Kenwood DMX120BT User manual

• Updated information (the latest Instruction Manual, etc.) is available from
<http://www.kenwood.com/cs/ce/>..
DMX120BT
MONITOR WITH RECEIVER
INSTRUCTION MANUAL
B5A-3198-00b (E)© 2019 JVC KENWOOD Corporation
Model name indication position
See “Removing the trim plate” (P.22)
Trim plate
!B5A-3198-00_DMX.indb 1 2019/06/11 13:39

2
Before use
Before use....................................................................................2
How to read this manual.......................................................................................2
Precautions ....................................................................................................................2
Getting Started..........................................................................3
Clock settings...............................................................................................................4
Touch panel adjustment.......................................................................................4
Basics .............................................................................................5
Functions of the Buttons on the Front Panel..........................................5
Common operations...............................................................................................5
HOME screen descriptions ..................................................................................6
Source control screen descriptions ...............................................................6
List screen .......................................................................................................................6
USB .................................................................................................7
Preparation.....................................................................................................................7
Playback operations.................................................................................................7
iPod/iPhone ................................................................................9
Preparation.....................................................................................................................9
Playback operations.................................................................................................9
Mirroring ....................................................................................11
Preparation...................................................................................................................11
Mirroring operations..............................................................................................11
Radio............................................................................................12
Radio Basic Operation.......................................................................................... 12
Presetting stations ................................................................................................. 12
FM RDS features ....................................................................................................... 12
Radio Setup................................................................................................................. 13
External Components...........................................................14
Using external audio/video players............................................................ 14
Rear view camera.................................................................................................... 14
Bluetooth smartphone.........................................................15
Register your smartphone to the unit ...................................................... 15
Receive a phone call............................................................................................. 15
Make a phone call................................................................................................... 16
Playing Bluetooth Audio Device....................................................................17
Delete the registered Bluetooth device...................................................17
Controlling Audio ...................................................................18
Controlling General Audio................................................................................ 18
Equalizer Control..................................................................................................... 18
Subwoofer settings ............................................................................................... 18
Remote control........................................................................19
Functions of the Remote control Buttons.............................................. 19
Installation................................................................................ 20
Before Installation...................................................................................................20
Installing the unit.................................................................................................... 21
About this Unit........................................................................ 25
More information....................................................................................................25
Troubleshooting......................................................................................................25
Copyrights ...................................................................................................................26
Specifications ............................................................................................................ 28
Precautions
#WARNING
Ñ To prevent injury or fire, take the
following precautions
• To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools) inside
the unit.
• Do not watch or fix your eyes on the unit’s display
when you are driving for any extended period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories, check
with your KENWOOD dealer to make sure that they
work with your model and in your area.
• The Radio Data System or Radio Broadcast Data
System feature won’t work where the service is not
supported by any broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ballpoint pen or similar
tool with the sharp tip.
Ñ Cleaning the Unit
If the front panel of this unit is stained, wipe it with
a dry soft cloth such as a silicon cloth. If the front
panel is stained badly, wipe the stain off with a cloth
moistened with neutral cleaner, then wipe it again
with a clean soft dry cloth.
! CAUTION
• Applaying spray cleaner directly to the unit may affect
its mechanical parts. Wiping the front panel with a
hard cloth or using a volatile liquid such as thinner
or alcohol may scratch the surface or erase screened
print.
Ñ How to reset your unit
If the unit or the connected unit fails to operate
properly, reset the unit.
Reset button
Contents
How to read this manual
• The panels shown in this guide are examples used to
provide clear explanations of the operations. For this
reason, they may be different from the actual panels.
• In operation procedures, bracket shape indicates the
key or button you should control.
< >: indicates the name of panel buttons.
[ ]: indicates the name of touch keys.
!B5A-3198-00_DMX.indb 2 2019/06/11 13:39

