SERVICE MANUAL

UHF DIGITAL TRANSCEIVER

NX-800, NX-800H

This service manual has been revised due to the modication of the Mixer IC.

This service manual applies to products with B2801161 (except B2801431 to B2801544) or

subsequent serial number. Refer to the NX-700/700H service manual (B51-8822-00) for any

information which has not been covered in this service manual.

SUPPLEMENT

2015/11

B5B-7219-00

KMC-36

(Option)

NX-800/800H

CONTENTS

PARTS LIST ................................................................................................................................. 3

ADJUSTMENT

NX-800/800H (K,K2) Receiver Section .................................................................................. 20

NX-800H (K3) Receiver Section ............................................................................................ 21

PC BOARD

NX-800/800H (K,K2): TX-RX UNIT (X57-8900-XX, XC1-0990-10) ......................................... 22

NX-800H (K3): TX-RX UNIT (X57-8900-18) ............................................................................ 28

BLOCK DIAGRAM

NX-800/800H (K,K2): TX-RX UNIT (X57-8900-XX, XC1-0990-10) ......................................... 34

NX-800H (K3): TX-RX UNIT (X57-8900-18) ............................................................................ 36

APPENDIX (SCHEMATIC DIAGRAM X57-8900-XX, XC1-0990-10: NX-800/800H (K,K2))

APPENDIX (SCHEMATIC DIAGRAM X57-8900-18: NX-800H (K3))

Document Copyrights

rights reserved.

No part of this manual may be reproduced, translated,

distributed, or transmitted in any form or by any means, elec-

tronic, mechanical, photocopying, recording, or otherwise,

for any purpose without the prior written permission of JVC

KENWOOD Corporation.

Firmware Copyrights

The title to and ownership of copyrights for ﬁrmware em-

bedded in KENWOOD product memories are reserved for

JVC KENWOOD Corporation. Any modifying, reverse engi-

neering, copy, reproducing or disclosing on an Internet web-

site of the ﬁrmware is strictly prohibited without prior written

consent of JVC KENWOOD Corporation. Furthermore,

any reselling, assigning or transferring of the firmware is

also strictly prohibited without embedding the firmware in

KENWOOD product memories.

Disclaimer

While every precaution has been taken in the preparation

of this manual, JVC KENWOOD Corporation assumes no

responsibility for errors or omissions. Neither is any liability

assumed for damages resulting from the use of the informa-

tion contained herein. JVC KENWOOD Corporation reserves

the right to make changes to any products herein at any time

for improvement purposes.

Transceivers containing AMBE+2™ Vocoder:

The AMBE+2™ voice coding technology is embedded in

the ﬁrmware under the license of Digital Voice Systems, Inc.

NX-800/800H

Chip capacitor

Code L W T

Empty 5.6±0.5 5.0±0.5 Less than 2.0

A 4.5±0.5 3.2±0.4 Less than 2.0

B 4.5±0.5 2.0±0.3 Less than 2.0

C 4.5±0.5 1.25±0.2 Less than 1.25

D 3.2±0.4 2.5±0.3 Less than 1.5

E 3.2±0.2 1.6±0.2 Less than 1.25

F 2.0±0.3 1.25±0.2 Less than 1.25

G 1.6±0.2 0.8±0.2 Less than 1.0

H 1.0±0.05 0.5±0.05 0.5±0.05

Chip resistor

Code L W T

E 3.2±0.2 1.6±0.2 1.0

F 2.0±0.3 1.25±0.2 1.0

G 1.6±0.2 0.8±0.2 0.5±0.1

H 1.0±0.05 0.5±0.05 0.35±0.05

• Rating wattage

Code Wattage Code Wattage Code Wattage

1J 1/16W 2C 1/6W 3A 1W

2A 1/10W 2E 1/4W 3D 2W

2B 1/8W 2H 1/2W

(Less than 10pF)

Code B C D F G

(pF) ±0.1 ±0.25 ±0.5 ±1 ±2

CAPACITORS

C C 4 5 T H 1 H 2 2 0 J

1 2 3 4 5 6

1 = Type ... ceramic, electrolytic, etc. 4 = Voltage rating

2 = Shape ... round, square, etc. 5 = Value

3 = Temp. coefficient 6 = Tolerance

• Temperature coefficient

1st Word C L P R S T U

Color* Black Red Orange Yellow Green Blue Violet

ppm/°C 0 –80 –150 –220 –330 –470 –750

• Tolerance (More than 10pF)

Code C D G J K M X Z P No code

(%) ±0.25 ±0.5 ±2 ±5 ±10 ±20 +40 +80 +100 More than 10μF : –10~+50

–20 –20 –0 Less than 4.7μF : –10~+75

• Voltage rating

2nd word

A B C D E F G H J K V

1st word

0 1.0 1.25 1.6 2.0 2.5 3.15 4.0 5.0 6.3 8.0 –

1 10 12.5 16 20 25 31.5 40 50 63 80 35

2 100 125 160 200 250 315 400 500 630 800 –

3 1000 1250 1600 2000 2500 2150 4000 5000 6300 8000 –

• Chip capacitors

(EX) C C 7 3 F S L 1 H 0 0 0 J Refer to the table above.

1 2 3 4 5 6 7 1 = Type

(Chip) (CH, RH, UJ, SL) 2 = Shape

3 = Dimension

(EX) C K 7 3 F F 1 H 0 0 0 Z 4 = Temp. coefficient

1 2 3 4 5 6 7 5 = Voltage rating

(Chip) (B, F) 6 = Value

7 = Tolerance

RESISTORS

• Chip resistor (Carbon)

(EX) R D 7 3 E B 2 B 0 0 0 J

1 2 3 4 5 6 7

(Chip) (B, F)

• Carbon resistor (Normal type)

(EX) R D 1 4 B B 2 C 0 0 0 J

1 2 3 4 5 6 7

1 = Type 5 = Rating wattage

2 = Shape 6 = Value

3 = Dimension 7 = Tolerance

4 = Temp. coefficient

CC45 Color*

2nd Word G H J K L

ppm/°C ±30 ±60 ±120 ±250 ±500

Example : CC45TH = –470±60ppm/°C

• Capacitor value

010 = 1pF 2 2 0 = 22pF

100 = 10pF

101 = 100pF Multiplier

102 = 1000pF = 0.001μ

F 2nd number

103 = 0.01μF

1st number

• Dimension

PARTS LIST

NX-800/800H

PARTS LIST

indicates safety critical components.

Parts without Parts No. are not supplied.

Les articles non mentionnes dans le Parts No. ne sont pas fournis.

Teile ohne Parts No. werden nicht geliefert.

L: Scandinavia K: USA P: Canada

Y: PX (Far East, Hawaii) T: England E: Europe

C: China X: Australia M: Other Areas

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

Ref. No.

Address Parts No. Description

Desti-

nation

TX-RX UINT (X57-8900-XX) -10: K -11: HK -13: HK2 -18: HK3

TX-RX UINT (XC1-0990-10): K2

C1 CK73HXR0J105K CHIP C 1.0UF K

C2 CC73HCH1H101J CHIP C 100PF J

C3 CK73HBB1H471K CHIP C 470PF K

C4 CK73HBB1A104K CHIP C 0.1UF K

C5 CK73HBB1E103K CHIP C 0.01UF K

C6 CC73HCH1H101J CHIP C 100PF J

C7 CC73HCH1H180J CHIP C 18PF J

C8 CC73HCH1H080B CHIP C 8.0PF B K,HK

C8 CC73HCH1H100B CHIP C 10PF B K2,HK2

C8 CC73HCH1H120G CHIP C 12PF G HK3

C9 CK73HBB1E103K CHIP C 0.01UF K

C10 CC73HCH1H390J CHIP C 39PF J

C11 CK73FB1A106K CHIP C 10UF K

C12 CC73HCH1H080B CHIP C 8.0PF B K,HK

C12 CC73HCH1H120G CHIP C 12PF G

K2,HK2,HK3

C13 CK73HBB1E103K CHIP C 0.01UF K

C14 CK73GB1E105K CHIP C 1.0UF K

C15 CC73HCH1H101J CHIP C 100PF J

C16 CK73HBB1E103K CHIP C 0.01UF K

C17 CK73HBB1E103K CHIP C 0.01UF K

C18 CC73HCH1H101J CHIP C 100PF J

C19 CC73HCH1H101J CHIP C 100PF J

C20 CC73HCH1H101J CHIP C 100PF J

C21 CC73HCH1H101J CHIP C 100PF J

C22 CC73HCH1H101J CHIP C 100PF J

C23 CC73HCH1H101J CHIP C 100PF J

C24 CK73HBB1A104K CHIP C 0.1UF K

C25 CC73HCH1H101J CHIP C 100PF J

C26 CC73HCH1H101J CHIP C 100PF J

C27 CK73HBB1A104K CHIP C 0.1UF K

C28 CC73HCH1H101J CHIP C 100PF J

C29 CC73HCH1H101J CHIP C 100PF J

C31 CC73HCH1H101J CHIP C 100PF J

C32 CS77MA1VR15M CHIP TNTL 0.15UF 35WV

C33 CC73HCH1H330J CHIP C 33PF J

C34 CC73HCH1H470J CHIP C 47PF J

C35 CS77ABE1D100M CHIP TNTL 10UF 20WV

C36 CC73HCH1H050B CHIP C 5.0PF B K,HK

C36 CC73HCH1H070B CHIP C 7.0PF B K2,HK2

C36 CC73HCH1H080B CHIP C 8.0PF B HK3

C37 C93-1906-05 CHIP TNTL

0.047UF

35WV

C38 CC730AD1H104J CHIP C 0.1UPF J

C39 CC73HCH1H030B CHIP C 3.0PF B

C41 CK73HBB1H471K CHIP C 470PF K

C43 CK73HBB1H471K CHIP C 470PF K

C44 CC73HCH1H101J CHIP C 100PF J

C45 CC73HCH1H101J CHIP C 100PF J

C46 CC73HCH1H050B CHIP C 5.0PF B K,HK

C46 CC73HCH1H070B CHIP C 7.0PF B K2,HK2

Ref. No.

Address Parts No. Description

Desti-

nation

C46 CC73HCH1H080B CHIP C 8.0PF B HK3

C47 CC73HCH1H470J CHIP C 47PF J

C48 CK73HXR0J105K CHIP C 1.0UF K

C49 CC73HCH1H100B CHIP C 10PF B K,HK

C49 CC73HCH1H150G CHIP C 15PF G K2,HK2

C49 CC73HCH1H180G CHIP C 18PF G HK3

C50 CC73HCH1H151J CHIP C 150PF J

C51 CC73HCH1H151J CHIP C 150PF J

C52 CK73HBB1H471K CHIP C 470PF K

C53 CK73HBB1H471K CHIP C 470PF K

C54 CK73HBB1A104K CHIP C 0.1UF K

C55 CK73HXR0J105K CHIP C 1.0UF K

C56 CK73HBB1H471K CHIP C 470PF K

C58 CC73HCH1H120G CHIP C 12PF G K,HK

C58 CC73HCH1H180G CHIP C 18PF G K2,HK2

C58 CC73HCH1H270G CHIP C 27PF G HK3

C59 CC73HCH1H150G CHIP C 15PF G K,HK

C59 CC73HCH1H200G CHIP C 20PF G K2,HK2

C59 CC73HCH1H470G CHIP C 47PF G HK3

C60 CC73HCH1HR75B CHIP C 0.75PF B K,HK

C61 CC73HCH1H0R5B CHIP C 0.5PF B K,HK

C63 CC73HCH1HR75B CHIP C 0.75PF B

C64 CC73HCH1H070B CHIP C 7.0PF B

K,K2,HK2,HK

C64 CC73HCH1H090B CHIP C 9.0PF B HK3

C65 CK73FB1A106K CHIP C 10UF K

C66 CC73HCH1H060B CHIP C 6.0PF B

K,K2,HK2,HK

C66 CC73HCH1H070B CHIP C 7.0PF B HK3

C67 CC73HCH1H050B CHIP C 5.0PF B K2,HK2

C67 CC73HCH1H060B CHIP C 6.0PF B K,HK

C67 CC73HCH1H070B CHIP C 7.0PF B HK3

C68 CC73HCH1H040B CHIP C 4.0PF B K,HK

C68 CC73HCH1H050B CHIP C 5.0PF B K2,HK2

C68 CC73HCH1H060B CHIP C 6.0PF B HK3

C69 CC73HCH1H050B CHIP C 5.0PF B

K,K2,HK2,HK

C69 CC73HCH1H060B CHIP C 6.0PF B HK3

C70 CK73HBB1H471K CHIP C 470PF K

C71 CK73GB1E105K CHIP C 1.0UF K

C72 CC73HCH1H030B CHIP C 3.0PF B K,HK

C72 CC73HCH1H040B CHIP C 4.0PF B K2,HK2

C72 CC73HCH1H050B CHIP C 5.0PF B HK3

C73 CK73HBB1H471K CHIP C 470PF K

C74 CC73HCH1H0R5B CHIP C 0.5PF B

C75 CK73HBB1H471K CHIP C 470PF K

C76 CC73HCH1H0R5B CHIP C 0.5PF B

C77 CK73HBB1H471K CHIP C 470PF K

C78 CK73HBB1H471K CHIP C 470PF K

C79 CC73HCH1H070B CHIP C 7.0PF B

C80 CK73HBB1H471K CHIP C 470PF K

C81 CC73HCH1H100B CHIP C 10PF B

C82 CC73HCH1H330J CHIP C 33PF J

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

C83 CK73HBB1H471K CHIP C 470PF K

C84 CK73HBB1H471K CHIP C 470PF K

C85 CK73HBB1A104K CHIP C 0.1UF K

C86 CC73HCH1H070B CHIP C 7.0PF B

C88 CK73HBB1E103K CHIP C 0.01UF K

C90 CK73HBB1E103K CHIP C 0.01UF K

C91 CK73HBB1E103K CHIP C 0.01UF K

C92 CK73HBB1E103K CHIP C 0.01UF K

C98 CK73HBB1H471K CHIP C 470PF K

C101 CK73HBB1H102K CHIP C 1000PF K

K,K2,HK2,HK

C101 CK73HBB1H471K CHIP C 470PF K HK3

C102 CK73HBB1H471K CHIP C 470PF K

C103 CK73HBB1E103K CHIP C 0.01UF K

C104 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C104 CK73HBB1H471K CHIP C 470PF K HK3

C105 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C105 CK73HBB1H471K CHIP C 470PF K HK3

C106 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C106 CK73HBB1H471K CHIP C 470PF K HK3

C107 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C107 CK73HBB1H471K CHIP C 470PF K HK3

C108 CK73FB1E475K CHIP C 4.7UF K

C109 CC73HCH1H060D CHIP C 6.0PF D

K,K2,HK2,HK

C109 CC73HCH1H090B CHIP C 9.0PF B HK3

C110 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C110 CK73HBB1H471K CHIP C 470PF K HK3

C111 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C111 CK73HBB1H471K CHIP C 470PF K HK3

C112 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C112 CK73HBB1H471K CHIP C 470PF K HK3

C115 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C115 CK73HBB1H471K CHIP C 470PF K HK3

C116 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C116 CK73HBB1H471K CHIP C 470PF K HK3

C117 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C117 CK73HBB1H471K CHIP C 470PF K HK3

C118 CC73HCH1H060D CHIP C 6.0PF D

K,HK2,HK3,HK

C118 CC73HCH1H080B CHIP C 8.0PF B K2

C118 CC73HCH1H100B CHIP C 10PF B HK3

C119 CC73HCH1H050B CHIP C 5.0PF B K2

C119 CC73HCH1H080B CHIP C 8.0PF B HK3

C120 CK73HBB1H471K CHIP C 470PF K

C121 CC73HCH1H020B CHIP C 2.0PF B HK3

C121 CC73HCH1H080B CHIP C 8.0PF B K2

C122 CC73HCH1H060B CHIP C 6.0PF B K2

C122 CC73HCH1H080B CHIP C 8.0PF B HK3

C123 CC73HCH1H220J CHIP C 22PF J

C125 CK73HBB1H471K CHIP C 470PF K

C127 CK73HBB1H471K CHIP C 470PF K

K,K2,HK3,HK

C128 CC73HCH1H470J CHIP C 47PF J

C131 CC73HCH1H101J CHIP C 100PF J

C132 CK73HBB1H471K CHIP C 470PF K

C133 CC73HCH1H220J CHIP C 22PF J

C134 CK73HBB1H471K CHIP C 470PF K

C135 CC73HCH1H101J CHIP C 100PF J

Ref. No.

