Kenwood TK-2202 User manual

VHF FM TRANSCEIVER
TK-2202/2206
©2004-2 PRINTED IN JAPAN
B51-8677-00 (S) 1246
SERVICEMANUAL
GENERAL .............................................................2
SYSTEM SET-UP .................................................2
REALIGNMENT....................................................3
DISASSEMBLY FOR REPAIR ..............................5
CIRCUIT DESCRIPTION .......................................8
TERMINAL FUNCTION......................................12
SEMICONDUCTOR DATA .................................12
COMPONENTS DESCRIPTION .........................13
PARTS LIST........................................................14
EXPLODED VIEW...............................................20
PACKING ............................................................21
ADJUSTMENT ...................................................23
PC BOARD
TX-RX UNIT (X57-6870-20)..........................28
SCHEMATIC DIAGRAM.....................................32
BLOCK DIAGRAM..............................................36
LEVEL DIAGRAM...............................................38
KSC-31 / KNB-29N / KNB-30A / KBH-10 .........39
SPECIFICATIONS............................BACK COVER
CONTENTS
Antenna
(T90-1036-05): TK-2202(K,M)
(KRA-26: Option) TK-2206 (M)
Knob (VOLUME)
(K29-9309-03)
Knob (PTT)
(K29-9308-03)
Cabinet assy
(A02-3852-23)(8CH):
TK-2202(K,M)
(A02-3851-23)(16CH):
TK-2206(M)
Knob (CH-SELECTOR)
(K29-9318-03)
TK-2206 :
Does not come with antenna.
Antenna is available as an option.
Photo is TK-2202.

TK-2202/2206
2
GENERAL / SYSTEM SET-UP
SYSTEM SET-UP
Merchandise received
License and frequency allocated by FCC
Choose the type of transceiver
Transceiver programming
Delivery
Are you using the speaker microphone?
A personal computer (IBM PC or compatible), programming
interface (KPG-22), and programming software (KPG-87D)
are required for programming.
(The frequency, TX power HI/LOW, and signalling data are programmed
for the transceiver.)
YES
NO
KMC-17 or KMC-21
Speaker microphone
(Option)
Are you using the optional antenna? YES
NO
KRA-22 or KRA-26
Optional antenna
TX/RX 136~174 5.0W
TK-2202 (K,M)
TK-2206 (M)
Frequency range (MHz) RF power Type
Unit
Model TX-RX Unit Frequency range Remarks
& destination
TK-2202 K,M X57-6870-20 136~174MHz IF1 : 38.85MHz
TK-2206 MLOC : 38.4MHz
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced technicians
familiar with similar types of commercial grade communications
equipment. It contains all required service information for the
equipment and is current as of the publication date. Changes
which may occur after publication are covered by either Service
Bulletins or Manual Revisions. These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment information,
the full part identification number should be included. This
applies to all parts, components, kits, or chassis. If the part
number is not known, include the chassis or kit number of
which it is a part, and a sufficient description of the required
component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
●DO NOT transmit until all RF connectors are verified secure
and any open connectors are properly terminated.
●SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
●This equipment should be serviced by a qualified technician
only.
SERVICE
This radio is designed for easy servicing. Refer to the
schematic diagrams, printed circuit board views, and alignment
procedures contained within.

TK-2202/2206
3
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode Received commands from PC
Clone mode
[PTT]+[Side2]+Power ON (Two seconds)
Mode Function
User mode For normal use.
PC mode Used for communication between the
radio and PC (IBM compatible).
Data programming Used to read and write frequency data
mode and other features to and from the radio.
PC test mode Used to check the radio using the PC.
This feature is included in the KPG-
87D.
Clone mode Used to transfer programming data
from one radio to another.
REALIGNMENT
1. Modes
User mode
PC mode
PC test mode
Data programming
mode
PC tuning mode
REALIGNMENT
3. PC Mode
3-1. Preface
The TK-2202/2206 transceivers are programmed using a
personal computer, a programming interface (KPG-22) and
programming software (KPG-87D).
The programming software can be used with an IBM PC
or compatible. Figure 1 shows the setup of an IBM PC for
programming.
3-2. Connection procedure
1. Connect the TK-2202/2206 to the personal computer with
the interface cable.
2. When the POWER is switched on, user mode can be
entered immediately. When the PC sends a command,
the radio enters PC mode.
When data is transmitting from the transceiver, the red
LED lights.
When data is received by the transceiver, the green LED
lights.
Notes:
•The data stored in the personal computer must match the
model type when it is written into the EEPROM.
•Change the TK-2202/2206 to PC mode, then attach the
interface cable.
3-3. KPG-22 description
(PC programming interface cable: Option)
The KPG-22 is required to interface the TK-2202/2206 with
the computer. It has a circuit in its D-subconnector (25-pin)
case that converts the RS-232C logic level to the TTL level.
The KPG-22 connects the SP/MIC connector of the TK-2202/
2206 to the computer’s RS-232C serial port.
3-4. Programming software description
KPG-87D is the programming software for TK-2202/2206
supplied on a CD-ROM. This software runs under Windows
98, ME, Windows 2000 or XP on an IBM-PC or compatible
machine.
The data can be input to or read from TK-2202/2206 and
edited on the screen. The programmed or edited data can be
printed out. It is also possible to tune the transceiver.
Tuning cable
(E30-3216-05)
RF Power meter
or SSG
Gray +
Gray/Black –
1.5D-XV Lead wire +
1.5D-XV Shield wire –
}
}SP
MIC
KPG-22
KPG-87D
IBM-PC
Fig. 1
Clone mode
4. Clone Mode
4-1. Outline
"Clone Mode" copies the transceiver data to another
transceiver.
The dealer can copy the transceiver data to another
transceiver even without the use of a personal computer.
4-2. Example
The transceiver can copy the programming data to one or
more transceivers via RF communication.
The clone master and clone slave/s must be in Clone mode.
4-3. Operation
1. To switch the clone slave/s to Clone mode, press and hold
the [PTT] and [side2] keys while turning the transceiver
power ON.
2. Wait for 2 seconds. The LED will light orange and the
transceiver will announce "Clone".
3. Select a channel table number using Side1(increment
channel table) and Side2(decrement channnel table) keys.

TK-2202/2206
4
Clone Frequency Table
Operating Frequency
Clone (MHz) 136~174
Frequency Table
4. To switch the clone master to Clone mode, press and hold
the [PTT] and [side2] keys while turning the transceiver
power ON.
5. Wait for 2 seconds. The LED will light orange and the
transceiver will announce "Clone".
6.
Select the same channel table number as the clone slave/s.
7. Press [PTT] on the clone master to begin data transmission.
When the clone slave starts to receive data, the LED will
light green.
When the clone master finishes sending data, a
"confirmation" tone will sound.
If data transmission fails while cloning, an "error" tone will
sound from the Slave unit.
8. If the cloning fails, no data will be available in the Slave unit
when it is returned to User mode.
9. When the cloning is successful, the Slave unit's "Scan" and
"Key lock" functions will return to their default values (Scan
= OFF, Key lock = OFF).
Notes:
•The dealer can clone data to two or more transceivers by
repeating the above procedures.
•If the transceivers Clone Mode is configured as "Disabled",
the transceiver cannot enter Clone mode.
•The table shown below will cover the frequency tables used
for wireless cloning.
•Clone mode cannot be entered in battery low state.
•Aunit cannot be a "Master Unit" if it is unprogrammed. If
[PTT] is pressed, an "error" tone will sound.
•The language used in cloning depends on the "Model type"
setting, not the FPU setting. C, C2, C5 and C6 type
TK-3207 transceivers will use Chinese. Other types English.
•Once a unit is set to be the Master, it cannot be a slave
after the data has been transmitted. This protects the data
in the Master unit.
•Electronic interface may cause a failure in data transfer
during Wireless Clone, such as when waveforms or
electromagnetics are being performed at the workbench.
•Clonemodecanbe used ONLY by the authorized service
personnel.
•The Clone mode setting must be configured as "Disable"
before being delivered to the end-user.
•To clone, replace the antenna from both the master
transceiver and the slave transceiver with a dummy
load.
•The transmit output power is automatically set to Low
in Clone mode.
REALIGNMENT
1136.000
2138.000
3140.000
4142.000
5144.000
6146.000
7148.000
8150.000
9152.000
10 154.000
11 156.000
12 158.000
13 160.000
14 162.000
15 164.000
16 166.000
17 168.000
18 170.000
19 172.000
20 174.000

