Kenwood DMX4707S User manual

DMX4 7 07 S
B5H-0358-xx (E)© 2020 JVCKENWOOD Corporation
MONITOR WITH RECEIVER
INSTRUCTION MANUAL
• Updated information (the latest Instruction Manual, etc.) is available
from
<http://www.kenwood.com/cs/ce/>.

Playable Media and Files........................................45
27
2
Contents
Before Use 3
Precautions................................................................... 3
How to read this manual ......................................... 3
Basic Operations 4
Functions of the Buttons on the Front Panel ... 4
Turning on the Unit ................................................... 4
Initial Settings.............................................................. 5
Adjusting the volume............................................... 6
Touch screen operations ......................................... 6
HOME screen descriptions...................................... 7
Source selection screen descriptions.................. 7
Source control screen descriptions .................... 9
MENU screen..............................................................
List screen ...................................................................10
APPS-Android Auto™/
Apple CarPlay 11
Apple CarPlay Operation.......................................11
Android Auto™ Operation.....................................12
USB 13
Connecting a USB device ......................................13
USB Basic Operation................................................13
Search Operation......................................................15
Radio 16
Radio Basic Operation ............................................16
Memory Operation ..................................................17
Selecting Operation ................................................17
Traffic Information (FM only)...............................18
Radio Setup ................................................................18
Bluetooth Control 19
Information for using Bluetooth® devices .......19
Register from the Bluetooth device ...................20
Bluetooth Setup ........................................................20
Playing Bluetooth Audio Device
.........................21
Using Hands-Free Unit
............................................23
Other External Components 27
View Camera ..............................................................
External audio/video players—AV-IN ...............28
Setting Up 29
Monitor Screen Setup .............................................29
System Setup .............................................................29
User Interface Setup ................................................30
Special Setup .............................................................30
Display Setup .............................................................31
AV Setup
......................................................................32
Controlling Audio 33
Speaker/ X’over setup .............................................33
Controlling General Audio ....................................34
Equalizer Control ......................................................35
Volume Offset ............................................................36
Sound Effect ...............................................................36
Listening Position/ DTA ..........................................37
Remote control 38
Functions of the Remote control Buttons .......38
Connection/Installation 39
Before Installation ....................................................39
Installing the unit .....................................................39
Troubleshooting 44
Problems and Solutions .........................................44
Error Messages ..........................................................44
Appendix 45
Specifications .............................................................46
About this Unit ..........................................................48
9

Before Use
Before Use
Precautions
#WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metal
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your KENWOOD dealer to make
sure that they work with your model and in
your area.
• You can select language to display menus,
audio file tags, etc. See User Interface Setup
(P.30 ).
•The Radio Data System or Radio Broadcast
Data System feature won’t work where the
service is not supported by any broadcasting
station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with the sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe the
stain off with a cloth moistened with neutral
cleaner, then wipe it again with a clean soft
dry cloth.
NOTE
• Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the faceplate
with a hard cloth or using a volatile liquid such
as thinner or alcohol may scratch the surface or
erase screened print.
Ñ How To Reset Your Unit
• If the unit or the connected unit fails to
operate properly, reset the unit.1 Press the
<Reset> button.The unit returns to factory
settings.
NOTE
• Disconnect the USB device before pressing the
<Reset> button. Pressing the <Reset> button
with the USB device connected can damage
the data stored in the USB device. For how to
disconnect the USB device, see Disconnect the
USB device (P.13).
• When the unit is turned on after resetting, the
Initial SETUP screen appears. See Initial setup
(P.6).
How to read this manual
• The screens and panels shown in this manual are
examples used to provide clear explanations of the
operations.
For this reason, they may be different from the actual
screens or panels used, or some display patterns may
be different.
• Indication language: English indications are used
for the purpose of explanation. You can select the
indication language from the [SETUP]menu. See
User Interface Setup (P.34 ).
Reset button
3
English

