Kenwood Vr-505 User manual

70%

AUDIO VIDEO SURROUND RECEIVER

A SPEAKERS B

STANDBY

POWER

MULTI CONTROL

LISTEN MODE

SOUND

SORCE DIRECT

AUTOBAND MEMORY

INPUT SELECTOR

VOLUME CONTROL

UPDOWN

DTS PROLOGIC 3 STEREO CS 5.1

DOLBY

DIGITAL

INPUT MODESET UP

S-VIDEO VIDEO L – AUDIO – R

AV AUX

DIMMER MONITOR

PHONES

ON/STANDBY

*Refer to parts list on page 36.

VR-505/506/507/

SERVICE MANUAL

GREEN

ORANGE GRAY

SURROUND SPEAKERS

FRONT SPEAKERSCENTER SPEAKER

BLUE

FRONT SPEAKERS

(8 ~ 16 )

RED

DVD

VIDEO 1 VIDEO 2 VIDEO 3

AC OUTLETS

AC120V 60Hz

SWITCHED TOTAL

150W 1.25A MAX.

CD/DVD

OPTICAL

VIDEO3

OPTICAL

MONITOR

OPTICAL

DIGITAL IN

DIGITAL OUT

VIDEO 2

COAXIAL

CENTER

RALC

LR

LR B

GND PLAY IN PLAY IN PLAY IN

VIDEO 1 VIDEO 2 VIDEO 3 SUB WOOFER

PRE OUT

REC OUTPLAY IN

MONITOR

REC OUTPLAY INREC OUT

MD / TAPE

CD / DVDPHONO

AUDIO

PLAY IN PLAY IN PLAY INREC OUTPLAY IN

MONITOR

OUT

S VIDEO

VIDEO 1

DVD

R

L

SYSTEM

CONTROL

VIDEO 2 IN

VIDEO 1 IN VIDEO 3 IN

CD/DVD

DVD

MONITOR

OUT

VIDEO 1

OUT

GND

ANTENNA

AM

DVD / 6CH. INPUT

SUB

WOOFER

FRONT

SURROUND

75 s

AM 10kHz

FM 100kHz

50 s

AM 9kHz

FM 50kHz

DE-

EMPHASIS

CHANNEL

SPACE

(8 ~ 16 ) (8 ~ 16 )

(8 ~ 16 )

[Y]

DVD IN

VIDEO3 IN MONITOR OUT

R REPEATE

OUT

ANTENNA

RF REMOTE

COMPONENT VIDEO

[Cb] [Cr]

[Y] [Cb] [Cr]

FM

75

Knob

(K29-7687-03) Front glass *

(B10-) Knob

(K29-7678-04) Panel *

(A60-)

Phone jack

(E11-0272-05) Knob

(K29-7687-03) Knob

(K29-7681-14) Knob

(K29-7675-22) Knob

(K29-7681-14) Cylindrical receptacle

(E56-0033-05)

Pin jack

(E63-1172-05)

Pin jack

(E63-0127-05) Pin jack

(E63-1139-05)

Metallic cabinet *

(A01-)

Optical receiving module

(W02-2802-05)

Pin jack

(E63-1080-05)

Cylindrical receptacle

(E56-0011-05)

Pin jack

(E63-1193-05)

Pin jack

(E63-1194-05)

Miniature phone jack

(E11-0904-05)

Pin jack x2

(E63-1143-05) Screw terminal board

(E70-0049-05)

Pin jack

(E63-1146-05)

Pin jack

(E63-1144-05)

Oscillating module

(W02-2803-05)

Lock terminal board

(E70-0128-05) AC power cord

(E30-2941-05)

Miniature phone jack

(E11-0293-05)

AC outlet *

(E03-)

Illustration is VR-509.

Miniature phone jack

(E11-0291-05)

AC power cord bushing