TK-2202/2206
5
DISASSEMBLY FOR REPAIR
■Removing the case assembly from the chassis.
1. Remove the volume knob z and channel knob x.
2. Remove the two screws c.
3. Lift and remove the chassis from the case assembly v.
(Use a flat-blade screwdriver to easily lift the chassis.)
■Removing the TX-RX unit from the chassis.
1. Remove the packing bfrom the SP / MIC jack of the TX-
RX unit.
2. Remove the eleven screws nfixing the TX-RX unit.
3. Remove the fixing bracket mof the SP / MIC.
4. Remove the solder of the antenna terminal with a soldering
iron ,.
5. Remove the solder of the positive terminal with a soldering
iron ..
Note: You can remove the TX-RX unit from the chassis without
removing the solder at the positive terminal. However,
in this case, you can not attach the packing (G53-1605-
03) that is on the positive terminal to the chassis in
assembling. So, it is advisable to remove the solder on
the positive terminal first.
6. Remove the FPC from the flat cable connector /.
7. Lift and remove the TX-RX unit from the chassis Ω.
1
3
3
4
2
9
666
66
11
5
6
6
6
7
8
10
■Removing the battery release lever from the case
assembly.
1. Press the upper part of the lever toward the inside of the
case assembly. One side of the shaft will be removed z.
2. Lift and remove the battery release lever from the case
assembly x.
■Attaching the battery release lever to the case
assembly.
1. Insert one side of the shaft into the hole at the lever fitting
section on the case assembly z.
Caution : The thin spring (G01-4543-04) should be positioned
above the two tabs of the lever.
2. Tilt the battery release lever slightly forward x, so that the
thick spring (G01-4542-04) is positioned below the case
surface.
3. With the thick spring positioned below the case surface,
attach the other side of the shaft to the case assembly by
pressing the battery release lever cuntil it snaps into place
v.
Caution : Be careful not to tilt the battery release lever too
forward.
If the battery release lever is pushed in this state
where the two tabs come below the case surface,
there is a possibility of damaging the two tabs.
2
1
1
3
2
4
A thin spring
Shaft
Two tabs
A thick spring

TK-2202/2206
6
■Cautions for assembly
1. Attaching the positive terminal to the chassis.
Always attach the positive terminal to the chassis, using
the following procedures, before mounting the TX-RX unit
onto the chassis.
1. Remove the holder assembly xfrom the packing zof
the positive terminal.
2. Mount the packing of the positive terminal into the chassis
hole c.
3. Mount the holder assembly into the packing of the positive
terminal v.
DISASSEMBLY FOR REPAIR
■Assembling the battery release lever
1. Place the lever xonto the stopper z.
2. Place the thick spring conto the lever.
3. Hook the right and left ends of the thin spring vonto the
tabs of the stopper, then place the thin spring onto the
lever b.
4. Slide the shaft through the hole of the stopper and lever
n.
2
1
3
4
2. Mounting the chassis to the case assembly.
1. Confirm that the waterproof packing attached to the
circumference of the chassis is securely inserted in the
groove of the chassis z.
2. Attach the speaker to the speaker recess of the case
assembly x. Make sure the speaker is securely inserted.
4
5
3
1
6
2
3. Insert the upper part of the chassis into the case assembly
c.
Caution: Take care that the speaker lead wire is not caught
by the microphone element.
4. Press the chassis vand the case assembly together to
attach them.
Caution: If the packing of the SP / MIC does not come to the
correct position after attaching the chassis to the
case assembly, reposition the packing with your
fingers.
Confirm that the
waterproof packing is
securely inserted in the
groove of the chassis.
1
2
3
4
4

TK-2202/2206
7
3. Attaching the antenna receptacle to the
chassis.
Screw the antenna receptacle to the chassis in the order
shown in the drawing so that the antenna receptacle comes
to the center of the case hole.
Tighten this screw first.
Tighten this screw second.
DISASSEMBLY FOR REPAIR
4. The nuts of the volume knob and channel
knob
Note that the shapes, colors and heights of nuts of the
volume knob and channel knob are different from one
another. (The nut of volume knob is silver, and the nut of
channel knob is gold)
Use the following jig when removing the nuts of the
volume knob and channel knob.
●Jig (Part No. : W05-1012-00)
Volume Knob
(Silver) Channel Knob (Gold)

TK-2202/2206
8
5) Audio Amplifier Circuit
The demodulated signal from IC201 goes to AF amplifier
through IC301.
The signal then goes through an AF volume control , and
is routed to an audio power amplifier (IC302) where it is
amplified and output to the speaker.
Fig. 3 Wide/Narrow switching circuit
CIRCUIT DESCRIPTION
1. Frequency Configuration
The receiver utilizes double conversion. The first IF is 38.85
MHz and the second IF is 450 kHz. The first local oscillator
signal is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the necessary
frequencies. Fig. 1 shows the frequencies.
Fig. 1 Frequency configuration
1) Front End (RF AMP)
The signal coming from the antenna passes through the
transmit/receive switching diode circuit, (D103,D104,D105
and D106) passes through a BPF (L214 and L213), and is
amplified by the RF amplifier (Q205).
The resulting signal passes through a BPF (L209 and L211)
and goes to the mixer. These BPFs are adjusted by variable
capacitors (D203,D204,D205 and D206). The input voltage
to the variable capacitor is regulated by voltage output from
the microprocessor (IC405).
2) First Mixer
The signal from the front end is mixed with the first local
oscillator signal generated in the PLL circuit by Q1 to
produce a first IF frequency of 38.85 MHz.
The resulting signal passes through the XF201 MCF to cut
the adjacent spurious and provide the opitimun
characteristics, such as adjacent frequency selectivity.
Fig. 2 Receiver section
2. Receiver
The frequency configuration of the receiver is shown in Fig. 2.
3) IF Amplifier Circuit
The first IF signal is passed through a four-pole monolithic
crystal filter (XF201) to remove the adjacent channel signal.
The filtered first IF signal is amplified by the first IF amplifier
(Q203) and then applied to the lF system IC (IC201). The
IF system IC provides a second mixer, second local
oscillator, limiting amplifier, quadrature detector and RSSI
(Received Signal Strength Indicator). The second mixer
mixes the first IF signal with the 38.4MHz of the second
local oscillator output (TCXO X1) and produces the second
IF signal of 450kHz.
The second IF signal is passed through the ceramic filter
(CF201) to remove the adjacent channel signal. The filtered
second IF signal is amplified by the limiting amplifier and
demodulated by the quadrature detector with the ceramic
discriminator (CD201). The demodulated signal is routed
to the audio circuit.
4) Wide/Narrow Switching Circuit
Narrow and Wide settings can be made for each channel
by switching the demodulation level.
The WIDE (low level) and NARROW (high level) data is
output from IC405, pin 45.
When a WIDE (low level) data is received, Q202 turn on.
WhenaNARROW (high level)data is received,Q202 turn off.
Q202 turns on/off with the Wide/Narrow data and the
IC201 detector output level is switched to maintain a
constant output level during wide or narrow signals.
SP
BPF
IC301 IC302
AF PA
IC201
IF,MIX,DET
ANT
AQUA
CF201
TCXO
TUNE
Q1
X3 multiply
TUNE
ANT SW
BPF MCF
1st Local
RF AMP
Q205 MIXER
Q204 XF201 IF AMP
Q203
AF VOL
X1
12.8MHz
2nd Local
Q202
L : Wide
H: Narrow
C214
RX_W/N
(IC405)
R211
R213 CD201
QUAD
IC201
FM IF SYSTEM
5R
AFOUT
Q203
IFOUT
SP
TX: 136 ~ 174MHz
(TK-2202(K,M) TK-2206(M))
PLL
VCO
IF SYSTEM
ANT
TCXO
X3 multiply
38.85MHz
MCF AF
AMP
MIC
MIC
AMP
TX
AMP RF
AMP
38.4MHz
CF
450kHz
RX: 174.85 ~ 212.85MHz
(TK-2202(K,M) TK-2206(M))
TX/RX: 136 ~ 174MHz (TK-2202(K,M) TK-2206(M))
12.8MHz
RF
AMP
ANT SW
1/2

