Altronix Pace1PTM User manual

Pace1PTM - 1 -
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
Input:
• PoE (15W) IEEE 802.3af compliant or
PoE+ (30W) IEEE 802.3at compliant
from Pace1PRM, Pace4PRM,
Pace8PRM, or Pace16PRM.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or
a single twisted pair UTP.
• Speed: 10/100BaseT, half/full duplex, auto
negotiation.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W)
delivered to camera by Pace1PTM.
• Throughput is rated to pass 100mbps of data.
CAT5e or Higher from Pace Receiver:
• Distance: up to 500m @ 100mbps
(see Max. Length of Cable Type vs.
Camera Power/PoE Class, pg. 4)
UTP (single twisted pair) from Pace1PRM:
• Distance: up to 152m @ 100mbps
(see Max. Length of Cable Type vs.
Camera Power/PoE Class, pg. 4)
LED Indicators:
• Green - PoE ON (by respective RJ45 jack).
•Yellow and Green LED IP Link status,
10/100Base-T/active.
Environmental:
• Operating Temperature:
For 15W: --- 40ºF to 167ºF (--- 40ºC to 75ºC).
For 25W: --- 40ºF to 158ºF (--- 40ºC to 70ºC).
For 30W: -- 40ºF to 140ºF (--- 40ºC to 60ºC).
• Storage Temperature:
-- 40ºF to 167ºF (--- 40ºC to 75ºC).
• Relative humidity:
20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog
CCTV CAT5e or UTP installations.
• Extend Network link distance in an
industrial environment over 610m.
• Works with Megapixel, HD720, HD1080
and VGA (SD) cameras with proper
headend equipment.
Mechanical:
• Dimensions (W x L x H approx.):
3.5” x 3.5” x 1”
(88.89mm x 88.89mm x 25.4mm).
Overview:
Pace1PTM is a long range Ethernet transceiver designed for use with Pace1PRM, Pace4PRM,
Pace8PRM and Pace16PRM receivers. They transmit data at 100mbps full duplex and power via
Cat5e or higher cable in a PoE(+) compliant format or a single twisted pair (UTP) (when paired
with Pace1PRM). The Pace1PTM will not deliver power to non compliant devices, thus avoid-
ing damage to improperly connected non-PoE cameras/devices. The receiver passes the PoE(+)
compliant power over the cable to the Pace1PTM transceiver which in turn passes this power to
an enabled IP camera/device. These plug and play units facilitate cost effective solutions for IP
devices that need to be installed at distances greater than 100m. They also provide a simple way to
replace legacy analog products with new IP devices over single twisted pair (UTP) (when paired
with Pace1PRM) or structured cable.
Features:
Rev. 111413
Installation Guide
Pace1PTM
IP and PoE+ Over Extended Distance UTP or CAT5e I.T.E. 43KC
All manuals and user guides at all-guides.com
all-guides.com

- 2 - Pace1PTM
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and
with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or
Recognized wire suitable for the application.
Pace1PTM is not intended to be connected to outside plant leads and should be installed indoors
within the protected premises. Pace1PTM is intended for indoor use only.
1. Secure unit to desired mounting surface with a proper fastening device utilizing the case’s
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in the proximity of camera/device.
2. Connect structured cable from IP camera/device to RJ45 jack marked [PoE Out] (Fig. 2, pg. 3).
3. Connect Pace1PTM to the receiver (Pace1PRM, Pace4PRM, Pace8PRM or Pace16PRM):
a. CAT5e or higher: Connect CAT5e or higher to the connector marked [RJ45 IN]
(Fig. 2, pg. 3).
UTP: For single UTP applications, jumpers (supplied) must be connected as follows:
1. Remove the four (4) screws from the Pace1PTM cover. Do not discard hardware.
2. Connect jumpers (supplied) to pins pairs [P5] and [P6] as shown (Figs. 1a & 1b, pg. 3).
3. Replace cover and secure it with the four (4) screws.
4. Connect UTP to connector marked [UTP IN].
Caution: Once PoE connection is established between the receiver and Pace1PTM, disconnection
from Pace1PTM will not disable the PoE output voltage on the receiver. Although the Pace1PTM
can be reconnected, caution should be taken not to connect the CAT5e or single UTP wiring from
the receiver to any non-PoE device.
Technical Specifications:
Parameter Description
Connections RJ45 for ethernet link or single pair UTP.
Input power
requirements
PoE (15W) IEEE 802.3af compliant or
PoE+ (30W) IEEE 802.3at compliant
from Pace1PRM, Pace4PRM, Pace8PRM or Pace16PRM.
Indicators
Yellow (RJ45 connector): On - Link, Off - No Link, Blinking - Activity.
Green (RJ45 connector): On - 100Base-TX, Off - 10Base-T.
Green: PoE Active.
Environmental
Conditions
Operating Ambient Temperature: UL60950-1:
For 15W: --- 40ºF to 167ºF (--- 40ºC to 75ºC).
For 25W: --- 40ºF to 158ºF (--- 40ºC to 70ºC).
For 30W: -- 40ºF to 140ºF (--- 40ºC to 60ºC).
Relative humidity: 20 to 85%, non-condensing.
Storage Temperature: -- 40ºF to 167ºF (--- 40ºC to 75ºC).
Operating Altitude: -- 1000 to 6,561.679 ft. (-- 304.8 to 2000m).
Regulatory
Compliance UL/CUL Listed for Information Technology Equipment (UL 60950-1).
Weights (approx.) Product: 3.88 oz. (0.11 kg.), Shipping: 6.70 oz. (0.19 kg.)
All manuals and user guides at all-guides.com