Basic Operations
6
Basic Operations
Functions of the Buttons on
the Front Panel
1
2
3
4
5
6
NOTE
• The panels shown in this guide are examples
used to provide clear explanations of the
operations. For this reason, they may be different
from the actual panels.
Name
• Motion
1
Remote Sensor
• Receives the remote control signal.
2
S, R(VOL)
• Adjusts volume.
The volume will go up until 15 when you
keep pressing R.
3
HOME
•Displays the HOME screen (P.7).
• Pressing for 1 second turns the power off.
•When the power off, turns the power on.
4
MENU
• Displays the MENU screen.
• Pressing for 1 second turns the screen off.
5
VOICE
• Displays the Voice Recognition screen
(P.26).
6
Reset
• If the unit or the connected unit fails to
operate properly, the unit returns to initial
settings when this button is pressed.
Turning on the Unit
The method of turning on is different
depending on the model.
1
Press the [HOME]button.
 The unit is turned on.
●To turn off the unit:
1
Press the [HOME]button for 1 second.
NOTE
• If it is your first time turning the unit on after
installation, it will be necessary to perform Initial
setup (P.7).
4

Basic Operations
Initial Settings
Initial setup
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■Language
Select the language used for the control
screen and setting items. Default is“British
English(en)”.
1Touch [Language].
2Touch [Language Select].
3Select the desired language.
4Touch [
].
For detailed operation, see User Interface
Setup (P.30).
■Clock
Adjusts clock.
For detailed operation, see Calendar/clock
settings (P.6).
■Display
Set the image on the screen.
1Touch [Display.
2Touch [Background].
3Select the image.
4Touch [
].
For detailed operation, see Display Setup
(P.31).
■Camera
Set the parameters for the camera.
1Touch [Camera].
2Set each item and touch [
].
For detailed operation, see Camera Setup
(P.27).
■DEMO
Set the demonstration mode. Default is “ON”.
1Touch [DEMO]and set ON or OFF.
2
Touch [Finish].
NOTE
• These settings can be set from the SETUP menu.
See Setting Up (P.29).
5
English

Basic Operations
Calendar/clock settings
1
Press the [MENU]button.
 MENU screen appears.
2
Touch [ ].
 SETUP Menu screen appears.
3
Touch [User Interface].
 User Interface screen appears.
4
Touch [Clock Adjust].
5
Adjust the date, then adjust the time.
6
Touch [Set].
NOTE
• Deactivate [RDS CT]before adjusting the clock.
See Radio Setup (P.16).
Adjusting the volume
To adjust the volume (0 to 40),
Press [R]to increase, and press [S]to decrease.
Holding [R]increases the volume continuously
to level 15.
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to select
an item, display setting menu screen or to
change the page, etc.
●Touch
Touch the screen gently to
select an item on the screen.
6

Basic Operations
HOME screen descriptions
Most functions can be performed from the
HOME screen.
3
2
45
1
1
• Displays the control screen of current source.
2
• Current source information
3
• Displays the source selection screen.
4
• Short-cut playback source icons
5
• Displays the Hands Free screen.
• When connecting as Apple CarPlay or
Android Auto, it works as a phone provided
in Apple CarPlay or Android Auto.
Display the HOME
1
Press the [HOME]button.
 HOME screen appears.
Source selection screen
descriptions
You can display all playback sources and options
on the source selection screen.
2
1
1
• Changes the playback source.
For playback sources, see .
2
3
• Returns to previous screen.
• Displays the SETUP Menu screen.
3
7
English

Basic Operations
Select the playback source
1
Touch [ ] on the HOME screen.
From the screen, you can select the
following sources and functions.
• Switches to the Apple CarPlay screen
from the connected iPhone. (P.##)
• Switches to the Android Auto screen
from the connected Android device.
(P.##)
• Displays the Hands Free screen. (P.##)
When neither Apple CarPlay, Android
Auto, nor a Bluetooth Hands-Free phone
is connected, displays Bluetooth pairing
waiting dialog.* (P.##)
• Switches to the Radio broadcast.
• Switches to the Digital Radio broadcast.
(P.##)
• Plays a Bluetooth audio player.
• [USB]
Plays files on a USB device. (P.##)
• Switches to an external component
connected to the AV-IN input terminal.
* When connecting as Apple CarPlay or Android
Auto, it works as a phone provided in Apple
CarPflay or Androfid Auto.
To select the playback source on the
HOME screen
The 3 items displayed on the source selection
screen as the large icons are shown on the
HOME screen.
To select the playback source on the
source control screen
Display source selection buttons by touching [
]
/[ ] or flicking left or right on the source control
screen, then select a playback source.
8

