Sencor STM 6350WH User manual

05/2017
- 1 -
Copyright © 2017, Fast ČR, a.s.
EN Food Processor
STM 6350 WH / STM 6351GR / STM 6352BL
STM 6353 OR / STM 6354RD / STM 6355VT
STM 6356 YL / STM 6357 GG / STM 6358RS

05/2017
- 2 -
Copyright © 2017, Fast ČR, a.s.
EN Food Processor
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■This appliance may be used by persons with physical or mental impairments or
by inexperienced persons, if they are properly supervised or have been informed
about how to use the appliance in asafe manner and understand the potential
dangers.
■Children must not use this appliance or play with it. Keep this appliance and the
power cord out of reach of children.
■Before connecting this appliance to apower socket, make sure the rated voltage
stated on its rating label corresponds to the voltage in your power socket.
■Never use accessories, which have not been supplied with this appliance or which
have not been explicitly recommended by the manufacturer for this type of
appliance.
■This appliance is designed for household use. Do not use it for commercial
purposes, in industrial surroundings, or outdoors, or for purposes other than those
for which it is intended.
■Always place the appliance on an even, dry and stable surface. Do not place it
on an electric or gas stove, in the vicinity of an open ame or appliances that are
sources of heat.
Do not put your hands into an area marked by this symbol. Otherwise injury
could result when the multi-function head is tilted out and is not properly
locked in the top position.
■Never use multiple attachments at the same time.
■Before putting the appliance into operation, check that it is correctly assembled
and that the multi-function head is tilted down in the horizontal position. For
safety reasons, this appliance is equipped with asafety mechanism that prevents
the motor from being started when the multi-function head is tilted out.
■In the event that the multi-function head tilts out during operation, the appliance
will automatically stop running. When the multi-function head is tilted to
the horizontal working position, the appliance will not automatically resume
operation. To resume operation, it is necessary to set the speed control knob to
the OFF position and then re-select the desired speed.
■Do not touch rotating parts of the appliance and ensure that foreign items such as
clothing, hair, etc. are kept away. An injury could occur or the appliance could be
damaged.

05/2017
- 3 -
Copyright © 2017, Fast ČR, a.s.
■In the event that an item, such as aspoon, falls into the bowl during operation,
immediately set the speed control knob to the OFF position (stand-by mode), and
disconnect the power cord from the power socket. Wait until the rotating parts
come to astop and then remove the item.
■If ingredients stick to the attachment or the sides of the bowl, turn the appliance
o, disconnect it from the power socket, and wait until the rotating parts come to
astop. Use asilicone spatula to clean the attachment and the inside of the bowl.
Then you can restart the appliance.
■Make sure that no hair, clothing or other items enter the feed tube of meat grinder
while it is running. Do not put anything other than the ingredients that are to be
processed into the feed tube.
■Never use your ngers or other items to push ingredients through the meat grinder
feed tube. For this purpose there is apusher included as an accessory.
Warning:
Incorrect use may lead to injuries.
■To prevent injury caused by sharp edges, be especially careful when handling
the grinding blade of the meat grinder and the blade assembly of the blender.
Increased attention must also be paid when emptying out the blending jar, when
removing the blade assembly from the blending jar, when removing the grinding
blade from the chamber, and when cleaning the appliance.
■Do not attempt to grind bones, nut shells or other hard ingredients.
■Hot liquids up to atemperature of 80 °C may be processed in the blending
jar. Be especially careful when handling hot liquids. Hot steam or splashing hot
foods and liquids may cause scalding. Never start the blender without the lid
properly seated in position. When processing hot liquids, do not remove the inner
cap during operation. Do not touch the hot surface. Use the handle to carry the
blending jar when it is hot.
■The maximum continuous operating time is 10 minutes. Do not exceed the
maximum operating time of 5 minutes when in the kneading mode and do not
exceed the maximum operating time of 2 minutes when using the blender. Before
starting it again, allow the appliance to cool down for 30 minutes.
■Always turn o the appliance, disconnect it from the power socket when
not be using it, when leaving it without supervision, and before assembling,
disassembling, cleaning or moving it. Prior to disassembling the appliance and
replacing accessories or accessible parts that move during use, wait until all
moving parts come to astop.
■Clean it according to the instructions in chapter Cleaning and maintenance.