3
English |
Continued on the next page...
Getting Started
1 Turn the ignition key of your car to ACC.
The unit is turned on.
2 Press the <8MENU> button.
3 Touch [Setup].
4 Touch the corresponding key and set the value.
Audio
Sound Effect
Displays the Equalizer screen. (P.18)
Beep
Activates or deactivates the key-touch tone.
“ON” (Default), “OFF”
Loudness
Sets the amounts of boost of low and high tones.
“ON”, “OFF” (Default)
Subwoofer
Displays the Subwoofer screen. (P.18)
Display
Touch
Adjust the sensing position of touch panel. See
“Touch panel adjustment” (P.4).
Display Mode
Select the screen mode.
“16:9” (Default), “4:3 Pan Scan”
Radio
Displays the Radio Settings screen. (P.13)
General
Language
Select the language used for the control screen and
setting items. Default is “English”.
1) Touch [Language].
2) Select the desired language.
* You can change the page to display more items
by pressing [ ]/ [ ].
BT Auto Connection
The unit automatically reconnect when the last
connected Bluetooth device is within range.
“ON” (Default), “OFF”
Clock Setting
Adjust the clock time. (P.4).
Default
Touch [Default] to set all the settings to the initial
default settings.
5 Touch [6].
!B5A-3198-00_DMX.indb 3 2019/06/11 13:39

4
Getting Started
Clock settings
Ñ Synchronizing the clock time with FM RDS
Activate [RDS Clock Sync]. See“Radio Setup”
(P.13).
Ñ Adjusting the clock manually
✎NOTE
• Deactivate [RDS Clock Sync] before adjusting the
clock. See “Radio Setup” (P.13).
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [General].
4 Touch [Clock Setting].
Clock screen appears.
5 Selects time format.
[12] / [24] (Default)
6 Touch [R] or [S] to set the clock time.
• If you have selected [12] as the time format, touch
[AM] or [PM] before setting the clock time.
7 Touch [6].
Touch panel adjustment
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [Display].
4 Touch [Touch].
5 Follow the instruction on the screen and touch
the center of each +.
• To cancel the touch panel adjustment, touch
[Cancel].
• If the touch position is deviated, [OK] is not
displayed. Retry from the beginning.
6 Touch [OK].
!B5A-3198-00_DMX.indb 4 2019/06/11 13:39

5
English |
Basics
Continued on the next page...
Basics
Functions of the Buttons on the Front
Panel
1
2
3
4
5
6
1Remote Sensor
• Receives the remote control signal.
28MENU
• Displays the HOME screen. (P.6)
• Pressing for 1 second turns the power off.
• When the power off, turns the power on.
3AUD
• Displays the Equalizer screen.* (P.18)
* During video file playback, you can set only the
preset equalizer curve.
* The Equalizer screen is not displayed during
picture file playback or on the list screen or
SETUP screen etc,
4+ , – (Volume)
• Adjusts volume. The volume will go up until 20
when you keep pressing [ + ].
5MUTE/ DISP OFF (Display off)
• Mutes/restores the sound.
• Pressing for 1 second turns the screen off.
When the screen is off, touch the display to turn
on the screen.
6Reset
• If the unit or the connected unit fails to operate
properly, the unit returns to factory settings when
this button is pressed.
Common operations
Ñ Turning on the power
1 Press the <8MENU> button.
✎NOTE
• If the gear is in the reverse (R) position, the power
cannot be turned on or off.
Ñ Turning off the power
1 Press and hold the <8MENU> button.
Ñ Adjusting the volume
1 Press the <+> or <–> button.
✎NOTE
• The volume will go up until 20 when you keep
pressing [ + ].
Ñ Mutes the sound
1 Press the <MUTE> button.
⿠To restore the sound, touch the button again, or
adjust the volume.
Ñ Turn off the screen
1 Press and hold the <MUTE> button.
⿠To turn on the screen, touch the display.
!B5A-3198-00_DMX.indb 5 2019/06/11 13:39

