Kenwood DNN9350BT User manual

14DNN_IM383_Ref_M_en_00 (M/M2/X)© 2014 JVC KENWOOD Corporation
CONNECTED NAVIGATION SYSTEM
DNN9350BT
DNN9350BTM
CONNECTED MONITOR WITH DVD RECEIVER
DNR8035BT
DNR8035BTM
INSTRUCTION MANUAL
Before reading this manual, click the button below to check the latest edition and the
modified pages.
http://manual.kenwood.com/edition/im383/
Check the latest edition

1
Return to the Top page
What Do You Want To Do?
Thank you for purchasing the KENWOOD CONNECTED NAVIGATION SYSTEM.
In this manual, you will learn various convenient functions of the system.
Click the icon of the media you want to play.
With one-click, you can jump to the section of each media!
iPod USB
VCD
DVD VIDEO
Music CD Disc Media
BT Audio Pandora Apps
Radio
Storage
Wireless Link

2
Before Use 4
#WARNING _______________________ 4
How to Read this Manual 6
Features of Connected systems 8
Basic Operations 10
Functions of the Buttons
on the Front Panel __________________ 10
Turning on the Unit _________________ 12
How to Play Media __________________ 17
Operation on the Home Screen________ 18
Common Operation _________________ 22
Navigation Operation
(DNN9350BT/ DNN9350BTM) _________ 24
Network Setup 28
Wi-Fi Setup ________________________ 28
Wi-Fi Hotspot Setup _________________ 30
Clock and Date Setup 32
Clock and Date Setup________________ 32
Account Setup 34
About Account _____________________ 34
Create User Account_________________ 34
Set Owner Account _________________ 35
Set User Account ___________________ 36
Switch the User Login _______________ 36
Delete User Account_________________ 37
Reset Owner Account________________ 37
Widget and Application
Operation 38
Today Widget ______________________ 38
SNS Widget ________________________ 38
RSS Widget ________________________ 39
Schedule Application________________ 40
Facebook (SNS Application)___________ 42
Twitter (SNS Application) _____________ 44
E-mail (SNS Application) _____________ 46
RSS Application ____________________ 48
Now playing Widget_________________ 50
Summary Board Widget______________ 52
Photo Frame Widget_________________ 52
Mixed Media Search_________________ 53
DVD/Video CD (VCD)
Operation 54
DVD/VCD Basic Operation ____________ 54
DVD Disc Menu Operation____________ 57
Zoom Control for DVD and VCD _______ 58
DVD Setup ________________________ 59
CD/Audio and Visual Files/iPod/
Apps Operation 62
Music/Video Basic Operation__________ 62
Search Operation ___________________ 68
Movie Control______________________ 72
Pandora® Operation
(region code 4 area only) _____________ 73
Apps Operation ____________________ 76
USB/iPod/DivX/Apps Setup ___________ 77
ñ
Contents

3
Cloud Storage Operation 82
Starting procedure __________________ 82
Music Basic Operation _______________ 82
Category search ____________________ 83
Kenwood Wireless Link
Operation 84
Starting procedure __________________ 84
Media Server function _______________ 85
Media Player function _______________ 85
Media Controller function ____________ 86
Media Renderer function _____________ 87
Radio Operation 88
Radio Basic Operation _______________ 88
Memory Operation__________________ 90
Selecting Operation _________________ 91
Traffic Information __________________ 92
Tuner Setup _______________________ 92
Streaming Service Application 94
Streaming Video Application__________ 94
AUPEO! Application _________________ 96
Bluetooth Control 98
Registering and Connecting
Bluetooth Unit _____________________ 98
Playing Bluetooth Audio Device _______ 101
Using Hands-Free Feature ____________ 102
Hands-Free Setup___________________ 106
Camera Control 108
Camera Control_____________________ 108
Switching the View Camera ___________ 108
Setting Up 110
Monitor Screen Setup _______________ 110
System Setup ______________________ 111
Display Setup ______________________ 114
Navigation Setup
(DNN9350BT/ DNN9350BTM) _________ 116
Camera Setup ______________________ 116
Software Information________________ 118
AV Input Setup _____________________ 119
AV Output Interface Setup____________ 119
Controlling Audio 120
Setting Audio ______________________ 120
Controlling General Audio ____________ 124
Equalizer Control ___________________ 125
Sound Effect _______________________ 126
Zone Control_______________________ 128
Listening Position___________________ 128
Remote Control 130
Battery Installation __________________ 130
Functions of the Remote Control Buttons _ 131
Troubleshooting 134
Problems and Solutions ______________ 134
Error Messages _____________________ 135
Resetting the Unit __________________ 137
Appendix 138
Playable Media and Files _____________ 138
Status Bar Indicator Items ____________ 141
Region Codes in the World____________ 143
DVD Language Codes _______________ 144
Specifications ______________________ 145
Trademarks ________________________ 148
Safety precaution ___________________ 151