TK-2202/2206
9
CIRCUIT DESCRIPTION
6) Squelch
Part of the AF signal from the IC enters the FM IC (IC201)
again, and the noise component is amplified and rectified
by a filter and an amplifier to produce a DC voltage
corresponding to the noise level.
The DC signal from the FM IC goes to the analog port of
the microprocessor (IC405). IC405 determines whether
to output sounds from the speaker by checking whether
the input voltage is higher or lower than the preset value.
To output sounds from the speaker, IC405 sends a high
signal to the SP MUTE line and turns IC302 on through
Q303,Q304,Q305,Q306 and Q316. (See Fig. 4)
7) Receive Signalling
(1) QT/DQT
The output signal from FM IC(IC201) enters the
microprocessor(IC405) through IC301. IC405 determines
whether the QT or DQT matches the preset value, and
controls the SP MUTE and the speaker output sounds
according to the squelch results.
(2) MSK (Fleet Sync)
The MSK input signal from theFM IC goes to pin 31 of IC 301.
The signal is demodulated by MSK demodulator in IC 301.
The demodulated data goes to the CPU for processing.
3) Unlock Detector
If a pulse signal appears at the LD pin of IC1, an unlock
condition occurs, and the DC voltage obtained from C4,R5
and D1 causes the voltage applied to the microprocessor
to go low. When the microprocessor detects this condition,
the transmitter is disabled, ignoring the push-to-talk switch
input signal.
4. Transmitter System
1) Microphone Amplifier
The signal from the microphone passes through the IC301.
When encoding DTMF, it is turned OFF for muting the
microphone input signal by IC301.
The signal passes through the Audio processor (IC301) for
the maximum deviation adjustment, and goes to the VCO
modulation input.
RECEIVE SIGNALLING
RECEIVE SIGNALLING
SP
Q306,316
SW
IF Amp
FM IF IC201 IC301
IC302
AF PA
IC405
Q303,304,305
SW
QT/DQT
DTMF
CLK,DATA,
STD,LOADN
SIGNAL
CPU
AQUA
AF CONT
QT/DQT IN
BUSY
Fig. 4 AF amplifier and squelch
(3) DTMF
The DTMF input signal from the FM IC (IC201) goes to
IC301. The decoded information is then processed by the
CPU.
3. PLL Frequency Synthesizer
The PLL circuit generates the first local oscillator signal for
reception and the RF signal for transmission.
1) PLL
Thefrequencystep of the PLL circuit is 2.5,5,6.25or 7.5kHz.
A 12.8MHz reference oscillator signal is divided at IC1 by a
fixed counter to produce an oscillator (VCO) output signal
which is buffer amplified by Q2 then divided in IC1 by a
programmable counter. The divided signal is compared in
phase with the 5 or 6.25kHz reference signal from the phase
comparator in IC1. The output signal from the phase
comparator is filtered through a low-pass filter and passed
to the VCO to control the oscillator frequency. (See Fig. 5)
2) VCO
The operating frequency is generated by Q4 in transmit
mode and Q3 in receive mode. The oscillator frequency is
controlled by applying the VCO control voltage, obtained
from the phase comparator, to the varactor diodes (D4 and
D7 in transmit mode and D5 and D9 in receive mode). The
RX pin is set high in receive mode causing Q5 turn on.
The TX pin is set high in transmit mode. The outputs from
Q3 and Q4 are amplified by Q6 and sent to the RF amplifiers.
PLL DATA
X1
12.8MHz
REF OSC
1M
1N
PLL IC IC1
PHASE
COMPARATOR CHARGE
PUMP
LPF
5kHz/6.25kHz
D4, 7
D5, 9
Q4
TX VCO
Q3
RX VCO
Q6
BUFF AMP IC2
1/2
Q2
BUFFER
Q5, 7
T/R SW
5kHz/6.25kHz
LPF
RX
TX
Fig. 5 PLL circuit

TK-2202/2206
10
CIRCUIT DESCRIPTION
Fig. 6 Microphone amplifier
Fig. 7 Drive and final amplifier and APC circuit
3) APC Circuit
The APC circuit always monitors the current flowing through
the RF power amplifier (Q106) and keeps a constant current.
The voltage drop at R127, R128 and R129 is caused by the
current flowing through the RF power amplifier and this
voltage is applied to the differential amplifier IC101(1/2).
IC101(2/2) compares the output voltage of IC101(1/2) with
the reference voltage from IC405. The output of IC101(2/2)
controls the VG of the RF power amplifier, drive amplifier
and pre-drive amplifier to make both voltages the same.
The change of power high/low is carried out by the change
of the reference voltage.
4) Encode Signalling
(1) QT/DQT
QT,DQT data of the QTTCXO Line is output from pin 28 of
the CPU. The signal passes through a low-pass CR filter
and goes to the TCXO(X1).
2) Drive and Final Amplifier
The signal from the T/R switch (D101 is on) is amplified by
thepre-drive(Q102)andthe drive amplifier (Q103) to 50mW.
Theoutputof the drive amplifier is amplified by theRFpower
amplifier (Q106) to 5.0W (1W when the power is low). The
RF power amplifier consists of two MOS FET stages. The
output of the RF power amplifier is then passed through
the harmonic filter (LPF) and antenna switch (D103 and
D104) and applied to the antenna terminal.
From
T/R SW
(D101) DRIVE
AMP RF
POWER AMP LPF
ANT
SW
D103
D104
AN
T
VGVGVD
Q103 Q106
Pre-DRIVE
AMP
Q102
VDD
5T
R127
R128
R129
+B
IC101
(2/2)
IC101
(1/2)
PCTV
(IC405)
IC301
IC405
LPF
DTMF
QTTCXO
QTVCO
CPU
AGC
VCO
MIC
X1
TCXO
LPF
LPF
AQUA
The QT,DQT data of the QTVCO Line is output from pin 24
of the CPU. The signal passes through a low pass CR filter,
mixeswiththe audio signal, and goes to theVCOmodulation
input. TX deviation is adjusted by the CPU.
(2) DTMF
High-speed data is output from pin 2 of the CPU. The signal
passes through a low-pass CR filter, and provides a TX and
SP out tone, and is then applied to the audio processor
(IC301). The signal is mixed with the audio signal and goes
to the VCO.
TX deviation is adjusted by the CPU.
(3) MSK (Fleet Sync)
Fleet Sync utilizes 1200bps and 2400bps MSK signal is
output from pin 6 of IC301. And is routed to the VCO.
When encoding MSK, the microphone input signal is muted.
5. Power Supply
There are four 5V power supplies for the microprocessor:
5M,5C,5R, and 5T. 5M for microprocessor is always output
while the power is on. 5M is always output, but turns off when
the power is turned off to prevent malfunction of the
microprocessor.
5C is a common 5V and is output when SAVE is not set to
OFF.
5R is 5V for reception and output during reception.
5T is 5V for transmission and output during transmission.
6. Control Circuit
The control circuit consists of a microprocessor (IC405) and
its peripheral circuits. It controls the TX-RX unit. IC405 mainly
performs the following:
(1) Switching between transmission and reception by the
PTT signal input.
(2) Reading system, group, frequency, and program data
from the memory circuit.
(3) Sending frequency program data to the PLL.
(4) Controlling squelch on/off by the DC voltage from the
squelch circuit.
(5) Controllingthe audio mutecircuitby the decodedatainput.
(6) Transmitting tone and encode data.
1) Frequency Shift Circuit
The microprocessor (IC405) operates at a clock of
7.3728MHz. This oscillator has a circuit that shifts the
frequency by BEAT SHIFT SW (Q407,Q408).
A beat sound may be able to be evaded from generation if
“Beat Shift” is set to ON when it is generated in the internal
spurious transmission modulated sound of a transceiver.

TK-2202/2206
11
Fig. 11 Control system
CIRCUIT DESCRIPTION
Channel selector
CPU
IC405
SIDE 2
EN4
EN3
EN2
EN1
47
48
49
50
PTT PTT
SW
SIDE 1
27
74
75
SW1
SW2
EN5
46
X2 XOUT
IC405
Q407
Q408
Hi: OFF
LOW: ON BSHIFT
Fig. 8 Frequency shift circuit
Fig. 9 Memory circuit
IC405
CPU
IC406
EEPROM
SB R404
R406
88
IC405
CPU
Fig. 10 Low battery warning
2) Memory Circuit
Memory circuit consists of the CPU (IC405) and an EEPROM
(IC406). An EEPROM has a capacity of 64k bits that contains
the transceiver control program for the CPU and data such
as transceiver channels and operating features.
3) Low Battery Warning
The battery voltage is checked using by the microprocessor.
Thetransceivergenerates a warning tone when itfallsbelow
the warning voltage shown in the table.
(1)The red LED blinks when the battery voltage falls below
the voltage (1) shown in the table during transmission.
Note:
The transceiver checks the battery voltage during reception
even when, in the FPU, the Battery Warning status function
is set to “On TX” (default setting).
However, the LED does not blink during reception. During
transmission, the LED blinks to generate the warning tone
of a low battery voltage.
(2)The transceiver immediately stops transmission when
the battery voltage falls below the voltage (2) shown in
the table. A message tone beeps while the PTT switch
is released.
7. Control System
Keys and channel selector circuit.
The signal from the keys and channel selector are directly
input to the microprocessor, as shown in fig. 11.
Ni-Cd Battery Ni-MH Battery
(1) 6.2[V] 6.2[V]
(2) 5.9[V] 5.9[V]

