NETCOM2P Installation Guide
This guide outlines how to install and program the NETCOM2P—serial to Ethernet
converter—for network communication. As the NETCOM2P can be configured to operate
with a CIM or directly from a PC109x or later ACU control board, this guide is divided into
the following two separate installation sections:
NETCOM2P/CIM Installation—page 2
NETCOM2P/ACU Control Board Installation (PC109x or later)—page 11
Please refer to the appropriate installation instructions and diagrams. Installation
procedures are different for each type of configuration.
Important
Installing the NETCOM2P involves two connection procedures, temporary serial
programming connections and permanent operation connections. This applies to both types
of installations. Please be sure to review the relevant diagrams for programming and
operating connections.
Before You Start
Verify that you have all the parts as outlined below.
Obtain a static IP address, Subnet Mask, and, if applicable, a Gateway from the
network administrator for each NETCOM2P. Space for recording addresses is provided
at the back.
Ensure that you install the latest Keyscan NETCOM Program Tool utility, which is on
the enclosed CD, on a laptop or PC that can be serially connected to program the
NETCOM2P.
If using Keyscan Aurora software, the control board requires firmware version 9.20 or
higher.
About the Reset Function
During the NETCOM2P programming procedures, you are prompted to reset the device,
which is a soft re-boot. This is equivalent to a power cycle.
Contents
NETCOM2P/CIM Installation
2
NETCOM2P/ACU Installation
11
Specifications
24
Parts List
NETCOM2P
1
Serial Data Cable
1
Utilities & Drivers CD
1

Keyscan Inc. A Member of the Kaba Group
2
NETCOM2P/CIM Installation
For installing a NETCOM2P mounted on a CIM, follow the directions in this section of the
installation guide.
Install Keyscan NETCOM Program Tool Utility
Each NETCOM2P that you are installing must be programmed with the Keyscan NETCOM
Program Utility. Ensure you have the latest NETCOM Program Utility software installed
which is on the enclosed CD; otherwise you may encounter communication difficulties. You
require a PC or laptop that has a direct serial connection with the NETCOM2P via the CIM
terminal block to program the device. To install the Keyscan NETCOM Program Tool utility,
load the Keyscan Utilities & Drivers CD into the CD-ROM or DVD drive. Locate and double
click on the Keyscan NETCOM Setup and follow the on-screen prompts.
Important
If you program the NETCOM2P with a previous version of the NETCOM Program Utility, you
may experience technical difficulties. You may have to re-program the NETCOM following
the procedures outlined in Manually Configure the NETCOM2 via a Serial Connection
located on page 18.
Connection Diagrams
Connection diagrams are on the succeeding pages of the guide as outlined:
See Figure 1 to Figure 4 for temporary serial programming connections to the
laptop/PC with the Keyscan NETCOM Program Tool utility software.
See Figure 5 for NETCOM2P/CIM permanent operating connections on the network.
Steps to Program and Install a NETCOM2P with a CIM
The NETCOM2P can only be programmed using a direct serial connection via the CIM
terminal block.
1. Mount the NETCOM2P in the socket on the CIM as shown below. Press down so the
standoffs secure the NETCOM2P to the CIM circuit board. Do not change the
orientation of the standoffs.
TD1
RD1
TD2
RD2
GND
RTS
CTS
GND
RTS
CTS B3 B2 B1 B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
1 2 1 2 1 2 1 2
Rx - COM COM
CAN CAN - Tx
J3J4 J9
J12
Power
Good
COM1
COM2
HDR1
J10
J11
Fault
(Flashing)
RJ45
Terminal
Jack
RESET
NETCOMP
Standoffs
NETCOMP
CIM
Standoff
- correct
mounting
orientation
Standoff
Program Mode
Jumper ON J12
KI-00466E-04-13
2. Mount the CIM/NETCOMP in the designated location in the metal enclosure.
As an option the NETCOMP can be programmed off-site before installation,
providing you have a 12 VDC power supply that can be connected to the CIM’s
TB4 power terminal.
Continued on the next page…

