SERVICE MANUAL /
This product uses Lead Free solder.
This product complies with the RoHS directive for the European market.
UHF FM TRANSCEIVER / UHF
TK-3000
© 2011-5 PRINTED IN JAPAN
B51-8978-00 (Y)
Helical antenna
(T90-1098-05)
Button knob (Side)
(K29-9490-13)
Knob (PTT)
(K29-9489-13)
Knob (Volume)
(K29-9487-03)
Knob(Selector)
(K29-9488-03)
C6 version / C6
无铅焊接通信产品
保护环境建伍领先
注意∶ 本产品是无铅化焊接产品
在维修时请使用无铅焊锡
和相应的焊接工具
详细事项请访问如下网址了解 :
http://www.kenwoodhk.com.hk/
版本
调频手持对讲机
维修手册
天线
按钮 (PTT)
钮扣按钮(侧面)
机壳
旋钮（选择器）
旋钮（音量）
Plastic cabinet assy
(A02-4135-03)

TK-3000
2
GENERAL....................................................3
SYSTEM SET-UP.........................................4
REALIGNMENT...........................................5
DISASSEMBLY FOR REPAIR.....................9
CIRCUIT DESCRIPTION ...........................11
SEMICONDUCTOR DATA .........................16
COMPONENTS DESCRIPTION................17
PARTS LIST...............................................19
EXPLODEDVIEW......................................24
ADJUSTMENT...........................................25
PC BOARD
TX-RX UNIT (X57-8100-23)....................32
LEVEL DIAGRAM......................................36
SCHEMATIC DIAGRAM ............................37
BLOCK DIAGRAM.....................................39
SPECIFICATIONS..................BACK COVER
Document Copyrights
Copyright 2011 by Kenwood Corporation. All rights re-
served.
No part of this manual may be reproduced, translated,
distributed, or transmitted in any form or by any means, elec-
tronic, mechanical, photocopying, recording, or otherwise,
for any purpose without the prior written permission of Ken-
wood.
Disclaimer
While every precaution has been taken in the prepara-
tion of this manual, Kenwood assumes no responsibility
for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained
herein. Kenwood reserves the right to make changes to any
products herein at any time for improvement purposes.
概 述..................................3
系统体系...............................4
模式组合...............................5
维修拆卸.............................. 9
电路说明..............................11
半导体数据............................16
元件说明..............................17
零 件 表..............................19
部件分解图............................24
调 整.................................26
印刷电路板
收发单元 (X57-8100-23) ..............32
电 平 图..............................36
原 理 图..............................37
方 块 图..............................39
规 格...............................封底
文档版权信息
Kenwood Corporation 拥有版权 2011。保留所有权利。
未经 Kenwood 公司预先书面同意，无论出于何种目的，均
不得以任何形式或任何方式包括电子、机械、影印、录音或
其他方式复制、翻译、分发或传播本手册的任何部分。
免责声明
Kenwood 公司在准备本文档时已采取所有必要的预防措施，
恕不对错误或疏漏承担任何责任，也不对因使用本文中所含
的信息而导致的损害负责。Kenwood 公司保留出于改进的需要
而随时对文中的产品信息做出更改的权利。
CONTENTS / 目录

TK-3000
3
INTRODUCTION
SCOPE OFTHIS MANUAL
This manual is intended for use by experienced techni-
cians familiar with similar types of commercial grade com-
munications equipment. It contains all required service
information for the equipment and is current as of the pub-
lication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment informa-
tion, the full part identification number should be included.
This applies to all parts : components, kits, or chassis. If the
part number is not known, include the chassis or kit number
of which it is a part, and a sufficient description of the re-
quired component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
• DO NOT transmit until all RF connectors are verified se-
cure and any open connectors are properly terminated.
• SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
• This equipment should be serviced by a qualified techni-
cian only.
SERVICE
This transceiver is designed for easy servicing. Refer
to the schematic diagrams, printed circuit board views, and
alignment procedures contained within.
Model Type TX-RX unit Frequency
range Remarks
TK-3000 C6
X57-8100-23 350~390MHz IF1: 38.85MHz
LOC: 38.4MHz
引言
本手册的范围
本手册是提供给熟悉通信专业并且具有维修经验的技术人
员使用的。它包括了维修该设备所需要的全部资料和现行出
版日期。在出版后可能发生变动，如果需要，可以参照《维
修通报》或《手册修订本》进行补充。
替换零件的订购
当订购替换零件或设备资料时，应注意完整的零件识别号
码。所有的零件均有识别号码∶元件，组件或机壳。如果不
知道零件的号码，为了正确地识别，必须注明此元件所属的
机壳或组件的号码，并对元件进行充分的说明。
个人安全
为了个人的安全，请注意下列事项∶
• 在没有认真核实所有射频插头之前或有任何一个脱开的插
头没有连接到相应端口上的情况下均不要发射。
• 在电爆管附近或在易燃性气体环境中，必须关闭电源，不
要操作本设备。
• 本设备只应该由有资格的技术人员进行维修。
维修服务
为了便于维修本设备，建立了完整的维修服务体系，提供
了包括原理图，印刷电路板图和调整步骤在内的资料供参考。
型 号 类 型 收发单元 频率范围 备 注
TK-3000 C6 X57-8100-23 350 ～ 390MHz IF1: 38.85MHz
LOC: 38.4MHz
GENERAL / 概述

TK-3000
4
Choose the type of transceiver
Transceiver programming
Delivery
Are you using the speaker microphone?
A personal computer, programming interface (KPG-22A/22U),
and FPU (programming software) are required for programming.
(The frequency, TX power HI/LOW, and signaling data are
programmed for the transceiver.)
YES /
NO /
KMC-21 or KMC-45 Speaker microphone
(Option)
TX/RX 350~3904.0W TK-3000 C6
Frequency range (MHz) RF power Type
Merchandise received
1. Modes
Mode Function
User mode For normal use.
PC mode Used for communication between the trans-
ceiver and PC.
Data programming
mode Used to read and write frequency data and other features to and from the transceiver.
PC test mode Used to check the transceiver using the PC.
This feature is included in the FPU.
Clone mode Used to transfer programming data from
one transceiver to another.
User mode
Data programming mode
PC test mode PC tuning mode
PC mode
Clone mode
接收订单
选择手持对讲机的类型
手持对讲机编程
您使用扬声器麦克风吗 ?
交货
KMC-21, 或 KMC-45 扬声器麦克风
频率范围 (MHz) 射频功率 类 型
编程时需要个人计算机，编程接口 (KPG-22A/22U) 和 FPU( 编程软件 )。
( 为手持对讲机设定频率，常规系统特性，TX 高 / 低功率，以及信令数据。)
( 可选件 )
否
是
1. 模式
User mode
Data programming mode
PC test mode PC tuning mode
PC mode
Clone mode
用户模式
PC 模式
PC 测试模式 PC 调谐模式
数据编程模式
复制模式
模 式 功 能
用户模式 一般使用。
PC 模式 用于手持对讲机与计算机之间的通信。
数据编程模式 用于阅读和写入频率数据以及其他功能。
PC 测试模式 用于使用计算机检测手持对讲机。
此特性包括在 FPU 内。
复制模式 用于从一个手持对讲机编程数据复制到另
一个手持对讲机。
SYSTEM SET-UP / 系统体系
REALIGNMENT / 模式组合