Address Parts No. Description

Desti-

nation

C136 CK73FB1H471K CHIP C 470PF K

C138 CS77MA1A6R8M CHIP TNTL 6.8UF 10WV

C141 CC73HCH1H220J CHIP C 22PF J

C142 CC73HCH1H470J CHIP C 47PF J

C143 CC73GCH1H220J CHIP C 22PF J K2

C145 CC73HCH1H101J CHIP C 100PF J

C146 CC73GCH1H100D CHIP C 10PF D K2

C147 CK73HBB1H471K CHIP C 470PF K

C150 CE32BY1E470M CHIP EL 47UF 25WV

C151 CC73GCH1H101J CHIP C 100PF J K2

C152 CC73HCH1H101J CHIP C 100PF J

C153 CC73HCH1H101J CHIP C 100PF J

C155 CC73HCH1H220J CHIP C 22PF J

C156 CC73HCH1H220J CHIP C 22PF J

C157 CC73HCH1H101J CHIP C 100PF J

C158 CK73HBB1H471K CHIP C 470PF K

C162 CC73FCH1H020C CHIP C 2.0PF C K,HK

C162 CC73FCH1H050B CHIP C 5.0PF B K2,HK2

C162 CC73FCH1H150G CHIP C 5.0PF G HK3

C164 CC73GCH1H0R5B CHIP C 0.5PF B

C165 CC73GCH1H010B CHIP C 1.0PF B K,HK3

C165 CC73GCH1H030B CHIP C 3.0PF B

K2,HK2,HK

C166 CC73HCH1H101J CHIP C 100PF J

C169 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C169 CK73HBB1H471K CHIP C 470PF K HK3

C170 CC73GCH1H0R3B CHIP C 0.3PF B K2

C170 CC73GCH1H0R5B CHIP C 0.5PF B

K,HK2,HK3,HK

C171 CC73GCH1H010B CHIP C 1.0PF B HK3

C171 CC73GCH1H020B CHIP C 2.0PF B HK

C171 CC73GCH1H030B CHIP C 3.0PF B K,HK2

C171 CC73GCH1H040B CHIP C 4.0PF B K2

C172 CC73HCH1H101J CHIP C 100PF J

C174 C93-0550-05 CHIP C 3.0PF C HK3

C174 C93-0552-05 CHIP C 2.0PF C HK

C174 C93-0553-05 CHIP C 3.0PF C K,HK2

C174 C93-0554-05 CHIP C 4.0PF D K2

C175 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C175 CK73HBB1H471K CHIP C 470PF K HK3

C177 C93-0556-05 CHIP C 6.0PF D K,K2

C178 CC73GCH1H0R5B CHIP C 0.5PF B

C179 CC73GCH1H010B CHIP C 1.0PF B HK2

C179 CC73GCH1H020B CHIP C 2.0PF B HK

C179 CC73GCH1H030B CHIP C 3.0PF B K,K2

C179 CC73GCH1H040B CHIP C 4.0PF B HK3

C180 CC73HCH1H101J CHIP C 100PF J

C181 CC73HCH1H101J CHIP C 100PF J

K,K2,HK2,HK

C181 CK73HBB1H471K CHIP C 470PF K HK3

C184 CM73F2H010C CHIP C 1.0PF C K,K2

C185 CM73F2H040C CHIP C 4.0PF C HK

C185 CM73F2H060D CHIP C 6.0PF D

K,K2,HK2

C185 CM73F2H120J CHIP C 12PF J HK3

C186 CM73F2H121J CHIP C 120PF J

C187 C93-0553-05 CHIP C 3.0PF C K

C187 C93-0555-05 CHIP C 5.0PF C K2

C187 CM73F2H020C CHIP C 2.0PF C HK3

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

C187 CM73F2H040C CHIP C 4.0PF C HK2

C187 CM73F2H050C CHIP C 5.0PF C HK

C188 CM73F2H080D CHIP C 8.0PF D K,HK

C188 CM73F2H090D CHIP C 9.0PF D K2,HK2

C188 CM73F2H150J CHIP C 15PF J HK3

C189 CM73F2H070D CHIP C 7.0PF D K

C189 CM73F2H080D CHIP C 8.0PF D K2

C189 CM73F2H090D CHIP C 9.0PF D HK

C189 CM73F2H120J CHIP C 12PF J HK2

C189 CM73F2H150J CHIP C 15PF J HK3

C190 C93-0555-05 CHIP C 5.0PF C K

C190 CM73F2H030C CHIP C 3.0PF C HK

C190 CM73F2H060D CHIP C 6.0PF D HK2

C190 CM73F2H070D CHIP C 7.0PF D K2,HK3

C193 CK73HBB1H471K CHIP C 470PF K

K,K2,HK2,HK

C194 CK73HBB1H471K CHIP C 470PF K

C201 CK73HBB1E103K CHIP C 0.01UF K

C202 CK73HBB1A104K CHIP C 0.1UF K

C203 CK73HBB1A104K CHIP C 0.1UF K

C204 CK73HBB1A104K CHIP C 0.1UF K

C205 CK73HBB1A104K CHIP C 0.1UF K

C206 CC73HCH1H100B CHIP C 10PF B

C207 CK73HBB1E103K CHIP C 0.01UF K

C208 CK73HBB1E103K CHIP C 0.01UF K

C210 CK73HBB1A104K CHIP C 0.1UF K

C211 CC73HCH1H100B CHIP C 10PF B

C212 CK73HBB1A104K CHIP C 0.1UF K

C214 CC73HCH1H680J CHIP C 68PF J

C215 CC73HCH1H101J CHIP C 100PF J

C216 CC73HCH1H680J CHIP C 68PF J

C217 CK73HBB1A104K CHIP C 0.1UF K

C218 CK73GXR0J475K CHIP C 4.7UF K

C219 CK73GXR0J475K CHIP C 4.7UF K

C220 CC73HCH1H470J CHIP C 47PF J

C221 CK73FB1A106K CHIP C 10UF K

C222 CK73HBB1E103K CHIP C 0.01UF K

C223 CK73HBB1E103K CHIP C 0.01UF K

C225 CK73HBB1A104K CHIP C 0.1UF K

C226 CK73FB1A106K CHIP C 10UF K

C227 CC73HCH1H820J CHIP C 82PF J

C228 CK73HBB1A104K CHIP C 0.1UF K

C229 CK73HBB1A104K CHIP C 0.1UF K

C231 CK73HBB1E103K CHIP C 0.01UF K

C232 CK73HBB1A104K CHIP C 0.1UF K

C233 CK73HXR0J105K CHIP C 1.0UF K

C234 CK73HBB1E103K CHIP C 0.01UF K

K,HK2,HK3,HK

C234 CK73HBB1E103K CHIP C 0.01UF K K2

C236 CC73HCH1H470J CHIP C 47PF J

C237 CK73HBB1H471K CHIP C 470PF K

C238 CK73HBB1E103K CHIP C 0.01UF K

C239 CK73HBB1E103K CHIP C 0.01UF K

C240 CK73HBB1E103K CHIP C 0.01UF K

C242 CK73HBB1H471K CHIP C 470PF K

C243 CK73HBB1E103K CHIP C 0.01UF K

C244 CC73HCH1H470J CHIP C 47PF J

Ref. No.

Address Parts No. Description

Desti-

nation

C245 CK73HBB1H471K CHIP C 470PF K

C246 CK73HBB1E103K CHIP C 0.01UF K

C248 CK73HBB1E103K CHIP C 0.01UF K

C249 CC73HCH1H2R5B CHIP C 2.5PF B

C252 CC73HCH1H0R5B CHIP C 0.5PF B

C254 CC73HCH1H2R5B CHIP C 2.5PF B

C256 CC73HCH1H220G CHIP C 22PF G

C257 CK73HBB1H471K CHIP C 470PF K

C258 CK73HBB1H471K CHIP C 470PF K

C259 CK73HBB1E103K CHIP C 0.01UF K

C260 CK73HBB1E103K CHIP C 0.01UF K

C261 CC73HCH1H101J CHIP C 100PF J

C262 CK73HBB1E103K CHIP C 0.01UF K

C264 CK73HBB1H471K CHIP C 470PF K

C265 CK73HBB1E103K CHIP C 0.01UF K

C266 CK73HBB1H102K CHIP C 1000PF K

C267 CC73HCH1H070B CHIP C 7.0PF B

K,K2,HK2,HK

C267 CC73HCH1H120G CHIP C 12PF G HK3

C268 CK73HBB1E103K CHIP C 0.01UF K

C269 CK73HBB1H471K CHIP C 470PF K

C271 CC73HCH1H100B CHIP C 10PF B

K,K2,HK2,HK

C271 CC73HCH1H120G CHIP C 12PF G HK3

C272 CC73HCH1H020B CHIP C 2.0PF B

C273 CC73HCH1H120G CHIP C 12PF G

C275 CC73HCH1H010B CHIP C 1.0PF B K,HK

C275 CC73HCH1H020B CHIP C 2.0PF B K2,HK2

C275 CC73HCH1H030B CHIP C 3.0PF B HK3

C276 CC73HCH1H060B CHIP C 6.0PF B

C279 CC73HCH1H150G CHIP C 15PF G HK3

C279 CC73HCH1H180G CHIP C 18PF G

K,K2,HK2,HK

C281 CK73HBB1H471K CHIP C 470PF K

C282 CK73GB1E105K CHIP C 1.0UF K

C283 CC73HCH1H080B CHIP C 8.0PF B

K,K2,HK2,HK

C283 CC73HCH1H100B CHIP C 10PF B HK3

C284 CK73HBB1H471K CHIP C 470PF K

C285 CC73HCH1H220G CHIP C 22PF G

K,K2,HK2,HK

C285 CC73HCH1H680J CHIP C 68PF J HK3

C286 CC73HCH1H060B CHIP C 6.0PF B K,HK

C286 CC73HCH1H070B CHIP C 7.0PF B

K2,HK2,HK3

C287 CC73HCH1H050B CHIP C 5.0PF B

C288 CK73HBB1H471K CHIP C 470PF K

C289 CK73HBB1H102K CHIP C 1000PF K

C290 CC73HCH1H150G CHIP C 15PF G K,HK

C290 CC73HCH1H180G CHIP C 18PF G K2,HK2

C290 CC73HCH1H680J CHIP C 68PF J HK3

C291 CC73HCH1H070B CHIP C 7.0PF B K,HK

C291 CC73HCH1H100B CHIP C 10PF B

K2,HK2,HK3

C292 CK73HBB1H471K CHIP C 470PF K

C293 CC73HCH1H080B CHIP C 8.0PF B

K,HK3,HK

C293 CC73HCH1H100B CHIP C 10PF B K2,HK2

C294 CK73HBB1H471K CHIP C 470PF K

C295 CC73HCH1H150G CHIP C 15PF G K,HK

C295 CC73HCH1H180G CHIP C 18PF G K2,HK2

C295 CC73HCH1H680J CHIP C 68PF J HK3

C296 CC73HCH1H050B CHIP C 5.0PF B K,HK

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

C296 CC73HCH1H060B CHIP C 6.0PF B HK3

C296 CC73HCH1H070B CHIP C 7.0PF B K2,HK2

C297 CC73HCH1H060B CHIP C 6.0PF B K,HK

C297 CC73HCH1H080B CHIP C 8.0PF B K2,HK2

C297 CC73HCH1H090B CHIP C 9.0PF B HK3

C298 CK73HBB1H471K CHIP C 470PF K

C299 CC73HCH1H220G CHIP C 22PF G

K,K2,HK2,HK

C299 CC73HCH1H680J CHIP C 68PF J HK3

C301 CC73HCH1H050B CHIP C 5.0PF B HK3

C301 CC73HCH1H070B CHIP C 7.0PF B

K,K2,HK2,HK

C302 CK73GB1H104K CHIP C 0.10UF K

C307 CK73HBB1H471K CHIP C 470PF K

C308 CK73HBB1H471K CHIP C 470PF K

C310 CC73HCH1H180G CHIP C 18PF G K2,HK2

C315 CC73HCH1H060B CHIP C 6.0PF B HK3

C315 CC73HCH1H070B CHIP C 7.0PF B K,HK

C315 CC73HCH1H100B CHIP C 10PF B K2,HK2

C316 CK73HBB1H471K CHIP C 470PF K

C317 CC73HCH1H100B CHIP C 10PF B K,HK

C317 CC73HCH1H220G CHIP C 22PF G K2,HK2

C317 CC73HCH1H330G CHIP C 33PF G HK3

C318 CC73HCH1H030B CHIP C 3.0PF B

K,K2,HK2,HK

C318 CC73HCH1H040B CHIP C 4.0PF B HK3

C319 CC73HCH1H030B CHIP C 3.0PF B

C320 CK73HBB1H471K CHIP C 470PF K

C321 CC73HCH1H040B CHIP C 4.0PF B K,HK

C321 CC73HCH1H060B CHIP C 6.0PF B K2,HK2

C321 CC73HCH1H080B CHIP C 8.0PF B HK3

C322 CC73HCH1H080B CHIP C 8.0PF B K,HK

C322 CC73HCH1H180G CHIP C 18PF G K2,HK2

C322 CC73HCH1H390G CHIP C 39PF G HK3

C323 CC73HCH1H050B CHIP C 5.0PF B HK3

C323 CC73HCH1H080B CHIP C 8.0PF B

K,K2,HK2,HK

C324 CC73HCH1H050B CHIP C 5.0PF B

K,K2,HK2,HK

C324 CC73HCH1H060B CHIP C 6.0PF B HK3

C325 CC73HCH1H030B CHIP C 3.0PF B K,HK

C325 CC73HCH1H100B CHIP C 10PF B HK3

C326 CC73HCH1H120G CHIP C 12PF G K2,HK2

C326 CC73HCH1H180G CHIP C 18PF G K,HK

C326 CK73HBB1H471K CHIP C 470PF K HK3

C327 CK73HBB1H471K CHIP C 470PF K

C330 CK73HBB1A104K CHIP C 0.1UF K

C331 CK73HBB1A104K CHIP C 0.1UF K

C332 CK73HBB1A104K CHIP C 0.1UF K

C333 CK73HBB1A104K CHIP C 0.1UF K

C334 CK73HBB1A104K CHIP C 0.1UF K

C335 CC73HCH1H060B CHIP C 6.0PF B K,HK

C335 CC73HCH1H120G CHIP C 12PF G K2,HK2

C335 CC73HCH1H470G CHIP C 47PF G HK3

C336 CK73HBB1E103K CHIP C 0.01UF K

C337 CK73HBB1A104K CHIP C 0.1UF K

C338 CK73HBB1A104K CHIP C 0.1UF K

C339 CK73HBB1E103K CHIP C 0.01UF K

C341 CK73HXR0J105K CHIP C 1.0UF K

C342 CK73FB1A106K CHIP C 10UF K

Ref. No.

