Redmond FC-J18 User manual

FC001
Model: FC-J18

Safety Instruction
Suggestion
-Please read the instruction carefully before using the machine
at the first time.
-In the absence of supervision , put the machine far away from
the children.Young children and the disability must use it under
supervision.
-Please check the rated voltage of the machine is in accor-
dance with the household supply voltage.
Any connection error will make warranty null and void.
-Your appliance is only suitable for using indoors.
-Please pull the plug,and then washing the machine after use.
-If the machine is damaged or does not work,please contact the
service center.
Do not immerse electrical appliances,wires and plugs into
water or other liquids.
-Do not hang wires in a place where children can reach them.
-The power cord must be kept away from the heat source and
sharp edges.
-For your safety,ONLY USE the parts we have equipped with the
machine.
Do not use your fingers,and there is no fork,spoon,knife or any
other tableware.
-The attachment can be removed when the appliance has a
complete stop.

Do not put any kitchen ware(spoon,shovel,...) into the glass
bowl.
Accessories should be used in turn.
Handle the metal blade and disk carefully: they are very sharp.
The blade must be removed before emptying the residue of the
glass.
Do not touch parts when moving.
Do not operate your electric machine at no load.
If the power cord is damaged, it must be replaced by the manu-
facturer,its service agent or similar person to avoid danger.
This appliance is not intended to be used by the persons(in-
cluding children) who is reduce physical, sensory or mental
abilities, or lack of experience and knowledge unless they have
been responsible for the supervision or guidance of the use of
the appliance for their safety.
Children should be supervised to ensure that they do not play
with electrical machine.
To disconnect the power adapter if no one is assembling,
disassembling or cleaning.
Children are not allowed to use unsupervised equipment.
Handle blade, glass should be careful when cleaning.
Rated voltage:120V, 60Hz Rated power:350W

Garlic peeler
Button 2
Button 1
Host
Glass bowl cover
Deputy mincing blade
Main mincing blade
Glass bowl 2.0L
Non-slip mat

Maximum capacity and working time
Pork and meat: Max 500 g
The maximum amount of prepared food such as pork, meat,
steak, etc. is 500 g with operation time of 30 seconds, and each
interval of using time is about 2 minutes.Then keep the
machine at room temperature.
Use appliance
1.Put the anti-skid pad on the bottom of the glass.
2.Place the glass on a flat platform.
3.Remove the protective sleeve of the blade and insert the
blade assembly in the glass bowl.
4.Add your food, and choose the range of food,please attention
to the guidance.
5.Cut large pieces of food into 1-2cm chunks.
Do not cut hard food, such as coffee beans, ice cubes, spices
or chocolate, otherwise you will damage the blade.
1.Put the lid on the glass.
2.Install host.
3.The host will match in 2 locations correctly.
4.Plug in the plug, press the button 1 or button 2 (according to
the food needs to choose the button, soft food select key 1,
hard food select key 2).
5.If the machine is running slowly, take out some of the mixture
and continue the batch processing.
6.If necessary, stop and take the machine down.
7.Pull out the plug and remove the assembly.

Use garlic peeler
1、Place the egg whisk on the glass bowl shaft
2、Place the glass on a flat platform.
3、Add the right amount of ingredient to the bowl, pay atten-
tion to the garlic rod accessories processing guide
4、place the lid on glass bowl
5、Install host,he host will match in 2 locations correctly.
6、Plug in the plug, press button 2 to start working
Clean
Disconnect the power plug from the socket.
Wipe the host with a damp cloth and dry it.
All accessories can wash:
Wash with water and detergent. Be very careful when dealing
with stainless steel blades to avoid hurting yourself.
Storage: Assemble the mincing machine, the power cord wind-
ing the host.
Processing Guide
Preparation
Max
capacity
Running
period
Caraway
(clery)
500g
250g
500g
500g
240g
30S
15S
Remove the bone ,cut the
meat to some piece size 1-2cm
Remove the skin
Nut (almond) 30-40S
15-30s
Remove the shell
Cut into 1 to 2mm chunkBread
Boiled egg 10pcs 15S
15S
A half or a quarter (depending
on the size )
Carrot (onion) Cut into 2mm size

120g 15s Breaking into squares
10-30pcs 30-45s
Break the garlic into pieces and
place in a bowl
(Remove the end of each garlic
head for better peeling)
30-50pcs 45-60s
Break the garlic into pieces and
place in a bowl
(Remove the end of each garlic
head for better peeling)
Attention ：
Do not disassemble the knife assembly and place it in the glass
optionally: the wrong operation may seriously
damage the product.
What should you do if your appliance doesn't work?
Check:
Connect.
The host is properly installed in the four position
of the glass cover.
Install correctly.
Is your appliance still not working?
Contact the service center or manufacturer.

Handle the product correctly
This sign indicates that this product should not be
treated with other domestic waste.To prevent the
endanger which to the environment and mankind’s
health caused by the uncontrolled waste treatment ,
should recycle ,promote the sustainable use of
substance resource .Recycle your used device,please
use recycle and collecting system or contact your
retailer．They can make the product safety recycle .
The second category of equipment symbol.
PRODUCT GUARANTEE
The Product Guarantee is for One year against any
manufacturing defect.
This guarantee will cover against any manufacturing
defects for twelve months from the date of original purchase.
Any misuse of the product such as accidental damage,
re-sold, wrong voltage or wrong power supply, careless use,
non-domestic use etc will not be covered under the Guarantee.
To meet the requirements for the 1-year guarantee, the product
must have been installed and used according to the
Manual book instruction.
NOTE: We intend to improve our products, so the specification
of the products is subject to modification without any notice.