■Never wash the appliance under running water or submerge it in water or another
liquid.

05/2017
- 4 -
Copyright © 2017, Fast ČR, a.s.
■Do not turn on the appliance when it is empty. Incorrect use of the appliance may
negatively aect its lifetime.
■Ensure that the power plug contacts do not come into contact with water or
moisture. Do not place heavy items on the power cord. Make sure that the power
cord does not hang over the edge of atable or that it is not touching ahot surface.
■Disconnect the power cord from the power socket by pulling on the plug, never
pulling on the cord. Otherwise, this could damage the power cord or the socket.
■If the power cord is damaged, have it replaced at aprofessional service centre. It is
forbidden to use the appliance if it has adamaged power cord.
■To avoid the danger of injury by electrical shock, do not repair the appliance
yourself or make any adjustments to it. Have all repairs performed at an authorised
service centre. By tampering with the appliance, you risk voiding your legal rights
arising from unsatisfactory performance or quality warranty.

05/2017
- 5 -
Copyright © 2017, Fast ČR, a.s.
A
1
2
3
11
10
9
7
6
12
14
8
15
4
513

05/2017
- 6 -
Copyright © 2017, Fast ČR, a.s.
B
1
2
3
4
5
6
7
8
9
14
13
12
11
10
15
16
1
4
3
5
6
C
2

05/2017
- 7 -
Copyright © 2017, Fast ČR, a.s.
EN Food Processor
User'smanual
■ Prior to using this appliance, please read the user’s manual thoroughly, even if you
already have experience in using simi
lar appl iances. Only use the appliance in the manner
described in this user’smanual. Keep this user’smanual in asafe place where it can be
easily retrieved for future use.
■ We recommend saving the original cardboard box, packaging material, purchase receipt
and responsibility statement of the vendor or warranty card for at least the duration of
the legal liability for unsatisfactory performance or quality. In the event of transportation,
we recommend that you pack the appliance in the original box from the manufacturer.
DESCRIPTION OF THE APPLIANCE AND ACCESSORIES
A1 Button for releasing the meat grinder
from the front attachment hub
A2 Removable cover of the front meat
grinder attachment hub
A3 A-shaped beater
A4 Balloon whisk
A5 Kneading hook
A6 Removable cover of the top blender
attachment hub
A7 Tilt-out multi-function head
A8 Attachment hub for mounting
attachments A3–A5
A9 Bowl cover with ahole for adding
ingredients
A10 4.5-litre stainless steel bowl
A11 Base unit
A12 Speed control knob
Serves to gradually set the speed level
MIN-1-2-3-4-5-6-MAX, set the pulse
level (PULSE) and to turning off the
appliance (OFF).
A13 Multi-function head release lock
A14 Anti-slip feet for stability of the
appliance during operation
A15 Lid
serves to close the stainless steel
bowl A10 for short term storage of
processed ingredients.
DESCRIPTION OF MEAT GRINDER ACCESSORIES
B1 Pusher
B2 Stainless steel hopper
B3 Feed tube
B4 Grinding chamber
B5 Screw shaft
B6 Grinding blade
B7 Screw ring
B8 Fine grinding plate
B9 Medium fine grinding plate
B10 Coarse grinding plate
B11 Separator
B12 Sausage stuffer attachment
B13 Moulder
B14 Conical attachment
B15 Cookie maker
B16 Cookie maker holder
Note:
Parts B11–B14 are contained inside the pusher B1.
Certain models are only equipped with ane and coarse grinding disc B8 and
B10.
DESCRIPTION OF THE BLENDER ACCESSORIES
C1 Inner cap of the blending jar
C2 Outer lid of the blending jar with
ahole for adding ingredients
C3 Handle
C4 Glass blending jar with 1.5l capacity
C5 Cu
C6 Blade assembly
BEFORE FIRST USE
1. Take the appliance and its accessories out of the packaging materials.
2. Thoroughly wash all accessory parts that are intended to come into contact with food
using warm water and aneutral kitchen detergent. Then rinse under clean running water
and thoroughly wipe dry with ane wiping cloth or allow them to dry naturally. After
washing and drying, we recommend to coat the grinding blade B6 and the grinding
plates B8–B10 with cooking oil.
3. Do not submerge the food processor or its power cord in water or any other liquids.
Attention:
The metal parts of the meat grinder and attachments A3–A5 are not
intended for
washing in adishwasher. Other removable parts may be washed in adishwasher.