TK-2202/2206
12
Microprocessor : 30622MAA-B89GP (TX-RX UNIT : IC405)
■Pin function
1PCTV O APC/BPF control data output
2DTMF O DTMF/ Beep output
3NC -NC
4EEPDAT I/O EEPROM data input/output
5EEPCLK O EEPROM clock output
6BYTE - GND
7GND - GND
8BSHIFT O Beat shift switch
9NC -NC
10 RESET I CPU reset
11 XOUT O CPU clock (7.3728MHz)
12 VSS - GND
13 XIN I CPU clock (7.3728MHz)
14-15 VCC - +5V
16 INT I Battery voltage monitor input
17 TCLK/DTRDO I Base band IC data input
18 RDF/FD I Base band IC data input
19 SCLK O Base band IC clock output
20 D I/O I/O Base band IC data input / output
21 TDATA/DTRCLK O Base band IC data output
22 DIR O Base band IC data output
23 STD I Base band IC data input
24 QT VCO O QT/DQT output
25 DTRLOADN O Base band IC data output
26 1/2 OSC O 3.6864 MHz (7.3728 MHz/2)
27 PTT I PTT switch input
28 QT TCXO O QT/DQT output
29 TXD O Serial data (FPU/FLASH)
30 RXD I Serial data (FPU/FLASH)
31 GND - GND
32 APCSW O APC switch
33-34 NC - NC
35 DCSW O APC voltage discharge switch
36 TX_W/N O TX Wide/Narrow switch
37 RX_SW O RX VCO switch
38 TX_SW O TX VCO switch
39 GND - GND
40 PLL_UL I PLL unlock detect input
41 PLL_STB O PLL strobe output
42 PLL_DAT O PLL data output
43 PLL_CLK O PLL clock output
Pin Port Name I/O Function
No. Pin Port Name I/O Function
No.
44 VCC - +5V
45 RX_W/N O RX Wide/Narrow switch
46 EN5 I Channel selector input
47 EN4 I Channel selector input
48 EN3 I Channel selector input
49 EN2 I Channel selector input
50 EN1 I Channel selector input
51 OPTDET I Headset input detect
52 AF_CONT O Speaker mute
53-59 NC - NC
60 VCC - +5V
61 NC - NC
62 VSS - GND
63-64 GND - GND
65-71 NC - NC
72 LEDTX O Red LED lights control output
73 LEDRX O Green LED lights control output
74 PF1 I SIDE1 key input
75 PF2 I SIDE2 key input
76 SIM1 - GND
77 SIM2 - GND
78-79 NC - NC
80 5T_C O 5T control output
81 5R_C O 5R control output
82 5C_C O 5C control output
83-87 NC - NC
88 BATT I Battery voltage input
89 RSSI I Received Signal Strength
Indicator input
90 BUSY I Busy level input
91 VOX I VOX level input
92 QT/DQT_IN I QT/DQT input
93 TH_DET I Thermistor input
94 AVSS - GND
95 NC - NC
96 VREF - +5V
97 AVCC - +5V
98 NC - NC
99 MIC_MUTE O MIC mute
100 NC - NC
■CN401
1B IB(Battery Voltage)
2SBOSwitched B
3SP1 I Audio input
4SP2 O Audio output
5GND - GND
6EN1 I Encoder pulse input
Pin
Name I/O Function
No. Pin
Name I/O Function
No.
7EN2 I Encoder pulse input
8GND - GND
9EN3 I Encoder pulse input
10 EN4 I Encoder pulse input
11 EN5 I Encoder pulse input
SEMICONDUCTOR DATA
TERMINAL FUNCTION / SEMICONDUCTOR DATA
TERMINAL FUNCTION

TK-2202/2206
13
COMPONENTS DESCRIPTION
IC1 IC PLL system
IC2 IC VCO 1/2 Divider
IC101 IC Comparator (APC)
IC201 IC FM IF system
IC301 IC Audio processor
IC302 IC AF AMP
IC401 IC Voltage regulator/ 5V
IC402 IC Voltage regulator/ 5V
IC403 IC Voltage detector / Reset
IC404 IC Voltage detector / INT
IC405 IC Microprocessor
IC406 IC EEPROM
Q1 Transistor Tripler
Q2 Transistor PLL IC f_in AMP
Q3 FET VCO / RX
Q4 FET VCO / TX
Q5 Transistor DC switch / TX VCO
Q6 FET RF Buffer AMP
Q7 Transistor DC switch / RX VCO
Q8 FET Ripple filter
Q9 Transistor RF AMP
Q102 Transistor RF AMP
Q103 FET TX Drive AMP
Q104 Transistor APC switch
Q105 FET APC switch
Q106 FET TX Final AMP
Q107 Transistor APC switch
Q108 FET APC switch
Q109 Transistor APC switch
Q202 Transistor W/N switch / RX
Q203 Transistor IF AMP
Q204 FET Mixer
Q205 FET RF AMP
Q301 Transistor W/N switch / TX
Q302 Transistor MIC AGC
Q303 Transistor DC switch / SP Mute
Q304 Transistor DC switch
Q305 Transistor DC switch / SP Mute
Q306 FET SP Mute switch
Q316 FET SP Mute switch
Q401 Transistor LED switch / Red
Q402 Transistor LED switch / Green
Q403 FET 5T switch
Q404 FET 5R switch
Q405 Transistor 5C switch
Q407 FET Beat Shift switch
Q408 FET Beat Shift switch
Ref. No. Use/Function Operation/Condition
TX-RX UNIT (X57-6870-20) Ref. No.
Use/Function Operation/Condition
D1 Diode Ripple Filter
D4
Variable
Frequency control / TX VCO
capacitance diode
D5
Variable
Frequency control / RX VCO
capacitance diode
D7
Variable
Frequency control / TX VCO
capacitance diode
D9
Variable
Frequency control / RX VCO
capacitance diode
D10
Variable
Modulator
capacitance diode
D11 Diode Current steering
D101 Diode TX/RX RF switch
D102 Zener diode APC protect
D103 Diode ANT switch
D104 Diode ANT switch
D105 Diode ANT switch
D106 Diode ANT switch
D202 Diode TX/RX RF switch
D203
Variable
RF BPF tuning
capacitance diode
D204
Variable
RF BPF tuning
capacitance diode
D205
Variable
RF BPF tuning
capacitance diode
D206
Variable
RF BPF tuning
capacitance diode
D301 Diode Detector
D302 Diode Detector
D303 Diode Isolation
D401 Diode 5V Protection
D402 Diode Reverse Protection
D403 LED LED/ Red
D404 LED LED/ Green
Ref. No. Use/Function Operation/Condition
Q901 FET W/N Switch/ TX
ADDITIONAL PCB