TK-3000
5
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode Received commands from PC
Clone mode [PTT]+[Side]+Power ON (Two seconds)
3. PC Mode
3-1. Preface
The transceiver is programmed by using a personal com-
puter, a programming interface (KPG-22A/22U, USB adapter
(KCT-53U)) and programming software (KPG-137D: ver.1.10
or later).
The programming software can be used with a PC. Fig-
ure 1 shows the setup of a PC for programming.
3-2. Connection Procedure
1. Connect the transceiver to the personal computer with
the interface cable and USB adapter (when the interface
cable is KPG-22A, the KCT-53U can be used).
Note:
• You must install the KPG-22U driver in the computer to
use the USB programming interface cable (KPG-22U).
• You must install the KCT-53U driver in the computer to
use the USB adapter (KCT-53U).
• When using the USB adapter (KCT-53U) for the first time,
plug the KCT-53U into a USB port on the computer with
the computer power ON.
2. When the POWER is switched on, user mode can be en-
tered immediately. When the PC sends a command, the
transceiver enters PC mode.
When data is read from the transceiver, the red LED
lights.
When data is written to by the transceiver, the green LED
lights.
Note:
• The data stored in the personal computer must match
Model Name and Model Type when it is written into EE-
PROM.
• Do not press the [PTT] key during data transmission or
reception.
3-3. KPG-22A Description
(PC programming interface cable: Option)
The KPG-22A is required to interface the transceiver with
the computer. It has a circuit in its D-sub connector case that
converts the RS-232C logic level to the TTL level.
The KPG-22A connects the SP/MIC connector of the
transceiver to the RS-232C serial port of the computer.
3-4. KPG-22U Description
(USB programming interface cable: Option)
The KPG-22U is a cable which connects to a USB port
on a computer.
2. 如何进入每一种模式
模 式 功 能
用户模式 接通电源
PC 模式 从计算机接收指令
复制模式 [PTT]+[ 侧面 ]+ 接通电源 (2 秒钟 )
3. PC 模式
3-1. 前言
手持对讲机采用个人电脑、编程接口 (KPG-22A/22U，USB
适配器 (KCT-53U)) 和编程软件 (KPG-137D:ver.1.10 或更高
版本 ) 进行编程。
编程软件可以在 PC 上进行使用。图 1 给出了 PC 进行编程
的设置。
3-2. 连接操作
1. 使用接口电缆和 USB 适配器将手持对讲机连接到个人电脑
( 接口电缆为 KPG-22A 时，可以使用 KCT-53U)。
注意 ：
• 必须在电脑上安装 KPG-22U 驱动程序才能使用 USB 编程接
口电缆 (KPG-22U)。
• 必须在电脑上安装 KCT-53U 驱动程序才能使用 USB 适配器
(KCT-53U)。
• 首次使用 USB 适配器 (KCT-53U) 时，请在电脑开机的情况
下将 KCT-53U 插入电脑的 USB 端口。
2. 手持对讲机电源打开时，可以立即进入用户模式 PC 发送
指令时，手持对讲机进入 PC 模式。
手持对讲机发送数据时，红色的 LED 点亮。
手持对讲机接收数据时，绿色的 LED 点亮。
注意 ：
• 个人电脑保存的数据写入 EEPROM 时，必须与机型和类型
相符。
• 请勿在数据发送或接收期间按 [PTT] 键。
3-3. KPG-22A 说明
(PC 编程接口电缆 ：选购件 )
将手持对讲机与电脑相连需要 KPG-22A。该电缆的 D-sub
连接器盒具有将 RS-232C 逻辑电平转换为 TTL 电平的电路。
KPG-22A 将手持对讲机的 SP/MIC 连接器连接到电脑的 RS-
232C 串行端口。
3-4. KPG-22U 说明
(PC 编程接口电缆 ：选购件 )
KPG-22U 是连接到电脑 USB 端口的电缆。
REALIGNMENT / 模式组合

TK-3000
6
When using the KPG-22U, install the supplied CD-ROM
(with driver software) in the computer. The KPG-22U driver
runs under Windows XP, Vista or 7.
3-5. KCT-53U Description (USB adapter: Option)
The KCT-53U is a cable which connects the KPG-22A to
a USB port on a computer.
When using the KCT-53U, install the supplied CD-ROM
(with driver software) in the computer. The KCT-53U driver
runs under Windows 2000, XP or Vista (32-bit).
3-6. Programming Software KPG-137D Description
The KPG-137D is the programming software for the
transceiver supplied on a CD-ROM. This software runs un-
der windows XP, Vista or 7 on a PC. The software on this
disk allows a user to program the transceiver via Program-
ming interface cable (KPG-22A/22U).
Note:
• Use the FPU that matches the market when you first set
the market code and model name/frequency data to the
service unit.The unit set by mistake cannot be restored.
• Receive frequencies listed below may result in the in-
terference of reception due to the harmonics of internal
oscillators.Enter a frequency not listed in the table.
No. FREQUENCY (MHz)
1 364.79375
2 364.79500
3 364.80000
4 364.80500
5 364.80625
6 383.99375
7 383.99500
8 384.00000
9 384.00500
10 384.00625
3-7. Programming with PC
If data is transferred to the transceiver from a PC with the
FPU, the data for each set can be modified.
Data can be programmed into the EEPROM in RS-232C
format via the SP/MIC jack.
In this mode the PTT line operate as TXD and RXD data
lines respectively.
使用 KPG-22U 时，请在电脑上安装附带的 CD-ROM( 带有驱
动程序 )。KGP-22U 驱动程序可以在 Windows XP、Vista 或 7
下运行。
3-5. KCT-53U 说明 (USB 适配器 ：选购件 )
KCT-53U 是将 KPG-22A 连接到电脑 USB 端口的电缆。
使用 KCT-53U 时，请在电脑上安装附带的 CD-ROM( 带有驱
动程序 )。KCT-53U 驱动程序在 Windows2000,XP 或 Vista(32
位 ) 下运行。
3-6. 编程软件 KPG-137D 说明
KPG-137D 是 CD-ROM 附带的用于手持对讲机的编程软件。
该软件在 PC 的 WindowsXP、Vista 或 7 下运行。该光盘上的
软件允许用户通过编程接口电缆 (KPG-22A/22U) 对手持对讲
机进行编程。
注意 ：
• 初次设置服务单元的市场代码和机型 / 频率数据时，请使
用与市场相符的 FPU。若单元设置有误，将无法予以恢复。
• 下面列出的接收频率由于内部振荡器的谐波可能对信号接
收造成干扰。输入在表格中没有列出的频率。
编号 频率 (MHz)
1 364.79375
2 364.79500
3 364.80000
4 364.80500
5 364.80625
6 383.99375
7 383.99500
8 384.00000
9 384.00500
10 384.00625
3-7. 使用 PC 编程
如果使用 FPU 将数据从 PC 传输到手持对讲机，则每套手
持对讲机的数据均可修改。
通过 SP/MIC 插孔可以将数据以 RS-232C 格式写入 EEPROM。
在该模式下，PTT 线路分别用作 TXD 和 RXD 数据线路。
REALIGNMENT / 模式组合

