Kenwood FP215 Installation guide

FP215


























before us ng your Kenwood appl ance
●Read these instructions carefully and retain for future reference.
●Remove all packaging and any labels.
safety
●The blades and discs are very sharp, handle with care. Always
hold the kn fe blade by the f nger gr p at the top,
away from the cutt ng edge, both when handl ng and
clean ng.
●Always remove the knife blade before pouring contents from the
bowl.
●Keep hands and utensils out of the processor bowl and liquidiser
jug whilst connected to the power supply.
●Switch off and unplug:
●●before fitting or removing parts
●●after use
●●before cleaning
●Never use your fingers to push food down the feed tube. Always
use the pusher/s supplied.
●Before removing the lid from the bowl or liquidiser from the
power unit:-
●●switch off;
●●wait until the attachment/blades have completely stopped;
●●Be careful not to unscrew the liquidiser jug from the blade
unit.
●Allow all liquids to cool to room temperature before placing them
in the liquidiser.
●Do not use the lid to operate the processor, always use the on/off
speed control.
●Th s mach ne w ll be damaged and may cause njury
f the nterlock mechan sm s subjected to excess ve
force.
●Never use an unauthorised attachment.
●Never leave the machine on unattended.
●Never use a damaged machine. Get it checked or repaired: see
‘service’.
●Never let the power unit, cord or plug get wet.
●Don’t let excess cord hang over the edge of a table or worktop
or touch hot surfaces.
●This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
●Children should be supervised to ensure that they do not play
with the appliance.
●Only use the appliance for its intended domestic use. Kenwood
will not accept any liability if the appliance is subject to improper
use, or failure to comply with these instructions.
●Misuse of your processor/liquidiser can result in injury.
before plugg ng n
●Make sure your electricity supply is the same as the one shown
on the underside of your appliance.
Important – UK only
●The wires in the cord are coloured as follows:
Blue = Neutral,
Brown = Live.
●The appliance must be protected by a 13A approved (BS1362)
fuse.
Note:
●For non-rewireable plugs the fuse cover MUST be refitted when
replacing the fuse. If the fuse cover is lost then the plug must not
be used until a replacement can be obtained. The correct fuse
cover is identified by colour and a replacement may be obtained
from your Kenwood Authorised Repairer (see Service).
●If a non-rewireable plug is cut off it must be DESTROYED
IMMEDIATELY. An electric shock hazard may arise if an
unwanted non-rewireable pug is inadvertently inserted into a 13A
socket outlet.
●This appliance conforms to EC directive 2004/10 /EC on
Electromagnetic Compatibility and EC regulation no. 1935/2004
of 27/10/2004 on materials intended for contact with food.
before us ng for the f rst t me
1 Remove all packaging including the plastic blade covers from the
knife blade. Take care the blades are very sharp. These
covers should be discarded as they are to protect the blade
during manufacture and transit only.
2 Wash the parts see ‘cleaning’
3 Push excess cord into the back of the machine.
key
processor
pusher
feed tube
lid
bowl
detachable drive shaft
speed + pulse control
power unit
safety interlock
cord storage
liquidiser
blade unit
sealing ring
jug
filler cap
lid
attachments
knife blade
emulsifying tool / whisk
thick slicing/coarse shredding disc
spatula
2

to use your food processor
1Fit the detachable shaft onto the power unit .
2 Then fit the bowl. Place the handle towards the back and turn
clockwise until it locks .
3Fit an attachment over the drive shaft.
●Always fit the bowl and attachment onto the machine before
adding ingredients.
4Fit the lid  - ensuring the top of the drive shaft locates into the
centre of the lid.
●Do not use the l d to operate the processor, always
use the on/off speed control.
5 Switch on and select a speed.
●The processor won’t work f the bowl and l d are
ftted ncorrectly.
●Use the pulse control for short bursts. The pulse will operate as
long as the control is held in position.
6 Reverse the above procedure to remove the lid, attachments and
bowl.
●Always sw tch off before remov ng the l d.
mportant
●Your processor is not suitable for crushing or grinding coffee
beans, or converting granulated sugar to caster sugar.
●When adding almond essence or flavouring to mixtures avoid
contact with the plastic as this may result in permanent marking.
to use your liquidiser
1 Fit the sealing ring  into the blade unit - ensuring the seal is
located correctly. Leak ng w ll occur f the seal s
damaged or not f tted correctly.
2 Hold the underside of the blade unit and insert the blades into
the jug - turn clockwise to lock.
3 Put your ingredients into the jug.
4 Fit the lid onto the jug and turn clockwise to lock . Fit the filler
cap.
5 Place the liquidiser onto the power unit and turn to lock .
6 Select a speed or use the pulse control.
h nts
●When making mayonnaise, put all the ingredients, except the oil
into the liquidiser. Then with the machine running, pour the oil into
the filler cap and let it run through.
●Thick mixtures, eg pates and dips, may need scraping down. If
it’s difficult to process, add more liquid.
●When crushing ice use the pulse in short bursts.
mportant
●Allow all l qu ds to cool to room temperature before
plac ng them n the l qu d ser.
●To ensure the long life of your liquidiser, never run it for longer
than 60 seconds. Switch off as soon as you’ve got the right
consistency.
●Don’t process spices - they may damage the plastic.
●The machine won’t work if the liquidiser is fitted incorrectly.
●Don’t put dry ingredients into the liquidiser before switching on. If
necessary, cut them into pieces; remove the filler cap; then with
the machine running, drop them through one by one.
●Don’t use the liquidiser as a storage container. Keep it empty
before and after use.
●Never blend more than 1.2 litres - less for frothy liquids like
milkshakes.
choosing a speed for all functions
tool/attachment funct on speed
knife blade Cake making 1 – 2
Rubbing fat into flour 2
Adding water to combine
pastry ingredients 1 – 2
Chopping/pureeing/pâtés 2
Yeasted dough mixes 2
Thick soup mixes (500mls liquid 1
to 500g dry ingredients)
Thinner soup mixes/ milk
(max 600mls) 1 – 2
emulsifying tool Egg whites 2
/ whisk Cream (max 250mls) 1 - 2
discs - slicing/ Firm food items such as carrots,
shredding hard cheeses 2
Softer items such as
cucumbers, tomatoes 1
liquidiser All processing 2
max mum capac t es
●Shortcrust pastry Flour wt 250g/9oz
●Yeast dough Flour wt 340g/12oz
●One Stage Cake Total wt 1Kg/2lb 4oz
●Chopping lean meat Total wt 400g/14oz
●Thick soup mixes 1 litre
Thinner soup mix/milk 600mls
●Whisk egg white 6
●Liquidiser 1.2 litres
using the attachments
see chart for speed of each attachment.
knife blade
The knife blade is the most versatile of all the attachments. The
length of the processing time will determine the texture achieved.
For coarser textures use the pulse control.
Use the knife blade for cake and pastry making, chopping raw
and cooked meat, vegetables, nuts, pate, dips, pureeing soups
and to also make crumbs from biscuits and bread.
It can also be used for yeasted dough mixes.
h nts
kn fe blade
●Cut food such as meat, bread, vegetables into cubes
approximately 2cm/3/4in before processing.
●Biscuits should be broken into pieces and added down the feed
tube whilst the machine is running.
●When making pastry use fat straight from the fridge cut into
2cm/3/4in.cubes.
●Take care not to over-process.
dough
●Place the dry ingredients in the bowl and add the liquid down the
feed tube whilst the machine is running. Process until a smooth
elastic ball of dough is formed this will take 60 secs.
●Re-knead by hand only. Re-kneading in the bowl is not
recommended as it may cause the processor to become
unstable.
3