BEATING, WHIPPING AND KNEADING
SELECTING ATTACHMENT TYPES
Attachment type Purpose of use
Beater A3 It is used for beating light and medium heavy yeast-free doughs, for
preparing sauces, creams, llings, etc. Do not use it for kneading
heavy doughs.
Balloon whisk A4 It is used for whisking whole eggs or egg whites, whipped cream,
foamy creams, etc.
Do not use it for beating or kneading doughs.
Kneading hook A5 It is used for kneading various types of doughs including heavy and
thick doughs such as for example bread dough, pizza dough, fresh
pastry doughs, etc.
ASSEMBLING AND DISASSEMBLING THE FOOD PROCESSOR
■ Before you start assembling or disassembling the food processor, check that it is turned
o and disconnected from the el. power socket.
1. Inserting the bowl and attaching the cover
1.1 Place the food processor on an even, dry and stable surface, for example on akitchen
countertop.
1.2 Use the lock A13 to release the multi-function head A7 and tilt it out all the way. After
tilting out the multi-function head A7 release the lock A13. Locking of the multi-function
head A7 inthe top open position is indicated by the lock A13 returning to the default
position, which is accompanied by an audible click.
1.3 Insert the stainless steel bowl A10 into the base unit A11 and secure it in place by turning
it clockwise. When the bowl A10 is properly attached, it cannot be separately lifted out of
the base unit A11.
1.4 On to the bottom part of the multi-function head A7 with attachment hub A8, slide the
cover A9 so that the latches along the perimeter of the round opening in the cover A9
slide into the grooves along the perimeter of the attachment hub A8.
1.5 The lid A15 is used for covering the bowl A10 for short term storage of processed
ingredients.
2. Mounting attachments
2.1 When attaching an attachment, the multi-function head A7 must be locked in the
open position, see point 1.2 in the previous chapter. To attachment hub A8, attach
one of the attachments A3–A5 in such away that the attachment hub shaft A8 slides
into the attachment. Push the attachment towards the attachment hub A8 and turn it
anticlockwise to secure it in place. Lightly pull the attachment downwards with one hand
to check that it is properly attached.
2.2 Place the ingredients that you wish to process into the bowl A10. Release the lock A13
and tilt the multi-function head A7 to ahorizontal position. After tilting down the multi-
function head A7, release the lock A13. The locked status of the multi-function head A7
in the tilted down work position is indicated by the lock A13 returning to the default
position. This is accompanied by an audible click.
3. Disassembly
3.1 Use the lock A13 to release the multi-function head A7 and tilt it out all the way. After
tilting out the multi-function head A7, release the lock A13. Locking of the multi-
function head A7 inthe top open position is indicated by the lock A13 returning to the
default position, which is accompanied by an audible click.
3.2 Push the attachment towards the attachment hubA8 andturn it clockwise to release it,
and then remove it. Turn the bowl A10 anticlockwise and remove it from the base unit
A11. Remove the cover A9 by pulling it downwards. Move the multi-function head A7
back to the horizontal position.
USING THE FOOD PROCESSOR
1. Select the right type of attachment based on its intended use and assemble the
appliance according to the instructions in the chapter Assembling and disassembling
the appliance. Place the ingredients into the bowl A10.
Attention:
In asingle batch, it is possible to precess no more than 2.2 litres of light dough or
0.8 litres of thick, heavy dough. The maximum number of egg whites that can be
whisked at once is 12. We recommend that you do not ll the bowl A10 past the
level of the 3l mark. If an insucient amount of ingredients are put in the bowl
A10 (less than 0.3 litres of dough), then they may not be optimally processed.
2. Make sure that the multi-function head A7 is tilted down in the horizontal working
position and that the speed control knob A12 is set to the OFF position. Connect the
power cord to apower socket.
3. Set the required speed using the speed control knob A12. Gradually turn the speed
control knob A12 clockwise to increase the speed, turning it in the opposite direction will
reduce the speed.To initially stir in the ingredients, rst set alower speed and then adjust
it as required. Electronic speed regulation ensures that the set speed will be maintained
under various loads. While it is running, ingredients may be added into the bowl A10
through the hole in the cover A9.