TK-3000
7
PC KPG-22A or KPG-22U or KPG-22A+KCT-53U
Illustration is KPG-22A.
KPG-137D
(ver. 1.10 or later)
Tuning cable /
(E30-3216-05)
D-SUB
Transceiver Transceiver Transceiver
KPG-22A
PC
Gray
Gray/Black
1.5D-XV Lead wire
1.5D-XV Shield wire
+
–
+
–
SP
MIC
(9-pin / )
KPG-22U
PC
USB
KPG-22A
KCT-53U
PC
USB
4. Clone Mode
Programming data can be transferred from one trans-
ceiver to another by connecting them via their SP/MIC con-
nectors.
Cloning can be performed as described below (the trans-
mit transceiver is the source and the receive transceiver is
the target).
The following data cannot be cloned.
• Tuning data
• Model name data
• ESN data
1. Turn the source transceiver and target transceiver power
OFF.
2. Turn the source transceiver power ON while pressing the
[PTT] and [Side] keys, to enter clone mode.
3. Connect the cloning cable (part No. E30-3410-05) to the
SP/MIC connectors on the source and target transceiv-
ers.
4.Turn the target transceiver power ON.
5. Press the [Side] key on the source transceiver.The data of
the source is sent to the target.While the source is send-
ing data, red LED will light. While the target is receiving
the data, green LED will light. When cloning of data is
completed, the source red LED turned off, and the target
automatically operates in the User mode.
6. Additional targets can be continuously cloned. When
the [Side] key on the source is pressed, the data of the
source is sent to the target again. Repeat steps 3 to 5 to
clone additional transceivers.
Fig. 1 / 图1
KPG-22A 或 KPG-22U 或 KPG-22A+KCT-53U
插图为 KPG-22A。
灰色
灰色/黑色
1.5D-XV 导线
1.5D-XV 屏蔽线
调谐电缆
9针
手持对讲机 手持对讲机 手持对讲机
4. 复制模式
用 SP/MIC 连接器连接手持对讲机，可以将编程数据从一
台手持对讲机传输到另一台手持对讲机。
如下所述可进行复制（发射手持对讲机为主机，接收手持
对讲机为子机）。
以下数据不能复制。
·调谐数据
·机型数据
·ESN 数据
1. 关闭主机和子机的电源。
2. 按 [PTT]和[侧面]键的同时打开主机的电源，使其进入
复制模式。
3. 将复制电缆（零件号 E30-3410-05）连接到主、子机的
SP/MIC 连接器上。
4. 打开子机的电源。
5. 按主机上的 [ 侧面 ] 键。
主机的数据便被发送到子机。主机发送数据时，红色 LED
将呈。子机接收数据时，绿色 LED 呈。数据复制完成后，
主机的红色 LED 熄灭，子机自动以用户模式运行。
6. 可以继续复制其他子机。按主机上的 [ 侧面 ] 键，主机的
数据再次被发送到子机。重复步骤3～5复制其他手持对
讲机。
REALIGNMENT / 模式组合
(ver.1.10 或更高版本 )

TK-3000
8
REALIGNMENT
Note:
• The Model name and Market codes must be the same in
order to clone the transceiver.
• If the transceivers clone mode is configured as “Disabled”,
the transceiver cannot enter clone mode.
• If the Read authorization password is set to the trans-
ceiver, the transceiver cannot enter to the clone mode.
• Cannot be cloned if the password (overwrite password) is
programmed to the target.
Cloning cable
(E30-3410-05)
注意 ：
• 机型和市场代码必须相同才能复制手持对讲机。
• 如果手持对讲机复制模式被设置为“无效”，则手持对讲
机不能进入复制模式。
• 如果手持对讲机设置了读取授权密码，则手持对讲机无法
进入复制模式。
• 如果子机编程设有密码 ( 改写密码），则无法复制。
复制电缆
Fig. 2 / 图2

TK-3000
9
1. Separating the Case Assembly from the
Chassis
1. Remove the two knobs (a).
2. Remove the two screws (b).
3. Expand the right and left sides of the bottom of the case
assembly, Iift the chassis, and remove it from the case
assembly (c).
4. Taking care not to cut the speaker lead (d), open the
chassis and case assembly.
Note:
Solder the speaker wire back in its original position if you
have removed it.
d
–
+BRN /
GRN /
aa
b
b
c
1. 从机架上分离外壳
1. 取下两旋扭 (a)。
2. 取下两颗螺钉 (b)。
3. 掀开外壳底部的左右两侧，取下机架，并外壳中取出 (c)。
4. 小心不要折断扬声器引线 (d)。拆下机架和外壳。
注意 :
如果取下了扬声器的导线，请将其焊接到原位上。
绿色
褐色
DISASSEMBLY FOR REPAIR / 维修拆卸

TK-3000
10
j
Antenna terminal
e
f
g
h
i
h
2. Removing theTX-RX unit from the
Chassis
1. Remove the packing (e).
2. Remove the 13 screws (f).
3. Remove the packing (g) and two hexagon nuts (h).
4. Remove the solder from the antenna terminal using a sol-
dering iron then lift the unit off (i).
Note:
When reassembling the unit in the chassis, be sure to
solder the antenna terminal.
3. Removing the Rear Panel
1. Raise the rear panel on the chassis (j).
2. 拆卸收发单元
1. 取下橡胶垫 (e)。
2. 取下 13 颗螺钉 (f)。
3. 取下橡胶垫 (g) 和两个六角形螺母 (h)。
4. 用电烙铁烫开天线端点处的焊锡 , 并拆卸主板 (i)。
注意 :
当重新将主板安装到机架上时，确保将天线端点处焊接
好。
3. 取下后面板
1. 从机架上提起后面板 (j)。
DISASSEMBLY FOR REPAIR / 维修拆卸
天线端点

TK-3000
11
1. Frequency Configuration
The receiver utilizes double conversion. The first IF is
38.85MHz and the second IF is 450kHz. The first Local os-
cillator is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the neces-
sary frequencies.
2. Receiver System
The receiver system is shown in Figure 2.
2-1. Front End (RF Amplifier) Circuit
The signal coming from the antenna passes through the
transmit/receive switching diode circuit (D101, D102, D103
and D105) and a BPF (L208 and L210), and is then ampli-
fied by the RF amplifier (Q204).
The resulting signal passes through a BPF (L215, L218
and L219) and goes to the mixer. These BPFs are adjusted
by variable capacitors (D201 D202, and D204). The input
voltage to the variable capacitor is a regulated voltage out-
put from the DAC (IC300)
.
TX/RX: 350~390MHz
1st MIX MCF SP
MIC
CF
450kHz
ANT
ANT
SW RF AMP IF SYSTEM
X2
doubler
PLL
VCO
38.85MHz 38.4MHz
TX
AMP RF AMP
AF
AMP
MIC
AMP
AF
filter
TCXO 19.2MHz
311.15~351.15MHz
350~390MHz
SP
ANT
IC200
IF,MIX,DET
Q203
1st MIX IC303
CF200
ANT
SW
Q201
X2 doubler
2nd Local
X1
TCXO
19.2MHz
BPF
BPF Q204 RF AMP XF200
MCF
Q202
IF AMP IC302 AF PA
BPF 1st Local
BPF VR500
AF filter
CIRCUIT DESCRIPTION / 电路说明
1. 频率构成
接收部采用二次变频超外差方式。第一中频为 38.85MHz，
第二中频为 450kHz。第一本振频率信号由锁相环电路提供。
发射部由锁相环电路直接产生所需的频率。
Fig. 1 Frequency configuration /
Fig. 2 Receiver system /
图 1 频率构成
图 2 接收部系统
2. 接收部系统
接收部系统的如图 2 所示。
2-1. 前端 ( 高频放大器 ) 电路
从天线接收的信号进入发送 / 接收转换开关二极管电路
(D101、D102，D103 和 D105)，然后通过 BPF(L208，L210)，
并且被射频放大器 (Q204) 放大。
此信号通过 BPF(L215，L218 和 L219) 然后进入混频。这
些 BPF 被可变电容器 (D201，D202 和 D204) 调整。输入可变
电容器的电压被经 DAC(IC300) 的电压输出调整。