6
Basics
Continued on the next page...
HOME screen descriptions
1 Press the <8MENU> button.
HOME screen appears.
2
5
3
6
4
7
1
1Clock display
Touch to displays the Clock screen.
2Switches to the radio broadcast. (P.12)
3[USB]
Plays files on a USB device. (P.7)
[iPod]
Plays an iPod/iPhone. (P.9)
• When iPod/iPhone is connected.
[Mirroring]
Displays the Mirroring screen.(P.11)
• When android device with “Mirroring OA for
KENWOOD” application installed is connected.
4Switches to an external component connected to
the AV-IN input terminal. (P.14)
5Displays the Hands Free screen. (P.16)
6Plays a Bluetooth audio player. (P.17)
7Displays the SETUP screen. (P.3)
Source control screen descriptions
You can perform source playback operations on the
source control screen.
1
4
3
2
5
1Clock display
Touch to displays the Clock screen.
2Source name
3• appears when the Bluetooth smartphone is
connected.
• appears when the Bluetooth audio player is
connected.
• appears when the mute function is active.
(P.5)
4[DIM]
Select dimmer mode. Dim 1, Dim 2, Not dim
5Returns to previous screen.
List screen
There are some common function keys in the list
screens of most sources.
1 You can change the page to display more items
by pressing [ ]/ [ ].
!B5A-3198-00_DMX.indb 6 2019/06/11 13:39

7
English |
USB
Continued on the next page...
USB
Preparation
Ñ Connecting a USB device
1 Remove the cap of the USB terminal.
2 Connect the USB device with the USB cable.
The unit reads the device and playback starts.
Ñ To disconnect the USB device
1 Press the <8MENU> button.
2 Touch a source other than [USB].
3 Detach the USB device.
Ñ Usable USB device
This unit can play MPEG1/ MPEG2/ MPEG4/ H.264/
MKV/ WMV/ MP3/WMA/ AAC/ WAV/ FLAC/ JPEG/ BMP/
PNG files stored in a USB mass storage class device.
(P.25)
• File system: FAT16/ FAT32
• This unit can recognize a total of 9 999 files and 320
folders (a maximum of 9 999 files per folder).
• The maximum number of characters:
– Folder names : 24 characters
– File names : 24 characters
– Tag : 30 characters
✎NOTE
• When the USB device is connected to this unit, it can
be charged through the USB cable.
• Install the USB device in the place where it will not
affect safe driving.
• You cannot connect a USB device via a USB hub and
Multi Card Reader.
• Take backups of the audio files used with this unit.
The files may be erased depending on the operating
conditions of the USB device.
We shall have no compensation for any damage
arising from any erased data.
• No USB device comes with this unit. You need to
purchase a commercially available USB device.
• Cap the USB terminal whenever not using.
Playback operations
Ñ Control the music you are listening to on
the source control screen
1
6
3
2
5
4
1The jacket of the currently playing file is displayed.
2##:##:## : Song time
Play time bar : For confirmation of current playing
position
3[L] : Plays or pauses.
[E][F] : Searches the previous/next content.
Touch and hold to fast forward or fast backward.
Touch [L] to resumes normal play.
[] : Selects Repeat playback mode.
Lights off (Default): Repeats all files in the USB
device.
: Repeats the current file.
FO : Repeats all files in the current folder.
[] : Selects Random playback mode.
: Randomly plays all files.
Lights off (Default): Normal playback.
4Displays the information of the current file.
Only a file name is displayed if there is no tag
information.
5Searches file. (P.8)
6D, etc. : Playback status
: Repeat playback mode indicator
: Random playback mode indicator
Continued on the next page...
!B5A-3198-00_DMX.indb 7 2019/06/11 13:39