 emulsifying tool / whisk
Use for egg whites and cream only.
h nts
●Best results are obtained when the eggs are at room
temperature.
●Ensure the bowl and whisk are clean and free from grease before
whisking.
 slicing/shredding discs
To use the discs.
revers ble sl c ng/shredd ng d scs - th ck
Use the shredding side for cheese, carrots, potatoes and foods
of a similar texture.
Use the slicing side for cheese, carrots, potatoes, cabbage,
cucumber, courgette, beetroot and onions.
safety
●Never remove the l d unt l the cutt ng d sc has
completely stopped.
●Handle the cutt ng d scs w th care - they are
extremely sharp
to use the cutting discs
1 Fit the drive shaft and bowl onto the power unit.
2 Holding by the centre grip, place the disc onto the drive shaft with
the appropriate side uppermost.
3 Fit the lid.
4 Put the food in the feed tube.
5 Switch on and push down evenly with the pusher - never put
your f ngers n the feed tube.
h nts
●Use fresh ingredients
●Don’t cut food too small. Fill the width of the feed tube fairly full.
This prevents the food from slipping sideways during processing.
●Food placed upright comes out shorter than food placed
horizontal.
●There will always be a small amount of waste on the disc or in
the bowl after processing.
care & cleaning
●Always switch off and unplug before cleaning.
●Handle the blades and cutting discs with care - they are
extremely sharp.
●Some foods may discolour the plastic. This is perfectly normal
and won’t harm the plastic or affect the flavour of your food. Rub
with a cloth dipped in vegetable oil to remove the discolouration.
power un t
●Wipe with a damp cloth, then dry. Ensure that the interlock area
is clear of food debris.
●Store excess cord in the storage area at the back of the machine .
l qu d ser
1 Empty the jug before unscrewing it from the blade unit.
2 Wash the jug by hand.
3 Remove and wash the sealing ring.
4 Don’t touch the sharp blades - brush them clean using hot
soapy water, then rinse thoroughly under the tap. Don’t
mmerse the blade un t n water.
5 Leave to dry upside down.
bowl/l d and attachments
●Wash by hand, then dry.
●Alternatively they can be washed on the top rack of your
dishwasher. A short low temperature program is recommended.
service & customer care
●If the cord is damaged it must, for safety reasons, be replaced
by Kenwood or an authorised Kenwood repairer.
UK
If you need help with:
●Using your appliance
●Servicing or repairs (in or out of guarantee)
call Kenwood on 023 92392333 and ask for customer care.
Have your model number ready - it’s on the underside of
the processor.
●spares and attachments
call 0 70 2413653.
other countr es
Contact the shop where you brought the food processor.
●Designed and engineered by Kenwood in the UK.
●Made in China.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL
OF THE PRODUCT IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as
urban waste.
It must be taken to a special local authority differentiated waste
collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials
to be recovered to obtain significant savings in energy and
resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
guarantee UK only
If your food processor goes wrong within one year from the date
you bought it, we will repair it (or replace it if necessary) free of
charge provided:
●you have not misused, neglected, or damaged it;
●it has not been modified (unless by Kenwood);
●it is not second hand;
●it has not been used commercially;
●you have not fitted a plug incorrectly; and
●you supply your rece pt to show when you bought t.
This guarantee does not affect your statutory rights.
4

Head Office Address:
Kenwood Limited, New Lane, Havant, Hampshire PO9 2NH, UK
www.kenwoodworld.com
Designed and engineered by Kenwood in the UK
Made in China 192 4/2