NETCOM2P Installation Guide
3
Installation Steps ...cont’d
3. On the CIM circuit board, place a jumper on J12.
4. Connect the ribbon cable from the HDR1 terminal on the CIM circuit board to the H2
terminal on the control board. See Figure 1 or Figure 3. The H2 terminal provides
power to the CIM and the NETCOMP.
5. Ensure the control board has power.
6. If the control board is newly installed and this is the first time it is powered up,
restore the factory defaults as outlined depending on the version of PC109x control
board:
J16 Jumpers –after applying power, place a jumper ON J16—pin H, then
momentarily place a jumper ON J1—Clear Memory to load the factory defaults.
Allow approximately 2 minutes and do not make any changes while the control
board re-configures. Remove the jumper from J16—pin H.
S1 and S3 Switches –After applying power, press S1, wait 5 seconds, and then
press S3 within 10 seconds to load the factory defaults. Allow approximately 2
minutes and do not make any changes while the control board re-configures.
7. Connect the RS-232 serial cable from the laptop or PC to the COM2 terminal block on
the CIM circuit board.
8. Turn on the laptop or PC connected to the CIM circuit board.
9. Select start > All Programs > Keyscan NETCOM Program Tool > Keyscan NETCOM
Program Tool.
10. From the Keyscan NETCOM Utility screen, click on Program NETCOM Device.
11. From the Select NETCOM Device Type screen, click on the Program NETCOM2 Family
of Boards button.
12. From the Program NETCOM2B, NETCOM2 & NETCOM2P Boards screen, enter the IP
address, the Subnet Mask and, if applicable, a Gateway.

Keyscan Inc. A Member of the Kaba Group
4
Installation Steps …cont’d
13. From Program via IP Address or Serial Port, select the port on the PC/laptop that has
the serial connection with the CIM/NETCOMP.
14. Select the baud rate that corresponds to the J16 jumper settings or the S2 switch
settings on the control board.
The recommended ACU bit/s (baud rate) is 57,600
15. Leave Ethernet Connection Type set on Automatic Negotiation unless the IT
administrator gives a specific setting.
If the NETCOM device experiences network communication difficulties, you may
have to alter the Ethernet Connection Type from automatic negotiation. (The
Ethernet Connection Type is the network speed & duplex setting). Set the
NETCOM so it matches the network equipment setting. If the network equipment
was on an automatic setting, then reconfigure both the network equipment,
which may include routers or switches, and the NETCOM to a matching fixed
speed and duplex setting. As an example, NETCOM = 100 Mbit/Half Duplex –
Network equipment = 100Mbit/Half Duplex.
16. The Discovery Port 77FE is disabled by default. Keyscan recommends that you leave it
on the default setting. This function is principally for troubleshooting communication
difficulties.
If you de-select the Disable Discovery Port 77FE function (the box does not have
a check mark) the Discover NETCOM Devices function will list the device by its
MAC address and IP address if it is located on the network.
17. Click on the Program NETCOM button.
18. The Program NETCOM2B, NETCOM2 & NETCOM2P Boards screen indicates it is waiting
for a NETCOM reset or power cycle. Momentarily place a jumper on the CIM board’s J1
RESET pins; then remove the jumper and wait while the NETCOM is programmed.
If the NETCOM does not program on the 1st attempt, keep the NETCOM Program
Settings screen open and press the F4 key. Click inside the box to the left of
Program Server Address Settings Only so it has a check mark. Ensure the
settings have been retained, including the IP Address, otherwise re-enter them.
Click on the Program NETCOM button. If successful, program the NETCOM one
more time. For additional programming tips, press the F1 key with the Keyscan
NETCOM Program Settings screen open.
19. When prompted by the NETCOM Program Tool Utility, ensure that you remove the
temporary RS-232 data cable connection from the CIM’s COM2 terminal after the
device has been programmed. Momentarily place a jumper on the NETCOM2P’s RESET
pins and then remove the jumper.
20. Remove the jumper from J12 on the CIM circuit board.
21. Place a jumper on J4 on the CIM unit to designate it as CIM 0.
22. Momentarily place a jumper on the CIM board’s J1 RESET pins to initiate the jumper
change in the preceding step.
23. Connect a network cable from the RJ45 jack on the NETCOMP to a network terminal.
24. At the PC/laptop, click on the OK button in the Disconnect the serial cable… screen.
25. If the PC /laptop has a network connection, verify network communication with the
NETCOMP by selecting the Start Ping button on the Keyscan NETCOM Utility screen.
If the PC/laptop does not have a network connection, close the NETCOM Program
Tool utility, complete any remaining connections for permanent operation, re-
locate to a PC connected to the network and PING the NETCOM2’s IP address
using the Command Prompt. The Average Round Trip Times should be less than
100 milliseconds and the Packets Sent should equal the Packets Received with
0% loss. Continue at step 26.
Continued on the next page...