Address Parts No. Description

Desti-

nation

C343 CK73HBB1A104K CHIP C 0.1UF K

C344 CC73HCH1H101J CHIP C 100PF J

C347 CK73HBB1H471K CHIP C 470PF K

C348 CK73HBB1E103K CHIP C 0.01UF K

C358 CK73HB1H182K CHIP C 1800F K HK3

C358 CK73HBB1H102K CHIP C 1000PF K

K,K2,HK2,HK

C361 CC73HCH1H101J CHIP C 100PF J

C364 CK73HBB1H102K CHIP C 1000PF K

C365 CK73HBB1H102K CHIP C 1000PF K

C366 CK73HBB1H102K CHIP C 1000PF K

C401 CD04CK1E102M ELECTRO 1000UF 25WV

C403 CK73HBB1H471K CHIP C 470PF K

C405 CK73HBB1H471K CHIP C 470PF K

C406 CK73HBB1H102K CHIP C 1000PF K

C409 CK73HBB1E103K CHIP C 0.01UF K

C410 CK73GBB1H103K CHIP C 1000PF K

C411 CK73HBB1H471K CHIP C 470PF K

C413 CK73GB1E105K CHIP C 1.0UF K

C415 CK73HBB1H471K CHIP C 470PF K

C417 CK73HBB1H471K CHIP C 470PF K

C419 CK73HBB1H102K CHIP C 1000PF K

C420 CK73HBB1A104K CHIP C 0.1UF K

C421 CK73GBB1H473K CHIP C

0.047UF

C422 CK73FB1E475K CHIP C 4.7UF K

C424 CK73GB1E105K CHIP C 1.0UF K

C425 CK73GB1H104K CHIP C 0.10UF K

C426 CK73HBB1E103K CHIP C 0.01UF K

C427 CK73HBB1H471K CHIP C 470PF K

C428 CC73HCH1H101J CHIP C 100PF J

C429 CK73GB1H104K CHIP C 0.10UF K

C430 CK73FB1E475K CHIP C 4.7UF K

C431 CK73FB1E475K CHIP C 4.7UF K

C432 CE32BY1E470M CHIP EL 47UF 25WV

C433 CK73GB1H104K CHIP C 0.10UF K

C434 CK73HBB1H102K CHIP C 1000PF K

C435 CK73FB1A106K CHIP C 10UF K

C436 CS77BA1A100M CHIP TNTL 10UF 10WV

C437 CK73HB1A224K CHIP C 0.22UF K

C438 CK73FB1A106K CHIP C 10UF K

C439 CK73HBB1E103K CHIP C 0.01UF K

C440 CK73GB1E105K CHIP C 1.0UF K

C441 CK73HBB1E103K CHIP C 0.01UF K

C442 CK73HBB1E103K CHIP C 0.01UF K

C443 CK73GB1E105K CHIP C 1.0UF K

C444 CK73GB1E105K CHIP C 1.0UF K

C445 CK73FB1A106K CHIP C 10UF K

C446 C92-0765-05 CHIP TNTL 4.7UF 16WV

C447 CK73HB1A224K CHIP C 0.22UF K

C448 CK73HBB1E103K CHIP C 0.01UF K

C449 CK73GXR1C225K CHIP C 2.2UF K

C450 CK73HBB1E103K CHIP C 0.01UF K

C451 CK73GXR1C225K CHIP C 2.2UF K

C452 CK73HXR0J105K CHIP C 1.0UF K

C453 CK73GB1E105K CHIP C 1.0UF K

C454 CK73HBB1H471K CHIP C 470PF K

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

C455 CK73HBB1E103K CHIP C 0.01UF K

C456 CK73HBB1E103K CHIP C 0.01UF K

C457 CK73GB1E105K CHIP C 1.0UF K

C458 CK73GB1E105K CHIP C 1.0UF K

C459 C92-0765-05 CHIP TNTL 4.7UF 16WV

C460 CK73HBB1A104K CHIP C 0.1UF K

C461 CC73HCH1H181J CHIP C 180PF J

C462 CK73HBB1H471K CHIP C 470PF K

C463 CK73HXR0J105K CHIP C 1.0UF K

C464 CC73HCH1H220J CHIP C 22PF J

C465 CK73GB1E105K CHIP C 1.0UF K

C466 CK73GB1E105K CHIP C 1.0UF K

C467 CK73GB1E105K CHIP C 1.0UF K

C468 CK73HBB1E103K CHIP C 0.01UF K

C471 CK73HXR0J105K CHIP C 1.0UF K

C473 CS77BA1E4R7M CHIP TNTL 4.7UF 25WV

C474 CK73HBB1E103K CHIP C 0.01UF K

C475 CK73FB1A106K CHIP C 10UF K

C476 CK73HBB1H102K CHIP C 1000PF K

C477 CC73HCH1H101J CHIP C 100PF J

C478 CK73HBB1H102K CHIP C 1000PF K

C479 CK73HBB1H102K CHIP C 1000PF K

C480 CK73HBB1H102K CHIP C 1000PF K

C481 CK73HBB1H102K CHIP C 1000PF K

C482 CK73HBB1H102K CHIP C 1000PF K

C483 CK73HBB1H102K CHIP C 1000PF K

C501 CK73HXR0J105K CHIP C 1.0UF K

C502 CK73HXR0J105K CHIP C 1.0UF K K2

C503 CK73HBB1A104K CHIP C 0.1UF K

C504 CK73HBB1A104K CHIP C 0.1UF K

C505 CK73HBB1A104K CHIP C 0.1UF K

C506 CK73HBB1A104K CHIP C 0.1UF K

C507 CK73HBB1A104K CHIP C 0.1UF K

C508 CK73HBB1H102K CHIP C 1000PF K

C509 CK73HBB1A104K CHIP C 0.1UF K

C511 CK73HBB1A104K CHIP C 0.1UF K

C512 CK73HBB1A104K CHIP C 0.1UF K

C513 CK73HBB1A104K CHIP C 0.1UF K

C514 CK73HBB1A104K CHIP C 0.1UF K

C515 CK73HXR0J105K CHIP C 1.0UF K

C516 CK73HBB1A104K CHIP C 0.1UF K

C517 CK73HBB1A104K CHIP C 0.1UF K

C518 CK73GB1E105K CHIP C 1.0UF K

C520 CK73HBB1E103K CHIP C 0.01UF K

C521 CK73HBB1E103K CHIP C 0.01UF K

C522 CK73HBB1E103K CHIP C 0.01UF K

C523 CK73HBB1E103K CHIP C 0.01UF K

C527 CK73HBB1E103K CHIP C 0.01UF K

C528 CK73HBB1A104K CHIP C 0.1UF K

C529 CK73HBB1E103K CHIP C 0.01UF K

C530 CK73HBB1E103K CHIP C 0.01UF K

C531 CK73HBB1A104K CHIP C 0.1UF K

C532 CK73HBB1E103K CHIP C 0.01UF K

C533 CK73HBB1A104K CHIP C 0.1UF K

C534 CC73HCH1H101J CHIP C 100PF J

Ref. No.

Address Parts No. Description

Desti-

nation

C535 CS77BP0J100M CHIP TNTL 10UF 6.3WV

C536 CK73HBB1E103K CHIP C 0.01UF K

C537 CK73HBB1A104K CHIP C 0.1UF K

C538 CK73HBB1A104K CHIP C 0.1UF K

C539 CK73HBB1E103K CHIP C 0.01UF K

C540 CK73HXR0J105K CHIP C 1.0UF K

C541 CK73HBB1A104K CHIP C 0.1UF K

C542 CS77BP0J100M CHIP TNTL 10UF 6.3WV

C543 CC73HCH1H101J CHIP C 100PF J

C544 CC73HCH1H101J CHIP C 100PF J

C545 CC73HCH1H101J CHIP C 100PF J

C546 CC73HCH1H101J CHIP C 100PF J

C547 CK73HBB1A104K CHIP C 0.1UF K

C548 CK73HBB1A104K CHIP C 0.1UF K

C549 CK73HBB1A104K CHIP C 0.1UF K

C550 CK73HBB1A104K CHIP C 0.1UF K

C551 CK73HBB1E103K CHIP C 0.01UF K

C552 CK73HXR0J105K CHIP C 1.0UF K

C553 CC73HCH1H101J CHIP C 100PF J

C554 CK73HBB1A104K CHIP C 0.1UF K

C555 CK73HBB1A104K CHIP C 0.1UF K

C556 CK73HBB1A104K CHIP C 0.1UF K

C557 CK73HBB1A104K CHIP C 0.1UF K

C558 CK73HBB1A104K CHIP C 0.1UF K

C559 CK73HBB1E103K CHIP C 0.01UF K

C560 CK73HXR0J105K CHIP C 1.0UF K

C561 CC73HCH1H101J CHIP C 100PF J

C562 CC73HCH1H101J CHIP C 100PF J

C563 CC73HCH1H101J CHIP C 100PF J

C565 CC73HCH1H101J CHIP C 100PF J

C566 CC73HCH1H101J CHIP C 100PF J

C567 CK73HBB1H102K CHIP C 1000PF K

C568 CC73HCH1H101J CHIP C 100PF J

C569 CC73HCH1H101J CHIP C 100PF J

C570 CC73HCH1H101J CHIP C 100PF J

C571 CC73HCH1H101J CHIP C 100PF J

C572 CC73HCH1H101J CHIP C 100PF J

C573 CC73HCH1H101J CHIP C 100PF J

C574 CC73HCH1H101J CHIP C 100PF J

C575 CC73HCH1H101J CHIP C 100PF J

C576 CC73HCH1H101J CHIP C 100PF J

C577 CC73HCH1H101J CHIP C 100PF J

C578 CC73HCH1H101J CHIP C 100PF J

C579 CK73HBB1H102K CHIP C 1000PF K

C580 CC73HCH1H101J CHIP C 100PF J

C581 CK73HBB1H102K CHIP C 1000PF K

C582 CK73HBB1H102K CHIP C 1000PF K

C583 CK73HBB1H102K CHIP C 1000PF K

C584 CC73HCH1H101J CHIP C 100PF J

C585 CC73HCH1H101J CHIP C 100PF J

C586 CK73HBB1E103K CHIP C 0.01UF K

C587 CK73HBB1H102K CHIP C 1000PF K

C588 CK73HBB1H102K CHIP C 1000PF K

C589 CK73HBB1H102K CHIP C 1000PF K

C590 CK73HBB1E103K CHIP C 0.01UF K

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

C591 CK73HBB1E103K CHIP C 0.01UF K

C592 CC73HCH1H101J CHIP C 100PF J

C593 CC73HCH1H101J CHIP C 100PF J

C594 CK73HBB1E103K CHIP C 0.01UF K

C595 CK73HBB1E103K CHIP C 0.01UF K

C596 CK73HBB1A104K CHIP C 0.1UF K

C597 CK73HBB1H102K CHIP C 1000PF K

C598 CK73HBB1H102K CHIP C 1000PF K

C599 CK73HBB1H102K CHIP C 1000PF K

C600 CK73HBB1H102K CHIP C 1000PF K

C601 CK73HBB1H102K CHIP C 1000PF K

C602 CK73HBB1H102K CHIP C 1000PF K

C603 CK73HBB1H102K CHIP C 1000PF K

C604 CK73HBB1H102K CHIP C 1000PF K

C605 CK73HBB1H102K CHIP C 1000PF K

C606 CK73HBB1H102K CHIP C 1000PF K

C607 CK73HBB1H102K CHIP C 1000PF K

C608 CC73HCH1H101J CHIP C 100PF J

C609 CK73HBB1H102K CHIP C 1000PF K

C610 CC73HCH1H101J CHIP C 100PF J

C611 CK73HBB1H102K CHIP C 1000PF K

C612 CK73GBB1H103K CHIP C 1000PF K

C613 CK73GB1E105K CHIP C 1.0UF K

C614 CK73GB1E105K CHIP C 1.0UF K

C615 CK73GB1E105K CHIP C 1.0UF K

C616 CK73GB1E105K CHIP C 1.0UF K

C618 CK73HBB1E103K CHIP C 0.01UF K

C620 CK73HBB1E103K CHIP C 0.01UF K

C621 CK73HBB1E103K CHIP C 0.01UF K

C622 CK73HBB1H102K CHIP C 1000PF K

C623 CK73HBB1E103K CHIP C 0.01UF K

C624 CK73HBB1E103K CHIP C 0.01UF K

C625 CK73HBB1E103K CHIP C 0.01UF K

C626 CK73HBB1E103K CHIP C 0.01UF K

C627 CK73HBB1E103K CHIP C 0.01UF K

C628 CK73HBB1E103K CHIP C 0.01UF K

C629 CK73HBB1E103K CHIP C 0.01UF K

C630 CK73GB1H104K CHIP C 0.10UF K

C701 CK73GB0J335K CHIP C 3.3UF K

K,K2,HK2,HK

C702 CK73HXR0J105K CHIP C 1.0UF K K2

C702 CK73HXR0J105K CHIP C 1.0UF K

K,HK2,HK3,HK

C704 CC73HCH1H030B CHIP C 3.0PF B

C705 CK73HB1H122K CHIP C 1200PF K

C706 CK73HB1H331K CHIP C 330PF K

C707 CK73HBB1A104K CHIP C 0.1UF K

C708 CK73HB1H122K CHIP C 1200PF K

C709 CC73HCH1H221J CHIP C 220PF J

C710 CK73HBB1E103K CHIP C 0.01UF K

C711 CC73HCH1H181J CHIP C 180PF J

C712 CC73HCH1H680J CHIP C 68PF J

C714 CK73HBB1E103K CHIP C 0.01UF K

C715 CK73HB1H122K CHIP C 1200PF K

C716 CC73HCH1H221J CHIP C 220PF J

C717 CK73HBB1A104K CHIP C 0.1UF K

C718 CC73HCH1H221J CHIP C 220PF J

Ref. No.