TK-2202/2206 PARTS LIST
14
∗New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
Parts No. Description Address New
parts
Destination Destination
TK-2202/2206
Ref. No. Parts No. Description
Address New
parts
TK-2202/2206 (Y50-5890-XX)
TX-RX UNIT (X57-6870-20)
Ref. No.
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
11A∗A02-3851-23 CABINET ASSY(16CH) BM
11A∗A02-3852-23 CABINET ASSY(8CH) AK,AM
21A∗A02-3858-13 CABINET
33A∗A10-4078-01 CHASSIS
41B∗A21-1644-13 DRESSING PANEL(16CH) BM
41B∗A21-1645-13 DRESSING PANEL(8CH) AK,AM
62C,2E ∗B09-0680-03 CAP(SP/MIC) ACCESSORY
72B∗B11-1817-04 ILLUMINATION GUIDE
81B∗B43-1156-04 BADGE
91C∗B62-1762-00 INSTRUCTION MANUAL AK,AM
10 1E ∗B62-1763-00 INSTRUCTION MANUAL BM
11 1A ∗D10-0649-03 LEVER
12 1A ∗D21-0863-04 SHAFT
13 1A ∗D32-0441-03 STOPPER
14 2A ∗E04-0451-05 RF COAXIAL RECEPTACLE(SMA)
15 3B ∗E23-1253-04 TERMINAL(BATT-)
16 2B E37-0794-05 PROCESSED LEAD WIRE(SP+)
17 2B E37-0803-05 PROCESSED LEAD WIRE(SP-)
18 3A ∗F20-3353-14 INSULATING SHEET(CHASSIS BATT+)
19 2A ∗G01-4542-04 COIL SPRING(LEVER)
20 1A ∗G01-4543-04 COIL SPRING(STOPPER)
21 2B ∗G10-1330-04 FIBROUS SHEET(IC302:AUDIO IC)
22 3A ∗G11-4283-04 RUBBER SHEET(Q106:FINAL FET)
23 2A ∗G11-4313-04 SHEET(MIC ELEMENT)
24 3B ∗G11-4318-04 SHEET
25 3A ∗G11-4320-14 SHEET
26 2B,3B ∗G11-4322-04 SHEET
27 2A ∗G11-4323-04 SHEET
29 3B ∗G13-2009-04 CUSHION(TERMINAL BATT-)
30 3A ∗G13-2033-04 CUSHION(TERMINAL BATT-)
31 3B ∗G13-2034-14 CUSHION(CHASSIS)
32 2B ∗G13-2037-04 CUSHION(CHASSIS VOL/CH)
33 3A ∗G13-2038-04 CUSHION(CHASSIS-CERAMIC FILTER)
34 2A ∗G13-2039-04 CUSHION(PCB-CERAMIC FILTER)
35 3A ∗G53-1604-03 PACKING(CHASSIS)
36 3A ∗G53-1605-03 PACKING(TERMINAL BATT+)
37 2B ∗G53-1606-03 PACKING(VOL/CH/LED)
38 1B ∗G53-1607-03 PACKING(SP/MIC)
39 2B ∗G53-1608-03 PACKING(SP)
40 2A ∗G53-1609-14 PACKING(MIC ELEMENT)
41 2B ∗G53-1610-04 PACKING(SMA)
43 2C,2F ∗H12-3158-05 PACKING FIXTURE
44 1D ∗H13-2109-03 CARTON BOARD AK,AM
45 1C,1E H25-0085-04 PROTECTION BAG (100/200/0.07)
46 3D ∗H52-2017-02 ITEM CARTON CASE AK,AM
47 3F ∗H52-2034-02 ITEM CARTON CASE BM
48 2C,2F ∗J19-5472-03 HOLDER(SP/MIC) ACCESSORY
49 2A ∗J19-5473-03 HOLDER ASSY(TERMINAL BATT+)
50 2B ∗J21-8477-04 HARDWARE FIXTURE(VOL/CH)
51 2B ∗J21-8478-04 HARDWARE FIXTURE(SP/MIC)
52 2C,2F ∗J29-0713-05 BELT CLIP ACCESSORY
54 2B ∗J82-0092-05 FPC
56 1A ∗K29-9307-03 BUTTON KNOB(SIDE1/SIDE2)
57 1A ∗K29-9308-03 BUTTON KNOB(PTT)
58 1B ∗K29-9309-03 KNOB(VOL)
59 1B ∗K29-9318-03 KNOB(CH)
A2B∗N14-0808-04 CIRCULAR NUT(CH KNOB)
B2B∗N14-0812-04 CIRCULAR NUT(VOL KNOB)
C2A,2B N30-2604-46 PAN HEAD MACHINE SCREW(SMA)
D3AN30-2606-46 PAN HEAD MACHINE SCREW
(CHASSIS)
E 2A,2B,3B N83-2005-46 PAN HEAD TAPTITE SCREW(PCB)
60 1C,2F ∗N99-2043-05 SCREW SET ACCESSORY
61 2B ∗R31-0653-05 VARIABLE RESISTOR(POWER SW/VOL)
62 2B ∗S60-0427-05 ROTARY SWITCH(16CH) BM
62 2B ∗S60-0428-15 ROTARY SWITCH(8CH) AK,AM
63 1B T07-0369-05 SPEAKER
64 1C T90-1036-05 HELICAL ANTENNA ACCESSORY AK,AM
65 2D ∗W08-0969-05 CHARGER ACCESSORY AK,AM
66 1D ∗W08-0970-05 AC ADAPTER(AC120V) ACCESSORY AK
66 1D ∗W08-0971-05 AC ADAPTER(AC230V) ACCESSORY AM
D403 B30-2156-05 LED(RED)
D404 B30-2157-05 LED(YELLOW)
C1 CK73HB1H332K CHIP C 3300PF K
C2 CK73HB1C682K CHIP C 6800PF K
C3 CK73GB1A105K CHIP C 1.0UF K
C4 CK73HB1C103K CHIP C 0.010UF K
C5 CK73HB1H102K CHIP C 1000PF K
C6 CK73HB1A104K CHIP C 0.10UF K
C7 ,8 CC73HCH1H101J CHIP C 100PF J
C9 CC73HCH1H100D CHIP C 10PF D
C10 C92-0713-05 CHIP-TAN 10UF 6.3WV
C11 CC73HCH1H101J CHIP C 100PF J
C12 CK73HB1H102K CHIP C 1000PF K
C13 CK73HB1A104K CHIP C 0.10UF K
C14 CK73HB1C103K CHIP C 0.010UF K
C15 CC73HCH1H100D CHIP C 10PF D
C16 CK73HB1H102K CHIP C 1000PF K
C17 CC73HCH1H470J CHIP C 47PF J
C18 CC73HCH1H180J CHIP C 18PF J
C19 CK73HB1A104K CHIP C 0.10UF K
C21 C92-0713-05 CHIP-TAN 10UF 6.3WV
C22 C92-0502-05 CHIP-TAN 0.33UF 35WV
C24 CK73HB1H102K CHIP C 1000PF K
C25 CC73HCH1H020B CHIP C 2.0PF B
C26 CC73HCH1H300J CHIP C 30PF J
C27 C92-0697-05 CHIP-TAN 3.3UF 16WV
C29 ,30 CK73HB1H471K CHIP C 470PF K
C32 C92-0001-05 CHIP C 0.1UF 35WV
C33 ,34 CK73HB1H102K CHIP C 1000PF K
C35 CC73HCH1H270J CHIP C 27PF J
TX-RX UNIT (X57-6870-20)

TK-2202/2206
PARTS LIST
15
TX-RX UNIT (X57-6870-20)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
C38 CC73HCH1H060B CHIP C 6.0PF B
C39 CK73GB1H332K CHIP C 3300PF K
C40 CC73HCH1H040B CHIP C 4.0PF B
C41 CK73GB1H682K CHIP C 6800PF K
C42 CC73HCH1H060B CHIP C 6.0PF B
C43 CC73HCH1H150J CHIP C 15PF J
C44 CK73HB1H471K CHIP C 470PF K
C45 CK73GB1A105K CHIP C 1.0UF K
C47 CC73HCH1H101J CHIP C 100PF J
C48 CK73HB1H471K CHIP C 470PF K
C49 CC73HCH1H101J CHIP C 100PF J
C50 CC73HCH1H100D CHIP C 10PF D
C51 CK73HB1H102K CHIP C 1000PF K
C52 CC73HCH1H181J CHIP C 180PF J
C53 CC73HCH1H0R5B CHIP C 0.5PF B
C54 CC73HCH1H040B CHIP C 4.0PF B
C55 CC73HCH1H121J CHIP C 120PF J
C57 CC73HCH1H1R5B CHIP C 1.5PF B
C58 CC73HCH1H060B CHIP C 6.0PF B
C59 CC73HCH1H1R5B CHIP C 1.5PF B
C60 CC73HCH1H010B CHIP C 1.0PF B
C61 CC73HCH1H040B CHIP C 4.0PF B
C62 CC73HCH1H050B CHIP C 5.0PF B
C63 CC73HCH1H101J CHIP C 100PF J
C64 CC73HCH1H040B CHIP C 4.0PF B
C65 -67 CC73HCH1H050B CHIP C 5.0PF B
C68 -70 CK73HB1H471K CHIP C 470PF K
C71 ,72 CK73HB1A104K CHIP C 0.10UF K
C73 ,74 CC73HCH1H0R5B CHIP C 0.5PF B
C75 ,76 CK73HB1H102K CHIP C 1000PF K
C77 CK73HB1H471K CHIP C 470PF K
C78 CC73HCH1H330J CHIP C 33PF J
C79 C92-0713-05 CHIP-TAN 10UF 6.3WV
C80 CK73HB1H471K CHIP C 470PF K
C81 CC73HCH1H150J CHIP C 15PF J
C82 -86 CK73HB1H102K CHIP C 1000PF K
C87 CC73HCH1H100D CHIP C 10PF D
C90 CK73HB1H102K CHIP C 1000PF K
C101 CK73HB1H102K CHIP C 1000PF K
C104 CC73GCH1H390J CHIP C 39PF J
C105 CK73HB1H102K CHIP C 1000PF K
C107 CK73HB1H102K CHIP C 1000PF K
C108 CC73GCH1H390J CHIP C 39PF J
C109 CK73GB1C104K CHIP C 0.10UF K
C110,111 CK73HB1H102K CHIP C 1000PF K
C115 CK73HB1H102K CHIP C 1000PF K
C116 CC73GCH1H220J CHIP C 22PF J
C117 CC73GCH1H100D CHIP C 10PF D
C118 CC73GCH1H101J CHIP C 100PF J
C119 CC73GCH1H270J CHIP C 27PF J
C120 CK73GB1H102K CHIP C 1000PF K
C121 CC73GCH1H100D CHIP C 10PF D
C123 CK73GB1A105K CHIP C 1.0UF K
C124,125 CK73HB1H102K CHIP C 1000PF K
C126 C92-0565-05 CHIP-TAN 6.8UF 10WV
C128 CK73HB1H102K CHIP C 1000PF K
C130 CC73GCH1H100D CHIP C 10PF D
C132 CK73HB1H102K CHIP C 1000PF K
C133 CK73GB1H103K CHIP C 0.010UF K
C134 CK73GB1C104K CHIP C 0.10UF K
C135 CK73GB1A105K CHIP C 1.0UF K
C136 CC73GCH1H270J CHIP C 27PF J
C137 CK73GB1H103K CHIP C 0.010UF K
C138 CK73GB1H102K CHIP C 1000PF K
C139 CC73GCH1H680J CHIP C 68PF J
C140 CC73GCH1H101J CHIP C 100PF J
C141 CC73GCH1H220J CHIP C 22PF J
C142 CC73GCH1H150J CHIP C 15PF J
C143 CC73GCH1H100D CHIP C 10PF D
C144 CC73GCH1H820J CHIP C 82PF J
C146 CK73GB1H102K CHIP C 1000PF K
C147 CK73HB1H102K CHIP C 1000PF K
C148 CK73GB1H102K CHIP C 1000PF K
C149 CC73GCH1H220G CHIP C 22PF G
C150 CC73GCH1H220J CHIP C 22PF J
C151 CK73GB1H102K CHIP C 1000PF K
C153 CC73GCH1H100C CHIP C 10PF C
C154 CC73GCH1H100D CHIP C 10PF D
C155 CC73GCH1H180J CHIP C 18PF J
C156 CC73GCH1H120J CHIP C 12PF J
C157 CC73GCH1H150J CHIP C 15PF J
C158 CC73GCH1H220J CHIP C 22PF J
C159 CC73GCH1H070D CHIP C 7.0PF D
C160 CC73GCH1H330J CHIP C 33PF J
C201 CK73GB1A224K CHIP C 0.22UF K
C206 CK73HB1H102K CHIP C 1000PF K
C207 CK73HB1H182K CHIP C 1800PF K
C208 CK73HB1H471K CHIP C 470PF K
C209 C92-0713-05 CHIP-TAN 10UF 6.3WV
C210 CK73HB1H471K CHIP C 470PF K
C211 CK73HB1C103K CHIP C 0.010UF K
C213 CK73HB1A104K CHIP C 0.10UF K
C214 CC73HCH1H680J CHIP C 68PF J
C215 CK73HB1H102K CHIP C 1000PF K
C216 CK73GB1C104K CHIP C 0.10UF K
C217 CK73HB1A104K CHIP C 0.10UF K
C218 CK73GB1C104K CHIP C 0.10UF K
C219 CC73HCH1H330J CHIP C 33PF J
C220 CK73HB1H102K CHIP C 1000PF K
C221 CK73GB1C104K CHIP C 0.10UF K
C222 CK73HB1H102K CHIP C 1000PF K
C224,225 CK73HB1C103K CHIP C 0.010UF K
C227 CK73HB1H102K CHIP C 1000PF K
C228 CC73GCH1H100C CHIP C 10PF C
C230 CC73HCH1H080B CHIP C 8.0PF B
C231,232 CK73GB1H103K CHIP C 0.010UF K
C233 CC73HCH1H020B CHIP C 2.0PF B
C234 CK73HB1C103K CHIP C 0.010UF K
C235 CC73HCH1H090B CHIP C 9.0PF B
C236 CK73GB1H102K CHIP C 1000PF K
C237 CC73HCH1H050B CHIP C 5.0PF B
C238 CC73GCH1H120J CHIP C 12PF J
C239 CC73HCH1H060B CHIP C 6.0PF B
C241 CK73HB1H102K CHIP C 1000PF K
C242 CK73GB1C104K CHIP C 0.10UF K
C243 CK73HB1H102K CHIP C 1000PF K
C244 CC73HCH1H040B CHIP C 4.0PF B
C245 CK73HB1H471K CHIP C 470PF K
C247 CC73GCH1H040B CHIP C 4.0PF B
C248 CC73GCH1H270J CHIP C 27PF J