NETCOM2P Installation Guide
5
Installation Steps ...cont’d
26. Wait for the Ping Status result message:
IP Success indicates the NETCOM2P has network communication
IP Timed Out indicates the NETCOM2P does not have network communication—
verify settings and connections
27. Click on the x in the upper right corner of the Keyscan NETCOM Utility screen to close
the application.
28. Depending on the type of installation do one of the following steps:
If this is a new installation, install the Keyscan software, set up the site, and
perform a full panel upload.
If this is an existing installation, log on to a Client software module, edit the site
setup screens and perform a panel upload.

Keyscan Inc. A Member of the Kaba Group
6
Temporary Programming Connections CIM/NETCOM2P
Figure 1 to Figure 4 illustrate serial programming connections from the PC or laptop to the
CIM/NETCOM2P using the enclosed data cable.
If the PC or laptop does not have a serial port, use Keyscan's optional USB-SER adaptor.
Figure 1 - Serial Programming Connections Powered via H2 on Control Board
PC or laptop with Keyscan
NETCOM Program Tool Utility.
Serial Data Cable
with loose
conductors
Green
Red
Black
Current Draw : CIM 150 mA +
NETCOMP 140 mA = 290 mA
CIM 0
TD1
RD1
TD2
RD2
GND
RTS1
CTS1
GND
RTS2
CTS2 B3 B2 B1 B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
Tx Data
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
Rx Data
1212 1212
COM COM
CAN CAN
J3J4 J9
J12
Power
Good
Fault
COM2
HDR1
J10
J11
RJ45
Terminal
Jack
RESET
U2
NETCOMP
Standoffs
To program
NETCOM2P/6P
jumper ON J12
KI-00465E-04-13
COM1
Control Board
(PC 109x)
Common AUX Inputs - E24
2322
2120191817
H1H2
Connect ribbon cable from
HDR1 on CIM 0 to H2 on
control board. Control board
requires power from DPS-15.
Place a jumper on J12 to set
the CIM for Program mode.
After programming remove
the jumper from J12 to set the
CIM on Run mode. Ensure
CIM 0 has a jumper on J4.
Temporary connections for programming only.

NETCOM2P Installation Guide
7
Figure 2 - Serial Programming Connections via Independent 12 VDC Supply
PC or laptop with Keyscan
NETCOM Program Tool Utility.
Serial Data Cable
with loose
conductors
Green
Red
Black
+
-
to
12VDC
power
supply Current Draw : CIM 150 mA + NETCOMP 140 mA = 290 mA
CIM 0
TD1
RD1
TD2
RD2
GND
RTS1
CTS1
GND
RTS2
CTS2 B3 B2 B1 B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
Tx Data
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
Rx Data
1212 1212
COM COM
CAN CAN
J3J4 J9
J12
Power
Good
Fault
COM2
HDR1
J10
J11
RJ45
Terminal
Jack
RESET
U2
NETCOMP
Standoffs
To program
NETCOM2P/6P
jumper ON J12
KI-00257E-04-13
COM1
Temporary connections for programming only.