Address Parts No. Description

Desti-

nation

C719 CK73HBB1A104K CHIP C 0.1UF K

C720 CK73HBB1A104K CHIP C 0.1UF K

C721 CC73HCH1H221J CHIP C 220PF J

C722 CC73HCH1H470J CHIP C 47PF J

C723 CK73HBB1A104K CHIP C 0.1UF K

C724 CK73HBB1A104K CHIP C 0.1UF K

C726 CK73HBB1A104K CHIP C 0.1UF K

C727 CC73HCH1H820J CHIP C 82PF J

C729 CK73HBB1A104K CHIP C 0.1UF K

C730 CK73HB1H561K CHIP C 560PF K

C731 CK73HBB1A104K CHIP C 0.1UF K

C734 CK73HBB1E103K CHIP C 0.01UF K

C735 CK73FB1E475K CHIP C 4.7UF K

C736 CC73HCH1H101J CHIP C 100PF J

C737 CK73HBB1A104K CHIP C 0.1UF K

C738 CK73HBB1H102K CHIP C 1000PF K

C740 CK73HBB1H472K CHIP C 4700PF K

C741 CK73HB1A154K CHIP C 0.15UF K

C742 CK73HBB1A104K CHIP C 0.1UF K

C743 CK73HBB1E103K CHIP C 0.01UF K

C744 CK73HBB1A104K CHIP C 0.1UF K

C745 CK73HBB1E103K CHIP C 0.01UF K

C746 CK73HBB1E103K CHIP C 0.01UF K

C747 CK73HBB1E103K CHIP C 0.01UF K

C748 CK73HBB1A104K CHIP C 0.1UF K

C749 CK73HBB1A104K CHIP C 0.1UF K

C750 CK73HBB1A104K CHIP C 0.1UF K

C751 CK73HBB1A104K CHIP C 0.1UF K

C752 CK73HBB1E103K CHIP C 0.01UF K

C753 CK73HBB1E103K CHIP C 0.01UF K

C754 CK73HBB1H102K CHIP C 1000PF K

C757 CC73HCH1H150J CHIP C 15PF J

C761 CK73HBB1E103K CHIP C 0.01UF K

C762 CK73HBB1A104K CHIP C 0.1UF K

C763 CK73HBB1A104K CHIP C 0.1UF K

C764 CC73HCH1H220J CHIP C 22PF J

C765 CK73GB1E105K CHIP C 1.0UF K

C766 CK73GB1E105K CHIP C 1.0UF K

C767 CK73HBB1A104K CHIP C 0.1UF K

C768 CK73HBB1E103K CHIP C 0.01UF K

C769 CK73HBB1E103K CHIP C 0.01UF K

C770 CK73HBB1A104K CHIP C 0.1UF K

C773 CK73HBB1A104K CHIP C 0.1UF K

C774 CK73HBB1H102K CHIP C 1000PF K

C775 CK73HBB1A104K CHIP C 0.1UF K

C776 CK73HXR0J105K CHIP C 1.0UF K K2

C776 CK73HXR0J105K CHIP C 1.0UF K

K,HK2,HK3,HK

C777 CK73HBB1H102K CHIP C 1000PF K

C778 CK73HBB1A104K CHIP C 0.1UF K

C779 CC73HCH1H680J CHIP C 68PF J

C782 CK73HBB1A104K CHIP C 0.1UF K

C783 CK73HBB1A104K CHIP C 0.1UF K

C784 CK73HBB1A104K CHIP C 0.1UF K

C785 CK73HBB1A104K CHIP C 0.1UF K

C786 CK73HBB1A104K CHIP C 0.1UF K

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

C787 CK73FB1A106K CHIP C 10UF K

C788 CK73HBB1A104K CHIP C 0.1UF K

C789 CK73FB1E475K CHIP C 4.7UF K

C790 CK73FB1A106K CHIP C 10UF K

C791 CK73HBB1H102K CHIP C 1000PF K

C792 CC73HCH1H470J CHIP C 47PF J

C793 CK73HBB1H102K CHIP C 1000PF K

C794 CK73FB1A106K CHIP C 10UF K

C795 CK73FB1A106K CHIP C 10UF K

C796 CK73HBB1A104K CHIP C 0.1UF K

C797 CK73HBB1A104K CHIP C 0.1UF K

C798 CK73HBB1A104K CHIP C 0.1UF K

C799 CK73HBB1A104K CHIP C 0.1UF K

C801 CK73GB1E105K CHIP C 1.0UF K

C802 CK73GB1E105K CHIP C 1.0UF K

C803 CK73HBB1H102K CHIP C 1000PF K

C804 CK73HBB1H102K CHIP C 1000PF K

C805 CK73HBB1H102K CHIP C 1000PF K

C806 C92-0906-05 ELECTRO 330UF 16WV

C807 CE32BY1E470M CHIP EL 47UF 25WV

C809 CK73HBB1H102K CHIP C 1000PF K

C810 CK73HBB1H471K CHIP C 470PF K

C811 CK73HBB1H102K CHIP C 1000PF K

C813 CK73FB1A106K CHIP C 10UF K

C814 CK73HBB1H471K CHIP C 470PF K

C815 CK73FB1A106K CHIP C 10UF K

C816 CK73FB1A106K CHIP C 10UF K

C817 CK73HBB1E103K CHIP C 0.01UF K

C818 CK73HXR0J105K CHIP C 1.0UF K K2

C818 CK73HXR0J105K CHIP C 1.0UF K

K,HK2,HK3,HK

C820 CK73GB1E105K CHIP C 1.0UF K

C821 CK73HBB1H102K CHIP C 1000PF K

C824 CK73HBB1H102K CHIP C 1000PF K

C825 CC73HCH1H101J CHIP C 100PF J

C826 CK73HBB1H102K CHIP C 1000PF K

C828 CC73HCH1H101J CHIP C 100PF J

C901 CC73HCH1H101J CHIP C 100PF J

C902 CK73HBB1H102K CHIP C 1000PF K

C903 CC73HCH1H101J CHIP C 100PF J

C904 CC73HCH1H101J CHIP C 100PF J

C905 CC73HCH1H101J CHIP C 100PF J

C906 CC73HCH1H101J CHIP C 100PF J

C907 CK73HBB1H102K CHIP C 1000PF K

C908 CC73HCH1H101J CHIP C 100PF J

C909 CC73HCH1H101J CHIP C 100PF J

C910 CC73HCH1H101J CHIP C 100PF J

C911 CC73HCH1H101J CHIP C 100PF J

C912 CC73HCH1H101J CHIP C 100PF J

C913 CC73HCH1H101J CHIP C 100PF J

C914 CC73HCH1H101J CHIP C 100PF J

C915 CC73HCH1H101J CHIP C 100PF J

C916 CC73HCH1H101J CHIP C 100PF J

C917 CC73HCH1H101J CHIP C 100PF J

C918 CC73HCH1H101J CHIP C 100PF J

C919 CC73HCH1H101J CHIP C 100PF J

Ref. No.

Address Parts No. Description

Desti-

nation

C920 CC73HCH1H101J CHIP C 100PF J

C921 CC73HCH1H101J CHIP C 100PF J

C922 CK73HBB1H102K CHIP C 1000PF K

C923 CK73HBB1H102K CHIP C 1000PF K

C928 CK73HBB1E103K CHIP C 0.01UF K K,K2

CD201 L79-1850-05 TUNING COIL

CF201 L72-1017-05 CERAMIC FILTER

K,K2,HK2,HK

CF201 L72-1027-05 CERAMIC FILTER HK3

CF202 L72-1021-05 CERAMIC FILTER

K,K2,HK2,HK

CF202 L72-1041-05 CERAMIC FILTER HK3

CF203 L72-1040-05 CERAMIC FILTER

CN401 E23-1260-14 TERMINAL

CN402 E23-1260-14 TERMINAL

CN403 E41-1682-05 PIN ASSY

CN405 J19-5386-05 HOLDER

CN502 E23-1278-05 TERMINAL

CN503 E23-1278-05 TERMINAL

CN504 E23-1278-05 TERMINAL

CN505 E23-1278-05 TERMINAL

CN506 E23-1278-05 TERMINAL

CN507 E23-1278-05 TERMINAL

CN508 E23-1278-05 TERMINAL

CN509 E23-1278-05 TERMINAL

CN510 E23-1278-05 TERMINAL

CN511 E23-1278-05 TERMINAL

CN512 E23-1278-05 TERMINAL

CN513 E23-1278-05 TERMINAL

CN516 E23-1278-05 TERMINAL

CN517 E23-1278-05 TERMINAL

CN520 E23-1278-05 TERMINAL

CN527 E23-1278-05 TERMINAL

CN540 E23-1278-05 TERMINAL

CN542 E23-1278-05 TERMINAL

CN543 E23-1278-05 TERMINAL

CN549 E40-6720-05 SOCKET FOR PIN ASSY

CN595 E40-6361-05 PIN ASSY

CN597 E40-6558-05 FLAT CABLE CONNECTOR

CN600 E40-6560-05 FLAT CABLE CONNECTOR

CN611 E23-1278-05 TERMINAL

CN612 E23-1278-05 TERMINAL

CN614 E23-1278-05 TERMINAL

CN705 E40-6582-05 PIN ASSY

CN901 E40-6560-05 FLAT CABLE CONNECTOR

D2 DA221 MULTIPLE DIODE

D3 1SV325F VARIABLE CAPACITANCE DIODE

D4 1SV325F VARIABLE CAPACITANCE DIODE

D7 1SV282-F VARIABLE CAPACITANCE DIODE

D8 1SV282-F VARIABLE CAPACITANCE DIODE

D9 1SV282-F VARIABLE CAPACITANCE DIODE

D10 1SV282-F VARIABLE CAPACITANCE DIODE

D11 1SV282-F VARIABLE CAPACITANCE DIODE

D12 1SV282-F VARIABLE CAPACITANCE DIODE

D14 1SV278F VARIABLE CAPACITANCE DIODE

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

D21 HVC131 DIODE

D101 HVC131 DIODE

D102 DZ2J056(M) ZENER DIODE

D103 L407CDB DIODE(50V/1W)

HK2,HK3,HK

D104 L407CDB DIODE(50V/1W)

D106 JDP2S12CR DIODE

D108 HSM88AS-E DIODE

D109 HSM88AS-E DIODE

D110 HSM88AS-E DIODE

D201 KDS112E-P MULTIPLE DIODE

D202 KDS112E-P MULTIPLE DIODE

D205 HVC131 DIODE

D207 1SV278F VARIABLE CAPACITANCE DIODE

D208 1SV278F VARIABLE CAPACITANCE DIODE

D209 1SV278F VARIABLE CAPACITANCE DIODE

D210 1SV278F VARIABLE CAPACITANCE DIODE

D212 1SV278F VARIABLE CAPACITANCE DIODE

D213 1SV278F VARIABLE CAPACITANCE DIODE

D216 HVC131 DIODE

D401 DZ2J180(M) ZENER DIODE

D403 1SS416 DIODE

D404 22ZR-10D SURGE ABSORBER

D405 DSA3A1 DIODE

D406 DA2S101 DIODE

D407 DB22306 SCHOTTKY BARRIER DIODE

D408 KDS121-P DIODE

D409 1SS388F SCHOTTKY BARRIER DIODE

D410 1SS388F SCHOTTKY BARRIER DIODE

D411 1SS388F SCHOTTKY BARRIER DIODE

D412 1SS388F SCHOTTKY BARRIER DIODE

D501 1SS388F SCHOTTKY BARRIER DIODE

D502 1SS388F SCHOTTKY BARRIER DIODE

D503 1SS416 DIODE

D504 1SS416 DIODE

D506 1SS416 DIODE

D507 1SS416 DIODE

D508 MC2850 DIODE

D509 1SS416 DIODE

D510 1SS416 DIODE

D511 MC2850 DIODE

D512 MC2850 DIODE

D702 DA2S101 DIODE

D703 KDR731 DIODE

D704 KDR731 DIODE

D705 KDR731 DIODE

D706 EMZ6.8N ZENER DIODE

D707 EMZ6.8N ZENER DIODE

D901 MC2850 DIODE

D902 MC2850 DIODE

D903 MC2850 DIODE

D904 MC2850 DIODE

D905 DZ2J180(M) ZENER DIODE

Ref. No.

Address Parts No. Description

Desti-

nation

D906 DZ2J180(M) ZENER DIODE

D907 MC2850 DIODE

D908 MC2850 DIODE

D909 1SS355 DIODE

D910 DZ2J180(M) ZENER DIODE

D911 MC2850 DIODE

D912 MC2850 DIODE

D913 1SS355 DIODE

D914 DZ2J180(M) ZENER DIODE

F401 F53-0328-15 FUSE

F501 F53-0352-05 FUSE

IC1 LM73CIMKX-0 MOS-IC

IC2 LMC7101BIM5 MOS-IC

IC3 SKY72310362LF MOS-IC

IC4 LMC7101BIM5 MOS-IC

IC5 TC75W51FK(F) MOS-IC

IC101 TA75W01FUF BIPOLAR IC

IC102 2A RA30H4452M123 MOS-IC K

IC102 2A RA55H3340M131 MOS-IC HK3

IC102 2A RA55H4047A123 MOS-IC HK2

IC102 RA55H4452M131 MOS-IC HK

IC103 TA75W01FUF BIPOLAR IC

IC202 TK10931VTL-G ANALOGUE IC

IC203 TC75W51FK(F) MOS-IC

IC204 AK1224 MOS-IC

IC207 BD7542FVM MOS-IC

IC401 XC6108C23CM-G MOS-IC

IC402 XC6204B332P-G MOS-IC

IC403 2A NJM78M08FA-ZB ANALOGUE IC

IC404 TA7805F-NQ MOS-IC

IC405 LT1616ES6-PBF ANALOGUE IC

IC406 TK71733S BI-POLAR IC

IC407 XC6204B332M-G MOS-IC

IC408 XC6204B332M-G MOS-IC

IC409 XC6205B152P-G MOS-IC

IC410 XC9101D09AK-G MOS-IC

IC501 Note1 ROM IC

IC502 Note1 MICROPROCESSOR IC

IC503 Note1 SRAM IC

IC504 RV5C386A MOS-IC

IC505 TC7SH08FU-F MOS-IC

IC506 XC6109C29AN-G MOS-IC

IC507 TC7SH126FU-F MOS-IC

IC508 SM5023CNDH-G MOS-IC

IC509 TC7WT125FUF MOS-IC

IC510 Note1 MOS-IC

IC511 TC7SH08FU-F MOS-IC

IC512 TC7SET08FU-F MOS-IC

IC513 TC7SET08FU-F MOS-IC

IC514 TC7WBD125AFK MOS-IC

IC515 TC7WT126FU-F MOS-IC

IC516 TC7WH126FU-F MOS-IC

IC517 PCA9535RGE MOS-IC

IC518 ADM202EARNZ MOS-IC

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

Note 1: This part cannot be replaced. Therefore, this part is not

supplied as a service part.

If a part reference number is listed in a shaded box, that part does not

come with the PCB.

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

IC701 TC75S51FE(F) MOS-IC

IC702 TC75W51FK(F) MOS-IC

IC703 TC75W51FK(F) MOS-IC

IC705 TC75W51FK(F) MOS-IC

IC706 TC75W51FK(F) MOS-IC

IC707 TC7W53FKF MOS-IC

IC708 TC7W53FKF MOS-IC

IC709 TC75W51FK(F) MOS-IC

IC710 TC7W53FKF MOS-IC

IC711 TC75W51FK(F) MOS-IC

IC712 M62364FP-F MOS-IC

IC713 TC7W53FKF MOS-IC

IC714 TC75S51FE(F) MOS-IC

IC715 2A LA4425A MOS-IC

J701 E1B-0001-00 3.5D PHONE JACK

J901 E58-0521-05 SUB SOCKET(D)

L1 LR77Z0AE4R7J SMALL FIXED INDUCTOR(4.7NH)

L3 LB73H0AV-003 CHIP FERRITE BEADS

L4 LK73G0AF12NJ SMALL FIXED INDUCTOR(12NH)

K,K2,HK2,HK

L4 LK73G0AF18NJ SMALL FIXED INDUCTOR(18NH) HK3

L6 LK73G0AQ100K SMALL FIXED INDUCTOR(10UH)

L7 LK73G0AQ100K SMALL FIXED INDUCTOR(10UH)

L10 L40-1878-92 SMALL FIXED INDUCTOR(18NH)

K,K2,HK2,HK

L10 L40-4775-92 SMALL FIXED INDUCTOR(47NH) HK3

L11 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

L12 LK73G0AFR18J SMALL FIXED INDUCTOR(180NH) K,HK

L12 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

K2,HK2,HK3

L13 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

L14 LK73G0AFR18J SMALL FIXED INDUCTOR(180NH) K,HK

L14 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

K2,HK2,HK3

L15 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

L16 LK73G0AFR18J SMALL FIXED INDUCTOR(180NH) K,HK

L16 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

K2,HK2,HK3

L17 L34-4607-15 AIR-CORE COIL K,HK

L17 LR79Z0CM22NG SMALL FIXED INDUCTOR(22NH) K2,HK2

L17 LR79Z0CM28NG SMALL FIXED INDUCTOR(28NH) HK3

L18 L34-4610-15 AIR CORE COIL HK3

L18 LR79Z0CM22NG SMALL FIXED INDUCTOR(22NH) K,HK

L18 LR79Z0CM28NG SMALL FIXED INDUCTOR(28NH) K2,HK2

L19 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

L20 L92-0446-05 BEADS CORE

L21 LK73G0AFR18J SMALL FIXED INDUCTOR(180NH) K,HK

L21 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

K2,HK2,HK3

L22 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

L23 LK73G0AFR18J SMALL FIXED INDUCTOR(180NH) K,HK

L23 LK73G0AFR22J SMALL FIXED INDUCTOR(220NH)

K2,HK2,HK3

L25 LK73H0AM27NJ SMALL FIXED INDUCTOR(27NH)

K2,HK2,HK3,HK

L25 LK73H0AM27NJ SMALL FIXED INDUCTOR(33NH) K

L26 LK73G0AF22NJ SMALL FIXED INDUCTOR(22NH) K,HK

L26 LK73G0AF33NJ SMALL FIXED INDUCTOR(33NH) K2,HK2

L26 LK73G0AF39NJ SMALL FIXED INDUCTOR(39NH) HK3

L31 LB73H0AV-003 CHIP FERRITE BEADS

L32 LB73H0AV-003 CHIP FERRITE BEADS

L33 LB73H0AV-003 CHIP FERRITE BEADS

L34 LB73H0AV-003 CHIP FERRITE BEADS

Ref. No.

