Keysight Technologies 11636C Service manual

Keysight 11636C/D
Power Divider
Operating and
Service Manual

2 Keysight 11636C/D Power Divider Operating and Service Manual
Notices
Copyright Notice
© Keysight Technologies 2007-2021
No part of this manual may be repro-
duced in any form or by any means
(including electronic storage and
retrieval or translation into a foreign
language) without prior agreement and
written consent from Keysight Technol-
ogies as governed by United States and
international copyright laws.
Manual Part Number
11636-90005
Edition
Edition 4, November 5, 2021
Printed in:
Printed in Malaysia
Published by:
Keysight Technologies
Bayan Lepas Free Industrial Zone,
11900 Penang, Malaysia
Technology Licenses
The hardware and/or software
described in this document are fur-
nished under a license and may be
used or copied only in accordance with
the terms of such license.
Declaration of Conformity
Declarations of Conformity for this
product and for other Keysight prod-
ucts may be downloaded from the
Web. Go to http://www.keysight.com/
go/conformity. You can then search by
product number to find the latest Dec-
laration of Conformity.
U.S. Government Rights
The Software is “commercial computer
software,” as defined by Federal Acqui-
sition Regulation (“FAR”) 2.101. Pursu-
ant to FAR 12.212 and 27.405-3 and
Department of Defense FAR Supple-
ment (“DFARS”) 227.7202, the U.S.
government acquires commercial com-
puter software under the same terms
by which the software is customarily
provided to the public. Accordingly,
Keysight provides the Software to U.S.
government customers under its stan-
dard commercial license, which is
embodied in its End User License
Agreement (EULA), a copy of which can
be found at http://www.keysight.com/
find/sweula. The license set forth in the
EULArepresentstheexclusiveauthority
by which the U.S. government may use,
modify, distribute, or disclose the Soft-
ware. The EULA and the license set
forth therein, does not require or per-
mit, among other things, that Keysight:
(1) Furnish technical information
related to commercial computer soft-
ware or commercial computer software
documentation that is not customarily
provided to the public; or (2) Relinquish
to, or otherwise provide, the govern-
ment rights in excess of these rights
customarily provided to the public to
use, modify, reproduce, release, per-
form, display, or disclose commercial
computer software or commercial com-
puter software documentation. No
additional government requirements
beyond those set forth in the EULA
shall apply, except to the extent that
those terms, rights, or licenses are
explicitly required from all providers of
commercial computer software pursu-
ant to the FAR and the DFARS and are
set forth specifically in writing else-
where in the EULA. Keysight shall be
under no obligation to update, revise or
otherwise modify the Software. With
respect to any technical data as
defined by FAR 2.101, pursuant to FAR
12.211 and 27.404.2 and DFARS
227.7102, the U.S. government
acquires no greater than Limited Rights
as defined in FAR 27.401 or DFAR
227.7103-5 (c), as applicable in any
technical data.
Warranty
THE MATERIAL CONTAINED IN THIS
DOCUMENT IS PROVIDED “AS IS,”
AND IS SUBJECT TO BEING
CHANGED, WITHOUT NOTICE, IN
FUTURE EDITIONS. FURTHER, TO THE
MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, KEYSIGHT DIS-
CLAIMS ALL WARRANTIES, EITHER
EXPRESS OR IMPLIED, WITH REGARD
TO THIS MANUAL AND ANY INFORMA-
TION CONTAINED HEREIN, INCLUD-
ING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. KEYSIGHT
SHALL NOT BE LIABLE FOR ERRORS
OR FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES IN CONNECTION
WITH THE FURNISHING, USE, OR
PERFORMANCE OF THIS DOCUMENT
OR OF ANY INFORMATION CON-
TAINED HEREIN. SHOULD KEYSIGHT
AND THE USER HAVE A SEPARATE
WRITTEN AGREEMENT WITH WAR-
RANTY TERMS COVERING THE MATE-
RIAL IN THIS DOCUMENT THAT
CONFLICT WITH THESE TERMS, THE
WARRANTY TERMS IN THE SEPARATE
AGREEMENT SHALL CONTROL.
Safety Information
CAUTION
A CAUTION notice denotes a hazard. It
calls attention to an operating proce-
dure, practice, or the like that, if not
correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not pro-
ceed beyond a CAUTION notice until
the indicated conditions are fully
understood and met.
WARNING
A WARNING notice denotes a hazard. It
calls attention to an operating proce-
dure, practice, or the like that, if not
correctly performed or adhered to,
could result in personal injury or death.
Do not proceed beyond a WARNING
notice until the indicated conditions are
fully understood and met.