8
USB
Ñ Playing videos and pictures
1 When the operation buttons are not displayed on
the screen, touch the display.
3
2
1
2
4
5
1D, etc. : Playback status
: Repeat playback mode indicator
: Random playback mode indicator
##:##:## : Song time (Video file only)
Play time bar : For confirmation of current playing
position (Video file only)
2To switch the operation buttons.
3[] : You can adjust image quality in video screen.
[Brightness]: Adjusts the brightness. (00 to 12)
[Contrast]: Adjusts the contrast. (00 to 12)
[Tint]: Adjusts the tint. (00 to 12)
[Color]: Adjusts the color. (00 to 12)
[Reset]: To clear the adjustment.
[] : Select the zoom ratio.
“Off”, “x2”, “x3”, “x4”, “x5”, “1/2”, “1/3”, “1/4”
[3][2][ < ] [ > ] : Scrolls the screen.
4The operation buttons disappear when 4is
touched or when no operation is done for about
10 seconds.
5Displays the File List screen.* (P.8)
* Stops the currently playing file.
Ñ Selecting a track in a list (Searches file)
1 Touch [ ].
2 Select whether you search by audio files [ ],
video files [ ] or picture files [ ].
3 Touch [Y] to moves to the upper hierarchy.
4 Touch the desired folder.
When you touch a folder its contents are displayed.
5 Touch desired item from the content list.
Playback starts.
✎NOTE
• When file types are switched, the Random/Repeat
playback setting is cancelled.
!B5A-3198-00_DMX.indb 8 2019/06/11 13:39

9
English |
iPod/iPhone
Continued on the next page...
iPod/iPhone
Preparation
Ñ Connecting iPod/iPhone
• For Lightning connector models: Use USB Audio
cable for iPod/iPhone—KCA-iP103 (optional
accessory).
• For details about connecting iPod/iPhone, see page
24 .
1 Remove the cap of the USB terminal.
2 Connect the iPod/iPhone.
The unit reads the device and playback starts.
Ñ To disconnect the iPod/iPhone
1 Press the <8MENU> button.
2 Touch a source other than [iPod].
3 Detach the iPod/iPhone.
Ñ Connectable iPod/iPhone
The following models can be connected to this unit.
Made for
iPhone XS Max
iPhone XS
iPhone XR
iPhone X
iPhone 8 Plus
iPhone 8
iPhone 7 Plus
iPhone 7
iPhone SE
iPhone 6s Plus
iPhone 6s
iPhone 6 Plus
iPhone 6
iPhone 5s
✎NOTE
• If you start playback after connecting the iPod, the
music that has been played by the iPod is played first.
• Cap the USB terminal whenever not using.
Playback operations
Ñ Control the music you are listening to on
the source control screen
1
6
3
2
5
4
1Artwork (Shown if the track contains artwork)
2##:##:## : Song time
Play time bar : For confirmation of current playing
position
3L : Plays or pauses.
[E][F] : Searches the previous/next content.
Touch and hold to fast forward or fast backward.
[] : Selects Repeat playback mode.
Lights off: Repeat off
: Functions the same as Repeat All.
1 : Functions the same as Repeat One.
[] : Selects Random playback mode.
: Functions the same as Shuffle Songs.
Lights off: Random off
4Displays the information of the current file.
5Searches content. (P.10)
6D, etc. : Playback status
: Repeat playback mode indicator
: Random playback mode indicator
!B5A-3198-00_DMX.indb 9 2019/06/11 13:39

10
iPod/iPhone
Ñ Selecting a content in a list
1 Touch [ ].
2 Touch desired item.
When you touch a category its contents are
displayed.
3 Touch desired item from the content list.
Playback starts.
• Touch [6] to moves to the upper hierarchy.
✎NOTE
• The source control screen appears when you touch
[6] at the top hierarchy.
!B5A-3198-00_DMX.indb 10 2019/06/11 13:39