Address Parts No. Description

Desti-

nation

L35 LB73H0AV-003 CHIP FERRITE BEADS

L36 LB73H0AV-003 CHIP FERRITE BEADS

L40 LB73H0AV-003 CHIP FERRITE BEADS

L41 LB73H0AV-003 CHIP FERRITE BEADS

L101 LK73G0AF18NJ SMALL FIXED INDUCTOR(18NH)

K,K2,HK2,HK

L101 LK73G0AF22NJ SMALL FIXED INDUCTOR(22NH) HK3

L102 LB73G0BA-004 CHIP FERRITE BEADS

L103 LK73G0AF22NJ SMALL FIXED INDUCTOR(22NH)

L104 LK73G0AF18NJ SMALL FIXED INDUCTOR(18NH) HK3

L104 LK73G0AF4N7S SMALL FIXED INDUCTOR(4.7NH) K2

L106 LB73G0BA-004 CHIP FERRITE BEADS

L107 LB73Z0AF-001 CHIP FERRITE BEADS

HK2,HK3,HK

L108 LB73Z0AF-001 CHIP FERRITE BEADS

L109 LB73Z0AF-001 CHIP FERRITE BEADS

L110 L34-4638-05 AIR-CORE COIL

L111 L34-4758-05 AIR-CORE COIL

L112 L34-4743-05 AIR-CORE COIL

K,K2,HK2,HK

L112 L34-4758-05 AIR-CORE COIL HK3

L113 L34-4743-05 AIR-CORE COIL

K,K2,HK2,HK

L113 L34-4758-05 AIR-CORE COIL HK3

L114 L34-4743-05 AIR-CORE COIL

K,K2,HK2,HK

L114 L34-4758-05 AIR-CORE COIL HK3

L115 L34-4848-05 AIR-CORE COIL

L117 LB73H0AV-003 CHIP FERRITE BEADS

L118 LB73H0AV-003 CHIP FERRITE BEADS

L119 LB73H0AV-003 CHIP FERRITE BEADS

L201 L40-1085-71 SMALL FIXED INDUCTOR(100NH)

L202 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)

L204 L41-4778-45 SMALL FIXED INDUCTOR(47NH)

L205 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)

L206 LB73G0BD-005 CHIP FERRITE BEADS

L207 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)

L208 LB73G0BD-005 CHIP FERRITE BEADS

L209 LK73G0AF22NJ SMALL FIXED INDUCTOR(22NH) K,HK

L209 LK73G0AF33NJ SMALL FIXED INDUCTOR(33NH) K2,HK2

L209 LK73G0AF39NJ SMALL FIXED INDUCTOR(39NH) HK3

L210 L39-1498-05 TOROIDAL COIL

L211 LB73G0BD-005 CHIP FERRITE BEADS

L212 L41-8285-14 SMALL FIXED INDUCTOR(820NH)

L213 LK73G0AF15NJ SMALL FIXED INDUCTOR(15NH) K,HK

L213 LK73G0AF22NJ SMALL FIXED INDUCTOR(22NH) K2,HK2

L213 LK73G0AF33NJ SMALL FIXED INDUCTOR(33NH) HK3

L214 L41-8285-14 SMALL FIXED INDUCTOR(820NH)

L215 LK73G0AF18NJ SMALL FIXED INDUCTOR(18NH) K,HK

L215 LK73G0AF22NJ SMALL FIXED INDUCTOR(22NH) K2,HK2

L215 LK73G0AF27NJ SMALL FIXED INDUCTOR(27NH) HK3

L216 LR79Z0DD21N9J SMALL FIXED INDUCTOR(21.9NH)

K,K2,HK2,HK

L216 LR79Z0DD27N4J SMALL FIXED INDUCTOR(27.4NH) HK3

L217 LR79Z0DD21N9J SMALL FIXED INDUCTOR(21.9NH)

K,K2,HK2,HK

L217 LR79Z0DD27N4J SMALL FIXED INDUCTOR(27.4NH) HK3

L218 LR79Z0DD21N9J SMALL FIXED INDUCTOR(21.9NH)

K,K2,HK2,HK

L218 LR79Z0DD27N4J SMALL FIXED INDUCTOR(27.4NH) HK3

L219 LR79Z0DD21N9J SMALL FIXED INDUCTOR(21.9NH)

K,K2,HK2,HK

L219 LR79Z0DD27N4J SMALL FIXED INDUCTOR(27.4NH) HK3

L221 L41-1578-14 SMALL FIXED INDUCTOR(15NH)

K,K2,HK2,HK

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

If a part reference number is listed in a shaded box, that part does not

come with the PCB.

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

L221 L41-2278-14 SMALL FIXED INDUCTOR(22NH) HK3

L223 LR79Z0DD32N5J SMALL FIXED INDUCTOR(32.5NH)

K,K2,HK2,HK

L223 LR79Z0DD37N7J SMALL FIXED INDUCTOR(37.7NH) HK3

L224 LR79Z0DD32N5J SMALL FIXED INDUCTOR(32.5NH)

K,K2,HK2,HK

L224 LR79Z0DD37N7J SMALL FIXED INDUCTOR(37.7NH) HK3

L225 L41-1278-14 SMALL FIXED INDUCTOR(12NH) K,HK

L225 L41-1578-14 SMALL FIXED INDUCTOR(15NH) K2,HK2

L225 L41-1878-14 SMALL FIXED INDUCTOR(18NH) HK3

L228 LK73G0AF12NJ SMALL FIXED INDUCTOR(12NH) HK3

L228 LK73G0AF2N7S SMALL FIXED INDUCTOR(2.7NH) K2,HK2

L229 LK73H0AM12NJ SMALL FIXED INDUCTOR(12NH) K,HK

L229 LK73H0AM15NJ SMALL FIXED INDUCTOR(15NH) K2,HK2

L229 LK73H0AM27NJ SMALL FIXED INDUCTOR(27NH) HK3

L230 LB73G0BD-005 CHIP FERRITE BEADS

L233 L41-2285-14 SMALL FIXED INDUCTOR(220NH)

L234 L41-3385-14 SMALL FIXED INDUCTOR(330NH)

L240 L40-4775-71 SMALL FIXED INDUCTOR(47NH) HK3

L240 LK73H0AM33NJ SMALL FIXED INDUCTOR(33NH)

K,K2,HK2,HK

L401 LB73Z0AF-001 CHIP FERRITE BEADS

HK2,HK3,HK

L402 LB73Z0AF-001 CHIP FERRITE BEADS

L403 LB73Z0AF-001 CHIP FERRITE BEADS

L404 LB73G0AM-004 CHIP FERRITE BEADS

L405 L33-1496-05 SMALL FIXED INDUCTOR(22UH)

L406 L33-1462-05 SMALL FIXED INDUCTOR(68UH)

L501 LB73G0BD-005 CHIP FERRITE BEADS

L502 LB73G0BD-005 CHIP FERRITE BEADS

L503 LB73G0BD-005 CHIP FERRITE BEADS

L506 LB73G0BD-005 CHIP FERRITE BEADS

L507 LB73G0BD-005 CHIP FERRITE BEADS

L508 LB73G0BD-005 CHIP FERRITE BEADS

L509 LB73G0BD-005 CHIP FERRITE BEADS

L510 LB73G0BD-005 CHIP FERRITE BEADS

L511 LB73G0BD-005 CHIP FERRITE BEADS

L512 LB73G0BA-004 CHIP FERRITE BEADS

L517 LB73G0BD-005 CHIP FERRITE BEADS

L518 LB73G0BD-005 CHIP FERRITE BEADS

L521 LB73H0AV-002 CHIP FERRITE BEADS

L522 LB73H0AV-002 CHIP FERRITE BEADS

L523 LB73H0AV-002 CHIP FERRITE BEADS

L901 LB73G0BA-004 CHIP FERRITE BEADS

L902 LB73G0BA-004 CHIP FERRITE BEADS

L903 LB73H0AV-002 CHIP FERRITE BEADS

L904 LB73H0AV-002 CHIP FERRITE BEADS

L905 LB73H0AV-002 CHIP FERRITE BEADS

Q1 2SC5383-T111 TRANSISTOR

Q3 2SC5636 TRANSISTOR

Q4 2SC5383-T111 TRANSISTOR

Q5 2SK508NV(K52) FET

Q6 2SK508NV(K52) FET

Q7 SSM6L05FU-F FET

Q8 SSM3J05FU-F FET

Q9 2SC5636 TRANSISTOR

Q10 2SC5636 TRANSISTOR

Q11 2SK1215-E(E) FET

Ref. No.

Address Parts No. Description

Desti-

nation

Q101 2SC5108F/Y/ TRANSISTOR

Q102 2SC5455-A TRANSISTOR

Q105 LTC014EEBFS8 DIGITAL TRANSISTOR

Q106 2SK1830F FET

Q201 LTA014EEBFS8 DIGITAL TRANSISTOR

Q202 LTC044EEBFS8 DIGITAL TRANSISTOR

Q203 2SC5636 TRANSISTOR

Q204 2SC3356(R23) TRANSISTOR

Q205 2SC3356(R23) TRANSISTOR

Q208 2SC5636 TRANSISTOR

Q209 2SC5383-T111 TRANSISTOR

Q210 NESG240034 TRANSISTOR

Q212 KRX206E-P TRANSISTOR

Q401 LTC014EEBFS8 DIGITAL TRANSISTOR

Q402 LTC014EEBFS8 DIGITAL TRANSISTOR

Q403 LTC014TEBFS8 DIGITAL TRANSISTOR

Q404 MTM981400BF FET

Q405 2SA1955A-F TRANSISTOR

Q406 UPA672T-A FET

Q407 12A02CH TRANSISTOR

Q409 12A02CH TRANSISTOR

Q410 SSM3K15TE(F) FET

Q411 2SA1955A-F TRANSISTOR

Q412 2SA1955A-F TRANSISTOR

Q413 LTC014EEBFS8 DIGITAL TRANSISTOR

Q415 LTC014EEBFS8 DIGITAL TRANSISTOR

Q416 SSM6L05FU-F FET

Q417 SSM5H01TU-F FET

Q501 UPA672T-A FET

Q701 SSM3K15TE(F) FET

Q702 2SC4617(Q) TRANSISTOR

Q703 SSM3K15TE(F) FET

Q704 2SC4738(GR)F TRANSISTOR

Q705 2SA1832(GR)F TRANSISTOR

Q706 2SJ243-A FET

Q707 2SJ243-A FET

Q708 2SA1832(GR)F TRANSISTOR

Q709 LTC014EEBFS8 DIGITAL TRANSISTOR

Q710 KRC401-P DIGITAL TRANSISTOR

Q901 QSX6 TRANSISTOR

Q902 QSX6 TRANSISTOR

R1 RK73HH1J223D CHIP R 22K

D 1/16W

R2 RK73HH1J223D CHIP R 22K

D 1/16W

R3 RK73HB1J334J CHIP R 330K J 1/16W

R4 RK73HB1J101J CHIP R 100 J 1/16W

R5 RK73HB1J224J CHIP R 220K J 1/16W

R6 RK73HB1J472J CHIP R 4.7K J 1/16W

R7 RK73HB1J103J CHIP R 10K J 1/16W

R8 RK73HB1J472J CHIP R 4.7K J 1/16W

R10 RK73HB1J000J CHIP R 0.0 J 1/16W

R12 RK73HB1J472J CHIP R 4.7K J 1/16W

R13 RK73HB1J473J CHIP R 47K J 1/16W

R15 RK73HB1J100J CHIP R 10 J 1/16W

R16 RK73HB1J100J CHIP R 10 J 1/16W

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

R17 RK73HB1J100J CHIP R 10 J 1/16W

R18 RK73HB1J100J CHIP R 10 J 1/16W

R19 RK73HB1J100J CHIP R 10 J 1/16W

R21 RK73HB1J100J CHIP R 10 J 1/16W

R22 RK73HB1J102J CHIP R 1.0K J 1/16W

R23 RK73HB1J102J CHIP R 1.0K J 1/16W

R25 RK73HB1J000J CHIP R 0.0 J 1/16W

R26 RK73HB1J104J CHIP R 100K J 1/16W

R27 RK73HB1J473J CHIP R 47K J 1/16W

R28 RK73HB1J683J CHIP R 68K J 1/16W

R29 RK73HB1J000J CHIP R 0.0 J 1/16W

R30 RK73HB1J184J CHIP R 180K J 1/16W

R31 RK73HB1J473J CHIP R 47K J 1/16W

R32 RK73HB1J151J CHIP R 150 J 1/16W

R34 RK73HB1J102J CHIP R 1.0K J 1/16W

R35 RK73HH1J391D CHIP R 390

D 1/16W

R36 RK73HB1J106J CHIP R 10M J 1/16W

R37 RK73HB1J103J CHIP R 10K J 1/16W

R40 RK73HB1J000J CHIP R 0.0 J 1/16W

R41 RK73HB1J000J CHIP R 0.0 J 1/16W

R42 RK73HB1J104J CHIP R 100K J 1/16W

R43 RK73HB1J100J CHIP R 10 J 1/16W

R44 RK73HB1J000J CHIP R 0.0 J 1/16W

R45 RK73HB1J104J CHIP R 100K J 1/16W

R46 RK73HB1J271J CHIP R 270 J 1/16W

R47 RK73HB1J154J CHIP R 150K J 1/16W

K,K2,HK2,HK

R47 RK73HB1J224J CHIP R 220K J 1/16W HK3

R49 RK73HB1J683J CHIP R 68K J 1/16W

R53 RK73HB1J473J CHIP R 47K J 1/16W

R54 RK73HB1J473J CHIP R 47K J 1/16W

R55 RK73HB1J472J CHIP R 4.7K J 1/16W

R56 RK73HB1J474J CHIP R 470K J 1/16W

R57 RK73HH1J181D CHIP R 180

D 1/16W

R58 RK73HB1J181J CHIP R 180 J 1/16W

R59 RK73HH1J181D CHIP R 180

D 1/16W

R60 RK73HB1J102J CHIP R 1.0K J 1/16W

R61 RK73HB1J473J CHIP R 47K J 1/16W

R62 RK73HB1J154J CHIP R 150K J 1/16W

R63 RK73HB1J101J CHIP R 100 J 1/16W

R64 RK73HB1J682J CHIP R 6.8K J 1/16W

R65 RK73HB1J103J CHIP R 10K J 1/16W

R66 RK73HB1J331J CHIP R 330 J 1/16W

R67 RK73HB1J222J CHIP R 2.2K J 1/16W

R68 RK73HB1J470J CHIP R 47 J 1/16W

R69 RK73HB1J000J CHIP R 0.0 J 1/16W

R70 RK73HB1J472J CHIP R 4.7K J 1/16W

R71 RK73HB1J474J CHIP R 470K J 1/16W

R72 RK73HB1J183J CHIP R 18K J 1/16W

R74 RK73HB1J102J CHIP R 1.0K J 1/16W

R75 RK73HB1J221J CHIP R 220 J 1/16W

R76 RK73HB1J474J CHIP R 470K J 1/16W

R77 RK73HB1J101J CHIP R 100 J 1/16W

R79 RK73HB1J000J CHIP R 0.0 J 1/16W

R80 RK73HB1J000J CHIP R 0.0 J 1/16W

R81 RK73HB1J000J CHIP R 0.0 J 1/16W

Ref. No.