Basic Operations
Source control screen
descriptions
There are some functions which can be
operated from most screens.
Indicators
1
2 3 4
Short-cut buttons
1
Connected Bluetooth device information.
2
All sources icon
Displays all sources.
3
Secondary screen
• [
]/[ ] : The Secondary screen changes every
time you touch it. You can also change the
Secondary screen by flicking left or right on
the screen.
•Indicators: Displays the current source
condition and so on.
– ATT: The attenuator is active.
– LOUD: The loudness control function is on.
4
[Û]
Touch to display the Hands Free screen.
(P.27)
When connecting as Apple CarPlay or Android
Auto, it works as a phone provided in Apple
CarPlay or Android Auto.
MENU screen
1
Press the [MENU]button.
 MENU screen appears.
2
Touch to display the MENU screen.
[ ]
9
English

Basic Operations
Turn off the screen
1
Select [ ] on the MENU screen.
●To turn on the screen
1
Touch the display.
List screen
There are some common function keys in the
list screens of most sources.
61 2
3 4 5
1
Displays list type selection window.
2
Displays music/movie file list.
3
Text scroll
Scrolls the displayed text.
4
etc.
Keys with various functions are displayed here.
• : Plays all tracks in the folder containing
the current track.
• [ : Moves to the upper hierarchy.
5
[ ] / [ ] / [ ] / [ ] Page scroll
You can change the page to display more items
by pressing [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
6
Return
Returns to previous screen.
NOTE
• Buttons which cannot be activated from the list
screen are not displayed.
10

APPS-Android Auto™/ Apple CarPlay
APPS-Android Auto™/ Apple CarPlay
Apple CarPlay Operation
CarPlay is a smarter, safer way to use your
iPhone in the car. CarPlay takes the things
you want to do with iPhone while driving and
displays them on the screen of the product. You
can get directions, make calls, send and receive
messages, and listen to the music from iPhone
while driving. You can also use Siri voice control
to make it easier to operate iPhone.
For details about CarPlay, visit https://ssl.apple.
com/ios/carplay/.
Compatible iPhone devices
You can use CarPlay with the following iPhone
models.
•iPhone 7 Plus
• iPhone 7
• iPhone SE
• iPhone 6s Plus
• iPhone 6s
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
• iPhone 5c
• iPhone 5
Ñ Preparation
1 Connect iPhone using KCA-iP103 via USB
terminal. (P.47)
When iPhone compatible with CarPlay
is connected to the USB terminal, the
Bluetooth smartphone currently connected
is disconnected.
2 Unlock your iPhone.
Ñ Operation buttons and
available Apps on the home
screen of CarPlay
You can use the Apps of the connected iPhone.
The items displayed and the language used on
the screen differ among the connected devices.
To enter CarPlay mode, touch Apple CarPlay]
icon in the HOME screen.
3
1
2
1
[ ]
• Displays the home screen of CarPlay.
•Touch and hold to activates Siri.
2
Application buttons
Starts the application.
3
[HOME]
Exits the CarPlay screen and displays the Home
screen.
To exit the CarPlay screen
1 Press the [HOME]button.
Ñ Use Siri
You can activate Siri.
1 Press the [VOICE]button.
2 Talk to Siri.
Ñ Switch to the Apple CarPlay
screen while listening to
another source
1 Press the [HOME]button.
 HOME screen appears.
2 Touch [Apple CarPlay].
11
English