TK-3000
12
2-2. First Mixer
The signal from the front end is mixed with the first local
oscillator signal generated in the PLL circuit by Q203 to pro-
duce a first IF frequency of 38.85 MHz.
The resulting signal passes through the XF200 MCF to
cut the adjacent spurious and provide the optimum charac-
teristics, such as adjacent frequency selectivity.
2-3. IF Amplifier Circuit
The first IF signal is passed through a four-pole mono-
lithic crystal filter (XF200) to remove the adjacent channel
signal.
The filtered first IF signal is amplified by the first IF ampli-
fier (Q202) and then applied to the lF system IC (IC200).
The IF system IC provides a second mixer, second local
oscillator, limiting amplifier, quadrature detector and RSSI
(Received Signal Strength Indicator).The second mixer
mixes the first IF signal with the 38.4MHz of the second lo-
cal oscillator output (TCXO X1) and produces the second IF
signal of 450kHz.
The second IF signal is passed through the ceramic filter
(CF200) to remove the adjacent channel signal. The filtered
second IF signal is amplified by the limiting amplifier and
demodulated by the quadrature detector with the ceramic
discriminator (CD200).The demodulated signal is routed to
the audio circuit.
2-4. Audio Amplifier Circuit
The demodulated signal from IC200 is amplified by
IC305, IC303 and goes to AF amplifier through IC302.
The signal then goes through an volume control (VR500),
and is routed to an audio power amplifier (IC302) where it is
amplified and output to the speaker.
To output sounds from the speaker, IC400 sends a high
signal to the SPMUT line and turns IC400 on through Q300,
Q301, Q302 and Q306.
3.Transmitter System
3-1. Microphone Amplifier Circuit
The signal from microphone amplified by IC301 and goes
through mute switch (IC300).
IC304 is composed of high-pass filter, low-pass filter and
pre-emphasis/IDC circuit.
The output signal from the DAC IC (IC300) goes to the
VCO modulation input.
BUFF X1
TCXO
VCO
LSDO
IC300
MIC
DAC
AMP
IC304
LSDO
MIC
IC301
2-2. 第一混频器
前端的信号与 PLL 电路产生的第一本振信号在 Q203 混频，
生成 38.85MHz 频率的第一中频信号。
生成的信号通过 XF200 MCF。
2-3. 中频放大电路
第一中频信号通过晶体滤波器 (XF200) 消除相邻信道的信
号。经滤波的第一中频信号被第一中频放大器 (Q202) 放大并
进入中频系统芯片 (IC200)。
中频系统芯片提供第二混频器、第二本振信号、限幅放大
器、正交检测器和 RSSI( 接收信号强度指示器 )。第二混频器
将第一中频信号与 38.4MHz 的第二本振信号输出 (TCXO X1)
进行混频，并生成 450kHz 的第二中频信号。
第二中频信号通过陶瓷滤波器 (CF200) 继续消除相邻信道
的信号。经滤波的第二中频信号被限幅放大器放大并被带有
陶瓷鉴频器 (CD200) 的正交检测器解调。经解调的信号进入
音频电路。
2-4. 音频放大器电路
来 自 于 IC200 的解调信号被IC305 放 大，并通过
IC302,IC303 送到 AF 放大器。
信号通过 AF 音量控制 (VR500)，在音频功率放大器 (IC302)
进行放大后输出到扬声器。
由扬声器输出声音时，IC400 发送高电平信号给 SPMUT，
通过 Q300、Q301、Q302 和 Q306 打开 IC400。
3. 发射机系统
3-1. 麦克风放大器电路
麦克风的信号被 IC301 放大，然后通过静音开关 (IC300)。
IC304 由高通滤波器、低通滤波器和预加重 /IDC 电路组成。
DAC IC(IC300) 的输出信号送入 VCO 调制输入。
CIRCUIT DESCRIPTION / 电路说明
Fig. 3 Microphone amplifi er circuit / 图 3 麦克风放大器电路

TK-3000
13
ANT
RF FINAL
AMP ANT SW LPF
From
T/R SW
(D100)
D101,102
+B
POWC
Q102
DRIVE
AMP
Q101
VDD VG
Pre-DRIVE
AMP
Q100
R121
R122
R123
CURDET
Fig. 4 Drive and final amplifier circuit /
3-2. Drive and Final Amplifier Circuit
The signal from the T/R switch (D100 is on) is amplified
by the pre-drive amplifier (Q100) to 30mW.
The output of the pre-drive amplifier is amplified by the
drive amplifier (Q101) and the RF final amplifier (Q102) to
4.0W (1W when the power is low).
The drive amplifier and the RF final amplifier consist of
two MOS FET stages.
The output of the RF final amplifier is then passed
through the harmonic filter (LPF) and antenna switch (D101
and D102) and is applied to the antenna terminal.
4. Frequency Synthesizer Circuit
4-1. Frequency Synthesizer
The frequency synthesizer consists of the TCXO (X1),
VCO, PLL IC (IC1) and buffer amplifiers.
The TCXO generates 19.2MHz.The frequency stability is
2.5 ppm within the temperature range of –30 to +60°C.
The frequency tuning and modulation of the TCXO are
done to apply a voltage to pin 1 of the TCXO. The output of
the TCXO is applied to pin 1 of the PLL IC.
The VCO consists of 1VCO and covers a dual range of
the 350.00~390.00MHz and the 311.15~351.15MHz. The
VCO generates 311.15~351.15MHz for providing to the first
local signal in receive.
The PLL IC consists of a prescaler, reference divider,
phase comparator, charge pump (The frequency step of the
PLL circuit is 5 or 6.25 kHz).
PLL data is output from DATA (pin 19), CLOCK (pin 18)
and PLDL (pin 20) of the MCU (IC400).The data are input to
the PLL IC when the channel is changed or when transmis-
sion is changed to reception and vice versa.A PLL lock con-
dition is always monitored by the pin 22 (PLUL) of the MCU.
When the PLL is unlocked, the PLUL goes low.
3-2. 驱动器和末级放大器电路
来自于 T/R 开关 (D100 ON) 的信号被预驱动放大器 (Q100)
放大到 30mW。
预驱动放大器的输出被驱动放大器 (Q101) 和射频末级放
大器 (Q102) 放大到 4.0W( 当低功率时为 1W)。
驱动放大器和 RF 末级放大器由 2 个 MOS FET 构成。
射频末级放大器的输出通过谐波滤波器 (LPF) 和天线开关
(D101 和 D102) 并且送到天线终端。
4. 频率合成器电路
4-1. 频率合成器
频率合成器由 TCXO(X1)、VCO、PLL IC(IC1) 和缓冲放大
器组成。
TCXO 产生 19.2MHz 的频率。在温度为 -30 ～ +60℃的范围内，
频率的稳定性为 2.5ppm。
进行频率调谐和 TCXO 调制，以便给 TCXO 的针脚 1 提供电压。
TCXO 的输出加在 PLL IC 的针脚 1 上。
VCO 由 1VCO 组成，并且覆盖了 350.00 ～ 390.00M Hz 和
311.15 ～ 351.15M Hz 双 波 段。VC O 产 生 311.15 ～ 351.15M H
的频率，以提供接收的第一个本振信号。
PLL IC 由预计数器、基准除法器、相位比较器、电荷泵组
成 (PLL 电路的频率步长为 5kHz 或 6.25kHz)。
PLL 数据从 MCU(IC400) 的 DATA( 针脚 19)，CLOCK( 针脚
18) 和 PLDL( 针脚 20) 输出。当信道改变时，或当由发射变为
接收或由接收变为发射时，数据输入 PLL IC。PLL 的锁定条
件总是由 MCU 的针脚 22(PLUL) 监控。当 PLL 失锁时，PLUL 为
低电位。
CIRCUIT DESCRIPTION / 电路说明
图 4 驱动及末级放大器电路