TK-2202/2206 PARTS LIST
16
TX-RX UNIT (X57-6870-20)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
C249 CK73HB1H102K CHIP C 1000PF K
C250 CC73GCH1H040B CHIP C 4.0PF B
C251 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C252 CK73HB1H102K CHIP C 1000PF K
C253 CC73GCH1H4R5B CHIP C 4.5PF B
C254 CC73GCH1H270J CHIP C 27PF J
C255 CC73GCH1H4R5B CHIP C 4.5PF B
C256 CK73HB1H102K CHIP C 1000PF K
C258 CK73HB1H102K CHIP C 1000PF K
C260 CK73HB1H102K CHIP C 1000PF K
C262 CK73HB1H102K CHIP C 1000PF K
C263 CC73GCH1H100C CHIP C 10PF C
C264 CC73GCH1H040B CHIP C 4.0PF B
C265 CC73GCH1H330J CHIP C 33PF J
C266 CK73HB1H102K CHIP C 1000PF K
C267,268 CC73GCH1H030B CHIP C 3.0PF B
C269 CC73GCH1H330J CHIP C 33PF J
C270 CC73GCH1H040B CHIP C 4.0PF B
C271 CC73GCH1H110J CHIP C 11PF J
C280 CK73HB1H102K CHIP C 1000PF K
C302 CK73HB1C103K CHIP C 0.010UF K
C304 CK73GB1A224K CHIP C 0.22UF K
C306 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C307,308 CK73HB1A104K CHIP C 0.10UF K
C309 CC73GCH1H820J CHIP C 82PF J
C310 CK73HB1A683K CHIP C 0.068UF K
C311 CK73GB1A105K CHIP C 1.0UF K
C312 CC73GCH1H120J CHIP C 12PF J
C313 CC73GCH1H121J CHIP C 120PF J
C314 CK73HB1A104K CHIP C 0.10UF K
C315 CK73GB1A105K CHIP C 1.0UF K
C316 CK73GB1C104K CHIP C 0.10UF K
C317 CK73HB1A104K CHIP C 0.10UF K
C318 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C319 CC73GCH1H271J CHIP C 270PF J
C320 CK73HB1C103K CHIP C 0.010UF K
C321 CK73GB1A105K CHIP C 1.0UF K
C322 CK73HB1C153K CHIP C 0.015UF K
C323 CC73GCH1H820J CHIP C 82PF J
C324 CC73HCH1H820J CHIP C 82PF J
C325 CK73HB1A104K CHIP C 0.10UF K
C326 CK73HB1H102K CHIP C 1000PF K
C327 CC73HCH1H101J CHIP C 100PF J
C328 CK73HB1H391K CHIP C 390PF K
C329,330 CK73GB1A105K CHIP C 1.0UF K
C331 CK73HB1A104K CHIP C 0.10UF K
C332 CK73HB1H471K CHIP C 470PF K
C333,334 CK73GB1C104K CHIP C 0.10UF K
C335 CC73GCH1H221J CHIP C 220PF J
C336 CK73FB1C474K CHIP C 0.47UF K
C338 CC73GCH1H101J CHIP C 100PF J
C339 C92-0560-05 CHIP-TAN 10UF 6.3WV
C340 CK73GB1C104K CHIP C 0.10UF K
C341 CK73GB1C473K CHIP C 0.047UF K
C342 C92-0560-05 CHIP-TAN 10UF 6.3WV
C343 CK73GB1C473K CHIP C 0.047UF K
C344 CC73GCH1H221J CHIP C 220PF J
C345 C92-0665-05 TANTAL 100UF 6.3WV
C346 CK73GB1H102K CHIP C 1000PF K
C348 CK73HB1H471K CHIP C 470PF K
C351,352 CK73HB1C103K CHIP C 0.010UF K
C354 CK73HB1A104K CHIP C 0.10UF K
C370 CK73HB1A104K CHIP C 0.10UF K
C401 CC73GCH1H471J CHIP C 470PF J
C402 CK73HB1H102K CHIP C 1000PF K
C403 CK73GB1C104K CHIP C 0.10UF K
C405 CC73GCH1H101J CHIP C 100PF J
C407 CK73HB1H102K CHIP C 1000PF K
C409,410 CK73GB1A105K CHIP C 1.0UF K
C411 CK73HB1H102K CHIP C 1000PF K
C415 CK73HB1H471K CHIP C 470PF K
C417 CK73GB1A105K CHIP C 1.0UF K
C418,419 CK73HB1H102K CHIP C 1000PF K
C421 CK73GB1A105K CHIP C 1.0UF K
C426,427 CK73GB1A105K CHIP C 1.0UF K
C428,429 CK73HB1H102K CHIP C 1000PF K
C430 CK73GB1H103K CHIP C 0.010UF K
C431 CK73HB1C103K CHIP C 0.010UF K
C432 CC73HCH1H050B CHIP C 5.0PF B
C433,434 CC73HCH1H030B CHIP C 3.0PF B
C435 CC73HCH1H050B CHIP C 5.0PF B
C440 CC73GCH1H1R5B CHIP C 1.5PF B
C443 CK73GB1A474K CHIP C 0.47UF K
TC1 ,2 C05-0384-05 CERAMIC TRIMMER CAP(10PF)
CN201 E23-1081-05 TERMINAL
CN401 ∗E40-6362-05 FLAT CABLE CONNECTOR
J301 E11-0457-05 PHONE JACK(2.5/3.5)
F401 F53-0190-05 FUSE(2.5A)
67 2A ∗J30-1282-04 SPACER(MIC ELEMENT)
CD201 L79-1582-05 TUNING COIL
CF201 2A L72-0973-05 CERAMIC FILTER(450KHZ)
L1 L40-4791-37 SMALL FIXED INDUCTOR(4.700UH)
L3 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)
L5 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)
L6 ,7 L92-0138-05 FERRITE CHIP
L8 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L9 L40-3375-92 SMALL FIXED INDUCTOR(33NH)
L10 L40-1885-92 SMALL FIXED INDUCTOR(180NH)
L11 L40-1085-92 SMALL FIXED INDUCTOR(100NH)
L12 L92-0138-05 FERRITE CHIP
L13 ,14 L40-2285-92 SMALL FIXED INDUCTOR(220NH)
L16 L40-3978-67 SMALL FIXED INDUCTOR(39NH)
L17 L40-2778-67 SMALL FIXED INDUCTOR(27NH)
L18 ,19 L41-2285-03 SMALL FIXED INDUCTOR
L20 ,21 L40-3391-86 SMALL FIXED INDUCTOR(3.3UH)
L22 L92-0138-05 FERRITE CHIP
L23 L40-3975-92 SMALL FIXED INDUCTOR(39NH)
L24 L92-0141-05 FERRITE CHIP
L25 L40-8275-92 SMALL FIXED INDUCTOR(82NH)
L50 L92-0138-05 FERRITE CHIP
L102 L40-1085-92 SMALL FIXED INDUCTOR(100NH)
L103 L92-0138-05 FERRITE CHIP
L104 L40-2775-92 SMALL FIXED INDUCTOR(27NH)
L105 L40-1585-54 SMALL FIXED INDUCTOR(150NH)
L106 L92-0149-05 FERRITE CHIP
L107 L40-2775-54 SMALL FIXED INDUCTOR(27NH)
L108 L92-0149-05 FERRITE CHIP
L109 L40-2295-85 SMALL FIXED INDUCTOR(2.2UH)