Keyscan Inc. A Member of the Kaba Group
8
Figure 3 - Optional USB-SER Serial Programming Connections Powered via H2 on
Control Board
PC or laptop with Keyscan
NETCOM Program Tool Utility.
Use 3 loose
RS-232 wires.
Green
Red
Black
Current Draw : CIM 150 mA +
NETCOMP 140 mA = 290 mA
CIM 0
TD1
RD1
TD2
RD2
GND
RTS1
CTS1
GND
RTS2
CTS2 B3 B2 B1 B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
Tx Data
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
Rx Data
1212 1212
COM COM
CAN CAN
J3J4 J9
J12
Power
Good
Fault
COM2
HDR1
J10
J11
RJ45
Terminal
Jack
RESET
NETCOMP
Standoffs
To program
NETCOM2P/6P
jumper ON J12
KI-00467E-04-13
COM1
BRN
WHT
GRN
WHT
+ TX - + RX -
485 OUT 485 IN
Connect ribbon cable from
HDR1 on CIM 0 to H2 on
control board. Control board
requires power from DPS-15.
Place a jumper on J12 to set
the CIM for Program mode.
After programming remove
the jumper from J12 to set the
CIM on Run mode. Ensure
CIM 0 has a jumper on J4.
Control Board
(PC 109x)
Common AUX Inputs - E24
2322
2120191817
H1H2
Temporary connections for programming only.

NETCOM2P Installation Guide
9
Figure 4 - Optional USB-SER Serial Programming Connections via Independent 12
VDC Supply
PC or laptop with Keyscan
NETCOM Program Tool Utility
Green
Red
Black
Use 3 loose
RS-232 wires
BRN
WHT
GRN
WHT
+ TX - + RX -
485 OUT 485 IN
USB cable
+
-
to
12VDC
power
supply Current Draw - CIM 150mA + NETCOMP 140mA = 290mA
CIM 0
TD1
RD1
TD2
RD2
GND
RTS1
CTS1
GND
RTS2
CTS2 B3 B2 B1 B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
Tx Data
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
Rx Data
1212 1212
COM COM
CAN CAN
J3J4 J9
J12
Power
Good
Fault
COM2
HDR1
J10
J11
RJ45
Terminal
Jack
RESET
NETCOMP
Standoffs
To program
NETCOM2P/6P
jumper ON J12
KI-00258E-04-13
Temporary connections for programming only.

Keyscan Inc. A Member of the Kaba Group
10
NETCOM2P/CIM Operational Connections
Figure 5 illustrates NETCOM2P operating connections with multiple CIM circuit boards.
Ensure that the CIM module with the NETCOM2P is designated as CIM 0 with a jumper on
J4.
Figure 5 - NETCOM2P/CIM Operational Connections
CIM 0
Jumper ON J4
COMMON AUXINPUTS-E
17 18 19 20 21 22 23 24
IOCB (COM1)
RX
TX
CPB/CB COMMS
(COM4)
H2
COMMON AUXINPUTS-E
17 18 19 20 21 22 23 24
IOCB (COM1)
RX
TX
CPB/CB COMMS
(COM4)
TD1
RD1
TD2
RD2
GND
RTS
CTS
GND
RTS
CTS B3 B2B1B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
1 2 1 2 1 2 1 2
Rx-COM COM CAN CAN-Tx
J3J4 J9
J12
Power
Good
Fault
HDR1
J10J11
COMMON AUXINPUTS-E
17 18 19 20 21 22 23 24
IOCB (COM1)
RX
TX
CPB/CB COMMS
(COM4)
TD1
RD1
TD2
RD2
GND
RTS
CTS
GND
RTS
CTS B3 B2B1B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
1 2 1 2 1 2 1 2
Rx-COM COM CAN CAN-Tx
J3J4 J9
J12
Power
Good
Fault
HDR1
J10J11
TD1
RD1
TD2
RD2
GND
RTS
CTS
GND
RTS
CTS B3 B2B1B0 Diag
J2
RESET
-
CAN2
+
EGND
-
CAN1
+
GND
V +
(+12V)
SCKT1
PC106x
J1
J7
J8
J6
J5
CAN2
CAN1
1 2 1 2 1 2 1 2
Rx-COM COM CAN CAN-Tx
J3J4 J9
J12
Power
Good
Fault
HDR1
J10J11
CIM 0
CIM 1
CIM n
Slave
Global
Master
Termination Jumpers ON
J5 & J6 / J7 & J8
first & last CIM
Connect EGND
terminal on all CIMs
to ground lugs in
ACU metal
enclosures.
Global Master
Jumper ON - J3
CAT 5
CANBUS
Slave - Jumper OFF - J3
H2
H2
KI-00471E-07-12
CAT 5
CANBUS
Termination Jumpers ON
J5 & J6 / J7 & J8
first & last CIM
Slave
H1
Slave - Jumper OFF - J3
H1
H1
NETCOMP
RJ45
Terminal
Jack
to network with path/
connectivity to PC/
server with
Communication
Manager
Bit Rate / Distance
Bit CAN Bus
9600 3280' (999.7 m)
19200 3280' (999.7 m)
57600 984' (299.9 m)
115200 262' (80 m)
Bit Rate / Jumper Settings (0 = OFF / 1 = ON)
Bit CIM Control Board
J9 J10 J11 J16 –1 2 6
9600 0 0 1 0 0 0
19200 0 1 0 0 1 0
57600 1 0 0 0 0 1
115200 1 0 1 0 1 1
White Orange
Orange
Blue
White Blue
Ground
White Orange
Orange
Blue
White Blue
Ground
White Orange
Orange
Blue
White Blue
Ground
to network
Host PC with
Communication
Manager
- Control Board
- PC with network connection
- CIM
- NETCOM2P/6P
- 10/100 Base-T Cable
- CAT 5 Cable –2 twisted pairs
Parts List