4. The pulse mode is used for increasing the speed to maximum for ashort time. To activate
the pulse mode, turn the speed control knob A12 to the PULSE position and to ensure
continuous operation hold it down in this position. As soon as you release the speed
control knob A12, it will automatically return to the OFF position.
5. If it is necessary to wipe ingredients o the inside of the mixing bowl A10 and the
attachment, rst turn o the food processor by setting the speed control knob A12 to
the OFF position and then disconnect it from the power socket. Wait until the rotating
parts come to astop and only then scrape away the ingredients with aspatula.
6. After you have nished using the appliance, set the speed control knob A12 to the OFF
position and disconnect the power cord from the power socket.
7. Wait until the rotating parts come to astop and disassemble the food mixer according
to the instructions included in chapter Assembling and disassembling the appliance. Use
asoft plastic spatula to empty out the contents of the bowl A10.
8. Clean out the food processor after each use according to the instructions in chapter
Cleaning and maintenance.
LED LIGHT
■ The multi-function head A7 has a LED light that turns on automatically when the food
processor is connected to a power socket. The LED light turns o automatically after
2.5 minutes of inactivity, i.e. when the appliance is not running or when the speed is not
set during this time. The LED light turns on again automatically when the food processor
is put into operation by the control knob A12 being set to a desired speed level.

05/2017
- 8 -
Copyright © 2017, Fast ČR, a.s.
QUICK GUIDE TO PROCESSING INGREDIENTS
Attachment type Ingredients Maximum
load
Processing
time
Speed
selection
Balloon whisk A4 Egg whites 12 pcs 4 min 5–6
Balloon whisk A4 Whipping cream 1l 6–8 min 5–6
Beater A3 Cake dough 2.2l 6 min 3–4
Kneading hook A5 Bread dough
Pizza dough
0.8l 4–5 min MIN to 2
Note:
The above processing times are only areference.
When whipping egg whites, the bowl A10 and the beater A4 must be perfectly
clean and dry. Even a small amount of fat may cause the egg whites not be
whipped to the desired snowy consistency.
Whipping cream should be cooled to a temperature of 6 °C prior to being
whipped.
Prior to processing them, allow the ingredients used for making various doughs
to rest at room temperature.
GRINDING MEAT, MAKING SAUSAGES AND KEBABS, AND
MAKING COOKIES
ASSEMBLING AND DISASSEMBLING THE MEAT GRINDER
1. Insert the screw shaft B5 into the grinding chamber B4 with the cogged wheel entering
rst.
2. Place the grinding blade B6 on to the shaft B5 (with the edge facing outwards from the
chamber) and on to it attach agrinding plate B8, B9 or B10 depending on the preferred
the grind. Make sure that the notch in the grinding chamber B4 slides into the groove in
the grinding plate.
Attention:
When attaching the blade B6 , be very careful not to injure yourself on the
sharp edge.
3. Place the screw ring B7 on to the grinding chamber B4 and tighten it securely by
screwing it clockwise. Place the stainless steel hopper B2 on to the feed tube B3.
4. Make sure that the food processor is turned o and disconnected from the power socket.
The multi-function head A7 must be tilted down in the horizontal position and the whisk,
beater or kneading attachments must be removed. Remove the front cover A2 from the
multi-function head A7. Place the assembled attachment against the attachment hub
so that the feed tube B3 is tilted to the right at an angle of approximately 45° from the
vertical axis and secure the attachment in vertical position by turning it anticlockwise.
The attachment is locked in place when the button A1 slides out.This is accompanied by
an audible click.
5. When disassembling the meat grinder, rst remove the hopper B2.Then press the button
A1 and remove the meat grinder by turning it clockwise. After removing the grinder, put
the cover A2 back in its place.
6. When disassembling the meat grinder into its individual parts, proceed in the reverse
sequence.
USING THE MEAT GRINDER
1. First prepare the meat for grinding in the following way. Remove all bones, tendons,
cartilage and cut the meat into 2 × 2 × 6 cm size pieces that will freely pass through the
feed tube B3.
Attention:
Do not process frozen meat. Allow it to defrost before grinding it.
2. Make sure that the food processor is correctly assembled and that the speed control
knob A12 is set to the OFF position.
3. Place the bowl A10 or another suitable container under the meat grinder. Insert the
power plug into apower socket.
