Kenwood TK-285 User manual

VHF FM TRANSCEIVER
TK-285/(N)
©2000-6 PRINTED IN JAPAN
B51-8530-00(S) 847
SERVICEMANUAL
GENERAL ................................................................................. 2
SYSTEM SET-UP ..................................................................... 2
OPERATING FEATURES......................................................... 3
REALIGNMENT ........................................................................ 4
CIRCUIT DESCRIPTION .......................................................... 6
SEMICONDUCTOR DATA ..................................................... 11
DESCRIPTION OF COMPONENTS....................................... 13
PARTS LIST............................................................................ 14
EXPLODED VIEW .................................................................. 22
PACKING ................................................................................ 23
ADJUSTMENT........................................................................ 24
TERMINAL FUNCTION .......................................................... 32
PC BOARD VIEWS
DISPLAY UNIT (X54-3210-13) ............................................ 33
TX-RX UNIT (X57-619X-XX) ............................................... 39
SCHEMATIC DIAGRAM ......................................................... 45
BLOCK DIAGRAM .................................................................. 49
LEVEL DIAGRAM ................................................................... 51
OPTIONS ................................................................................ 52
SPECIFICATIONS ...............................................BACK COVER
CONTENTS
CAUTION
When using an external power connector, please use
with maximum final module protection of 9V.
Photo is K type
Knob (ENC)
(K29-5232-03)
Knob (VOL)
(K29-5231-03)
Cabinet assy
(A02-2055-53)
(16 keys)
Badge
(B43-1106-14)
Packing
(G53-0896-02)
(16 keys)
Panel assy
(A62-0535-04)
Helical antenna
(T90-0733-05):K, E
(T90-0734-05):(N)M
Knob (PTT etc)
(K29-5157-03)
fineline6

ABCDE FGH I OPQRS
1
3
4
5
6
7
8
9
10
11
12
13
14
2
33 34
TK-285/(N)
DISPLAY UNIT (X54-3210-13) Component Side View
Component side
Foil side
Pattern 1
Pattern 2
Pattern 3
Pattern 4
DISPLAY UNIT
(X54-3210-13)
PC BOARD VIEW
S301
MON S302 PTT S303 LAMP
CN302
C329 C330
D305
D306
C3
2
1
6
5
4
9
8
7
#
0
∗
B
A
S
D307
D308
D309D310
C337
C338
MIC
LCD ASSY
X54-3210-13 (A/2)
J72-0517-22
X54-3210-13 (B/2)
J72-0517-22
+
–
C317 C316
SP+ 1
SP– 2
C336
D301
.oN.feRsserddA
103DC9
503DL8
603DL6
703DN8
803DN6
903DQ8
013DQ6
fineline6

TK-285/(N)
General
Frequency Range
RX, TX..............................................................................K, E : 217 to 250MHz (RX) 218 to 250MHz (TX)
(N)M : 240 to 270MHz (TX, RX)
Channel Spacing..............................................................12.5kHz (PLL channel stepping, 6.25kHz)
Battery Voltage.................................................................DC 7.5V ±20%
Battery Life (Conventional Mode).....................................More than 8 hours at 5-5-90 duty cycle with KNB-16A battery
More than 10 hours at 5-5-90 duty cycle with KNB-17A battery
Temprature Range ...........................................................–30˚C to +60˚C (-22˚F to + 140˚F)
Dimension and Weight
With KNB-16A (1100mAh battery) ................................5.33” (135mm) H x 2.29” (58mm) W x 1.34” (34mm) D 1.01lbs (460g)
(Dimensions not including Protrusions, Weight includes antenna and belt hook)
Receiver(Measurements made per TIA/EIA-603, ETS)
RF Input Impedance.........................................................50Ω
Sensitivity
12dB SINAD .................................................................. 0.28µV
Selectivity .........................................................................63dB (EIA), 63dB (ETS)
ntermodulation ................................................................65dB (EIA), 65dB (ETS)
Spurious (Except for IF 1/2) .............................................70dB
Frequency Stability...........................................................±0.00025% (-30˚C to +60˚C)
Channel Spread ...............................................................33MHz : K, E
30MHz : (N)M
Audio Power Output .........................................................500mW at 16Ωless than 5% distortion
Transmitter(Measurements made per TIA/EIA-603,ETS)
RF Power Output
Hi ...................................................................................5W
Low................................................................................1W
RF Output Impedance......................................................50Ω
Spurious ...........................................................................-70dB (EIA), -36dBm ≤1GHz,-30dBm >1GHz (ETS)
Modulation .......................................................................8K50F3E, 7K50F2D (E, (N)M)
11K0F3E, 10K5F2D (K)
FM Noise..........................................................................-40dB
Audio Distortion................................................................Less than 3%
Frequency Stability...........................................................±0.00025% (-30˚C to +60˚C)
Channel Spread ...............................................................32MHz : K, E
30MHz : (N)M
SPECIFICATIONS