NETCOM2P Installation Guide
11
NETCOM2P/ACU Control Board Installation
For installing a NETCOM2P mounted directly on an ACU control board—PC109x or later—
follow the directions from page 11 to page 18.
Install Keyscan NETCOM Program Tool Utility
Each NETCOM2P that you are installing must be programmed with the Keyscan NETCOM
Program Utility. Ensure you have the latest NETCOM Program Utility software installed
which is on the enclosed CD; otherwise you may encounter communication difficulties. You
require a PC or laptop that has a direct serial connection with the NETCOM2P via the CIM
terminal block to program the device. To install the Keyscan NETCOM Program Tool utility,
load the Keyscan Utilities & Drivers CD into the CD-ROM or DVD drive. Locate and double
click on the Keyscan NETCOM Setup and follow the on-screen prompts.
Important
If you program the NETCOM2P with a previous version of the NETCOM Program Tool utility,
you may experience technical difficulties. You may then have to re-program the NETCOM
following the procedures outlined in Manually Configure the NETCOM via a Serial
Connection on page 18.
Connection Diagrams
Connection diagrams are on the succeeding pages of the guide as outlined:
See Figure 6 or Figure 7 for temporary serial programming connections to the
laptop/PC with the Keyscan NETCOM Program Tool software.
See Figure 8 for permanent network operating connections with a NETCOM2P and
ACU. This format only supports a one panel communication loop.
Steps to Program and Install a NETCOM2P on a Control Board
The NETCOM2P can be plugged directly into a PC109x or later control board. Please note
that this configuration only supports a single control board communication loop. For
programming the NETCOM2P (required), use a direct serial connection via the RS-232
(COM4) terminal block on the ACU as instructed.
1. Touch the earth ground lug in the ACU metal enclosure to discharge body static.
2. Power down the ACU control board.
3. Using a #4 Phillips screwdriver, unfasten the 6 screws holding the ACU protective
cover. Remove the cover and set it aside with the six screws.
PC109x
Use # 4
Phillips
screwdriver
to remove
screws.
KI-00251E-01-14

Keyscan Inc. A Member of the Kaba Group
12
Steps to Program and Install a NETCOM2P/ACU Control Board …cont’d
4. Mount the NETCOM2P into M1 in the correct orientation as shown in Figure 6 or Figure
7.
5. On the control board, set communication for M1 to program mode for the NETCOMP
depending on the PC109x version:
J16 –pins F and G –ON
S2 –switches 7 and 8 –ON
6. Connect the serial programming cable from the RS-232 (COM4) terminal on the ACU
to the laptop or PC. If using the USB-SER adaptor, be sure the USB-SER adaptor has
been configured before programming.
7. Apply power to the ACU control board.
8. Turn on the laptop or PC connected to the ACU control board.
9. Select start > All Programs and select Keyscan NETCOM Program Tool from the
Keyscan menu.
10. From the Keyscan NETCOM Utility screen, click the Program NETCOM Device button.
11. From the Select NETCOM Device Type screen, click on the Program NETCOM2 Family
of Boards button.
Continued on the next page…