APPS-Android Auto™/ Apple CarPlay
NOTE
• If sound is output using Apple CarPlay when the
Apple CarPlay screen is displayed, the source is
switched to Apple CarPlay.
Android Auto™ Operation
Android Auto enables you to use functions of
your Android device convenient for driving. You
can easily access route guidance, make calls,
listen to music, and access convenient functions
on the Android device while driving.
For details about Android Auto, visit https://
www.android.com/auto/ and https://
support.google.com/androidauto.
Compatible Android devices
You can use Android Auto with Android devices
of Android version 5.0 (Lollipop) or later.
NOTE
• Android Auto may not be available on all devices
and is not available in all countries or regions.
Ñ Preparation
1 Connect an Android device via USB
terminal. (P.47)
To use the hands-free function, connect the
Android device via Bluetooth.
When an Android device compatible
with Android Auto is connected to the
USB terminal, the device is connected via
Bluetooth automatically, and the Bluetooth
smartphone currently connected is
disconnected.
2 Unlock your Android device.
Ñ Operation buttons and
available Apps on the Android
Auto screen
You can perform the operations of the Apps of
the connected Android device.
The items displayed on the screen differ among
the connected Android devices.
To enter Android Auto mode, touch [Android
Auto]icon in the HOME screen. (P.9)
1
1
Application/information buttons
Starts the application or displays information.
To exit the Android Auto screen
1 Press the [HOME]button.
Ñ Using voice control
1 Press the [VOICE]button .
To cancel
1 Press the [VOICE]button.
Ñ Switch to the Android Auto
screen while listening to
another source
1 Press the [HOME]button.
 HOME screen appears.
2 Touch [Android Auto].
NOTE
• If sound is output using Android Auto when the
Android Auto screen is displayed, the source is
switched to Android Auto.
[ ]
12

USB
17
English
USB
Connecting a USB device
1 Connect the USB device with the USB
cable. (P.46)
2 Press the [HOME]button.
3 Touch [ ].
4 Touch [USB].
Ñ Disconnect the USB device
1 Press the [HOME]button.
2 Touch a source other than [USB].
3 Detach the USB device.
Ñ Usable USB device
You can use a mass-storage-class USB device on
this unit.
The word “USB device” appearing in this manual
indicates a flash memory device.
●About file system
The file system should be the one of the
following.
• FAT16 • FAT32 • NTFS
NOTE
• Install the USB device in the place where it will
not affect safe driving.
• You cannot connect a USB device via a USB hub
and Multi Card Reader.
•Take backups of the audio files used with this
unit. The files can be erased depending on the
operating conditions of the USB device.
We shall have no compensation for any damage
arising from any erased data.
USB Basic Operation
Most functions can be controlled from the
source control screen and playback screen.
Control screen
4
3
5
2
6
1
7
Open the drawer
5
4
1
[ ] / [ ]
• [
]: Repeats the current track/folder. Each
time you touch the key, repeat mode switches
in the following sequence;
File repeat ( ), Folder repeat ( ),
Repeat all ( )
• [
]: Randomly plays all tracks in current
folder. Each time you touch the key, random
mode switches in the following sequence;
File random ( ), Random off ( )
•When a high-resolution source is played, its
format information is displayed.
2
Track information
Displays the information of the current file.
Only a file name and a folder name are
displayed if there is no tag information.
13
English

operation
USB
14
3
[Operation keys
• 1]: Searches track/file. For details on search
• E][F]: Searches the previous/next track/
file.
Touch and hold to fast forward or fast
backward.
•[D]H: Plays or pauses.
• : Touch to attenuates/restores the sound.
4
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel.
•[
][ ] : Searches previous/next folder.
• Aspect: Select screen mode.
Full: Changes the aspect ratio of video and
displays fully on the screen.
Normal: Display with 4:3 ratio.
Auto: Displays video fully on vertical or
horizontal with no ratio change.
5
Content list
Touch on the right side of the screen to display
the Content list. Touch again to close the list.
Displays the playing list. When you touch a
track/file name on the list, playback will start.
6
Indicator Items
• VIDEO: Identifies the video file.
•MUSIC: Identifies the music file.
7
Artwork/ Play mode indicator/ Playing
time
The jacket of the currently playing file is
displayed.
• D, B, etc.: Current play mode indicator
The meanings of each icon are as follows;
D(play), B(fast forward), A(fast
backward), H(pause).
Video screen
9
88
8
Searching file area (Video file only)
Touch to search the next/previous file.
9
Key display area (Video file only)
Touch to display the control screen.

