keylitos KJ70F-117 User manual

READ AND SAVE THESE INSTRUCTIONS
PICTURE FOR REFERENCE ONLY
AIR PURIFIER
Model: KJ70F-117
INSTRUCTIONS

ACTIVATE YOUR 5 YEARS WARRANTY
PLEASE VISIT NOW
CUSTOMER SERVICE
https://keylitos.com/warranty
[email protected]
@Keylitos
[phone]
(Register within 2 weeks after receiving your air purifier)
Please Download User Manual on Below Link:
https://keylitos.com/downloads

CATALOG
SAFETY INFORMATION
PRODUCT SPECIFICATIONS
PRODUCT CLEANING SYSTEM
GETTING STARTED
OPERATION INSTRUCTION
FILTER CLEANING/REPLACEMENT
TROUBLESHOOTING GUIDANCE
WARRANTY AND SERVICE
01
03
05
06
08
09
11
12

SAFETY INFORMATION 01
This product should be used only in accordance with the specifications outlined in this manual. Usage other
than what has been specified here may result in serious injury.
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric
shock and injury to persons, including the following:
·Read all instructions before using the product.
·To avoid fire or shock hazard, plug the appliance directly into a correct electrical outlet.
·To avoid fire or shock hazard, DO NOT pull, bend, distort and damage the power cord.
·DO NOT use the product if the power cord/ power plug/ power outlet is damaged.
·To protect against electrical hazards, DO NOT immerse in water or other liquids. Do not use the product near
water.
·Children cannot recognize the danger associated with the usage of electrical appliances. For this reason,
always supervise children when they are near the unit.
·DO NOT touch the power cord with wet hands.
·Always unplug the air purifier before moving it, opening the grill, changing filters, cleaning or whenever the air
purifier is not in use. To disconnect the cord, pull the cord by grasping the plug. Never pull the cord itself.
·NEVER drop or insert any object into any openings.
·DO NOT cover cord with throw rugs, runners, or similar coverings.
·DO NOT use outdoors.
·DO NOT place anything on top of the unit.
·NEVER block the air openings, grills/outlets or place on a soft surface such as a bed or sofa, asthis could
cause the unit to tip over, blocking the air intake or outtake opening.
·DO NOT use gasoline, benzene, thinner, harsh cleaners, etc, on and/or in the unit while cleaning as they will
damage the product. NEVER use alcohol or other solvents.
·WARNING - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY
SOLID-STATE SPEED CONTROL DEVICE.
FOR USAGE
WARNINGS
· DO NOT use the machine without filter in.

SAFETY INFORMATION 02
·DO NOT place the machine near heat sources such as heater, radiators, stoves and so on.
·To ensure the effect of purification, keep the air purifier around with a certain area to let the wind go in and out. Do not
clean and reuse the composite filter; Please be careful when cleaning the machine.
·Only soft cloth can be used to clean the surface of the machine, otherwise, the machine may be damaged or broken,
and may cause sensor failure.
·It is forbidden to wipe with alcohol or organic solvent, otherwise, it will damage the product or cause electric shock, fire,
etc.
·When cleaning the machine or not using this machine, please disconnect the device power supply and wipe the dust
or other matter of the power plug. Otherwise, it may cause electric shock or fire caused by short circuit.
·This appliance has a polarized plug(one blade is wider than the other). To reduce risk of electric shock, this plug is
intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still doesn't
fit, please contact a qualified electrician. Do not attempt to defeat this safety feature.
·This machine is not suitable for people with disabilities, perceptual impairment, mental retardation or children.
·It is prohibited to sit, lean on or climb onto the equipment to prevent the machine from being unstable and causing
injury.
·When moving, be sure to stop running and pull out the power plug.
·DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit.
·Doing so will void your warranty. The inside of the unit contains no user serviceable parts. All servicing should be
performed by qualified personnel only.
·If the equipment produces odors /noise at the running time, please stop using the equipment and clean or replace the
filter.
Warm Reminder
FOR USAGE
·Please install the equipment in a dry environment.
·Do not install the equipment in a flammable environment.
·Please take out the polybag outside before installing the machine.

03
PRODUCT SPECIFICATIONS
Air purifier main machine
(The filter is placed inside)
1 piece combination filter User manual
The left outlet
Rotate Speed switch
Decoration
Front panel
Removable base
Air Inlet
Packing Includes
Product Structure

04
PRODUCT SPECIFICATIONS
Item: Air Purifier
Model: KJ70F-117
Voltage: 110V-60Hz
Wattage: 35W
CADR: 120m3 / h
Product Size: 6.3*8.7*13.8inch
Material: ABS
Speed: 1/2/3
Filter: 1pc composite filter
(pre + activated carbon, HEPA)
HEPA filter: H13
Removal rate: 99.9％
Noise(max): ≤54 dB（A）
Coverage area: 150ft² / 14m²
Specifications

PRODUCT CLEANING SYSTEM
Main machine
Combination filter
( Pre-filter/Charcoal filter+ HEPA filter)
Front panel
Pollen
Smoke
PM2.5
viruses
Germs
Odor
Germs
Dust
PM2.5
Odor
viruses
Hair
Combination filter (Pre-filter/Charcoal filter+ HEPA filter)
Capture the initial dust and allergen particles. It can effectively filter pollutants
such as smoke, dust and bacteria.
05