TK-2202/2206
PARTS LIST
17
TX-RX UNIT (X57-6870-20)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
L110 L40-5675-92 SMALL FIXED INDUCTOR(56NH)
L111 L40-1092-81 SMALL FIXED INDUCTOR
L112 L34-4577-05 AIR-CORE COIL
L113 L34-4563-05 AIR-CORE COIL
L114,115 L34-4573-05 AIR-CORE COIL
L116 L34-4576-05 AIR-CORE COIL
L117 L34-4575-05 AIR-CORE COIL
L118 L34-4567-05 AIR-CORE COIL
L119 L34-4566-05 AIR-CORE COIL
L201 L40-1091-37 SMALL FIXED INDUCTOR(1.000UH)
L202 L40-3975-92 SMALL FIXED INDUCTOR(39NH)
L203 L92-0138-05 FERRITE CHIP
L204 L40-5685-85 SMALL FIXED INDUCTOR(0.56UH)
L205 L40-6875-92 SMALL FIXED INDUCTOR(68NH)
L206 L40-1885-92 SMALL FIXED INDUCTOR(180NH)
L207 L40-1585-92 SMALL FIXED INDUCTOR(150NH)
L209 L41-5678-14 SMALL FIXED INDUCTOR
L210 L92-0138-05 FERRITE CHIP
L211 L41-5678-14 SMALL FIXED INDUCTOR
L213 L41-5678-14 SMALL FIXED INDUCTOR
L214 L41-4778-14 SMALL FIXED INDUCTOR
L301 L92-0140-05 FERRITE CHIP
L302 L92-0149-05 FERRITE CHIP
L401 L92-0149-05 FERRITE CHIP
L402-404 L92-0138-05 FERRITE CHIP
X1 L77-1931-05 TCXO(12.8MHZ)
X2 ∗L78-1411-05 RESONATOR(7.37MHZ)
XF201 L71-0619-05 MCF(38.85MHZ)
CP404 RK75HA1J473J CHIP-COM 47K J 1/16W
CP405 RK75HA1J102J CHIP-COM 1.0K J 1/16W
R1 RK73HB1J223J CHIP R 22K J 1/16W
R2 RK73HB1J103J CHIP R 10K J 1/16W
R3 RK73HB1J333J CHIP R 33K J 1/16W
R4 RK73HB1J563J CHIP R 56K J 1/16W
R5 RK73HB1J104J CHIP R 100K J 1/16W
R6 RK73HB1J823J CHIP R 82K J 1/16W
R7 RK73HB1J101J CHIP R 100 J 1/16W
R8 -11 R92-1368-05 CHIP R 0 OHM
R12 RK73HB1J222J CHIP R 2.2K J 1/16W
R13 R92-1252-05 CHIP R 0 OHM J 1/16W
R14 RK73HB1J334J CHIP R 330K J 1/16W
R15 RK73GB1J221J CHIP R 220 J 1/16W
R16 RK73GB1J561J CHIP R 560 J 1/16W
R17 RK73HB1J101J CHIP R 100 J 1/16W
R18 R92-1252-05 CHIP R 0 OHM J 1/16W
R19 RK73GB1J152J CHIP R 1.5K J 1/16W
R20 RK73HB1J100J CHIP R 10 J 1/16W
R21 RK73GB1J681J CHIP R 680 J 1/16W
R22 R92-1252-05 CHIP R 0 OHM J 1/16W
R23 RK73GB1J103J CHIP R 10K J 1/16W
R25 RK73HB1J223J CHIP R 22K J 1/16W
R26 RK73HB1J103J CHIP R 10K J 1/16W
R27 RK73HB1J220J CHIP R 22 J 1/16W
R30 RK73HB1J123J CHIP R 12K J 1/16W
R31 RK73HB1J564J CHIP R 560K J 1/16W
R32 RK73HB1J102J CHIP R 1.0K J 1/16W
R33 RK73HB1J154J CHIP R 150K J 1/16W
R34 RK73HB1J472J CHIP R 4.7K J 1/16W
R35 ,36 RK73HB1J274J CHIP R 270K J 1/16W
R37 RK73HB1J101J CHIP R 100 J 1/16W
R38 RK73HB1J181J CHIP R 180 J 1/16W
R39 RK73HB1J151J CHIP R 150 J 1/16W
R40 RK73HB1J101J CHIP R 100 J 1/16W
R41 RK73HB1J154J CHIP R 150K J 1/16W
R42 RK73HB1J472J CHIP R 4.7K J 1/16W
R43 RK73HB1J101J CHIP R 100 J 1/16W
R44 RK73HB1J102J CHIP R 1.0K J 1/16W
R45 ,46 RK73HB1J332J CHIP R 3.3K J 1/16W
R47 RK73HB1J470J CHIP R 47 J 1/16W
R48 RK73HB1J331J CHIP R 330 J 1/16W
R49 RK73HB1J222J CHIP R 2.2K J 1/16W
R50 RK73HB1J472J CHIP R 4.7K J 1/16W
R51 RK73HB1J100J CHIP R 10 J 1/16W
R101 RK73HB1J123J CHIP R 12K J 1/16W
R103 R92-1252-05 CHIP R 0 OHM J 1/16W
R107 RK73GB1J561J CHIP R 560 J 1/16W
R108 RK73GB1J152J CHIP R 1.5K J 1/16W
R109 RK73GB1J150J CHIP R 15 J 1/16W
R110,111 RK73GB1J331J CHIP R 330 J 1/16W
R112 RK73GB1J180J CHIP R 18 J 1/16W
R113 RK73GB1J331J CHIP R 330 J 1/16W
R114 RK73GB1J473J CHIP R 47K J 1/16W
R115 RK73GB1J103J CHIP R 10K J 1/16W
R116 RK73GB1J150J CHIP R 15 J 1/16W
R117 RK73GB1J683J CHIP R 68K J 1/16W
R119 RK73GB1J331J CHIP R 330 J 1/16W
R120 R92-1252-05 CHIP R 0 OHM J 1/16W
R121 RK73GB1J561J CHIP R 560 J 1/16W
R122 RK73GB1J473J CHIP R 47K J 1/16W
R123 RK73GB1J820J CHIP R 82 J 1/16W
R124 RK73GB1J123J CHIP R 12K J 1/16W
R126 RK73GB1J222J CHIP R 2.2K J 1/16W
R127-129 RK73EB2ER39K CHIP R 0.39 K 1/4W
R130-135 RK73GH1J154D CHIP R 150K D 1/16W
R136,137 RK73GB1J271J CHIP R 270 J 1/16W
R138 RK73GB1J105J CHIP R 1.0M J 1/16W
R139 RK73GB1J473J CHIP R 47K J 1/16W
R140 RK73GB1J563J CHIP R 56K J 1/16W
R141 RK73GB1J104J CHIP R 100K J 1/16W
R142 R92-1252-05 CHIP R 0 OHM J 1/16W
R143 RK73GB1J104J CHIP R 100K J 1/16W
R203 RK73HB1J184J CHIP R 180K J 1/16W
R206 RK73GB1J100J CHIP R 10 J 1/16W
R207 RK73HB1J472J CHIP R 4.7K J 1/16W
R208 RK73HB1J823J CHIP R 82K J 1/16W
R209 RK73HB1J272J CHIP R 2.7K J 1/16W
R210,211 RK73HB1J332J CHIP R 3.3K J 1/16W
R212 RK73HB1J823J CHIP R 82K J 1/16W
R213 RK73HB1J392J CHIP R 3.9K J 1/16W
R215 RK73HB1J101J CHIP R 100 J 1/16W
R216 RK73HB1J124J CHIP R 120K J 1/16W
R217 RK73HB1J472J CHIP R 4.7K J 1/16W
R218 RK73HB1J561J CHIP R 560 J 1/16W
R219,220 RK73GB1J561J CHIP R 560 J 1/16W
R221 RK73GB1J102J CHIP R 1.0K J 1/16W
R222 RK73GB1J221J CHIP R 220 J 1/16W
R223-226 RK73HB1J823J CHIP R 82K J 1/16W
R227 R92-1252-05 CHIP R 0 OHM J 1/16W
R228,229 RK73HB1J105J CHIP R 1.0M J 1/16W