4. Use the speed control knob to set the desired speed.We recommend to initially set speed
3 and then increase it as required. Gradually place the meat pieces into the feed tube
B3 and push them in using the pusher B1. Take care not to clog up the feed tube B3 by
alarge amount of meat. Do not process more than 5 kg of meat per batch.The processing
time is only several minutes.
Attention:
Do not use ngers or other items to push the meat in. Always use the pusher B1
designed for this purpose.
5. The ground meat will fall into the prepared bowl. The meat that remains in the grinding
chamber B4 can be removed by grinding aslice of bread or abread roll.
6. To turn o the food processor, set the speed control knob A12 to the OFF position.
7. Clean out the meat grinder after each use according to the instructions in chapter
Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE SAUSAGE STUFFER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the dierence
that instead of the grinding blade B6 and the grinding plate B8, B9 or B10, only parts
B11 aB12 are used.
2. Place the separator B11 on to the screw shaft so that the notch in the grinding chamber
B4 ts into the groove in the separator B11. Place the sausage stuer attachment B12 on
to the separator B11 and complete the entire sausage stuer assembly by screwing the
screw ring B7 on to the grinding chamber B4. Place the stainless steel hopper B2 on to
the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point 4 in
chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and remove
the attachment by turning it clockwise. After removing the attachment, put the cover A2
back in its place.
5. When disassembling the attachment into its individual parts, proceed in the reverse
sequence.
USING THE SAUSAGE STUFFER ATTACHMENT
1. Make sure that the food processor is correctly assembled and that the speed control
knob A12 is set to the OFF position. Insert the power plug into apower socket.
2. Prepare asausage casing that you will stu with ground meat and allow it to soak in
lukewarm water for approx. 10 minutes. Place the ground meat mixture on to the hopper
B2. Take the sausage casing out of the water and skewer or tie up one end and slide the
other end like asock on to the sausage stuer attachment B12.
3. Use the speed control knob A12 to set the desired speed. We recommend to initially set
the lowest speed and then increase it as required. With one hand hold the sausage casing
on the attachment B12 and use the other hand to push the ground meat mixture with
the pusher B1 through the feed tube B3. If the sausage casing sticks to the attachment
B12, it is necessary to moisten it with water again.
Attention:
Do not use ngers or other items to push the ground meat in. Always use the
pusher B1 designed for this purpose.
4. To turn o the appliance, set the speed control knob A12 to the OFF position.
5. Clean out the individual parts of the attachment after each use according to the
instructions in chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE KEBAB MAKER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the dierence
that instead of the grinding blade B6 and the grinding plate B8, B9 or B10, only parts
B13 aB14 are used.
2. Place the moulder B13 on to the screw shaft B5 so that the notch in the grinding chamber
B4 ts into the groove in the moulder B13. Place the kebab moulder attachment B13
on to the conical attachment B14 and complete the entire kebab maker assembly by
screwing the screw ring B7 on to the grinding chamber B4. Place the stainless steel
hopper B2 on to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point 4 in
chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and remove
the attachment by turning it clockwise. After removing the attachment, put the cover A2
back in its place.
5. When disassembling the attachment into its individual parts, proceed in the reverse
sequence.
USING THE KEBAB MAKER ATTACHMENT
1. Make sure that the food processor is correctly assembled and that the speed control
knob A12 is set to the OFF position. Insert the power plug into apower socket.
2. Place the prepared kebab meat mixture on to the hopper B2. Use the speed control knob
A12 to set the desired speed. We recommend to initially set the lowest speed and then
increase it as required. Using the pusher B1, push the mixture through the feed tube
B3. The result will be ahollow meat tube that is then cut into smaller pieces. The kebab
is atraditional meal from the Middle East made predominantly from ground meat and
whole grain wheat.
Attention:
Do not use ngers or other items to push the ground meat in. Always use the
pusher B1 designed for this purpose.
3. To turn o the appliance, set the speed control knob A12 to the OFF position.
4. Clean out the individual parts of the attachment after each use according to the
instructions in chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE COOKIE MAKER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the dierence
that instead of the grinding blade B6 and the grinding plate B8, B9 or B10 only parts
B11,B15 and B16 are used.
2. Place the separator B11 on to the screw shaft so that the notch in the grinding chamber
B4 ts into the groove in the separator B11. Insert the cookie maker holder B16 into
the screw ring B7. Screw the screw ring B7 clockwise on to the grinding chamber B4.