USB
15
English
Search Operation
You can search music or video files by the
following operations.
1 Touch [1].
2 Touch [S].
3 Select the list type.
NOTE
• For operations in the list screen, see List screen
(P.11).
Ñ Category search
You can search a file by selecting category.
1 Touch [Category List].
2 Select whether you search by audio files [
]or video files [
].
3 Touch the desired category.
 The list corresponding to your selection
appears.
4 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
Ñ Link search
You can search a file of same artist/album/genre
as the current track.
1 Touch [Link Search].
2 Touch the desired tag type. You can select
from artist, album and genre.
 The list corresponding to your selection
appears.
3 Touch desired item from the content list.
Ñ Folder search
You can search a file according to hierarchy.
1 Touch [Folder List].
2 Touch the desired folder.
When you touch a folder its contents are
displayed.
3 Touch to select desired item in the list.
Repeat this step until you find the desired
file.

Radio
16
Radio
Radio Basic Operation
Most functions can be controlled from the
source control screen.
To enter Radio source, touch [Radio]icon in the
source selection screen.
Control screen
4
6
5
3
1
2
Open the drawer
4
7
5
1
Information display
Displays the information of the current station:
Frequency
Touching [ ] allows you to switch between
Content A and Content B.
Content A: PS name, Radio Text, PTY Genre
Content B: Radio Text plus, Title Artist
Preset#: Preset number
2
Seek mode
Switches the seek mode in the following
sequence; [AUTO1], [AUTO2], [MANUAL].
• [AUTO1]: Tunes in a station with good
reception automatically.
• [AUTO2]: Tunes in stations in memory one
after another.
• [MANUAL]: Switches to the next frequency
manually.
3
Operation keys
•[E][F]: Tunes in a station. The method of
frequency switching can be changed (see 2
in table).
•: Touch to attenuates/restores the sound.
4
Preset list
• Touch on the right side of the screen to
display the Preset list. Touch again to close
the list.
•Recalls the memorized station.
• When touched for 2 seconds, stores the
current receiving station in memory.
5
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel.
•[TI](FM only): Sets the traffic information
mode on. For details, see Traffic Information
• [SETUP: Displays the TUNER SETUP screen. For
details, see Radio Setup (P.
• [AME]: Presets stations automatically. For
details, see Auto memory (P. .
• [PTY](FM only): Searches a program by setting
program type. For details, see Search by
program type (P. .
•[MONO](FM only): Select the Monaural
reception.
• [LO.S](FM only): Turns the Local Seek function
on or off.
6
[FM][AM]
Switches the band.

[ ]
Radio
17English
7
Indicator Items
•ST: A stereo broadcast is being received.
•MONO: The forced monaural function is on.
•AF: The AF search function is on.
•LOS: The Local Seek function is on.
•RDS: Indicates the state of the Radio Data
System station when the AF function is on.
White: Radio Data System is being received.
Orange: Radio Data System is not being
received.
•[TI]: Indicates the reception state of traffic
information.
White: TP is being received.
Orange: TP is not being received.
Memory Operation
Ñ Auto memory
You can store stations with good reception in
memory automatically.
1 Touch desired band key.
2 Touch [ ] on the left side of the screen.
Touch [AME].
 Auto memory starts.
Ñ Manual memory
You can store the current receiving station in
memory.
1 Select a station you wish to store in
memory.
2 Touch [FM#](#:1-24) or [AM#](#:1-12) in
which you want to store the station for 2
seconds until a beep sounds.
Selecting Operation
Ñ Preset select
You can list and select memorized station.
1 Touch [ ] on the right side of the screen.
Select a station from the list.
Ñ Search by program type
(FM only)
You can tune to a station with a specific
program type when listening to FM.
1 Touch [ ] on the left side of the screen.
Touch [PTY].
 PTY Search screen appears.
2 Select a program type from the list.
3 Touch [Search].
You can search a station of the selected
program type.