Address Parts No. Description

Desti-

nation

R82 RK73HB1J000J CHIP R 0.0 J 1/16W

R83 RK73HB1J000J CHIP R 0.0 J 1/16W

R84 RK73GB2A000J CHIP R 0.0 J 1/10W

R85 RK73GB2A000J CHIP R 0.0 J 1/10W

R86 RK73GB2A272J CHIP R 2.7K J 1/10W

R101 RK73HB1J332J CHIP R 3.3K J 1/16W

R102 RK73HB1J271J CHIP R 270 J 1/16W HK3

R102 RK73HB1J821J CHIP R 820 J 1/16W

K,K2,HK2,HK

R103 RK73HB1J180J CHIP R 18 J 1/16W HK3

R103 RK73HB1J5R6J CHIP R 5.6 J 1/16W

K,K2,HK2,HK

R104 RK73HB1J271J CHIP R 270 J 1/16W HK3

R104 RK73HB1J821J CHIP R 820 J 1/16W

K,K2,HK2,HK

R105 RK73HB1J333J CHIP R 33K J 1/16W

R106 RK73HB1J221J CHIP R 220 J 1/16W

K,K2,HK2,HK

R106 RK73HB1J471J CHIP R 470 J 1/16W HK3

R107 RK73HB1J682J CHIP R 6.8K J 1/16W

R108 RK73GB2A100J CHIP R 10 J 1/10W

R109 RK73HB1J331J CHIP R 330 J 1/16W HK3

R109 RK73HB1J471J CHIP R 470 J 1/16W

K,K2,HK2,HK

R110 RK73GB2A220J CHIP R 22 J 1/10W

R111 RK73HB1J561J CHIP R 560 J 1/16W

R112 RK73HB1J272J CHIP R 2.7K J 1/16W

R113 RK73GB2A100J CHIP R 10 J 1/10W

R114 RK73HB1J331J CHIP R 330 J 1/16W

R115 RK73HB1J000J CHIP R 0.0 J 1/16W

R116 RK73GB2A000J CHIP R 0.0 J 1/10W

K,HK2,HK3,HK

R117 RK73HB1J103J CHIP R 10K J 1/16W

R119 RK73HB1J473J CHIP R 47K J 1/16W

R120 RK73HB1J104J CHIP R 100K J 1/16W

R121 RK73GB2A000J CHIP R 0.0 J 1/10W

R122 RK73HB1J683J CHIP R 68K J 1/16W

R123 RK73HB1J273J CHIP R 27K J 1/16W

R124 RK73HB1J332J CHIP R 3.3K J 1/16W

R125 RK73FB2B271J CHIP R 270 J 1/8W

R126 RK73FB2B390J CHIP R 39 J 1/8W

R127 RK73FB2B390J CHIP R 39 J 1/8W

R129 RK73FB2B271J CHIP R 270 J 1/8W

R131 RK73HB1J331J CHIP R 330 J 1/16W

R132 RK73HB1J104J CHIP R 100K J 1/16W

R133 RK73HB1J104J CHIP R 100K J 1/16W

R134 RK73HB1J224J CHIP R 220K J 1/16W HK

R134 RK73HB1J274J CHIP R 270K J 1/16W

K,HK2,HK3

R136 RK73HB1J104J CHIP R 100K J 1/16W

R137 RK73HB1J334J CHIP R 330K J 1/16W

R138 RK73EB2E301J CHIP R 300 J 1/4W

R140 RK73HB1J104J CHIP R 100K J 1/16W

R141 RK73HB1J124J CHIP R 120K J 1/16W

R142 RK73HB1J104J CHIP R 100K J 1/16W

R143 RK73GB2A000J CHIP R 0.0 J 1/10W

R144 RK73HB1J824J CHIP R 820K J 1/16W

R145 RK73HB1J333J CHIP R 33K J 1/16W HK2

R145 RK73HB1J393J CHIP R 39K J 1/16W HK3,HK

R145 RK73HB1J823J CHIP R 82K J 1/16W K,K2

R146 RK73HB1J104J CHIP R 100K J 1/16W

R147 RK73HB1J104J CHIP R 100K J 1/16W

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

R148 RK73HB1J103J CHIP R 10K J 1/16W

R149 RK73HB1J104J CHIP R 100K J 1/16W K,K2,HK

R149 RK73HB1J823J CHIP R 82K J 1/16W

HK2,HK3

R150 RK73HB1J683J CHIP R 68K J 1/16W HK3

R150 RK73HB1J823J CHIP R 82K J 1/16W

K,K2,HK2,HK

R151 RK73HB1J104J CHIP R 100K J 1/16W HK

R151 RK73HB1J124J CHIP R 120K J 1/16W

K,K2,HK2

R151 RK73HB1J154J CHIP R 150K J 1/16W HK3

R152 R92-1061-05 JUMPER REST 0 OHM

R153 RK73HB1J121J CHIP R 120 J 1/16W K,HK

R153 RK73HB1J151J CHIP R 150 J 1/16W

K2,HK2,HK3

R154 RK73EB2E301J CHIP R 300 J 1/4W

R156 RK73HB1J000J CHIP R 0.0 J 1/16W

R158 RK73HB1J000J CHIP R 0.0 J 1/16W

R160 RK73HB1J000J CHIP R 0.0 J 1/16W

R161 RK73HB1J332J CHIP R 3.3K J 1/16W

R170 RK73GB2A000J CHIP R 0.0 J 1/10W

R201 RK73HB1J153J CHIP R 15K J 1/16W

K,K2,HK2,HK

R201 RK73HB1J222J CHIP R 2.2K J 1/16W HK3

R202 RK73HB1J223J CHIP R 22K J 1/16W

R203 RK73HB1J223J CHIP R 22K J 1/16W

R204 RK73HB1J470J CHIP R 47 J 1/16W

R205 RK73HB1J223J CHIP R 22K J 1/16W

R206 RK73HB1J223J CHIP R 22K J 1/16W

R207 RK73HB1J334J CHIP R 330K J 1/16W

R208 RK73HB1J153J CHIP R 15K J 1/16W

R210 RK73HB1J100J CHIP R 10 J 1/16W

R212 RK73HB1J000J CHIP R 0.0 J 1/16W

R213 RK73HB1J102J CHIP R 1.0K J 1/16W

R215 RK73HB1J122J CHIP R 1.2K J 1/16W K2,HK2

R215 RK73HB1J272J CHIP R 2.7K J 1/16W K,HK

R215 RK73HB1J332J CHIP R 3.3K J 1/16W HK3

R216 RK73HB1J000J CHIP R 0.0 J 1/16W

R219 RK73HB1J103J CHIP R 10K J 1/16W

R222 RK73HB1J102J CHIP R 1.0K J 1/16W

R223 RK73HB1J274J CHIP R 270K J 1/16W

R224 RK73HB1J103J CHIP R 10K J 1/16W

R225 RK73HB1J153J CHIP R 15K J 1/16W

R226 RK73HB1J473J CHIP R 47K J 1/16W

R227 RK73HB1J104J CHIP R 100K J 1/16W

R228 RK73HB1J223J CHIP R 22K J 1/16W

R229 RK73HB1J102J CHIP R 1.0K J 1/16W

R230 RK73HB1J102J CHIP R 1.0K J 1/16W HK3

R230 RK73HB1J272J CHIP R 2.7K J 1/16W

K,K2,HK2,HK

R231 RK73HB1J221J CHIP R 220 J 1/16W

R232 RK73HB1J101J CHIP R 100 J 1/16W

R234 RK73HB1J103J CHIP R 10K J 1/16W

R235 RK73HB1J000J CHIP R 0.0 J 1/16W

R236 RK73HB1J000J CHIP R 0.0 J 1/16W

R237 RK73HB1J473J CHIP R 47K J 1/16W

R238 RK73HB1J103J CHIP R 10K J 1/16W

R239 RK73HB1J104J CHIP R 100K J 1/16W

R242 RK73HB1J221J CHIP R 220 J 1/16W

R243 RK73HB1J101J CHIP R 100 J 1/16W

R244 RK73HB1J000J CHIP R 0.0 J 1/16W

Ref. No.

Address Parts No. Description

Desti-

nation

R245 RK73HB1J154J CHIP R 150K J 1/16W

R246 RK73HB1J104J CHIP R 100K J 1/16W

R248 RK73HB1J474J CHIP R 470K J 1/16W

R250 RK73HB1J222J CHIP R 2.2K J 1/16W

R251 RK73HB1J000J CHIP R 0.0 J 1/16W

R252 RK73HB1J000J CHIP R 0.0 J 1/16W

R254 RK73HB1J101J CHIP R 100 J 1/16W

R256 RK73HB1J221J CHIP R 220 J 1/16W

R261 RK73HB1J472J CHIP R 4.7K J 1/16W

R262 RK73HB1J682J CHIP R 6.8K J 1/16W

R263 RK73HB1J101J CHIP R 100 J 1/16W

R265 RK73HB1J103J CHIP R 10K J 1/16W

R266 RK73HB1J222J CHIP R 2.2K J 1/16W

R267 RK73HB1J271J CHIP R 270 J 1/16W

R269 RK73HB1J470J CHIP R 47 J 1/16W

R270 RK73HB1J393J CHIP R 39K J 1/16W

R272 RK73HB1J271J CHIP R 270 J 1/16W

R273 RK73HB1J180J CHIP R 18 J 1/16W

R274 RK73HB1J102J CHIP R 1.0K J 1/16W

R275 RK73HB1J271J CHIP R 270 J 1/16W

R276 RK73HB1J102J CHIP R 1.0K J 1/16W

R277 RK73GB2A000J CHIP R 0.0 J 1/10W

R278 RK73HB1J271J CHIP R 270 J 1/16W HK3

R278 RK73HB1J471J CHIP R 470 J 1/16W K2,HK2

R279 RK73HB1J000J CHIP R 0.0 J 1/16W K,HK

R279 RK73HB1J120J CHIP R 12 J 1/16W K2,HK2

R279 RK73HB1J180J CHIP R 18 J 1/16W HK3

R280 RK73HB1J271J CHIP R 270 J 1/16W HK3

R280 RK73HB1J471J CHIP R 470 J 1/16W K2,HK2

R281 RK73HB1J472J CHIP R 4.7K J 1/16W

R283 RK73HB1J104J CHIP R 100K J 1/16W

R284 RK73HB1J104J CHIP R 100K J 1/16W

R285 RK73HB1J103J CHIP R 10K J 1/16W

R286 RK73HB1J104J CHIP R 100K J 1/16W

R287 RK73HB1J104J CHIP R 100K J 1/16W

R288 RK73HB1J101J CHIP R 100 J 1/16W

R289 RK73HB1J104J CHIP R 100K J 1/16W

R290 RK73HB1J274J CHIP R 270K J 1/16W

K2,HK2,HK3

R290 RK73HB1J474J CHIP R 470K J 1/16W K,HK

R291 RK73HB1J104J CHIP R 100K J 1/16W

R294 RK73HB1J000J CHIP R 0.0 J 1/16W

R296 RK73HB1J103J CHIP R 10K J 1/16W

R297 RK73HB1J000J CHIP R 0.0 J 1/16W

R299 RK73HB1J101J CHIP R 100 J 1/16W

R301 RK73HB1J684J CHIP R 680K J 1/16W

R302 RK73HB1J104J CHIP R 100K J 1/16W

R303 RK73HB1J104J CHIP R 100K J 1/16W

R306 RK73HB1J183J CHIP R 18K J 1/16W

R307 RK73HB1J183J CHIP R 18K J 1/16W

R310 RK73HB1J000J CHIP R 0.0 J 1/16W

R313 RK73GB2A000J CHIP R 0.0 J 1/10W

R314 RK73HB1J000J CHIP R 0.0 J 1/16W

R315 RK73HB1J104J CHIP R 100K J 1/16W

R316 RK73HB1J104J CHIP R 100K J 1/16W

R317 RK73HB1J000J CHIP R 0.0 J 1/16W

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

R323 RK73HB1J470J CHIP R 47 J 1/16W

R324 RK73HB1J182J CHIP R 1.8K J 1/16W

K,K2,HK2,HK

R325 RK73HB1J182J CHIP R 1.8K J 1/16W

K,K2,HK2,HK

R326 RK73HB1J122J CHIP R 1.2K J 1/16W HK3

R327 RK73HB1J332J CHIP R 3.3K J 1/16W

K,K2,HK2,HK

R328 RK73HB1J102J CHIP R 1.0K J 1/16W

R329 RK73HB1J562J CHIP R 5.6K J 1/16W

K,K2,HK2,HK

R329 RK73HB1J682J CHIP R 6.8K J 1/16W HK3

R330 RK73GB2A100J CHIP R 10 J 1/10W

R331 RK73HB1J473J CHIP R 47K J 1/16W

R332 RK73HB1J000J CHIP R 0.0 J 1/16W

R333 RK73HB1J102J CHIP R 1.0K J 1/16W

R334 RK73HB1J000J CHIP R 0.0 J 1/16W

R338 RK73HB1J000J CHIP R 0.0 J 1/16W

R339 RK73HB1J470J CHIP R 47 J 1/16W

R340 RK73HB1J121J CHIP R 120 J 1/16W

R341 RK73HB1J121J CHIP R 120 J 1/16W

R343 RK73HB1J000J CHIP R 0.0 J 1/16W

R344 RK73HB1J000J CHIP R 0.0 J 1/16W HK3

R344 RK73HB1J152J CHIP R 1.5K J 1/16W

K,K2,HK2,HK

R345 RK73HB1J000J CHIP R 0.0 J 1/16W

R346 RK73HB1J223J CHIP R 22K J 1/16W

R352 RK73HB1J000J CHIP R 0.0 J 1/16W

R353 RK73HB1J000J CHIP R 0.0 J 1/16W

R354 RK73HB1J000J CHIP R 0.0 J 1/16W

K,HK3,HK

R360 RK73GB2A000J CHIP R 0.0 J 1/10W K,HK

R401 RK73HH1J105D CHIP R 1.0M

D 1/16W

R402 RK73HB1J471J CHIP R 470 J 1/16W

R403 RK73HH1J104D CHIP R 100K

D 1/16W

R404 RK73HB1J103J CHIP R 10K J 1/16W

R405 RK73HH1J274D CHIP R 270K

D 1/16W

R406 RK73HH1J104D CHIP R 100K

D 1/16W

R407 RK73HB1J103J CHIP R 10K J 1/16W

R408 RK73HB1J103J CHIP R 10K J 1/16W

R409 RK73HB1J103J CHIP R 10K J 1/16W

R410 RK73HB1J684J CHIP R 680K J 1/16W

R411 RK73HB1J104J CHIP R 100K J 1/16W

R413 RK73HB1J474J CHIP R 470K J 1/16W

R415 RK73HB1J332J CHIP R 3.3K J 1/16W

R417 RK73HB1J473J CHIP R 47K J 1/16W

R418 RK73HB1J103J CHIP R 10K J 1/16W

R420 RK73HB1J473J CHIP R 47K J 1/16W

R421 RK73HB1J474J CHIP R 470K J 1/16W

R422 RK73HB1J103J CHIP R 10K J 1/16W

R423 RK73GB2A472J CHIP R 4.7K J 1/10W

R425 RK73GB2A472J CHIP R 4.7K J 1/10W

R426 RK73HB1J474J CHIP R 470K J 1/16W

R428 RK73HB1J103J CHIP R 10K J 1/16W

R429 RK73HB1J103J CHIP R 10K J 1/16W

R430 RK73HH1J124D CHIP R 120K

D 1/16W

R431 RK73HH1J183D CHIP R 18K

D 1/16W

R432 RK73HH1J223D CHIP R 22K

D 1/16W

R433 RK73HB1J102J CHIP R 1.0K J 1/16W

R434 RK73HB1J330J CHIP R 33 J 1/16W

R435 RK73GB2A100J CHIP R 10 J 1/10W

Ref. No.