4
Return to the Top page
Before Use
#WARNING
ÑTo prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or
leave any metallic objects (such as coins or
metal tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any
extended period.
• If you experience problems during
installation, consult your Kenwood dealer.
ÑPrecautions on using this unit
• When you purchase optional accessories,
check with your Kenwood dealer to make
sure that they work with your model and in
your area.
• You can select language to display menus,
audio file tags, etc. See Language setup
(P.112).
• The Radio Data System or Radio Broadcast
Data System feature won’t work where
the service is not supported by any
broadcasting station.
ÑProtecting the monitor
To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with the sharp tip.
ÑCleaning the unit
If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe the
stain off with a cloth moistened with neutral
cleaner, then wipe it again with a clean soft
dry cloth.
!
• Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the faceplate
with a hard cloth or using a volatile liquid such
as thinner or alcohol may scratch the surface or
erase screened print.
ÑLens fogging
When you turn on the car heater in cold
weather, dew or condensation may form
on the lens in the disc player of the unit.
Called lens fogging, this condensation on
the lens may not allow discs to play. In such
a situation, remove the disc and wait for the
condensation to evaporate. If the unit still
does not operate normally after a while,
consult your Kenwood dealer.
ÑPrecautions on handling discs
• Do not touch the recording surface of the
disc.
• Do not stick tape etc. on the disc, or use a
disc with tape stuck on it.
• Do not use disc type accessories.
• Clean from the center of the disc and move
outward.
• When removing discs from this unit, pull
them out horizontally.
• If the disc center hole or outside rim has
burrs, use the disc only after removing the
burrs with a ballpoint pen etc.
• Discs that are not round cannot be used.
• 8-cm (3 inch) discs cannot be used.
• Discs with coloring on the recording
surface or discs that are dirty cannot be
used.
• This unit can only play the CDs with
.
This unit may not correctly play discs which
do not have the mark.
• You cannot play a disc that has not been
finalized. (For the finalization process see
your writing software, and your recorder
instruction manual.)
ñ
Before Use

5
Return to the Top page
Before Use
ÑErase the personal information
Before giving or selling this unit to others, be
sure to delete the information (mail, search
logs, etc.) stored in this unit by yourself and
confirm that the data has been deleted.
We shall not be liable for any damage caused
by leakage of undeleted data.
1 Press the <HOME> button.
HOME 6
2 Press the <MENU> button.
HOME 6
3 Touch [Setting].
4 Touch [Backup & Reset].
5 Touch [Factory data reset].
6 Enter owner password. Touch [Rest].
7 Touch [ERASE].

6
Return to the Top page
How To Read This Manual
30
Return to the Top page
CD/Audio and Visual Files/iPod/Apps Operation
30
Search Operation
You can search music, video or picture files
by the following operations.
NOTE
• If you use a remote controller, you can jump
directly to the desired track/file with entering the
track/folder/file number, play time, etc. For details,
see Direct search mode (P.135).
ÑList search
You can search tracks, folders, and files
according to hierarchy.
1 Touch illustrated area.
List Control screen appears.
2 Touch desired track/file.
Playback starts.
ÑOther search
When you want to narrow the list down,
there are other search ways.
This function is not available when music CD
is the current source.
1 Touch [ ] in the control screen.
The search type screen appears.
2 Touch desired search way.
ñ
How to Read this Manual
NOTE
• The screens and panels shown in this
manual are examples used to provide clear
explanations of the operations.
For this reason, they may be different from the
actual screens or panels used, or some display
patterns may be different.
Link header
You can refer each section or top page with
one-click.
Reference mark
Displayed in blue notes.
With one-click, you can jump to the
article related to the current section.
Screen shot
Shows some screen shots displayed during
operation for reference.
The area or keys to touch are surrounded
with a red frame.
Operation procedure
Explains necessary procedures to
achieve the operation.
< >: Indicates the name of panel
buttons.
[ ]: Indicates the name of touch
keys.
Operation title
Introduces the function.
NOTE
Introduces some tips, notes, etc.