Radio
18
Traffic Information (FM only)
You can listen and watch the traffic information
automatically when a traffic bulletin starts.
However, this feature requires a Radio Broadcast
Data System that includes the TI information.
1 Touch [ ] on the left side of the screen.
Touch [TI].
 Traffic information mode is set.
Ñ When the traffic bulletin starts
The Traffic Information screen appears
automatically.
Radio Setup
You can set tuner related parameters.
1 Touch [ ] on the left side of the screen.
Touch [SETUP].
 Radio SETUP screen appears.
2 Set each item as follows.
■AF
When station reception is poor, automatically
switches to the station that is broadcasting
the same program over the same Radio Data
System network. Default is“ON”.
■RDS CT
Synchronizing the Radio Data System station
time data and this unit’s clock.
“ON” (Default), “OFF”

19
Bluetooth Control
English
Bluetooth Control
Using the Bluetooth function, various functions
can be used: listening to the audio file, making/
receiving a call.
Information for using
Bluetooth® devices
Bluetooth is a short-range wireless radio
communication technology for mobile devices
such as mobile phones, portable PCs, and other
devices.
Bluetooth devices can be connected without
cables and communicate with each other.
NOTE
• While driving, do not perform complicated
operations such as dialing numbers, using the
phone book, etc. When you perform these
operations, stop your car in a safe place.
• Some Bluetooth devices may not connect to
this unit depending on the Bluetooth version of
the device.
• This unit may not work for some Bluetooth
devices.
• Connecting conditions may vary depending on
your environment.
• For some Bluetooth devices, the device is
disconnected when the unit is turned off.
Ñ About the cell-phone and
Bluetooth audio player
This unit conforms to the following Bluetooth
specifications:
Version
Bluetooth Ver. 4.1
Profile
Cell-phone:
HFP (Hands Free Profile)
SPP (Serial Port Profile)
PBAP (Phonebook Access Profile)
Audio player:
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio/Video Remote Control Profile)
Sound codec
SBC, AAC
NOTE
• The units supporting the Bluetooth function
have been certified for conformity with the
Bluetooth Standard following the procedure
prescribed by Bluetooth SIG.
• However, it may be impossible for such units to
communicate with your cell-phone depending
on its type.

Bluetooth Control
20
Register from the Bluetooth
device
It is necessary to register the Bluetooth audio
player or cell-phone to this unit before using the
Bluetooth function.
You can register up to 7 Bluetooth devices.
NOTE
• Up to 7 Bluetooth devices can be registered. If
an attempt is made to register the 8th Bluetooth
device, the Bluetooth device connected on the
earliest date will be deleted to register the 8th
one.
•This unit is compatible with the Apple Easy
Pairing function. When an iPod touch or iPhone
is connected to this unit, an authentication
dialog appears. Performing operation for
authentication on this unit or iOS smartphone
registers the smartphone as a Bluetooth device.
1 Turn on the Bluetooth function on your
smartphone/cell-phone.
2 Search the unit from your smartphone
/cell-phone.
3 Operate your smartphone/cell-phone
according to the displayed messages.
■Confirm the request on the
smartphone/cell-phone.
■If a PIN code is required, enter the PIN
code (“0000”).
When data transmission and connection
have completed, the Bluetooth connection
icon appears on the screen.
Bluetooth Setup
1 Press the [MENU]button.
 MENU screen appears.
2 Touch [ ].
 SETUP Menu screen appears.
3 Touch [Bluetooth].
 Bluetooth SETUP screen appears.
See the following section for each
setting.
• Connect the Bluetooth device
[ ].