11
English |
Mirroring
Continued on the next page...
Mirroring
Preparation
Pair your smartphone with the unit via Bluetooth.
See Register your smartphone to the unit (P.15)
and Connect the Bluetooth device.
Ñ Compatible Android smartphone
• Android version 7.0 or later
• Bluetooth support
✎NOTE
• This unit may not work for some Android smartphone’s.
Ñ Connecting Android smartphone
• For details about connecting Android smartphone,
see page 24 .
1 Download Mirroring App from Google Play.
Install the latest version of the Mirroring application
“Mirroring OA for KENWOOD” on your Android.
2 Remove the cap of the USB terminal.
3 Connect the Android smartphone.
4 Launch Mirroring App on your Android
Smartphone.
Touch “OK” to start Mirroring App.
Touch “Start now” to start capturing your Android
screen.
5 Start to enjoy Mirroring.
Ñ To disconnect the Android smartphone
1 Press the <8MENU> button.
2 Touch a source other than [Mirroring].
3 Detach the Android smartphone.
Mirroring operations
Ñ Mirroring Operation
1 Touch [Mirroring].
• You can display the same screen of the Android
device on the monitor of the unit.
Ñ To turn off the Mirroring
1 Press the <8MENU> button.
• HOME screen appears.
!B5A-3198-00_DMX.indb 11 2019/06/11 13:39

12
Radio
Radio Basic Operation
1 Press the <8MENU> button.
2 Touch [Radio].
Ñ Source control screen
4
1
3
2
5
1Displays the information of the current station:
PS name, Frequency, PTY Genre, Indicator Items
[<<] [>>] : Touch to the next frequency manually.
2Recalls the memorized station.
When touched for 2 seconds, stores the current
receiving station in memory.
3[E][F] : Tunes in a station with good
reception automatically. *1
[TA] : Sets the traffic information mode.
“ON”, “OFF” (Default) *2(P.12)
[PTY] : Select the available Program Type. *2(P.12)
*1 If “AF” is set to ON on the Tuner screen, only RDS
stations are received. (P.13)
*2 FM only
4[1] : Presets stations automatically. (P.12)
5[FM] : Switches the FM band.
“FM1”, “FM2”, “FM3”
[AM] : Switches the AM band.
“AM1”, “AM2”
Presetting stations
Ñ Auto memory
You can preset 18 stations for FM and 12 stations for
AM.
1 Touch [FM] or [AM] to select the band.
2 Touch [1].
The local stations with the strongest signals are
found and stored automatically.
• If “AF” is set to “ON” on the Tuner screen, only RDS
stations are stored in the memory. (P.13)
Ñ Manual memory
You can store the current receiving station in
memory.
1 Tune in to a station you want to preset.
2 Touch and hold [#] (#:1-6) in which you want to
store the station.
Ñ Recalling the preset station
1 Touch [#] (#:1-6).
✎NOTE
• Only frequencies are registered as preset stations.
Information about RDS stations is not registered.
FM RDS features
Ñ Search by program type
1 Touch [PTY].
2 Select a program type from the list.
PTY Search starts.
Ñ Traffic Information
1 Touch [TA].
Switches to the traffic information automatically
when the traffic bulletin starts. (TA indicator lights
up.)
“ON”, “OFF” (Default)
• If “AF” is set to “ON” on the Tuner screen, the station is
switched to the RDS station. (P.13)
When the traffic bulletin starts
The Traffic Information screen appears automatically.
!B5A-3198-00_DMX.indb 12 2019/06/11 13:39

13
English |
Radio
Continued on the next page...
Radio Setup
Ñ Function menu
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [Radio].
4 Set each item as follows.
Stereo
Determines whether to receive stereo broadcasts
in the stereo mode or monaural mode (the MONO
indicator lights up).
“ON” (Default), “OFF”
Local
Tunes in only to the stations with sufficient signal
strength. (LOC indicator lights up.)
“ON”, “OFF” (Default)
RDS Clock Sync
Synchronizing the Radio Data System station time
data and this unit’s clock.
“ON” (Default), “OFF”
AF
When station reception is poor, automatically switches
to the station that is broadcasting the same program
over the same Radio Data System network.
“ON” (Default), “OFF”
5 Touch [6].
!B5A-3198-00_DMX.indb 13 2019/06/11 13:39