TK-3000
14
5. Control Circuit
The control consists of the MCU (IC400) and its peripher-
al circuits. It controls the TX-RX unit. IC400 mainly performs
the following;
1) Switching between transmission and reception by PTT
signal input.
2) Reading channel information, frequency, and program
data from the memory circuit.
3) Sending frequency program data to the PLL.
4) Controlling squelch on/off via the DC voltage from the
squelch circuit.
5) Controlling the audio mute circuit via the decode data in-
put.
6) Transmitting tone and encode data.
Note:
The EEPROM stores tuning data (Deviation, Squelch,
etc.).
Realign the transceiver after replacing the EEPROM.
6. Signaling Circuit
6-1. Encode
■Low-speed data (QT, DQT)
Low-speed data is output from pin 49 (LSDO) of the MCU
(IC400).The signal passes through a low-pass CR filter.The
signal is mixed with the audio signal and goes to the VCO
and TCXO (X1) modulation input after signal processing in
the DAC IC (IC300).
■High-speed data (DTMF)
High-speed data (HSD) is output from pin 50 (HSDO) of
the MCU.
The signal passes through a low-pass CR filter.TX devia-
tion making an adjustment by MCU is applied to the DAC IC
(IC300). The signal is mixed with the audio signal and goes
to the VCO and TCXO.
INV
VCO
PLL
MCU
IC400 CLOCK,PLDL
IC1
PLUL
8
1
5
14
RF
SWLPF To mixer
LSDO
Q6
BUFF
Q5
TCXO
X1
SW To
RF AMP
T/RSHF
(TX: Low)
D100
D200
Q1
CV AMP
DATA,
Fig. 5 PLL block diagram / 图 5 PLL 方块图
5. 控制电路
控制电路是由微处理器 (IC400) 和外部电路构成。它控制
收发单元。IC400 的主要功能如下 :
1) 根据 PTT 的输入信号来转换发射和接收状态。
2) 从存储电路读出信道信息、频率以及编程数据。
3) 发送频率数据给 PLL。
4) 根据静噪电路输出的 DC 电压来控制静噪的开启和关闭。
5) 根据解码数据控制音频静音。
6) 发射 Tone 及编码数据。
注意 :
EEPROM 保存调谐数据 ( 频偏、静噪等 )。
更换 EEPROM 后，请重新校正手持对讲机。
6. 信令电路
6-1. 编码
■ 低速数据 (QT, DQT)
低速数据从微处理器 (IC400) 的针脚 49(LSDO) 输出。信
号通过低通 CR 滤波器。此信号与音频信号混合，在 DAC
IC(IC300) 中进行信号处理之后，进入 VCO 和 TCXO(X1) 调制
输入。
■ 高速数据 (DTMF)
高速数据 (HSD) 从微处理器的针脚 50(HSDO) 输出。
信号通过低通 CR 滤波器。由微处理器进行调整的 TX 频偏
被施加到 DAC IC(IC300)。此信号与音频信号混合，然后送入
VCO 和 TCXO。
CIRCUIT DESCRIPTION / 电路说明

TK-3000
15
6-2. Decode
■QT/DQT
The output signal from IF IC (IC200) enters the MCU
(IC400) through IC300. IC400 determines whether the QT
or DQT matches the preset value, and controls the SPMUT
and the speaker output sounds according to the squelch re-
sults.
7. Power Supply
There are five 5V power supplies for the MCU:
5M is always output while the power is on.
5C is a common 5V and is output when SAVE is not set
to ON.
5R is 5V for reception and output during reception.
5T is 5V for transmission and output during transmission.
5MS is 5V for the SP/MIC connector and the DAC IC
(IC300).
HSDO
LSDO
IC400
MCU IC300
DAC
AF
AMP
TCXO
50
49
19
20 FADJ
VCO
24
MOD
21
BEEP
18
12
Fig. 6 Encode / 图 6 编码
6-2. 解码
■ QT/DQT
IF IC(IC200) 的输出信号通过IC300 送入微处理器
(IC400)。IC400 确 认 QT 或 DQ T 是否与预设值匹配，控制
SPMUT，然后扬声器根据静噪结果输出声音。
7. 电源
微处理器有5个5V电源。
电源打开时，5M 总是输出。
5C 是普通的 5V 电源，它在 SAVE 没有设为 ON 时输出。
5R 是接收用 5V 电源，它在接收期间输出。
5T 是为发射用的 5V 电源，它在发射期间保持输出。
5MS 是 SP/MIC 和 DAC IC(IC300) 的 5V 电源。
CIRCUIT DESCRIPTION / 电路说明