Complete the assembly by inserting the cookie maker B15 into the holder B16 and
attaching the hopper B2 to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point 4 in
chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and remove
the attachment by turning it clockwise. After removing the attachment, put the cover A2
back in its place.
5. When disassembling the attachment into its individual parts, proceed in the reverse
sequence.

05/2017
- 9 -
Copyright © 2017, Fast ČR, a.s.
USING THE COOKIE MAKER ATTACHMENT
1. Place the prepared dough on to the hopper B2. Slide the cookie maker B15 to the left or
right to set the desired cookie shape.
2. Insert the power plug into a power socket. Set the required speed using the speed
control knob A12. When starting it for the rst time, we recommend that you set speed 3
and then increase or decrease it as required.
3. Use the pusher B1 to push the dough through the feed tube B3. The food processor will
push the dough out in the required shape that you set using the cookie maker B15.
We recommend that you place atray or your palm underneath the pushed out dough.
Then cut the formed dough into smaller pieces.
Attention:
Do not use ngers or other items to push the dough in. Always use the pusher B1.
4. When you have nished using the food processor, turn it o by setting the speed control
knob A12 to the OFF position.
5. Clean out the attachment after each use according to the instructions in chapter
Cleaning and maintenance.
BLENDING
ASSEMBLING AND DISASSEMBLING THE BLENDER
1. From underneath, insert the blade assembly C6 into the blending jar C4 and screw it in
clockwise all the way.
2. On to the blending jar C4, place the outer lid C2 so that its edges copy the neck of the jar,
and push it down thoroughly along its entire perimeter. Into the hole in the lid C2, place
the inner cap C1 and push it down all the way.
Note:
Do not remove the cu C5 from the blending jar C4.
3. Make sure that the food processor is turned o and disconnected from the power
socket. The multi-function head A7 must be tilted down in the horizontal position and
the whisk, beater or kneading attachments must be removed. Release and remove the
top attachment hub cover A6. Place the assembled blending jar on to the top hub and
pulling it gently turn it in the direction of the symbol all the way. The safety mechanism
will prevent the blender from starting unless it is correctly secured to the multi-function
head A7.
4. To disassemble proceed in the reverse sequence.
USING THE BLENDER
1. The blender is intended for preparing meals and drinks such as milkshakes, creamy
soups, sauces, spreads, fresh baby foods, etc. It is not intended for juicing fruit and
vegetables, preparing potato purée, yeast dough or for whipping egg whites.
2. Assemble the blender according to the instructions in chapter Assembling and
disassembling the blender, and put the ingredients (larger pieces need to be cut up in
advance) into the blending jar C4.
Note:
The maximum capacity of the blending jar C4 is 1.5 litres. Never ll it past the
maximum mark. When processing hot liquids or liquids that expand in volume
during the blending process, it is recommended to ll the blending jar to no more
than ⅔ of its maximum capacity.
3. Make sure that the food processor is correctly assembled and that the speed control
knob A12 is set to the OFF position. Connect the power cord to apower socket. Set the
required speed using the speed control knob A12. We recommend to rst set aslower
speed to allow the ingredients to mix together. Then the speed may be increased.
The pulse level is appropriate when you wish to blend food only very quickly. To start
the pulse level, turn the speed control knob A12 to the PULSE position and hold it in
this position for amoment. As soon as you release the speed control knob A12, it will
automatically return to the OFF position.
Attention:
The maximum operating time of the blender is 2 minutes. Do not leave the
appliance in continuous operation for longer than indicated above. Then allow it
to cool down for 30 minutes.
4. While blending, you may add food or liquids to the blending jar C4 through the hole in
the lid C2 after removing the inner cap C1. Never open the outer lid C2 during operation.
When processing hot liquids, the inner cap C1 must remain closed.
5. In the event that food is sticking to the blade assembly C6 or the walls of the blending jar
C4, turn the appliance o by turning the speed control knob A12 to the OFF position and
disconnect it from the power socket. Make sure that the blade assembly C6 has stopped
rotating. Carefully remove the assembled blending jar from the multi-function head A7
by turning it in the direction of the symbol . Take o the lid and using aplastic spatula,
clean the blade assembly C6 and the inside of the blending jar C4. Put the lid back on and
reattach the blender assembly to the multi-function head A7. Plug the power cord into
apower socket and continue blending.