NETCOM2P Installation Guide
13
Steps to Program and Install a NETCOM2P/ACU Control Board …cont’d
12. From the Program NETCOM2B, NETCOM2 & NETCOM2P Boards screen, enter the IP
address, the Subnet Mask, and a Gateway (optional).
13. From Program via IP Address or Serial Port, select the port on the PC/laptop with the
serial connection to the control board’s RS-232 (COM4) terminal so the NETCOM2P
can be programmed.
14. Select the baud rate that corresponds to the control board communication J16 or S2
setting. The recommended ACU bit/s (baud rate) is 57,600.
15. Leave Ethernet Connection Type set on Automatic Negotiation unless the IT
administrator gives a specific setting.
If the NETCOM device experiences network communication difficulties, you may
have to alter the Ethernet Connection Type from automatic negotiation. (The
Ethernet Connection Type is the network speed & duplex setting). Set the
NETCOM so it matches the network equipment setting. If the network equipment
was on an automatic setting, then reconfigure both the network equipment,
which may include routers or switches, and the NETCOM to a matching fixed
speed and duplex setting. As an example, NETCOM = 100 Mbit/Half Duplex –
Network equipment = 100Mbit/Half Duplex.
16. Click on the Program NETCOM button.
17. The Program NETCOM screen indicates it is waiting for a NETCOM reset or power
cycle. Momentarily place a jumper on the control board’s J6 RESET pins then remove
the jumper or press the S1 button.
18. Wait while the NETCOM Program Tool utility programs the NETCOM device.
If the NETCOM does not program on the 1st attempt, keep the NETCOM Program
Settings screen open and press the F4 key. Click inside the box to the left of
Program Server Address Settings Only so it has a check mark. Ensure the
settings have been retained, including the IP Address, otherwise re-enter them.
Click on the Program NETCOM button. If successful, program the NETCOM one
more time. For additional programming tips, press the F1 key with the Keyscan
NETCOM Program Settings screen open.
19. When prompted, disconnect the serial cable from the RS-232 (COM4) terminal on the
control board.
Continued on the next page...

Keyscan Inc. A Member of the Kaba Group
14
Steps to Program and Install a NETCOM2P/ACU Control Board …cont’d
20. Connect an Ethernet cable from a network jack to the RJ45 terminal on the
NETCOM2P.
21. Enable M1 for communication with the NETCOM2P as follows:
J16 –pin F = ON / pin G = OFF
S2 –switch 7 = ON / switch 8 = OFF
22. Momentarily place a jumper on J6 Reset or press the S1 switch on the control board.
23. At the PC/laptop, click on the OK button in the Disconnect the serial cable… screen.
24. If the PC/laptop has a network connection, verify network communication with the
NETCOM2P. Select the Start PING button on the Keyscan NETCOM Utility screen.
If the PC/laptop does not have a network connection, close the NETCOM Program
Tool utility, complete any remaining connections for permanent operation, re-
locate to a PC connected to the network and PING the NETCOM2’s IP address
using the Command Prompt. The Average Round Trip Times should be less than
100 milliseconds and the Packets Sent should equal the Packets Received with
0% loss. Continue at step 26.
25. Wait for the PING Status result message:
IP Success indicates the NETCOM2P has network communication
IP Timed Out indicates the NETCOM2P does not have network communication—
verify settings and connections
26. Click on the x in the upper right corner of the Keyscan NETCOM Utility screen to close
the application.
27. Disconnect the power from the ACU control board.
28. Re-mount the ACU protective cover.
29. Re-apply power after the ACU protective cover has been re-mounted.
30. On the control board, do one of the following steps depending on the PC109x control
board version:
J16 Jumpers - Place a jumper on J16—pin H. Momentarily place a jumper on J1
to re-load the factory default settings. This may take two minutes. Do not make
any changes to the control board while the system status LED is flashing red and
the piezo is beeping. When completed, remove the jumper from J16—pin H.
S1 and S3 Switches –After applying power, press S1, wait 5 seconds, and then
press S3 within 10 seconds to load the factory defaults. Allow approximately 2
minutes and do not make any changes to the control board while the system
status LED is flashing red and the piezo is beeping.
31. Close and secure the ACU enclosure door.
32. Depending on the type of installation do one of the following steps:
If this is a new installation, install the Keyscan software, set up the site, and
perform a full panel upload.
If this is an existing installation, log on to a Client software module, edit the site
setup screens and perform a panel upload.