Pace1PTM - 3 -
Side View
Top View
UTP
Link P5
Jumper
P6
P5 P6
Single PoE Camera Connection:
Fig. 2 Fig. 2a
PoE compliant
100m max.
100m max.
Mounting Hole
PoE Camera
Pace1PTM
Pace1PRM
I.T.E. 43KC
RJ45
Link
Z1409
UTP
Link
RJ45 LEDs Yellow - Activity
Green - Speed
Green LED Power and PoE
PoE
Out
Output
PoE
LED
Input
PoE
LED
www.altronix.com
IP-UTP Transceiver
Passes PoE/PoE+
Pace1PTM - Transceiver
RJ45
Link
Output
PoE
LED
Input
PoE
LED
UTP
Link
PoE
Input
I.T.E. 43KC
Z1409
RJ45 LEDs Yellow - Activity
Green - Speed
Green LED Power and PoE
www.altronix.com
IP-UTP Receiver
Passes PoE/PoE+
Pace1PRM - Receiver
Structured Cable
or Single UTP
Legend:
PoE+ over CAT5e up to 500m max.
or
Single UTP up to 152.4m max.
Powered Switch or MidSpan
Structured
Cable to
Midspan/
Endspan
Green LED
indicates
PoE Present
from Midspan/
Endspan
Green LED
indicates
PoE being
transmitted
to Pace1PTM
CAT5 or higher
from Pace1PTM
Single UTP
from
Pace1PTM
Structured
Cable from
Camera/Device
Green LED
indicates
PoE transmitted
to Camera/Device
Green LED
indicates
PoE received
from Pace1PRM
CAT5 or higher
from Pace
receiver
Single UTP
from
Pace1PRM
Fig. 1
To access pins which are located
behind the UTP Link you must
remove cover.
Note: Make sure jumpers are lined
up with pins pairs [P5] and [P6] as
shown in top and side views noted
in Figs. 1a & 1b.
Fig. 1a Fig. 1b
All manuals and user guides at all-guides.com

- 4 - Pace1PTM
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIPace1PTM G22O MEMBER
Pace8PRM - Front Panel
Powered Switch or NetWay MidSpan
450m max.
450m max.
450m max.
450m max.
450m max.
450m max.
450m max.
450m max.
100m max. 100m max. 100m max. 100m max. 100m max. 100m max. 100m max. 100m max.
Pace1PTM
OUT
Ports
1 4
IN
OUT
Ports
5 8
IN
PoE Camera
PoE Camera
PoE Camera
PoE Camera
PoE compliant
100m) max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
PoE Camera
PoE Camera
PoE Camera
PoE Camera
PoE compliant
100m) max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Multiple PoE Cameras Connection:
Pace8PRM shown. Pace4PRM and Pace16PRM are similar,
with four (4) and sixteen (16) channels respectively.
Fig. 3
Maximum Length of Cable Type vs. Camera Power/PoE Class:
Cable Type Total Power
Consumption
Max.
Data Distance
Max.
Power Distance
Cat5e 15W 500m 846m
Cat5e 30W 500m 423m
1 Pair UTP 15W 150m 210m
1 Pair UTP 30W 150m 105m
Note: Calculations based on 56VDC starting voltage from power source and accounts for a
10VDC voltage drop. IEEE standards voltage range requirement for powered devices are:
PoE (15W) - 37VDC to 57VDC
PoE+ (30W) - 44VDC to 57VDC.
