibook 2000, 2100, 2103, 2105, 300, 3000, 3100, 3101, 4100., 4101, 4103, 4105, 4150, 425,
430, 500, 5000, 510, 530, 5500, 5700, 6000 14 in display, 6000 15 in display, 600c, 600ct,
6100 14 in display, 6100 15 in display, 7100., 7103, 7150, 900, 900b, vt6200, XE, XE2, XE3 14
in display, XE3 15 in display, xe4000, xe4100, xe4200, xe4400, xe4500, xt1000, xt1500,
xt6050, xt6200 Series 14 inch, xt6200 Series 15 inch, ZE, ZE2, ZE3
Pavilion 2105, 3000, 3100, 3101, 4100, 4101, 4103, 4105, 5159, 6000, 6100, 7100, N3000,
N3100, N3110, N3150, N3190, N3200, N3210, N3215, N3220, N3250, N3270, N3290, N3295,
N3300, N3310, N3330, N3350, N3370, N3390, N3400, N3402, N3410, N3438, N3478, N3490,
N5100, N5124, N5125, N5130, N5135, N5140, N5150, N5159, N5170, N5190, N5195, N5210, N5221,
N5240, N5241, N5250, N5261, N5270, N5271, N5290, N5295, N5310, N5311, N5340, N5341,
N5350, N5351, N5371, N5381, N5390, N5400, N5402, N5412, N5415, N5420, N5421, N5422,
N5425, N5430, N5435, N5440, N5441, N5442, N5444, N5445, N5450, N5452, N5454, N5455,
N5461, N5462, N5470, N5472, N5474, N5475, N5481, N5482, N5484, N5490, N5491, N5495,
N6000, N6100, N6190, N6195, N6300, N6395, N6396, N6397, N6398, N6399, N6400,
N6401, N6402, N6403
4 • SmartTip Compatibility Chart

HP N3 Pavilion N6404, N6490, xf125, xf145, xf235, xf255, xf315, xf325, xf328, xf335, xh136, XH156,
xh176, xh215, xh216, xh226, xh355, xh365, xh455, xh485, xh535, xh545,
xh555, xH575, xh675, xt115, xt118, xt125, xt128, xt155, xt178, xt183, xt188, xt236, xt276, xt345,
xt375, xt395, xt412, xt537, xt5377, xt545, xt555, xt565, xt575, xt585, xt595, xu155, xz133, xz148,
xz163, xz168, xz185, xz275, xz295, xz335, xz355, xz815, zd7000 series, ze1000, ze1100, ze1110,
ze1115, ze1145, ze1200, ze1201, ze1202,
ze1210, ze1230, ze1250, ze1260, ze4100 series, ze4200 series, ze4300 series,
zt1100 series, zt1200 series, zt1331, zt3340us, zu1155, zu1175
N9 Pavilion dv1000 series, ze4900 series, zt3000 series, zt3100 series, zt3200 series,
zt3300 series
IBM N2 ThinkPad 240, 240X, 290, 365, 365XD, 380, 380D, 380E, 380ED, 380XD, 380Z, 385, 385D,
385ED, 385XD, 390, 390E, 390X, 550, 560, 560E, 560X, 560Z, 570, 600, 600D, 600X, 660, 701,
770, 770E, 770ED, 770X, 770Z, A20, A20, A21, A20M, A20P, A21, A21E, A21M, A21P, A22, A22M,
A31, E530, i Series 1200 models, i Series 1300 models, i Series 1400-2621 models, i Series
1500-2621 models, i Series 1700 models, R30, R31, R32, R40, R40e, R50, R50p, S, T20, T21, T22,
T23, T40, T41, TransNote, X20, X21, X22, X31, X40
Transnote 2625
N8 ThinkPad 310, 310D, 310E, 310ED, 315, i Series 1400-2611 models,
i Series 1500-2611 models
NEC N3 LaVie C LaVie C LC500/4D, LC700/4D, LC700/6D, LC700/7D, LC900/4D, LC900/7D,
LC950/4D, PC-LC3001A, PC-LC3002D, PC-LC5001D, PC-LC5002D, PC-LC5003D,
PC-LC5004D, PC-LC5005D, PC-LC5503DW, PC-LC7001D, PC-LC7003D, PC-LC7004D,
PC-LC7005D, PC-LC9001D, PC-LC9002D, PC-LC9003E, PC-LC9004D, PC-LC9005D,
PC-LC950/4D, PC-LC9503E, PC-LC9504E
LaVie F LF550/4D, PC-LF5504D, PC-LF5505D, PC-LF7507D
SmartTip Compatibility Chart • 5