NETCOM2P Installation Guide
15
Serial Programming Connections—ACU/NETCOM2P
Figure 6 illustrates serial programming connections from the PC or laptop to the NETCOM2P
via the RS-232 (COM4) terminal block on the control board using the enclosed data cable.
If the PC or laptop does not have a serial port, use Keyscan's optional USB-SER Adaptor as
shown in Figure 7.
Figure 6 - Serial Programming Connections
RJ45
Terminal
Jack
NETCOMP
RESET
Control Board
(PC 109x)
Cut view with ACU
protective cover removed.
Common AUX Inputs - E
CPB/CB MODULE
(COM4)
AUX Inputs - D
Common
IOCB (COM1)
NETCOMP plugs into M1 on
control board.
For programming a NETCOM2P or NETCOM6P
J16 –jumpers F & G - ON
Or
S2 –DIP switches 7 & 8 - ON.
RS-232 (COM4)
GND
TD
RD
DCD
DTR
CTS
PC or laptop with Keyscan
NETCOM Program Tool
Utility.
Green
Red
Black
Serial Data
Cable
with loose
conductors
TAMPER TB3
SWITCH
+
-
KI-00253E-08-13

Keyscan Inc. A Member of the Kaba Group
16
Figure 7 - Serial Programming Connections with USB Adaptor
Green
Red
Black
Use 3 loose
RS232 wires.
BRN
WHT
GRN
WHT
+ TX - + RX -
485 OUT 485 IN
RJ45
Terminal
Jack
NETCOMP
RESET
Control Board
(PC 109x)
Cut view with ACU
protective cover removed.
Common AUX Inputs - E
CPB/CB MODULE
(COM4)
AUX Inputs - D
Common
IOCB (COM1)
NETCOMP plugs into M1 on
control board.
RS-232 (COM4)
GND
TD
RD
DCD
DTR
CTS
PC or laptop with Keyscan
NETCOM Program Tool
Utility.
TAMPER TB3
SWITCH
+
-
KI-00254E-08-13
For programming a NETCOM2P or NETCOM6P
J16 –jumpers F & G - ON
Or
S2 –DIP switches 7 & 8 - ON

NETCOM2P Installation Guide
17
NETCOM2P/Control Board Operational Connections
Figure 8 illustrates NETCOM2P operating connections and jumper settings when mounted
on a PC109x or higher control board. This configuration only supports a single control
board communication loop.
Multiple Building Communication on a WAN
Keyscan requires a point-to-point private network where NETCOMs are used on a LAN/WAN
(TCP/IP) that integrates building to building communication.
Figure 8 - NETCOM2P/PC109x (or higher) Control Board Connections
- PC
- 10/100 Base-T Cable
- Control Board
- NETCOM2P or NETCOM6P
to network
Host PC with
Communication Manager
Parts List
to network
10 or 100
Base-T
Current Draw
ACU + NETCOMP = 270 mA
RJ45
Terminal
Jack
NETCOMP
RESET
Control Board
(PC 109x)
Cut view with
ACU protective
cover removed.
Common AUX Inputs - E
CPB/CB MODULE
(COM4)
AUX Inputs - D
Common
IOCB (COM1)
NETCOMP plugs into M1 on
control board.
RX
TX
KI-00161E-04-13
J16
Pin F = ON
Pin G = OFF
Or
S2
DIP switch 7 = ON
DIP switch 8 = OFF

