Elements Ember Nightstand CEB700NSE User manual

1-7
Item #: CEB700NSE
Ember Nightstand WHITE NIGHSTAND W/ USB
ASSEMBLY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS
Item #: CEB700NSE
Please identify and locate all assembly parts (see parts list) before discarding any packing materials.
Some parts may have become loose during transit.
2PCS
TOP PANEL
1
QYT
DESCRIPTIONNO. SKETCH
1PC
SHELF PANEL
2
1PC
BOTTOM PANEL
3
1PC
BACK PANEL
4
MADE IN TAIWAN
PARTS LIST
2-7
1PC5
SIDE FRAME
BACK

1PCDOOR PAENL6
QYT
DESCRIPTIONNO.
1PCUSB7
1PCDOOR BUCKLE8
9
MADE IN TAIWAN 3-7
4PCS
CAP
16 x 16mm
10
11 12PCS
SHORT BOLT
3/16" x 12mm
2PCSHINGE INSERT
SKETCH

2PCS
SCREW
3 x 12mm
12
QYT
DESCRIPTIONNO.
2PCSLONG BOLT13
1PC
ALLEN KEY
4mm
14
MADE IN TAIWAN 4-7
SKETCH

5-7
Step 1: 1.Insert Cap (10) into Side Frame (1) as shown.
2.Attach Back Panel (5) to Side Frame (1) as shown.
3.Attach Top Panel (2) to the assemble in Step 1 -2 using Short Bolt (11) as shown.
Step 2: 1.Install Door Buckle (8) onto the Shelf Panel (3)
2.Attach Shelf Panel (3) to the assemble in Step 1 using Short Bolt (11) as shown.
2
1
5
1
10
10
10
10
311
11
8
12
11
11

6-7
Step 3: 1.Insert Hinge Insert (9) into Shelf Panel (3) and Bottom Panel (4) as shown.
2.Install Door Panel (6) onto Hinge Insert (9) and then attach Bottom Panel (4) using Short Bolt (11).
9
6
9
11
11
4
13
4
5
3
Step 4: 1.Install Long Bolt (13) onto the hole as shown.

7-7
Step 5: Install Usb (7) onto the Top Panel (2) as shown.
Complete. Congratulations on your assemble success.
7
2