TK-3000
16
MCU: F2136ACNKDRB (TX-RX unit IC400)
Pin No. Signal Name I/O Function
1NC ONC
2 VREF - Reference voltage input
3 MODE I Mode select for MCU
4, 5 NC O NC
6 RESET I Reset signal input
7 XOUT O Oscillation circuit
8 Vss - GND
9 XIN I Oscillation circuit
10 Vcc - Power supply
11 BSFT O Beat shift for MCU clock
12~14 NC O NC
15 E2WP O Write protect for EEPROM
16 E2DAT I/O Data input/output from EEPROM
17 E2CLK O Clock for EEPROM
18 CLOCK O Clock for PLL/DAC IC
19 DATA O Data for PLL/DAC IC
20 PLDL O Load enable for PLL IC
21 PLPS O Power saving for PLL IC
22 PLUL I Lock detect signal from PLL IC
23 NC O NC
24 EN4 I Encoder input 4
25 EN3 I Encoder input 3
26 EN2 I Encoder input 2
27 EN1 I Encoder input 1
28 NC O NC
29 OPTDET I 2pin option detection
30 LEDR O LED (red) control
31 LEDG O LED (green) control
32 SPMUT O Power switch for AF amp
33 NC O NC
34 5TC O 5T control
35 5CC O 5C control (SAVE)
36 5MSC O 5MS control
37 DACLD O Load enable for DAC IC
38 PTT I PTT key input
39 PFKEY I PF key input
40 INT I INT signal input
41 VDCSW O Voltage discharge switch
42 WID/NAR O Wide/Narrow control
43 RXD I Serial data input (FPU)
44 TXD O Serial data output (FPU)
45, 46 NC O NC
47 VOXIN I VOX level input
48 CVDET I VCO voltage detection
微处理器 : F2136ACNKDRB ( 收发单元 IC400)
管脚号 端口名称 输入/输出 功 能
1NC
输出 未连接
2 VREF - 基准电压
3 MODE
输入 选择模式 (MCU)
4,5 NC
输出 未连接
6 RESET
输入 MCU 复位
7 XOUT
输出 MCU 时钟输出
8 Vss - 接地
9 XIN
输入 11.0592MHz 时钟输入
10 Vcc - 5.0V
11 BSFT
输出 拍频偏移
12～14 NC
输出 未连接
15 E2WP
输出 EEPROM 写入控制
16 E2DAT
输入/输出 EEPROM 数据输入 / 输出
17 E2CLK
输出 EEPROM 时钟
18 CLOCK
输出 PLL/DAC 时钟
19 DATA
输出 PLL/DAC 数据
20 PLDL
输出 PLL 启用
21 PLPS
输出 PLL 省电状态控制
22 PLUL
输入 PLL 失锁检测
23 NC
输出 未连接
24 EN4
输入 编码器输入 4
25 EN3
输入 编码器输入 3
26 EN2
输入 编码器输入 2
27 EN1
输入 编码器输入 1
28 NC
输出 未连接
29 OPTDET
输入 耳机检测
30 LEDR
输出 红色 LED 控制
31 LEDG
输出 绿色 LED 控制
32 SPMUT
输出 AF IC 开关
33 NC
输出 未连接
34 5TC
输出 5T 控制
35 5CC
输出 5C 控制
36 5MSC
输出 5MS 控制
37 DACLD
输出 DAC 启用
38 PTT
输入 PTT 键输入
39 PFKEY
输入 侧面键输入
40 INT
输入 MCU 停止
41 VDCSW
输出 电压放电开关
42 WID/NAR
输出 宽 / 窄切换
43 RXD
输入 串行数据输出 (FPU)
44 TXD
输出 串行数据输入 (FPU)
45,46 NC
输出 未连接
47 VOXIN
输入 VOX 水平输入
48 CVDET
输入 VCO 电压电平
SEMICONDUCTOR DATA / 半导体数据

TK-3000
17
Pin No. Signal Name I/O Function
49 LSDO O Low speed data output
50 HSDO O DTMF/beep output
51 BATT I Battery voltage input
52 RSSI I RSSI input
53 SQL I Squelch input
54 LSDIN I LSD input
55 THDET I Thermistor input
56 CURDET I Current detection
57 T/RSHF O VCO Shift control
58 5VC O 5V control
59~61 NC O NC
62 TYPE2 I Destination selection 2
63 TYPE1 I Destination selection 1
64 5RC O 5R control
管脚号 端口名称 输入/输出 功 能
49 LSDO
输出 低速数据
50 HSDO
输出 侧音 AF 输出
51 BATT
输入 电池电压输入
52 RSSI
输入 RSSI 电平
53 SQL
输入 静噪电平
54 LSDIN
输入 低速数据
55 THDET
输入 热敏电阻输入
56 CURDET
输入 电流检测
57 T/RSHF
输出 VCO 偏移控制
58 5VC
输出 5V 控制
59～61 NC
输出 未连接
62 TYPE2
输入 类型选择 2
63 TYPE1
输入 类型选择 1
64 5RC
输出 5R 控制
SEMICONDUCTOR DATA / 半导体数据
COMPONENTS DESCRIPTION / 元件说明
TX-RX unit (X57-8100-23) 收发单元 (X57-8100-23)
Ref. No. Part Name Description
IC1 IC PLL system
IC200 IC FM IF system
IC300 IC DAC
IC301 IC LSD buffer
IC302 IC AF power AMP
IC303 IC AF filter
IC304 IC MIC AMP
IC305 IC QT/DQT filter
IC400 IC MCU
IC401 IC EEPROM
IC500 IC Voltage detector/RESET
IC501 IC Voltage regulator/5V
IC503 IC Voltage regulator/5V
Q1 Transistor DC switch
Q2 Transistor TX/RX RF switch
Q3 Transistor Ripple filter
Q4 FET VCO
Q5 Transistor RF buffer AMP
Q6 Transistor RF AMP
Q7 Transistor Voltage regulator/3V
有关号码 零件名称 说 明
IC1 IC PLL 系统
IC200 IC FM IF 系统
IC300 IC DAC
IC301 IC LSD 缓冲器
IC302 IC AF 放大器
IC303 IC AF 滤波器
IC304 IC 麦克风放大器
IC305 IC QT/DQT 滤波器
IC400 IC 微处理器
IC401 IC EEPROM
IC500 IC 电压检测器 / 复位
IC501 IC 电压调节器 /5V
IC503 IC 电压调节器 /5V
Q1 晶体管 直流开关
Q2 晶体管 收发开关
Q3 晶体管 纹波滤波器
Q4 场效应管 VCO 振荡器
Q5 晶体管 射频缓冲放大器
Q6 晶体管 射频放大器
Q7 晶体管 电压调节器 /3V

TK-3000
18
有关号码 零件名称 说 明
Q100 晶体管 预驱动放大器
Q101 场效应管 驱动放大器
Q102 场效应管 末级放大器
Q103 晶体管 电压放电开关
Q200 晶体管 宽 / 窄开关
Q201 晶体管 倍频器
Q202 晶体管 IF 放大器
Q203 场效应管 混频器
Q204 场效应管 高频放大器
Q300,301 晶体管 直流开关
Q302 场效应管 静音开关
Q303 场效应管 直流开关
Q304 晶体管 直流开关
Q305 晶体管 宽 / 窄开关
Q306 场效应管 静音开关
Q400 晶体管 开关
Q401,402 晶体管 直流开关
Q500,501 场效应管 直流开关
Q502 晶体管 直流开关
D1 二极管 整流
D2,3 可变电容二极管 频率控制 /VCO
D4 二极管 收发开关
D5 可变电容二极管 频率控制 /VCO
D6 可变电容二极管 调制器 /TX VCO
D7 二极管 纹波滤波器
D8 二极管 整流
D100 二极管 收发开关
D101 ～ 103 二极管 天线开关
D105 二极管 天线开关
D200 二极管 收发开关
D201,202 可变电容二极管 RX BPF 调谐
D204 可变电容二极管 RX BPF 调谐
D260,261 可变电容二极管 RX BPF 调谐
D301 二极管 整流
D400 LED LED/ 绿色
D401 LED LED/ 红色
D402 二极管 VCO 加速
D500 二极管 保护
D501 二极管 整流
COMPONENTS DESCRIPTION / 元件说明
Ref. No. Part Name Description
Q100 Transistor Pre drive AMP
Q101 FET Drive AMP
Q102 FET Final AMP
Q103 Transistor Voltage discharge switch
Q200 Transistor W/N switch
Q201 Transistor Doubler
Q202 Transistor IF AMP
Q203 FET Mixer
Q204 FET RF AMP
Q300, 301 Transistor DC switch
Q302 FET Mute swtch
Q303 FET DC switch
Q304 Transistor DC switch
Q305 Transistor W/N switch
Q306 FET Mute switch
Q400 Transistor Switch
Q401,402 Transistor DC switch
Q500,501 FET DC switch
Q502 Transistor DC switch
D1 Diode Current steering
D2, 3 Variable capaci-
tance diode Frequency control/ VCO
D4 Diode TX/RX RF switch
D5 Variable capaci-
tance diode Frequency control/ VCO
D6 Variable capaci-
tance diode Modulator /TX VCO
D7 Diode Ripple filter
D8 Diode Current steering
D100 Diode TX/RX RF switch
D101~103 Diode ANT switch
D105 Diode ANT switch
D200 Diode TX/RX RF switch
D201, 202 Variable capaci-
tance diode RX BPF tuning
D204 Variable capaci-
tance diode RX BPF tuning
D260, 261 Variable capaci-
tance diode RX BPF tuning
D301 Diode Current steering
D400 LED LED/green
D401 LED LED/red
D402 Diode VCO speed up
D500 Diode Protect
D501 Diode Current steering