14
External ComponentsExternal Components
Using external audio/video players
Ñ Starting playback
1 Connect an external component to the AV-IN
input terminal. (P.23)
2 Press the <8MENU> button.
3 Touch [AV-IN].
4 Turn on the connected component and start
playing the source.
Ñ For Video playback
1 When the operation buttons are not displayed on
the screen, touch the display.
1
The operation buttons disappear when 1is
touched or when no operation is done for about 5
seconds.
✎NOTE
• When the picture from the rear view camera is
displayed on the AV-IN screen, the picture output
from the Visual Output terminal disappears.
Rear view camera
To use a rear view camera, the REVERSE lead
connection is required. For connecting a rear view
camera. (P.23)
Ñ Displaying the picture from the rear view
camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
• To erase the caution message, touch the screen.
!B5A-3198-00_DMX.indb 14 2019/06/11 13:39

15
English |
Bluetooth smartphone
Continued on the next page...
Bluetooth smartphone
Ñ About the Bluetooth smartphone and
Bluetooth audio player
This unit conforms to the following Bluetooth
specifications:
Version
Bluetooth Ver.2.1 + EDR
Profile
Smartphone/ Cell-phone:
HFP (V1.6) (Hands Free Profile)
PBAP (V1.1.1) (Phonebook Access Profile)
Audio player:
A2DP (V1.2) (Advanced Audio Distribution Profile)
AVRCP (V1.3) (Audio/Video Remote Control Profile)
Sound codec
SBC
Ñ About mobile phones compatible with
Phone book Access Profile (PBAP)
If your mobile phone supports PBAP, you can display
the following items on the touch panel screen when
the mobile phone is connected.
• Phone book (up to 1000 entries)
• Dialed calls, received calls, and missed calls (up to 20
entries in total)
Register your smartphone to the unit
You can use your Bluetooth smartphone when paired
to this unit.
You can register up to 5 Bluetooth devices.
• You can pair the device and the unit using SSP (Secure
Simple Pairing) which only requires confirmation.
• One device can be connected at a time.
• When you register a new Bluetooth device, disconnect
the Bluetooth device currently connected and then
register the new device.
• A new device cannot be registered if there are 5
registered Bluetooth units. Delete unnecessary
registration. (P.17)
1 Turn on the Bluetooth function on your
smartphone/cell-phone.
2 Search the unit from your smartphone/cell-phone.
If a PIN code is required, enter the PIN code (“0000”).
• appears when the Bluetooth smartphone is
connected.
• appears when the Bluetooth audio player is
connected.
Ñ Disconnecting the device
• Turn off the Bluetooth function from your
smartphone/cell-phone.
• Turn off the ignition switch.
Receive a phone call
1 Touch [Û].
• [Ý] : Reject an incoming call.
Ñ Operations during a call
[Ý]Ending a call
You can send tones by touching desired keys
on the screen.
• Touch [ ] to close the window.
Switches the speaking voice output between
cell-phone and speaker.
⿠Adjust the receiver volume
Press the <+> or <–> button.
!B5A-3198-00_DMX.indb 15 2019/06/11 13:39

16
Bluetooth smartphone
Make a phone call
1 Press the <8MENU> button.
2 Touch [TEL].
3 See the table below for each operation method.
• [ ] : Disconnects the Bluetooth smartphone.
• [ ] : Closes the screen for sending tones while
talking.
• [ ] : Displays the screen for deleting the
previously registered Bluetooth devices.
(P.17)
Call by entering a phone number
1) Touch [ ].
2) Enter a phone number with number keys.
3) Touch [Û].
Make a call
• Touch [W] to delete the last entry.
Call using call records
1) Touch [ ] (Incoming Calls), [ ] (Outgoing
Calls), [ ] (Missed Calls).
2) Select the phone number from the list.
Make a call
Call using the phonebook
1) Touch [ ].
2) Select the name from the list.
Make a call
• [ ] : Updates the phonebook. Touch this
button after you have made a change to
the phonebook of your cell-phone.
Call by voice
You can make a voice call using the voice recognition
function of the Bluetooth smartphone.
1) Touch [ ].
2) Touch [ ].
3) Say the name registered in the Bluetooth
smartphone.
• Touch [ ] to cancel voice dialing.
!B5A-3198-00_DMX.indb 16 2019/06/11 13:39