Keyscan Inc. A Member of the Kaba Group
18
Manually Configure the NETCOM2P via a Serial
Connection
These procedures should only be performed in the event that the NETCOM Program Tool
utility was used to program the NETCOM2P and the device is still failing to communicate.
If this condition does not apply to the NETCOM2P, use the appropriate procedures outlined
in the preceding sections of this installation guide.
These procedures are intended for advanced computer users only.
Important
Keyscan recommends that you review the setup procedures before you actually perform
them so you are familiar with the steps, some of which are intricate and require quick
dexterity.
1. Depending on the type of NETCOM2P installation, refer to the Temporary Serial
Programming Connection diagrams - NETCOM2P/CIM or NETCOM2P/ACU Control
Board and with the serial data cable establish a connection to the PC laptop with the
NETCOM Program Tool utility.
2. Ensure you have made the necessary settings as indicated on the respective
temporary serial programming diagrams.
If you reset jumpers on the CIM board when powered, ensure that you
momentarily place a jumper on the J1 RESET pins to re-configure the board
If you reset jumpers or DIP switches on the control board when powered, ensure
that you momentarily place a jumper on the J6 RESET pins or press the S1
switch to re-initialize the control board
3. Open the NETCOM Program Tool utility and select the Keyscan Hyper Terminal button.
4. The Comm Port Number is defaulted to port #1. If you are using a different port
connection, select the correct port #.
5. Leave the baud rate set on 9600. Click on the Open Port button.
If this fails, then you will have to re-open the session and try with the baud rate
set at 57,600.
6. To enter Setup Mode, reset the NETCOM2P as follows:
NETCOM2P/CIM –momentarily place a jumper on the CIM board’s J1 RESET pins
NETCOM2P/ACU –momentarily place a jumper on the control board’s J6 pins or
press the S1 switch
7. Within 1 second of the NETCOM2P reset, enter 3 lowercase x characters—xxx.
Tip—The easiest way to enter Setup Mode is to hold down the x key at the
terminal (or emulation) while resetting the unit.
8. When the Setup Mode window opens, press the Enter key within 5 seconds to enter
setup mode.
9. Once you reach the Change Setup: prompt, Press 0 for Server setup parameters and
enter the following values for 0 Server and 1 Channel 1 (Keyscan Values)
10. Go to the next page for setting NETCOM2P values.

NETCOM2P Installation Guide
19
0 Server (User Defined Values)
IP Address: Enter the User Static IP Address, and press the Enter key.
Set Gateway IP Addr: Press the Y key for yes or the N key for no.
If Y was selected in the previous step, then enter the Gateway IP address, and
press the Enter key.
Netmask: Specify the Netmask by entering its list number (the number on the
left opposite the Netmask) and press the Enter key.
3= 255.255.255.248
4= 255.255.255.240
5=255.255.255.224
6= 255.255.255.192
7= 255.255.255.128
8= 255.255.255.0 (Default)
9= 255.255.254.0
10 = 255.255.252.0
11 = 255.255.248.0
12 = 255.255.240.0
13 = 255.255.224.0
14 = 255.255.192.0
15 = 255.255.128.0
16 = 255.255.0.0
17 = 255.254.0.0
18 = 255.252.0.0
19 = 255.248.0.0
20 = 255.240.0.0
21 = 255.224.0.0
22 = 255.192.0.0
23 = 255.128.0.0
24 = 255.0.0.0
Set DNS Server IP addr: Press the N key for no.
Change telnet config password: Press the N key for no.
Continued on the next page…

Keyscan Inc. A Member of the Kaba Group
20
11. After completing the Server parameters, press 1 for Channel 1 setup parameters and
enter the following Keyscan values. Press the Enter key after each entry.
1 Channel 1 (Keyscan Values)
Baudrate = 9600 (Must match ACU settings)
I/F Mode =4C
Flow = 00
Port No. =3001
ConnectMode =C0
Send ‘+++’ in Modem Mode =N
Show IP addr after ‘RING’ = N
Remote IP Address = 000.000.000.000
Remote Port = 0
DisConnMode =00
FlushMode =80
Pack Cntrl =01
DisConnTime =15:00
SendChar 1 =00
SendChar 2 =00
12. After completing the Channel 1 parameters, Press 9 to save the configuration and
restart the NETCOM2P unit.
Note
To exit without saving any changes, press 8.
