Kettler PFS25 User manual

Assembly Instructions
2.5m & 3.0m Free-Arm Parasol
PFS25/PFR30
Sept 2020
IMPORTANT
PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE.
THIS IS IMPORTANT INFORMATION REGARDING THE
USE AND CARE OF YOUR GARDEN FURNITURE. ASSEMBLY
TIME
PERSONS
REQUIRED
30
MINUTES

Parts List
Helpful advice before you begin:
1. We suggest you spend a short time reading through this leaet and then follow the simple
step by step instructions.
2. Do not discard any of the packaging until you have checked that you have all the parts and
the pack of ttings.
3. Assemble this product on a soft surface.
4. Keep ttings out of children’s reach.
5. Do not use any other tools other than those recommended to build this product.
6. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler.
7. In the unlikely event that this product has missing or damaged parts, please visit our website
www.kettler.co.uk
Part Qty
A1
B1
C1
D1
E 4
F4
G1
H 1
I1

Assembly
2
1
D
C
FF
EE1
Open
Sand Water
Close
Each section of the
base requires 20kg of
sand and then needs
to be topped up with
water. Water alone will
not support the base.
Tip: use kiln dried
sand for easier lling.

Assembly
3
4
E
A
F
B
Before opening the
umbrella, release the band
and allow the umbrella to
relax. There are 4 holes on
the side pole, when you
open the umbrella, raise
the slide handle to the third
hole counted from the
bottom, then release the
slide handle.

Operating Instructions
1 2
360º
3
The umbrella will rotate
360 degrees by pulling out
the knob and turning the
knob 180 degrees.

Operating Instructions
The parasol should be closed and the night cover tted in windy
conditions and when not in use. Failure to do this may result in
damage to the parasol.
The night cover
ts over the
canopy and
frame.
6
1. 2.
Protective cover assembly:
Fibreglass
supporting
rod
Assemble the 3 part bleglass rods
in sequence and insert into the slit in
fabric at bottom of zip.
Place cover over the parasol and
frame and zip down.
H

Information
This parasol has UV50+ protection. What does that mean?
For example, a fabric with a UPF rating of 50 only allows 1/50th of the sun’s UV
radiation to pass through it. This means that this fabric will reduce your skin’s
UV radiation exposure by 50 times (98% UV block).
UV
Hand wash canopy
The canopy can be carefully removed and washed via hand only. We advise putting
back onto the frame to dry naturally.

For Your Safety
• This product may only be used for its intended purpose as furniture for residential properties.
• Check all components regularly for correct function, damage and loose connections especially
at the start of the season and at 1-2 month intervals dependent on use.
• Damaged components may endanger your safety or shorten the life of the product. Replace all
damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to
purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop
• Kettler will not be responsible for damaged caused by improper use.
Attention
• Whilst assembling this product keep out of the reach of children. (Choking hazard –
contains small parts)
• Ensure that your working area is free of possible sources of danger, for example don’t
leave any tools lying around.
• Always dispose of packaging material in such a way that it may not cause any danger.
There is always a risk of suocation if children play with plastic bags!
• We reserve the right to make changes for technical reasons.