7
Return to the Top page
How To Read This Manual

8
Return to the Top page
Basic Operations
ñ
Features of Connected systems
By connecting this unit to Internet, you can use various services.
Use of internet service
• Streaming service such as YouTube, Aupeo!.
• Internet service such as email, Gmail, Google calendar, and social networking service such as
Facebook and Twitter.
• Information (RSS, etc.) service.
Cooperation with Route Collector site
• Destinations and routes specified on the PC can be input to this navigation system.
• The routes you have traveled and the songs you have listened to can be logged. (P.25)
• By uploading music files to Dropbox and creating a play list on Route Collector site, you can listen
to music anywhere through streaming without music files on this unit. (P.82)
• Speech to Text (STT) and Text to Speech (TTS).
Notes
You can use following feature for 2 years after
registration of the owner account. To use it
continuously, a usage fee is required. For details,
see web site of Route Collector.
http://www.route-collector.com/
• TTS (by Nuance)
• STT (by Nuance)
To use the following services, you need to
register the corresponding free or paid accounts.
• Aupeo!
• Facebook
• Twitter
• Gmail (by Google)
• Google calendar (by Google)
• Dropbox
About the account
• To use internet services via this system,
you need to create an account in the
Route Collector site.
• In addition to the owner account, you
can register up to four user accounts.
• You can use a guest account as well.
• By switching among accounts, you can
secure the privacy when using the mail
feature or social media.
For details, see About Account (P.34).
http://www.route-collector.com/

9
Return to the Top page
Basic Operations
• Media player for DVD video, CD, USB memory, iPod, etc.
• Radio.
• Navigation (DNN9350BT/ DNN9350BTM)
Wi-Fi access point
• Connect to Internet using the tethering
function of your smartphone or an
Internet device. (P.28)
HOME 6
Wi-Fi (11n/g/b)
4G, 3G, LTE
or EDGE
Wi-Fi hotspot
• This unit becomes the Wi-Fi access
point and you can enjoy music and
video in a smartphone Wi-Fi connected
by Kenwood Wireless Link.(P.30)

10
Return to the Top page
Basic Operations
ñ
Functions of the Buttons on the Front Panel
HOME 6
DNR8035BT/
DNR8035BTM 10
9
1 4 5 6 7 82 3
NOTE
• The panels shown in this guide are examples used to provide clear explanations of the operations. For this reason,
they may be different from the actual panels.
How to insert an SD Card (DNN9350BT/ DNN9350BTM)
1) Press
8
<G> button for 1 second.
The panel fully opens.
2) Hold the SD card as the illustration in the right
and insert it into the slot until it clicks.
VTo eject the card:
Push the card until it clicks and then remove your finger
from the card.
The card pops up so that you can pull it out with your
fingers.
ñ
Basic Operations
0
Labelled
side

11
Return to the Top page
Basic Operations
Number Name Motion
1
s(Reset) • If the unit or the connected unit fails to operate properly, the unit
returns to initial settings when this button is pressed (P.137).
• If the SI function is turned on, this indicator flashes when the vehicle
ignition is off (P.113).
2
S, R(Vol) Adjusts volume.
3
Remote
Sensor
Receives the remote control signal.
4
NAV
(DNN9350BT/
DNN9350BTM)
• Displays the navigation screen.
• Pressing for 1 second turns the screen off.*
APPS
(DNR8035BT/
DNR8035BTM)
• Displays the APPS screen .
• Pressing for 1 second turns the screen off.*
5
MENU • Displays the option menu screen.
• Pressing for 1 second switches AV out sources.
6
HOME • Displays the Home screen (P.18).
• Pressing for 1 second turns the power off.
• When the power off, turns the power on.
7
6(Back) • Return to the previously viewed screen.
• Pressing for 1 second displays the Hands Free screen (P.102).
8
G(Eject) • Ejects the disc.
• When the panel is opened, pressing closes the panel and pressing for 1
second ejects the disc forcibly.
• When the panel is closed, pressing for 1 second fully opens the panel to
the location of the SD card slot.
9
Disc insert
slot
A slot to insert a disc media.
10
SD card slot
(DNN9350BT/
DNN9350BTM)
An SD card slot for upgrading the map. For how to upgrade the map, refer
to the instruction manual of the navigation system.
* The function of the [NAV]/ [APPS] button can be changed to camera view function. See User
interface (P.111).

12
Return to the Top page
Basic Operations
ñ
Turning on the Unit
The method for turning on the power varies between different models.
Press the <HOME> button.
HOME 6
The unit is turned on.
ö To turn off the unit:
Press the <HOME> button for 1 second.
If it is your first time turning the unit on after installation, it will be necessary to perform
Initial setup (P.14).
1

13
Return to the Top page
Basic Operations
Login
Select the login user.
When the owner has not been registered
When the owner has been registered
Enter the password.
When you selected Administrator or Guest, you do not need to enter a password.
[Auto Login?]: Checking this checkbox allows you to log in to the system automatically from
the next time.
Touch [Login].
NOTE
• If you forgot your password, create your new password on the Route Collector site.
http://www.route-collector.com/
1
2
3