6. After you have nished using the appliance, set the speed control knob A12 to the OFF
position and disconnect the power cord from the power socket. Check that the blade
assembly C6 has stopped rotating and carefully take the blending jar assembly o the
multi-function head A7. Put the cover A6 back in its place and use asoft plastic spatula
to remove food from the blending jar C4.
7. Disassemble the assembled bowl and clean the individual parts after each use according
to the instructions in chapter Cleaning and maintenance.
ADVICE AND TIPS FOR BLENDING
■ First cut food with arm consistency such as fruit and vegetables into smaller pieces
measuring 3 cm and only then blend it.
■ First, blend asmaller amount of ingredients and then gradually add more ingredients
through the hole in the lid C2 while blending. In this way, you will achieve better results
than by adding all ingredients into the blending jar C4 at once.
■ If you need to blend food of asolid consistency together with liquids, we recommend
that you rst blend the food of solid consistency and apart of the liquids. Then gradually
add the remaining liquids through the hole in the lid C2 while blending.
■ To blend very thick liquids, we recommend using the pulse level so that the blade
assembly C6 does not get jammed too often. Start the blender repeatedly in short
intervals.
■ Ice cubes must be processed immediately upon being removed from the freezer. When
the ice starts to melt, the ice cubes will stick together and it will not be possible to blend
them.
QUICK GUIDE TO PROCESSING INGREDIENTS
Ingredients Speed selection Recommended
blending time
Fruit, vegetables cut into smaller pieces 5–6 30 s
Baby food 5–6 40 s
Spreads, dressings, marinades 3–4 30 s
Smoothies and cocktails 6 to MAX 40 s
Soups 6 to MAX 30 s
Ice cubes PULSE
Note:
The above food processing times are only areference. The actual blending time
depends on the size of the ingredients, their amount and the required nal
consistency.
CLEANING AND MAINTENANCE
■ Before cleaning the food processor, always switch it o by setting the speed control knob
A12 to the OFF position and disconnect it from the power socket.
■ Disassemble the food processor into its individual parts. Wait until moving parts come to
acomplete stop before disassembly.
■ Thoroughly wash the used removable parts after every use using warm water with
aneutral dishwashing detergent. Then rinse them under clean running water and wipe
them dry with a ne wiping cloth or allow them to dry naturally. After washing and
drying, we recommend to coat the grinding blade B6 and the grinding plates B8, B9
andB10 with cooking oil.
■ If you whisked egg whites, rst rinse the bowl A10 and the beater A4 under cold water. If
you were to use hot water, the egg white remains would harden and their removal would
be more dicult.
■ The metal parts of the meat grinder and attachments A3–A5 are not intended for
washing in adishwasher. Other removable parts may be washed in adishwasher.
■ For cleaning the base unit A11 and the multi-function head A7, use acloth lightly dipped
in aweak detergent solution. Then wipe everything with aclean dampened cloth and
thoroughly wipe dry.
■ For cleaning, do not use solvents or cleaning agents with abrasive eects. Otherwise, the
surface of the appliance may be damaged.
■ Do not submerge the food processor or its power cord in water or any other liquids.
STORAGE
■ When not using the food processor, store it in aclean, dry place out of children’sreach.
Make sure that the multi-function head A7 is tilted down into the horizontal position.
TECHNICAL SPECIFICATIONS
Rated voltage range.........................................................................................................................220−240 V
Rated frequency.................................................................................................................................... 50/60 Hz
Rated power input................................................................................................................................. 1 000 W
Electrical shock protection class.....................................................................................................................II
Noise level................................................................................................................................................ 85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which represents alevel Aof
acoustic power with respect to areference acoustic power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-duty insulation.

05/2017
- 10 -
Copyright © 2017, Fast ČR, a.s.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on products or original documents means that used electric or
electronic products must not be added to ordinary municipal waste. For
proper disposal, renewal and recycling hand over these appliances to
determined collection points. Alternatively, in some European Union states
or other European countries you may return your appliances to the local
retailer when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural resources and
prevents potential negative eects on the environment and human health,
which could result from improper waste disposal. Ask your local authorities
or collection facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect disposal
of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier for the
necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product, request
the necessary information about the correct disposal method from the local council or from
your retailer.
This product meets all the basic requirements of EU directives related to it.