17
English |
Bluetooth smartphone
Continued on the next page...
Playing Bluetooth Audio Device
1 Press the <8MENU> button.
2 Touch [BT Audio].
Ñ Source control screen
2
3
1
1[L] : Plays or pauses.
[E][F] : Searches the previous/next content.
2Displays the information of the current file.
Only a file name and a folder name are displayed if
there is no tag information.
3D, etc. : Playback status
: Repeat playback mode indicator *
: Random playback mode indicator *
* The settings on the Bluetooth audio device are
displayed.
✎NOTE
• Operations and display indications may differ
according to their availability on the connected
device.
Delete the registered Bluetooth
device
1 Press the <8MENU> button.
2 Touch [TEL].
3 Touch [ ].
4 Touch the device name.
5 Touch [ ].
!B5A-3198-00_DMX.indb 17 2019/06/11 13:39

18
Controlling Audio
Controlling General Audio
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [Audio].
4 Touch [Sound Effect].
5 Touch [ ].
6 Set each item as follows.
Fader
[] [ ]
Adjust the front and rear volume balance.
12 (front) to -12 (rear)
Balance
[] [ ]
Adjust the left and right volume balance.
12 (right) to -12 (left)
[Reset] To clear the adjustment.
Ñ Loudness
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [Audio].
4 Touch [Loudness].
Sets the amounts of boost of low and high tones.
“ON”, “OFF” (Default)
Equalizer Control
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [Audio].
4 Touch [Sound Effect].
5 Set each item as follows.
1
3
2
1You can select frequency bar and adjust its level.
(-7 to +7)
• The adjustments are stored and “User” is activated.
2To recall the preset equalizer curve.
3The “User” preset and the current EQ curve returns
to flat.
Subwoofer settings
1 Press the <8MENU> button.
2 Touch [Setup].
3 Touch [Audio].
4 Touch [Subwoofer].
5 Set each item as follows.
Frequency
[80Hz], [120Hz],
[160Hz], [OFF]
Low Pass Filter adjustment. /
[OFF]: Turns off the subwoofer
output. (Default OFF)
Volume
[–], [+]
Adjusts the subwoofer level. 0 to 12
(Default 6)
Controlling Audio
!B5A-3198-00_DMX.indb 18 2019/06/11 13:39

19
English |
Remote control
Continued on the next page...
Remote control
This unit can be operated using the remote control
KNA-RCDV331 (optional accessory).
! CAUTION
• Put the remote control in a place where it will
not move during braking or other operations. A
dangerous situation could result, if the remote control
falls down and gets wedged under the pedals while
driving.
• Do not leave the battery near fire or under direct
sunlight. A fire, explosion or excessive heat generation
may result.
• Do not recharge, short, break up or heat the battery
or place it in an open fire. Such actions may cause the
battery to leak fluid. If spilled fluid comes in contact
with your eyes or on clothing, immediately rinse with
water and consult a physician.
• Place the battery out of reach of children. In the
unlikely event that a child swallows the battery,
immediately consult a physician.
Ñ Battery Installation
If the remote control operates only over shorter
distances or does not operate at all, it is possible that
the batteries are depleted.
In such instances, replace the both batteries with new
ones.
1 Insert two “AAA”/“R03”-size batteries with the
and poles aligned properly, following the
illustration inside the case.
Ñ Switch the operation mode
Turn its operation mode switch to “DVD.”
DVD
T V
NAV
AUD
•
•
•
•
Functions of the Remote control
Buttons
• Aim the remote control directly at the remote sensor
on the faceplate.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
1
3
4
6
9
5
2
7
8
10
1SRC Switches to the source to be played.
2IStop playback.
3LPlays or pauses.
4AUDIO Displays the Equalizer screen. (P.18)
5ÛWhen a call comes in, answers the call.
6VOL RSAdjusts the volume.
7FM+
AM–
Selects the folder to be played.
During tuner source, select FM/ AM
band to be received.
8E
F
Selects the track or file to be played.
During tuner source, switches to
broadcast stations received by the unit.
9ATT Mutes/restores the sound
10 CLEAR Clears the telephone number input on
the Phone screen.
–Other Not used.
!B5A-3198-00_DMX.indb 19 2019/06/11 13:39