14
Return to the Top page
Basic Operations
Initial setup
Perform this setup when you use this unit for the first time or when you reset the unit. See
Resetting the Unit (P.137).
Set each item as follows.
Language Setup
Select the language used for the GUI and input methods. Default is “English (United States)”.
1Touch [Language Setup].
2Select a language from the list.
WiFi Setup
Configure settings for connection to Wi-Fi.
1Touch [WiFi Setup].
2Slide Wi-Fi to ON.
3Select the Wi-Fi access point to register from the list.
4Enter the Password.
5Touch [Connect].
6After setting, press the < 6> button.
For details on operation, see Wi-Fi Setup (P.28).
Date Setup
Set the date and time.
1Touch [Date Setup].
2Touch [Select time zone].
3Select a time zone.
4After setting, press the < 6> button.
For details on operation, see Clock and Date Setup (P.32).
Account Setup
Set the information about the user of this unit.
1Touch [Account Setup].
For details on operation, see About Account (P.34).
1

15
Return to the Top page
Basic Operations
Touch [Next].
Set each item as follows.
Locale
Select the country for the navigation system.
The language, the distance unit, and the gasoline unit are set.
1Touch [SET].
2Select the desired country.
3Touch [Enter].
Language
Select the language used for the control screen and setting items. Default is “American English (en)”.
1Touch [SET].
2Touch [C] or [D] to select the desired language.
3Touch [Enter].
For details on operation, see Language setup (P.112).
Angle
Adjust the position of the monitor. Default is “0”.
1Touch [SET].
2Touch desired angle number and [ ].
For details on operation, see Monitor angle control (P.114).
2
3
Continued

16
Return to the Top page
Basic Operations
Color
Set the screen and button illumination color. You can select whether to allow color scan operation or
select a fixed color for operation.
1Touch [SET].
2Touch [ON] or [OFF] of [Panel Color Scan].
3If you want to change color, touch [SET] of [Panel Color Coordinate].
4Touch your desired color and [ ].
For details on operation, see Panel color coordinate (P.115).
Camera
Set the parameters for the camera.
1Touch [SET].
2Set each item and touch [ ].
For details on operation, see Camera Setup (P.116).
DEMO
Set the demonstration mode. Default is “ON”.
1Touch [ON] or [OFF].
Touch [Finish].
NOTE
• These settings can be set from the SETUP menu. See Setting Up (P.110).
4

17
Return to the Top page
Basic Operations
ñ
How to Play Media
Music CD and disc media
Press the <G> button.
HOME 6
The panel opens.
Insert the disc into the slot.
The panel closes automatically.
The unit loads the disc and playback
starts.
ö To eject the disc:
Press the <G> button.
USB device
Connect the USB device with the
USB cable.
The unit reads the device and playback
starts.
ö To disconnect the device:
Touch [G] on the screen and disconnect
the device from the cable.
iPod
Connect the iPod.
NOTE
• For the details of the necessary cable and adapter
to connect with iPod/iPhone, refer to Music/
Video Basic Operation (P.62).
The unit reads the iPod and playback
starts.
ö To disconnect the iPod/iPhone
connected with the cable:
Touch [G] on the screen and disconnect
the device from the cable.
1
2
1
1

18
Return to the Top page
Basic Operations
ñ
Operation on the Home Screen
Most functions can be operated on the Home screen.
Press the <HOME> button.
HOME 6
Home screen appears.
Flick the screen left or right to select the Service panel, Media panel, Source
launcher panel, or Network contents panel.
Panel Description
1Service panel Network widget: Displays the schedule, SNS, or RSS.
2Media panel Now playing: Displays the title of the song being played or the name
of the station you are listening to, and allows you to perform simple
operations.
Media widget: Displays the Summary board that shows the songs you
marked with Like and the playback history, and the Photo frame that
shows photos.
3Source launcher panel Allows you to select a source.
4Network contents panel Allows you to select a network-related application.
1
2

19
Return to the Top page
Basic Operations
Source launcher panel and Network contents panel
(Shortcut icon)
You can register sources and applications
you use frequently so that you can start them
quickly.
(All source list/ All apps list)
Displays all sources and applications.
All source list/ All apps list
(All source list/ All apps list)
You can scroll the list screen by flicking the
screen up/down.
(Home)
Returns to the Source launcher panel or the
Network contents panel.
From All source list, you can perform the following functions.
Function Icon Operation
Switch the audio source
etc.
Touch the icon of the
desired source.
Switch the video source
etc.
Touch the icon of the
desired video source.
Display navigation
screen (DNN9350BT/
DNN9350BTM) or
Touch [NAV] or
navigation information.
Turn off all audio
function
Touch [STANDBY].