TK-3000
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
19
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
C: China X: Australia M: Other Areas
TK-3000
TX-RX UNIT (X57-8100-23)
1 1A A02-4135-03 PLASTIC CABINET ASSY
2 3A A10-4150-21 CHASSIS
3 3B A82-0081-02 REAR PANEL
4 2B B11-1892-03 ILLUMINATION GUIDE
6 3B E04-0486-05 RF COAXIAL RECEPTACLE(SMA)
7 2A E23-1364-04 TERMINAL
8 1B E37-1539-05
PROCESSED LEAD WIRE(SP- BRN)
9 1B E37-1540-05
PROCESSED LEAD WIRE(SP+ GRN)
10 2A E72-0436-03 TERMINAL BLOCK
11 3B G01-4571-04 COIL SPRING
G10-1828-04 FIBROUS SHEET(SP)
13 2A G11-4437-04 SHEET(Q102-CHASSIS)
14 3A G13-2364-14 CUSHION(CHASSIS)
15 3B G13-2348-14 CUSHION(BATT-TERMINAL)
16 2A
✽
G53-1867-13 PACKING(CHASSIS)
18 1B
✽
G53-1868-12 PACKING(TOP)
19 3B
✽
G53-1869-13 PACKING(JACK)
20 1A
✽
G53-1871-14 PACKING(MIC)
22 1B K29-9487-03 KNOB(VOL)
23 1B K29-9488-03 KNOB(SELECTOR)
24 1A
✽
K29-9489-13 KNOB(PTT)
25 1A
✽
K29-9490-13 BUTTON KNOB(SIDE)
26 3B K29-9491-03 LEVER KNOB(BATTERY)
A 2B N09-2438-05 BINDING HEAD SCREW
B 3A N30-2606-48 PAN HEAD MACHINE SCREW
C 1A,2A N83-2005-48 PAN HEAD TAPTITE SCREW
28 1B T07-0787-05 SPEAKER
ACCESSORIES /
B09-0744-03
CAP(SP/MIC) ACCESSORY
B62-2309-00
INSTRUCTION MANUAL ACCESSORY
J29-0751-05 BELT CLIP
ACCESSORY
N35-3005-43
BINDING HEAD SCREW ACCESSORY
T90-1098-05
HELICAL ANTENNA ACCESSORY
W08-1245-05 AC ADAPTER
ACCESSORY
W08-1248-15 CHARGER
ACCESSORY
W09-1071-15 BATTERY ASSY
ACCESSORY
✽
X57-8100-24 TX-RX UNIT (FOR SERVICE)
D400 B30-1782-05 LED(GREEN)
D401 B30-1779-05 LED(RED)
C1 CS77CA1ER47M CHIP TNTL 0.47UF 25WV
C2 CK73HB1H102K CHIP C 1000PF K
C3 CK73HB1A104K CHIP C 0.10UF K
C4 CS77CA1C100M CHIP TNTL 10UF 16WV
C5 CS77CA1E010M CHIP TNTL 1.0UF 25WV
C7 CC73HCH1H220G CHIP C 22PF G
C8 CK73HB1A104K CHIP C 0.10UF K
C9 CC73HCH1H030B CHIP C 3.0PF B
C10 ,11 CK73HB1A105K CHIP C 1.0UF K
C12 CC73HCH1H680G CHIP C 68PF G
C13 CS77CP0J010M CHIP TNTL 1.0UF 6.3WV
C14 ,15 CK73HB1C103K CHIP C 0.010UF K
C16 CK73HB1H102K CHIP C 1000PF K
C17 CC73HCH1H040B CHIP C 4.0PF B
C19 CK73HB1H102K CHIP C 1000PF K
C20 CS77CA1A220M CHIP TNTL 22UF 10WV
C21 ,22 CC73GCH1HR75B CHIP C 0.75PF B
C23 ,24 CK73HB1H102K CHIP C 1000PF K
C25 CC73HCH1H050B CHIP C 5.0PF B
C26 CK73HB1H102K CHIP C 1000PF K
C27 CC73HCH1H220J CHIP C 22PF J
C28 CK73HB1H102K CHIP C 1000PF K
C29 CC73GCH1H0R5B CHIP C 0.5PF B
C30 CK73HB1H102K CHIP C 1000PF K
C31 CK73HB1C103K CHIP C 0.010UF K
C32 CK73HB1H102K CHIP C 1000PF K
C33 CC73HCH1H330J CHIP C 33PF J
C34 CK73HB1H102K CHIP C 1000PF K
C35 CC73HCH1H060B CHIP C 6.0PF B
C36 CC73HCH1H040B CHIP C 4.0PF B
C37 CC73HCH1H060B CHIP C 6.0PF B
C38 CC73GCH1H220J CHIP C 22PF J
C39 CC73HCH1H150G CHIP C 15PF G
C40 ,41 CK73HB1H102K CHIP C 1000PF K
C42 CC73HCH1H040B CHIP C 4.0PF B
C43 CK73HB1H102K CHIP C 1000PF K
C54 CC73HCH1H040B CHIP C 4.0PF B
C100 CC73HCH1H100B CHIP C 10PF B
C101 CC73HCH1H271J CHIP C 270PF J
C102 CC73HCH1H220J CHIP C 22PF J
C103,104 CC73HCH1H271J CHIP C 270PF J
C105 CK73HB1A104K CHIP C 0.10UF K
C107 CC73HCH1H271J CHIP C 270PF J
C108 CC73HCH1H120J CHIP C 12PF J
C109 CC73HCH1H090B CHIP C 9.0PF B
C110,111 CC73HCH1H271J CHIP C 270PF J
C112 CC73HCH1H221J CHIP C 220PF J
C113,114 CC73HCH1H271J CHIP C 270PF J
C116 CK73HB1C103K CHIP C 0.010UF K
C117 CK73FB1A225K CHIP C 2.2UF K
C119,120 CC73HCH1H271J CHIP C 270PF J
TK-3000 TX-RX UNIT (X57-8100-23)
✽ 新零件。 代表对安全至关重要的零件。
我们不会提供没有零件号的零件。
PARTS LISTPARTS LIST / 零件表
随机附件