20
InstallationInstallation
Before Installation
Before installation of this unit, please note the
following precautions.
#WARNINGS
• If you connect the ignition wire (red) and the battery
wire (yellow) to the car chassis (ground), you may
cause a short circuit, that in turn may start a fire.
Always connect those wires to the power source
running through the fuse box.
• Do not cut out the fuse from the ignition wire (red)
and the battery wire (yellow). The power supply must
be connected to the wires via the fuse.
#CAUTION
• Install this unit in the console of your vehicle.
Do not touch the metal part of this unit during and
shortly after the use of the unit. Metal part such as the
heat sink and enclosure become hot.
✎NOTE
• Mounting and wiring this product requires skills and
experience. For best safety, leave the mounting and
wiring work to professionals.
• Make sure to ground the unit to a negative 12V DC
power supply.
• Do not install the unit in a spot exposed to direct
sunlight or excessive heat or humidity. Also avoid
places with too much dust or the possibility of water
splashing.
• Do not use your own screws. Use only the screws
provided. If you use the wrong screws, you could
damage the unit.
• If the power is not turned ON (“There is an error in
the speaker wiring. Please check the connections.” is
displayed), the speaker wire may have a short-circuit or
touched the chassis of the vehicle and the protection
function may have been activated. Therefore, the
speaker wire should be checked.
• If your car’s ignition does not have an ACC position,
connect the ignition wires to a power source that
can be turned on and off with the ignition key. If you
connect the ignition wire to a power source with a
constant voltage supply, such as with battery wires,
the battery may be drained.
• If the console has a lid, make sure to install the unit so
that the front panel will not hit the lid when closing
and opening.
• If the fuse blows, first make sure the wires aren’t
touching to cause a short circuit, then replace the old
fuse with one with the same rating.
• Insulate unconnected wires with vinyl tape or other
similar material. To prevent a short circuit, do not
remove the caps on the ends of the unconnected
wires or the terminals.
• Secure the wires with cable clamps and wrap vinyl
tape around the wires that comes into contact with
metal parts to protect the wires and to prevent short
circuit.
• Connect the speaker wires correctly to the terminals
to which they correspond. The unit may be damaged
or fail to work if you share the ¤wires or ground
them to any metal part in the car.
• When only two speakers are being connected to
the system, connect the connectors either to both
the front output terminals or to both the rear output
terminals (do not mix front and rear). For example,
if you connect the ¢connector of the left speaker
to a front output terminal, do not connect the ¤
connector to a rear output terminal.
• After the unit is installed, check whether the brake
lamps, blinkers, wipers, etc. on the car are working
properly.
• Mount the unit so that the mounting angle is 30° or
less.
• Do not press hard on the panel surface when installing
the unit to the vehicle. Otherwise scars, damage, or
failure may result.
• Reception may drop if there are metal objects near
the Bluetooth antenna.
Bluetooth antenna unit
Ñ Supplied accessories for installation
1
x1
2
x2
3
x1
4(3 m)
x1
5(2 m)
x1
!B5A-3198-00_DMX.indb 20 2019/06/11 13:39