Address Parts No. Description

Desti-

nation

R436 RK73HB1J000J CHIP R 0.0 J 1/16W

R437 RK73HB1J474J CHIP R 470K J 1/16W

R438 RK73HB1J154J CHIP R 150K J 1/16W

R440 RK73HB1J102J CHIP R 1.0K J 1/16W

R441 RK73HB1J123J CHIP R 12K J 1/16W

R442 RK73HH1J334D CHIP R 330K

D 1/16W

R443 RK73HH1J223D CHIP R 22K

D 1/16W

R444 RK73HB1J272J CHIP R 2.7K J 1/16W

R445 RK73HB1J473J CHIP R 47K J 1/16W

R446 RK73GB2A100J CHIP R 10 J 1/10W

R447 RK73HB1J473J CHIP R 47K J 1/16W

R448 RK73HB1J000J CHIP R 0.0 J 1/16W

R449 RK73GB2A220J CHIP R 22 J 1/10W

R450 RK73HB1J000J CHIP R 0.0 J 1/16W

R501 RK73HB1J104J CHIP R 100K J 1/16W

R503 RK73HB1J102J CHIP R 1.0K J 1/16W

R504 RK73HB1J104J CHIP R 100K J 1/16W

R506 RK73HB1J474J CHIP R 470K J 1/16W

R507 RK73HB1J000J CHIP R 0.0 J 1/16W

R509 RK73HB1J000J CHIP R 0.0 J 1/16W

R510 RK73HB1J474J CHIP R 470K J 1/16W

R511 RK73HB1J220J CHIP R 22 J 1/16W

R512 RK73HB1J104J CHIP R 100K J 1/16W

R514 RK73HB1J000J CHIP R 0.0 J 1/16W

R515 RK73HB1J104J CHIP R 100K J 1/16W

R516 RK73HB1J104J CHIP R 100K J 1/16W

R520 RK73HB1J473J CHIP R 47K J 1/16W

R521 RK73HB1J473J CHIP R 47K J 1/16W

R522 RK73HB1J474J CHIP R 470K J 1/16W

R523 RK73HB1J473J CHIP R 47K J 1/16W

R524 RK73HB1J000J CHIP R 0.0 J 1/16W

R525 RK73HB1J104J CHIP R 100K J 1/16W

R527 RK73HB1J104J CHIP R 100K J 1/16W

R528 RK73HB1J000J CHIP R 0.0 J 1/16W

R529 RK73HB1J000J CHIP R 0.0 J 1/16W

R531 RK73HB1J104J CHIP R 100K J 1/16W

R532 RK73HB1J101J CHIP R 100 J 1/16W

R533 RK73HB1J000J CHIP R 0.0 J 1/16W

R534 RK73HB1J000J CHIP R 0.0 J 1/16W

R536 RK73HB1J000J CHIP R 0.0 J 1/16W

R537 RK73HB1J000J CHIP R 0.0 J 1/16W

R538 RK73HB1J101J CHIP R 100 J 1/16W

R539 RK73HB1J000J CHIP R 0.0 J 1/16W

R540 RK73HB1J101J CHIP R 100 J 1/16W

R541 RK73HB1J101J CHIP R 100 J 1/16W

R542 RK73HB1J104J CHIP R 100K J 1/16W

R543 RK73HB1J000J CHIP R 0.0 J 1/16W

R544 RK73HB1J104J CHIP R 100K J 1/16W

R545 RK73HB1J000J CHIP R 0.0 J 1/16W

R548 RK73GB2A000J CHIP R 0.0 J 1/10W

R550 RK73GB2A000J CHIP R 0.0 J 1/10W

R551 RK73HB1J101J CHIP R 100 J 1/16W

R552 RK73HB1J104J CHIP R 100K J 1/16W

R553 RK73HB1J104J CHIP R 100K J 1/16W

R554 RK73HB1J104J CHIP R 100K J 1/16W

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

R556 RK73HB1J104J CHIP R 100K J 1/16W

R557 RK73HB1J104J CHIP R 100K J 1/16W

R558 RK73HB1J104J CHIP R 100K J 1/16W

R560 RK73HB1J000J CHIP R 0.0 J 1/16W

R561 RK73HB1J473J CHIP R 47K J 1/16W

R562 RK73GB2A000J CHIP R 0.0 J 1/10W

R565 RK73GB2A000J CHIP R 0.0 J 1/10W

R567 RK73HB1J151J CHIP R 150 J 1/16W

R568 RK73HB1J102J CHIP R 1.0K J 1/16W

R569 RK73HB1J220J CHIP R 22 J 1/16W

R572 RK73HB1J220J CHIP R 22 J 1/16W

R574 RK73GB2A000J CHIP R 0.0 J 1/10W

R575 RK73HB1J103J CHIP R 10K J 1/16W

R576 RK73HB1J000J CHIP R 0.0 J 1/16W

R577 RK73HB1J102J CHIP R 1.0K J 1/16W

R578 RK73HB1J000J CHIP R 0.0 J 1/16W

R579 RK73HB1J000J CHIP R 0.0 J 1/16W

R580 RK73HB1J000J CHIP R 0.0 J 1/16W

R581 RK73HB1J474J CHIP R 470K J 1/16W

R582 RK73HB1J000J CHIP R 0.0 J 1/16W

R583 RK73HB1J000J CHIP R 0.0 J 1/16W

R584 RK73HB1J000J CHIP R 0.0 J 1/16W

R585 RK73HB1J000J CHIP R 0.0 J 1/16W

R586 RK73HB1J000J CHIP R 0.0 J 1/16W

R587 RK73HB1J102J CHIP R 1.0K J 1/16W

R588 RK73HB1J000J CHIP R 0.0 J 1/16W

R589 RK73HB1J000J CHIP R 0.0 J 1/16W

R590 RK73HB1J000J CHIP R 0.0 J 1/16W

R591 RK73HB1J102J CHIP R 1.0K J 1/16W

R592 RK73HB1J000J CHIP R 0.0 J 1/16W

R593 RK73HB1J000J CHIP R 0.0 J 1/16W

R594 RK73HB1J102J CHIP R 1.0K J 1/16W

R595 RK73HB1J000J CHIP R 0.0 J 1/16W

R596 RK73HB1J104J CHIP R 100K J 1/16W

R597 RK73HB1J102J CHIP R 1.0K J 1/16W

R598 RK73FB2B102J CHIP R 1.0K J 1/8W

R599 RK73FB2B102J CHIP R 1.0K J 1/8W

R600 RK73FB2B102J CHIP R 1.0K J 1/8W

R601 RK73FB2B102J CHIP R 1.0K J 1/8W

R602 RK73HB1J102J CHIP R 1.0K J 1/16W

R603 RK73HB1J000J CHIP R 0.0 J 1/16W

R604 RK73HB1J000J CHIP R 0.0 J 1/16W

R605 RK73HB1J102J CHIP R 1.0K J 1/16W

R606 RK73HB1J103J CHIP R 10K J 1/16W

R607 RK73HB1J102J CHIP R 1.0K J 1/16W

R608 RK73HB1J102J CHIP R 1.0K J 1/16W

R610 RK73HB1J102J CHIP R 1.0K J 1/16W

R611 RK73HB1J105J CHIP R 1.0M J 1/16W

R612 RK73HB1J105J CHIP R 1.0M J 1/16W

R614 RK73HB1J474J CHIP R 470K J 1/16W

R615 RK73HB1J000J CHIP R 0.0 J 1/16W

R616 RK73HB1J000J CHIP R 0.0 J 1/16W

R617 RK73HB1J102J CHIP R 1.0K J 1/16W

R618 RK73HB1J102J CHIP R 1.0K J 1/16W

R619 RK73HB1J102J CHIP R 1.0K J 1/16W

Ref. No.

Address Parts No. Description

Desti-

nation

R620 RK73HB1J102J CHIP R 1.0K J 1/16W

R621 RK73HB1J000J CHIP R 0.0 J 1/16W

R622 RK73HB1J102J CHIP R 1.0K J 1/16W

R623 RK73HB1J104J CHIP R 100K J 1/16W

R624 RK73HB1J104J CHIP R 100K J 1/16W

R625 RK73HB1J104J CHIP R 100K J 1/16W

R627 RK73HB1J104J CHIP R 100K J 1/16W

R628 RK73HB1J104J CHIP R 100K J 1/16W

R629 RK73HB1J105J CHIP R 1.0M J 1/16W

R630 RK73HB1J102J CHIP R 1.0K J 1/16W

R632 RK73HB1J103J CHIP R 10K J 1/16W

R633 RK73HB1J000J CHIP R 0.0 J 1/16W

R634 RK73HB1J103J CHIP R 10K J 1/16W

R636 RK73HB1J000J CHIP R 0.0 J 1/16W

R637 RK73HB1J103J CHIP R 10K J 1/16W

R638 RK73HB1J104J CHIP R 100K J 1/16W

R639 RK73HB1J102J CHIP R 1.0K J 1/16W

R640 RK73HB1J103J CHIP R 10K J 1/16W

R641 RK73HB1J104J CHIP R 100K J 1/16W

R642 RK73HB1J104J CHIP R 100K J 1/16W

R644 RK73GB2A000J CHIP R 0.0 J 1/10W

R646 RK73HB1J682J CHIP R 6.8K J 1/16W

R648 RK73HB1J682J CHIP R 6.8K J 1/16W

R650 RK73GB2A000J CHIP R 0.0 J 1/10W

R651 RK73FB2B102J CHIP R 1.0K J 1/8W

R652 RK73HB1J104J CHIP R 100K J 1/16W

R654 RK73GB2A000J CHIP R 0.0 J 1/10W

R656 RK73HB1J471J CHIP R 470 J 1/16W

R658 RK73GB2A000J CHIP R 0.0 J 1/10W

R659 RK73HB1J104J CHIP R 100K J 1/16W

R660 RK73HB1J104J CHIP R 100K J 1/16W

R661 RK73HB1J104J CHIP R 100K J 1/16W

R662 RK73HB1J474J CHIP R 470K J 1/16W

R663 RK73HB1J474J CHIP R 470K J 1/16W

R664 RK73HB1J104J CHIP R 100K J 1/16W

R665 RK73HB1J104J CHIP R 100K J 1/16W

R666 RK73HB1J104J CHIP R 100K J 1/16W

R667 RK73HB1J104J CHIP R 100K J 1/16W

R668 RK73HB1J104J CHIP R 100K J 1/16W

R669 RK73HB1J104J CHIP R 100K J 1/16W

R670 RK73HB1J104J CHIP R 100K J 1/16W

R671 RK73HB1J104J CHIP R 100K J 1/16W

R672 RK73HB1J104J CHIP R 100K J 1/16W

R673 RK73HB1J104J CHIP R 100K J 1/16W

R674 RK73HB1J104J CHIP R 100K J 1/16W

R676 RK73HB1J104J CHIP R 100K J 1/16W

R677 RK73HB1J474J CHIP R 470K J 1/16W

R678 RK73HB1J104J CHIP R 100K J 1/16W

R680 RK73HB1J102J CHIP R 1.0K J 1/16W

R681 RK73HB1J102J CHIP R 1.0K J 1/16W

R682 RK73HB1J102J CHIP R 1.0K J 1/16W

R683 RK73HB1J102J CHIP R 1.0K J 1/16W

R684 RK73HB1J104J CHIP R 100K J 1/16W

R685 RK73HB1J104J CHIP R 100K J 1/16W

R686 RK73HB1J104J CHIP R 100K J 1/16W

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

R687 RK73HB1J472J CHIP R 4.7K J 1/16W

R688 RK73HB1J472J CHIP R 4.7K J 1/16W

R689 RK73HB1J474J CHIP R 470K J 1/16W

R690 RK73HB1J474J CHIP R 470K J 1/16W

R691 RK73HB1J223J CHIP R 22K J 1/16W

R692 RK73HB1J104J CHIP R 100K J 1/16W

R693 RK73HB1J104J CHIP R 100K J 1/16W

R694 RK73HB1J104J CHIP R 100K J 1/16W

R695 RK73HB1J104J CHIP R 100K J 1/16W

R696 RK73HB1J104J CHIP R 100K J 1/16W

R697 RK73HB1J000J CHIP R 0.0 J 1/16W

R698 RK73HB1J000J CHIP R 0.0 J 1/16W

R701 RK73HB1J104J CHIP R 100K J 1/16W

R703 RK73HB1J103J CHIP R 10K J 1/16W

R704 RK73HB1J563J CHIP R 56K J 1/16W

R705 RK73HB1J104J CHIP R 100K J 1/16W

R706 RK73HB1J333J CHIP R 33K J 1/16W

R707 RK73HB1J153J CHIP R 15K J 1/16W

R708 RK73HB1J683J CHIP R 68K J 1/16W

R709 RK73HB1J822J CHIP R 8.2K J 1/16W

R710 RK73HB1J104J CHIP R 100K J 1/16W

R712 RK73HB1J683J CHIP R 68K J 1/16W

R713 RK73HB1J563J CHIP R 56K J 1/16W

R714 RK73HB1J104J CHIP R 100K J 1/16W

R715 RK73HB1J473J CHIP R 47K J 1/16W

R716 RK73HB1J000J CHIP R 0.0 J 1/16W

R718 RK73HB1J000J CHIP R 0.0 J 1/16W

R720 RK73HB1J104J CHIP R 100K J 1/16W

R721 RK73HB1J222J CHIP R 2.2K J 1/16W

R722 RK73HB1J683J CHIP R 68K J 1/16W

R723 RK73HB1J000J CHIP R 0.0 J 1/16W

R724 RK73HB1J563J CHIP R 56K J 1/16W

R725 RK73HB1J683J CHIP R 68K J 1/16W

R726 RK73HB1J100J CHIP R 10 J 1/16W

R727 RK73HB1J274J CHIP R 270K J 1/16W

R728 RK73HB1J000J CHIP R 0.0 J 1/16W

R729 RK73HB1J104J CHIP R 100K J 1/16W

R731 RK73HB1J000J CHIP R 0.0 J 1/16W

R732 RK73HB1J473J CHIP R 47K J 1/16W

R737 RK73HB1J473J CHIP R 47K J 1/16W

R738 RK73HB1J102J CHIP R 1.0K J 1/16W

R739 RK73HB1J000J CHIP R 0.0 J 1/16W

R740 RK73HB1J104J CHIP R 100K J 1/16W

R741 RK73HB1J104J CHIP R 100K J 1/16W

R744 RK73HB1J473J CHIP R 47K J 1/16W

R745 RK73HB1J104J CHIP R 100K J 1/16W

R746 RK73HB1J103J CHIP R 10K J 1/16W

R747 RK73HB1J334J CHIP R 330K J 1/16W

R748 RK73HB1J000J CHIP R 0.0 J 1/16W

R749 RK73HB1J823J CHIP R 82K J 1/16W

R750 RK73HB1J332J CHIP R 3.3K J 1/16W

R751 RK73HB1J271J CHIP R 270 J 1/16W

R752 RK73HB1J102J CHIP R 1.0K J 1/16W

R753 RK73HB1J563J CHIP R 56K J 1/16W

R755 RK73HB1J103J CHIP R 10K J 1/16W

Ref. No.