TK-3000
20
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-8100-23)
C124 CC73HCH1H271J CHIP C 270PF J
C127 CC73GCH1H181J CHIP C 180PF J
C128 CC73GCH1H0R5B CHIP C 0.5PF B
C129 CC73HCH1H271J CHIP C 270PF J
C130 CC73GCH1H090B CHIP C 9.0PF B
C131 CC73GCH1H820J CHIP C 82PF J
C132 CC73GCH1H060B CHIP C 6.0PF B
C133 CC73HCH1H070B CHIP C 7.0PF B
C134 CC73HCH1H271J CHIP C 270PF J
C135 CC73GCH1H030B CHIP C 3.0PF B
C136 CC73GCH1H150J CHIP C 15PF J
C137 CC73GCH1H3R5B CHIP C 3.5PF B
C138 CC73GCH1H090B CHIP C 9.0PF B
C139 CK73FB1A475K CHIP C 4.7UF K
C145 CC73HCH1H271J CHIP C 270PF J
C146 CC73HCH1H1R5B CHIP C 1.5PF B
C150 CC73HCH1H020C CHIP C 2.0PF C
C153 CC73HCH1H390J CHIP C 39PF J
C158,159 CC73HCH1H271J CHIP C 270PF J
C173 CC73GCH1H560J CHIP C 56PF J
C174 CC73GCH1H120J CHIP C 12PF J
C175 CC73GCH1H330J CHIP C 33PF J
C179 CC73GCH1H220J CHIP C 22PF J
C182 CC73GCH1H220J CHIP C 22PF J
C183 CC73GCH1H150J CHIP C 15PF J
C185 CC73GCH1H120J CHIP C 12PF J
C187 CC73GCH1H090B CHIP C 9.0PF B
C200 CK73FB1A106K CHIP C 10UF K
C201 CK73HB1H102K CHIP C 1000PF K
C202 CK73HB1C103K CHIP C 0.010UF K
C203 CC73HCH1H101J CHIP C 100PF J
C204 CK73HB1E223K CHIP C 0.022UF K
C205 CK73HB1A104K CHIP C 0.10UF K
C206,207 CC73HCH1H221J CHIP C 220PF J
C208 CK73HB1A104K CHIP C 0.10UF K
C209 CC73HCH1H220J CHIP C 22PF J
C210 CK73HB1A104K CHIP C 0.10UF K
C211 CK73HB1C333K CHIP C 0.033UF K
C212,213 CK73HB1A104K CHIP C 0.10UF K
C214 CK73HB1C103K CHIP C 0.010UF K
C215 CC73HCH1H220J CHIP C 22PF J
C216 CK73HB1C103K CHIP C 0.010UF K
C217 CC73HCH1H050C CHIP C 5.0PF C
C218 CK73HB1C103K CHIP C 0.010UF K
C219 CC73HCH1H220J CHIP C 22PF J
C220 CK73HB1H102K CHIP C 1000PF K
C221 CK73HB1C103K CHIP C 0.010UF K
C222 CC73HCH1H080D CHIP C 8.0PF D
C223 CC73HCH1H080B CHIP C 8.0PF B
C224 CK73HB1C103K CHIP C 0.010UF K
C225 CC73HCH1H050B CHIP C 5.0PF B
C226 CK73HB1H471K CHIP C 470PF K
C227 CK73HB1C103K CHIP C 0.010UF K
C228 CC73HCH1H030B CHIP C 3.0PF B
C230 CC73HCH1H050B CHIP C 5.0PF B
C233 CC73HCH1H040B CHIP C 4.0PF B
C236 CC73HCH1H100B CHIP C 10PF B
C237 CC73HCH1H120J CHIP C 12PF J
C238 CC73HCH1H040B CHIP C 4.0PF B
C239 CC73HCH1HR75B CHIP C 0.75PF B
C240-242 CK73HB1H471K CHIP C 470PF K
C243 CK73HB1A104K CHIP C 0.10UF K
C244 CK73HB1H471K CHIP C 470PF K
C245 CC73HCH1H020B CHIP C 2.0PF B
C247 CC73HCH1HR75B CHIP C 0.75PF B
C248 CK73HB1A104K CHIP C 0.10UF K
C250 CK73HB1H471K CHIP C 470PF K
C252 CC73HCH1H010B CHIP C 1.0PF B
C253 CC73HCH1H100B CHIP C 10PF B
C254 CC73HCH1H1R5B CHIP C 1.5PF B
C255 CK73HB1A104K CHIP C 0.10UF K
C256 CK73HB1H471K CHIP C 470PF K
C257 CC73HCH1H030B CHIP C 3.0PF B
C258 CK73HB1H102K CHIP C 1000PF K
C259 CK73HB1C103K CHIP C 0.010UF K
C262 CK73HB1H471K CHIP C 470PF K
C263 CC73HCH1H180J CHIP C 18PF J
C268,269 CC73HCH1H100B CHIP C 10PF B
C270 CC73HCH1H1R5B CHIP C 1.5PF B
C271 CC73HCH1H020B CHIP C 2.0PF B
C274 CK73HB1H471K CHIP C 470PF K
C275 CK73HB1C103K CHIP C 0.010UF K
C276 CK73HB1H471K CHIP C 470PF K
C277 CK73HB1A104K CHIP C 0.10UF K
C300,301 CK73HB1H102K CHIP C 1000PF K
C302 C92-0953-05 ELECTRO 100UF 6.3WV
C303 CK73HB1C473K CHIP C 0.047UF K
C304 CK73FB1A106K CHIP C 10UF K
C305 CK73HB1C103K CHIP C 0.010UF K
C306 CK73HB1A224K CHIP C 0.22UF K
C308 CK73GB1E105K CHIP C 1.0UF K
C309 CK73HB1A104K CHIP C 0.10UF K
C310 CK73HB1C473K CHIP C 0.047UF K
C311 CK73HB1A105K CHIP C 1.0UF K
C312 CK73HB1C473K CHIP C 0.047UF K
C313 CK73HB1A104K CHIP C 0.10UF K
C314 CC73HCH1H101J CHIP C 100PF J
C315 CK73FB1A106K CHIP C 10UF K
C316 CK73HB1A104K CHIP C 0.10UF K
C317 CK73HB1C103K CHIP C 0.010UF K
C318 CC73HCH1H221J CHIP C 220PF J
C319 CK73HB1C103K CHIP C 0.010UF K
C320 CK73GB1E104K CHIP C 0.10UF K
C321 CK73HB1C103K CHIP C 0.010UF K
C322 CC73HCH1H271J CHIP C 270PF J
C323 CK73HB1A104K CHIP C 0.10UF K
C324 CK73HB1A184K CHIP C 0.18UF K
C326 CK73HB1H822K CHIP C 8200PF K
C328 CK73HB1A394K CHIP C 0.39UF K
C329 CK73HB1C333K CHIP C 0.033UF K
C330 CK73HB1H561K CHIP C 560PF K
C332 CK73HB1C103K CHIP C 0.010UF K
C333 CK73HB1H102K CHIP C 1000PF K
C334,335 CK73HB1A184K CHIP C 0.18UF K
C336 CK73HB1C103K CHIP C 0.010UF K
C337 CK73HB1A184K CHIP C 0.18UF K
C338 CC73HCH1H331J CHIP C 330PF J
C339 CK73HB1A104K CHIP C 0.10UF K
C340 CC73HCH1H100B CHIP C 10PF B
C341 CK73HB1H222K CHIP C 2200PF K
PARTS LISTPARTS LIST / 零件表