TK-2202/2206 PARTS LIST
18
TX-RX UNIT (X57-6870-20)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
R230 RK73GB1J222J CHIP R 2.2K J 1/16W
R231 RK73GB1J470J CHIP R 47 J 1/16W
R233 RK73GB1J221J CHIP R 220 J 1/16W
R234 RK73GB1J104J CHIP R 100K J 1/16W
R237 RK73GB1J184J CHIP R 180K J 1/16W
R238 RK73GB1J104J CHIP R 100K J 1/16W
R239 RK73GB1J470J CHIP R 47 J 1/16W
R240 R92-1252-05 CHIP R 0 OHM J 1/16W
R241,242 RK73HB1J105J CHIP R 1.0M J 1/16W
R243 R92-0670-05 CHIP R 0 OHM
R291 R92-1252-05 CHIP R 0 OHM J 1/16W
R301 RK73HB1J473J CHIP R 47K J 1/16W
R304 RK73HB1J564J CHIP R 560K J 1/16W
R305 RK73HB1J104J CHIP R 100K J 1/16W
R306 RK73HB1J102J CHIP R 1.0K J 1/16W
R307,308 R92-1368-05 CHIP R 0 OHM
R310 RK73GB1J394J CHIP R 390K J 1/16W
R311 RK73HB1J123J CHIP R 12K J 1/16W
R312 RK73GB1J334J CHIP R 330K J 1/16W
R313 RK73GB1J104J CHIP R 100K J 1/16W
R314 RK73GB1J103J CHIP R 10K J 1/16W
R315 RK73GB1J334J CHIP R 330K J 1/16W
R316 RK73GB1J124J CHIP R 120K J 1/16W
R317 RK73GB1J474J CHIP R 470K J 1/16W
R318 RK73GB1J122J CHIP R 1.2K J 1/16W
R319 RK73HB1J563J CHIP R 56K J 1/16W
R320 RK73HB1J332J CHIP R 3.3K J 1/16W
R321 RK73HB1J224J CHIP R 220K J 1/16W
R322 RK73HB1J184J CHIP R 180K J 1/16W
R323 RK73HB1J563J CHIP R 56K J 1/16W
R324,325 RK73GB1J104J CHIP R 100K J 1/16W
R326 R92-1252-05 CHIP R 0 OHM J 1/16W
R327 RK73GB1J184J CHIP R 180K J 1/16W
R328 RK73GB1J103J CHIP R 10K J 1/16W
R329 RK73GB1J823J CHIP R 82K J 1/16W
R330 RK73HB1J332J CHIP R 3.3K J 1/16W
R331 RK73GB1J393J CHIP R 39K J 1/16W
R332 RK73GB1J153J CHIP R 15K J 1/16W
R334 RK73GB1J473J CHIP R 47K J 1/16W
R335 RK73GB1J222J CHIP R 2.2K J 1/16W
R336 RK73GB1J102J CHIP R 1.0K J 1/16W
R337 RK73GB1J101J CHIP R 100 J 1/16W
R338 RK73GB1J222J CHIP R 2.2K J 1/16W
R339 RK73GB1J471J CHIP R 470 J 1/16W
R340 RK73GB1J182J CHIP R 1.8K J 1/16W
R341 RK73GB1J103J CHIP R 10K J 1/16W
R342 RK73GB1J100J CHIP R 10 J 1/16W
R343 RK73GB1J474J CHIP R 470K J 1/16W
R344 RK73GB1J102J CHIP R 1.0K J 1/16W
R345,346 RK73GB1J101J CHIP R 100 J 1/16W
R347 RK73GB1J104J CHIP R 100K J 1/16W
R348 RK73GB1J563J CHIP R 56K J 1/16W
R349 RK73GB1J333J CHIP R 33K J 1/16W
R350 R92-1368-05 CHIP R 0 OHM
R354,355 RK73HB1J103J CHIP R 10K J 1/16W
R357 R92-1368-05 CHIP R 0 OHM
R360 R92-1368-05 CHIP R 0 OHM
R365 RK73HB1J473J CHIP R 47K J 1/16W
R403 RK73GB1J101J CHIP R 100 J 1/16W
R404 RK73HH1J474D CHIP R 470K D 1/16W
R405 RK73GB1J334J CHIP R 330K J 1/16W
R406 RK73HH1J474D CHIP R 470K D 1/16W
R407 RK73HB1J334J CHIP R 330K J 1/16W
R408-412 RK73HB1J473J CHIP R 47K J 1/16W
R413,414 RK73GB1J331J CHIP R 330 J 1/16W
R415,416 RK73GB1J473J CHIP R 47K J 1/16W
R417-420 RK73HB1J473J CHIP R 47K J 1/16W
R421,422 RK73HB1J102J CHIP R 1.0K J 1/16W
R423 R92-1368-05 CHIP R 0 OHM
R424,425 RK73HB1J473J CHIP R 47K J 1/16W
R426 R92-1368-05 CHIP R 0 OHM
R435 RK73HB1J473J CHIP R 47K J 1/16W
R436 R92-1252-05 CHIP R 0 OHM J 1/16W
R437,438 RK73HB1J473J CHIP R 47K J 1/16W
R445,446 R92-1252-05 CHIP R 0 OHM J 1/16W
R447 RK73HB1J472J CHIP R 4.7K J 1/16W
VR1 R12-7491-05 TRIMMING POT.(68K)
S401-403 S70-0414-05 TACT SWITCH
MIC301 T91-0543-05 MIC ELEMENT
D1 MA2S111 DIODE
D4 ,5 1SV325 VARIABLE CAPACITANCE DIODE
D7 1SV325 VARIABLE CAPACITANCE DIODE
D9 1SV325 VARIABLE CAPACITANCE DIODE
D10 1SV278 VARIABLE CAPACITANCE DIODE
D11 MA2S111 DIODE
D101 HSC277 DIODE
D102 HZU5CLL ZENER DIODE
D103-106 HVC131 DIODE
D202 HSC277 DIODE
D203-206 1SV305 VARIABLE CAPACITANCE DIODE
D301,302 RB706F-40 DIODE
D303 DAN222 DIODE
D401 RB521S-30 DIODE
D402 1SR154-400 DIODE
IC1 MB15A02 MOS IC
IC2 UPB1509GV BI-POLAR IC
IC101 TA75W01FU MOS IC
IC201 TA31136FN MOS IC
IC301 AQUA MOS IC
IC302 TA7368F MOS IC
IC401,402 XC6204B502MR MOS IC
IC403 ∗BD4840FVE MOS IC
IC404 ∗BD4845FVE MOS IC
IC405 ∗30622MAA-B89GP MPU
IC406 ∗BR24L08F-W ROM IC
Q1 KTC4082 TRANSISTOR
Q2 2SC5108(Y) TRANSISTOR
Q3 ,4 2SK508NV(K52) FET
Q5 DTA143TE DIGITAL TRANSISTOR
Q6 2SC5108(Y) TRANSISTOR
Q7 DTA143TE DIGITAL TRANSISTOR
Q8 2SC4617(S) TRANSISTOR
Q9 2SC5108(Y) TRANSISTOR
Q102 2SC4926YD TRANSISTOR
Q103 2SK2596 FET
Q104 DTC114EE DIGITAL TRANSISTOR
Q105 2SK879(Y) FET

TK-2202/2206
PARTS LIST
19
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
TX-RX UNIT (X57-6870-20)
ADDITIONAL PCB
Q106 2SK2595 FET
Q107 DTC114EE DIGITAL TRANSISTOR
Q108 2SK1824 FET
Q109 DTA144EE DIGITAL TRANSISTOR
Q202 DTA144EE DIGITAL TRANSISTOR
Q203 2SC4649(N,P) TRANSISTOR
Q204,205 3SK318 FET
Q301 DTA114EE DIGITAL TRANSISTOR
Q302 2SC4919 TRANSISTOR
Q303 DTC144EE DIGITAL TRANSISTOR
Q304 2SA1362(GR) TRANSISTOR
Q305 DTC144EE DIGITAL TRANSISTOR
Q306 CPH3413 FET
Q316 CPH3413 FET
Q401,402 DTC114EE DIGITAL TRANSISTOR
Q403,404 CPH3317 FET
Q405 DTA123JE DIGITAL TRANSISTOR
Q407,408 2SK1830 FET
TH101 157-104-65001 THERMISTOR
TH203 157-104-65001 THERMISTOR
C901,902 CK73GB1A105K CHIP C 1.0UF K
R901,902 RK73GB1J472J CHIP R 4.7K J 1/16W
Q901 2SK1824 FET
ADDITIONAL PCB

TK-2202/2206
20
AB
1
2
3
A :N14-0808-04
B :N14-0812-04
C :N30-2604-46
D :N30-2606-46
E :N83-2005-46
Parts with the exploded numbers larger than 700 are not supplied.
TX-RX Unit
57 2
8
13
11
20
19
12
40
23 E
E
Ex2
Ex2 E
E21
Ex2
49
36
18
3
Dx2
30
15 E
29
35
33
22
14
32
32
61
62
26
C
C
41
54 A7
B
37
39
63
51
38
58
59
4
16
17
34
50
56
1
EXPLODED VIEW
27
67
MIC301
26
CF201
31
24
26 26
25
25