06
GETTING STARTED
1.Open the front panel of the device.
Gently hold both sides of the front panel with both hands, and open the device outwards.
2.Take out the combination filter from its plastic packaging.
3. Install combination filter back( the one with cloth strip facing out ).
cloth

OPERATION INSTRUCTION
1. Turn on the switch by clockwise, speed is 1-2-3
respectively. (Fig. 1)
2. Turn on the switch by counterclockwise, then
return to OFF button. ( The machine stops
running on “OFF”) (Fig. 2)
Fig. 1 Fig. 2
4.Align the matching slots and install the front panel.
07
GETTING STARTED
Rotary Switches Speed Level

OPERATION INSTRUCTION
The device Placement instructions
This device can be applied to various scenes in two different ways.
1.Standing type：Suitable scenarios: Table, living room, bedroom.
2.Lying type：All of the above places are applicable.
(1) When place the unit lying down, please place the left side of the unit up on
the table and make sure that the air inlet and outlet are without any blocks.
(2) The machine base is detachable. When you don't want to use, you can take
it off and save it for next use.
Note:Push the base along the arrow direction to assemble/ disassemble
Removable machine base
08
Important notes:
Please use the accessories provided in the box.
DO NOT leak any liquid into the machine. If any liquid enters into the
machine,do not operate the machine. Please disconnect device`s power
supply and contact after-sales for help.

FILTER CLEANING
FILTER REPLACEMENT
Please check your device manual first before attempting to clean the purifier, proceed as follows:
1.Wear a protective face mask and gloves. If you suffer from severe allergies, or if your filter is capturing
any strong pollutants, protect yourself during the cleaning process.
2.Unplug the unit, remove the filter element.
3.First use a dry brush or cloth to clean the dust on the surface, and use a vacuum cleaner or the cold
air outlet of the hairdryer to blow the filter element.
Note: This filter element cannot be washed, nor can it be wiped with a wet cloth.
09
FILTER CLEANING/REPLACEMENT
1.Turn off the device.
2.Open the front panel of the device.
After ensuring that the knob position switch
is in the 0FF position, the power plug must
be unplugged and then cut off the main unit
power.
Attention

10
FILTER CLEANING/REPLACEMENT
3.Take out the combination filter and wrap the used filter with a garbage bag to avoid
the pollutants on the filter from falling on the floor.
4.Install the panel well after replace a new filter ( the one with cloth strip facing out) inside,
then turn on the unit to work.
The filter service time may differ from the different
using environment. It is normally suggested to
replace the filter every 3-6 months.
Attention
a.Please read the replacement filter operating
instructions carefully to ensure the purification
effect of the purifier.
b.The filter that reaches its service time can not
be used again even it is clean.
Attention
cloth

After all the checks above, troubleshooting still existed, please contact our service
center or contact technical service center. Do not attempt to disassemble and
maintain the maintenance by yourself, to avoid any danger and damages to
the machine.
11
TROUBLESHOOTING GUIDANCE
Machine can not start A. Unplug power plug.
B. Machine front panel not in position.
A . Reconnect power plug.
B. Re-install the front panel in
position according to the
instructions.
A. It is recommended that the
room be ventilated.
B. Replace with the new filter.
A. Install the filter correctly.
B. Place the unit at least a foot
away from the obstacles.
C. Replace for new
combination filter.
A.Contact after-sales
[email protected].
B.Use a brush to remove the
dust, and then use vacuum
cleaner or the cold air outlet
of hairdryert to blow the filter.
Adjust the filter to right direction
and install the filter to the
bottom slot( the one with cloth
strip facing out).
A. More pollutants indoor such
as more smoking.
B. Filter is polluted severely.
A. Whether the installation is not tight.
B. Other matter stored in the machine.
Filter is installed opposite.
A. Filter is not installed into the
machine.
B. Machine is placed in narrow
space or space with obstacles
nearby which may have negative
impact on the purification effect.
C. Filter is too dirty.
Odor in the outlet
None obvious dust
removal effect,none
air quality improvement
Running noise loud
Filter cannot be installed
Phenomenon Possible reason Solution
If malfunction occurs in the air purifier, please check as phenomenon showed before
repair

WARRANTY AND SERVICE 12
Register your warranty to receive premium benefits! By registering your product, you will receive 5 years
warranty, expedited customer support, hassle-free returns and helpful product tips. You will also get first
access to new products and giveaways, in just a few simple steps!
ACTIVATE YOUR 5 YEARS WARRANTY NOW
—https://keylitos.com/warranty
Or SCAN ME
(Register within 2 weeks after receiving your air purifier)
If your air purifier should prove to be defective, contact us, we'll offer replacement or refund.
To obtain warranty service, simply contact an authorized service representative:
LIMITED FIVE-YEAR WARRANTY
[email protected]
@Keylitos
[phone]

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
MADE IN CHINA
FCC COMPLIANCE