Address Parts No. Description

Desti-

nation

R756 RK73HB1J153J CHIP R 15K J 1/16W

R758 RK73HB1J103J CHIP R 10K J 1/16W

R759 RK73HB1J104J CHIP R 100K J 1/16W

R760 RK73HB1J152J CHIP R 1.5K J 1/16W

R761 RK73HB1J104J CHIP R 100K J 1/16W

K,K2,HK2,HK

R761 RK73HB1J683J CHIP R 68K J 1/16W HK3

R762 RK73HB1J334J CHIP R 330K J 1/16W HK3

R762 RK73HB1J474J CHIP R 470K J 1/16W

K,K2,HK2,HK

R763 RK73HB1J183J CHIP R 18K J 1/16W

R764 RK73HB1J124J CHIP R 120K J 1/16W

R765 RK73HB1J102J CHIP R 1.0K J 1/16W

R766 RK73HB1J104J CHIP R 100K J 1/16W

R767 RK73HB1J473J CHIP R 47K J 1/16W

R768 RK73HB1J473J CHIP R 47K J 1/16W

R769 RK73HB1J472J CHIP R 4.7K J 1/16W

R770 RK73HB1J563J CHIP R 56K J 1/16W

R771 RK73HB1J104J CHIP R 100K J 1/16W

R772 RK73HB1J123J CHIP R 12K J 1/16W

R773 RK73HB1J684J CHIP R 680K J 1/16W

R774 RK73HB1J474J CHIP R 470K J 1/16W

R775 RK73HB1J823J CHIP R 82K J 1/16W

R776 RK73HB1J334J CHIP R 330K J 1/16W

R777 RK73HB1J154J CHIP R 150K J 1/16W

R778 RK73HB1J394J CHIP R 390K J 1/16W

R779 RK73HB1J474J CHIP R 470K J 1/16W

R780 RK73HB1J104J CHIP R 100K J 1/16W

K,K2,HK2,HK

R781 RK73HB1J104J CHIP R 100K J 1/16W

K,K2,HK2,HK

R782 RK73HB1J153J CHIP R 15K J 1/16W

R783 RK73HB1J000J CHIP R 0.0 J 1/16W

R784 RK73HB1J154J CHIP R 150K J 1/16W

R785 RK73HB1J103J CHIP R 10K J 1/16W

R786 RK73HB1J393J CHIP R 39K J 1/16W

R787 RK73HB1J274J CHIP R 270K J 1/16W

R788 RK73HB1J223J CHIP R 22K J 1/16W

R789 RK73HB1J000J CHIP R 0.0 J 1/16W

R790 RK73HB1J224J CHIP R 220K J 1/16W

R791 RK73HB1J564J CHIP R 560K J 1/16W

R792 RK73HB1J102J CHIP R 1.0K J 1/16W

R793 RK73HB1J000J CHIP R 0.0 J 1/16W

R794 RK73HB1J000J CHIP R 0.0 J 1/16W

R795 RK73HB1J224J CHIP R 220K J 1/16W

R796 RK73HB1J103J CHIP R 10K J 1/16W

R797 RK73HB1J334J CHIP R 330K J 1/16W

R798 RK73HB1J684J CHIP R 680K J 1/16W

R799 RK73HB1J563J CHIP R 56K J 1/16W

R800 RK73HB1J472J CHIP R 4.7K J 1/16W

R801 RK73HB1J104J CHIP R 100K J 1/16W

R802 RK73HB1J273J CHIP R 27K J 1/16W

R803 RK73HB1J153J CHIP R 15K J 1/16W

R804 RK73HB1J681J CHIP R 680 J 1/16W

R805 RK73HB1J823J CHIP R 82K J 1/16W

R806 RK73HB1J562J CHIP R 5.6K J 1/16W

R807 RK73HB1J103J CHIP R 10K J 1/16W

R808 RK73HB1J103J CHIP R 10K J 1/16W

R809 RK73HB1J104J CHIP R 100K J 1/16W

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

PARTS LIST

Ref. No.

Address Parts No. Description

Desti-

nation

R810 RK73HB1J102J CHIP R 1.0K J 1/16W

R812 RK73HB1J472J CHIP R 4.7K J 1/16W

R813 RK73HB1J472J CHIP R 4.7K J 1/16W

R814 RK73HB1J104J CHIP R 100K J 1/16W

R815 RK73HB1J104J CHIP R 100K J 1/16W

R816 RK73HB1J104J CHIP R 100K J 1/16W

R817 RK73HB1J473J CHIP R 47K J 1/16W

R818 RK73HB1J333J CHIP R 33K J 1/16W

R819 RK73HB1J000J CHIP R 0.0 J 1/16W

R820 RK73HB1J474J CHIP R 470K J 1/16W

R821 RK73HB1J000J CHIP R 0.0 J 1/16W

R822 RK73HB1J101J CHIP R 100 J 1/16W

R823 RK73HB1J472J CHIP R 4.7K J 1/16W

R825 RK73HB1J103J CHIP R 10K J 1/16W

R826 RK73HB1J103J CHIP R 10K J 1/16W

R827 RK73HB1J332J CHIP R 3.3K J 1/16W

R828 RK73HB1J000J CHIP R 0.0 J 1/16W

R831 RK73HB1J000J CHIP R 0.0 J 1/16W

R833 RK73HB1J101J CHIP R 100 J 1/16W

R834 RK73HB1J101J CHIP R 100 J 1/16W

R835 RK73HB1J101J CHIP R 100 J 1/16W

R836 RK73HB1J000J CHIP R 0.0 J 1/16W

R837 RK73HB1J472J CHIP R 4.7K J 1/16W

R838 RK73HB1J000J CHIP R 0.0 J 1/16W

R841 RK73HB1J000J CHIP R 0.0 J 1/16W

R842 RK73FB2B102J CHIP R 1.0K J 1/8W

R843 RK73HB1J471J CHIP R 470 J 1/16W

R845 RK73HB1J102J CHIP R 1.0K J 1/16W

R846 RK73HB1J332J CHIP R 3.3K J 1/16W

R847 RK73HB1J000J CHIP R 0.0 J 1/16W

R850 RK73GB2A000J CHIP R 0.0 J 1/10W HK3

R901 RK73GB2A471J CHIP R 470 J 1/10W

R902 RK73HB1J101J CHIP R 100 J 1/16W

R903 RK73HB1J101J CHIP R 100 J 1/16W

R904 RK73HB1J471J CHIP R 470 J 1/16W

R905 RK73HB1J471J CHIP R 470 J 1/16W

R906 RK73HB1J471J CHIP R 470 J 1/16W

R907 RK73HB1J471J CHIP R 470 J 1/16W

R908 RK73HB1J471J CHIP R 470 J 1/16W

R909 RK73HB1J471J CHIP R 470 J 1/16W

R910 RK73HB1J471J CHIP R 470 J 1/16W

R911 RK73HB1J471J CHIP R 470 J 1/16W

R912 RK73HB1J471J CHIP R 470 J 1/16W

R913 RK73HB1J471J CHIP R 470 J 1/16W

R914 RK73GB2A471J CHIP R 470 J 1/10W

R915 RK73HB1J000J CHIP R 0.0 J 1/16W

R916 RK73HB1J000J CHIP R 0.0 J 1/16W

R917 RK73HB1J000J CHIP R 0.0 J 1/16W

R918 RK73HB1J101J CHIP R 100 J 1/16W

R919 RK73HB1J101J CHIP R 100 J 1/16W

R920 RK73HB1J000J CHIP R 0.0 J 1/16W

R921 RK73HB1J474J CHIP R 470K J 1/16W

R922 RK73HB1J000J CHIP R 0.0 J 1/16W

HK2,HK3,HK

R923 RK73HB1J473J CHIP R 47K J 1/16W HK3

R924 RK73HB1J000J CHIP R 0.0 J 1/16W

Ref. No.

Address Parts No. Description

Desti-

nation

TH101 ERTJ0V104H THERMISTOR

TH103 ERTJ0V104H THERMISTOR K2

TH102 ERTJ0V104H THERMISTOR

K,HK2,HK3,HK

TH701 ERTJ0V104H THERMISTOR

X1 L77-3016-05 TCXO (19.2M)

X501 L77-1802-05 CRYSTAL RESONATOR(32768HZ)

X502 L77-3015-05 TCXO (18.432M)

XF202 L71-0649-05 MCF (58.05MHZ)

TX-RX UINT (X57-8900-XX)

TX-RX UINT (XC1-0990-10)

NX-800/800H

NX-800/800H(K,K2) Receiver Section

Item

Condition Measurement Adjustment Speciﬁ cations /

Remarks

Panel test mode PC test mode

Test-

equipment

Unit

Terminal

Unit Parts Method

1. AF level

setting

[Panel test mode]

1) CH-Sig: 1-1

SSG output:

–47dBm (1mV)

(MOD: 1kHz,

Dev: ±1.5kHz)

1) Test Channel

Channel: 1

Test Signaling

Mode: Analog

Signaling: 1

SSG output:

–47dBm (1mV)

(MOD: 1kHz,

Dev: ±1.5kHz)

SSG

DVM

AF VTVM

Dummy

load (4Ω)

ANT

Ext.SP

connec-

tor

[Panel

tuning

mode]

[ ],[ ]

[PC test

mode]

[ ],[ ]

(Volum

Button in

PC test

mode

screen)

Volume Up/Down

knob to obtain

2.83V AF output.

(2.0W @ 4Ω load)

2.83V±0.3V

2. Sensitivity 2

Adjust

(BPF adjust)

1) Adj item: [SENS2]

Adjust: [***]

2) Adj item:

[L SENS2]Õ

[L’ SENS2]Õ

[C SENS2]Õ

[H’ SENS2]Õ

[H SENS2]

Adjust: [***]

Press [<] key to store

the adjustment value.

1) Adj item:

[Sensitivity 2]

2) Adj item: [Low],

[Low’], [Center],

[High’], [High]

Press [Apply All]

button to store the

adjustment value.

[Panel

tuning

mode]

[ ],[ ]

[PC test

mode]

[ ],[ ]

Write the value as

followings (Fixed).

[L SENS2] / [Low]

: 60 K,HK

50 K2,HK2

[L’ SENS2] / [Low’]

: 95 K,HK

88 K2,HK2 K2,HK2

[C SENS2] / [Center]

: 130 K,HK,

125 K2,HK2

[H’ SENS2] / [High’]

: 165 K,HK,

174 K2,HK2

[H SENS2] / [High]

: 200 K,HK,

222 K2,HK2

Variable-Capacitor

Tune voltage is

adjusted.

(Output voltage ad-

justment of IC205)

3. Sensitivity 1

Adjust

(BPF adjust)

1) Adj item: [SENS1]

Adjust: [***]

2) Adj item:

[L SENS1]Õ

[L’ SENS1]Õ

[C SENS1]Õ

[H’ SENS1]Õ

[H SENS1]

Adjust: [***]

Press [<] key to store

the adjustment value.

1) Adj item:

[Sensitivity 1]

2) Adj item: [Low],

[Low’], [Center],

[High’], [High]

Press [Apply All]

button to store the

adjustment value.

Write the value as

followings (typical

value).

[L SENS2] / [Low]

: 80 K,HK

71 K2,HK2

(Fixed)

[L’ SENS2] / [Low’]

: 120 K,HK

107 K2,HK2

(Fixed)

[C SENS2] / [Center]

: 150 K,HK

138 K2,HK2

(Fixed)

[H’ SENS2] / [High’]

: 180 K,HK

157 K2,HK2

(Fixed)

[H SENS2] / [High]

: 200 K,HK

180 K2,HK2

(Preset)

Variable-Capacitor

Tune voltage is

adjusted.

(Output voltage ad-

justment of IC206)

If sensitivity is low,

ﬁne-tune the value.

[H SENS1] / [High]

Check Sens1

FH(Narrow)

RX Sensitivity >12dB

at SSG output:

-118.5dBm

(0.266uV).

If RX Sensitivity Out

of Speciﬁcation,

set SSG output:

-90dBm (7.08uV),

FM:1.5kHz,

Align Sens 1 FH to

the last RSSI peak,

and -30 digit shift

from the last RSSI

peak.

ADJUSTMENT

Other manuals for NEXEDGE NX-800 series

This manual suits for next models

Table of contents

Other Kenwood Car Receiver manuals

Kenwood

Kenwood Z910DVD User manual

Kenwood

Kenwood KRC-22 User manual

Kenwood

Kenwood KRC-S300 User manual

Kenwood

Kenwood KRC-Z965 User manual

Kenwood

Kenwood KRC-391 User manual

Kenwood

Kenwood KDC-MP732 User manual

Kenwood

Kenwood KDC-BT61U User manual

Kenwood

Kenwood KRC-340 User manual

Kenwood

Kenwood KDC-X7200DAB User manual

Kenwood

Kenwood DPX-U5130 User manual

Kenwood

Kenwood KRC-860 User manual

Kenwood

Kenwood CAW-1170-05 User manual

Kenwood

Kenwood DDX9016S User manual

Kenwood

Kenwood KDC-232MR User manual

Kenwood

Kenwood KDC-BT45U User manual

Kenwood

Kenwood KDC-4057UB User manual

Kenwood

Kenwood KRC-152LA/LG User manual

Kenwood

Kenwood KDC-X599 User manual

Kenwood

Kenwood CA-P70 Instruction Manual

Kenwood

Kenwood KDC-W4537U User manual

Kenwood

Kenwood KVT-534DVD User manual

Kenwood

Kenwood KRC-366 User manual

Kenwood

Kenwood KRC-480 User manual

Kenwood

Kenwood KDC-MP538U User manual

Popular Car Receiver manuals by other brands

JL Audio

JL Audio 94537 installation guide

JVC

JVC KS-FX280 instructions

Sony

Sony CDX-M3DI (XT-XM1) Installation/connections

Pioneer

Pioneer FH-X755BT owner's manual

Sony

Sony XR-C4120 operating instructions

Sony

Sony HCD-VX333 Service manual

Jensen

Jensen VM9223 - Touch Screen Double Din MultiMedia... installation guide

Farenheit

Farenheit HRD-93 user manual

JVC

JVC KD-LH3150J Schematic diagrams

Alpine

Alpine CDA-9887 owner's manual

Alpine

Alpine CDA-5755 owner's manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Product guide

ASA Electronics

ASA Electronics VR50 owner's manual

JVC

JVC KDA605 - KD Radio / CD Installation & connection manual

Pioneer

Pioneer P1280 - CDX CD Changer owner's manual

Boss Audio Systems

Boss Audio Systems BV6820 user manual

LG LAC6700R Service manual

Audiosystem

Audiosystem EX 130 SQ EVO3 user manual

Kenwood NEXEDGE NX-800 series User manual

Popular Car Receiver manuals by other brands