Keysight 11636C/D Power Divider Operating and Service Manual 3
Regulatory Information
Sales and Technical Support
To contact Keysight for sales and technical support, refer to the support links on
the following Keysight websites:
–www.keysight.com/find/mta
(product-specific information and support, software and
documentation updates)
–www.keysight.com/find/assist
(worldwide contact information for repair and service)
TheCEmarkisaregistered
trademark of the European
Community. If it is
accompanied by a year, it
indicates the year the
design was proven.
This symbol indicates the time period during
which no hazardous or toxic substance
elements are expected to leak or deteriorate
during normal use. Forty years is the expected
useful life of the product.
This Keysight CCR (Customer Compliance Response) email ID is for manufacturer identification and
indicates that the product complies with all the relevant European Legal Directives.
The crossed out wheeled bin symbol indicates that separate collection for waste electric and
electronic equipment (WEEE) is required, as obligated by the EU DIRECTIVE and other National
legislation.
Please refer to www.keysight.com/go/takeback to understand your Trade-in options with Keysight in
addition to product take back instructions.

4 Keysight 11636C/D Power Divider Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11636C/D Power Divider Operating and Service Manual 5
Table of Contents
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Sales and Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1Introduction
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2 Characteristics and Specifications
Specifications and Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3 Installation and Verification
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Initial inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Operator’s Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Performance Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Input Return Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Output Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Service Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

6 Keysight 11636C/D Power Divider Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11636C/D Power Divider Operating and Service Manual 7
List of Figures
Figure 1-1 Keysight 11636C DC to 50 GHz Power Divider . . . . . .10
Figure 1-2 Keysight 11636D DC to 67 GHz Power Divider . . . . . .11
Figure 2-1 Keysight 11636C/D schematic and dimensions . . . . .15
Figure 3-1 Quick-check configuration . . . . . . . . . . . . . . . . . . . . . .21
Figure 3-2 Input return loss test setup . . . . . . . . . . . . . . . . . . . . .23
Figure 3-3 Output tracking test setup (Port 3 Terminated) . . . . .25
Figure 3-4 Output tracking test setup (Port 2 Terminated) . . . . .26

8 Keysight 11636C/D Power Divider Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11636C/D Power Divider
Operating and Service Manual
9
1 Introduction
Product Overview 10
This chapter provides an overview of the Keysight 11636C/D power divider.

1Introduction
10 Keysight 11636C/D Power Divider Operating and Service Manual
Product Overview
Keysight 11636C and 11636D Power Dividers operating from DC to 50 GHz and
67 GHz respectively, provide an excellent output power symmetry between the
two output ports. Their design features excellent amplitude and phase tracking to
ensure excellent source match for fault location applications using network
analyzers and also precise power division.
Any port may be used as an input, as the Keysight 11636C/D provides a
symmetrical power division. The 11636C/D can also be used as a power
combiner. When signals are input at two output ports, the sum of the two appears
at the input port. However, this is not recommended for ratio or source leveling
applications.
Figure 1-1 Keysight 11636C DC to 50 GHz Power Divider

Introduction 1
Keysight 11636C/D Power Divider Operating and Service Manual 11
Figure 1-2 Keysight 11636D DC to 67 GHz Power Divider
Features
11636C
– Broadband coverage from DC to 50 GHz
– Excellent amplitude (0.3 dB from DC to 50 GHz) and phase tracking
(±2° typical) minimizes amplitude and phase difference between the two
outputs to ensure an accurate power division.
– Low SWR of 1.67 at 50 GHz minimizes your measurement uncertainty
11636D
– Broadband coverage from DC to 67 GHz
– Excellent amplitude (0.4/0.65 dB from DC to 67 GHz) and phase tracking (±4°/
±7° typical) minimizes amplitude and phase difference between the two
outputs to ensure an accurate power division.
– Low SWR of 2.1 at 67 GHz minimizes your measurement uncertainty

1Introduction
12 Keysight 11636C/D Power Divider Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11636C/D Power Divider
Operating and Service Manual
13
2 Characteristics and
Specifications
Specifications and Characteristics 14
Environmental Conditions 16

2 Characteristics and Specifications
14 Keysight 11636C/D Power Divider Operating and Service Manual
Specifications and Characteristics
For the specifications and characteristics of the 11636C/D power divider, refer to
the technical overview document at
www.keysight.com/us/en/assets/7018-01590/technical-overviews/
5989-6698.pdf.
Physical Dimensions
The table below lists the physical dimensions of 11636C/D Power Divider.
Pin depth 0.000 to 0.076 mm (0.000 to 0.003 in)[a]
[a] Allowable recession of the end of the female center pin behind the outer conductor mating plane.
Dimensions 35.1 mm H x 35.5 mm W x 10 mm D (1.38 x 1.39 x 0.39 in)
Weight 0.036 kg (0.079 lb)

Characteristics and Specifications 2
Keysight 11636C/D Power Divider Operating and Service Manual 15
Figure 2-1 Keysight 11636C/D schematic and dimensions

2 Characteristics and Specifications
16 Keysight 11636C/D Power Divider Operating and Service Manual
Environmental Conditions
The 11636C/D is designed to fully comply with Keysight Technologies’ product
operating environmental specifications. Table 2-1 and Table 2-2 list the
environmental specifications of 11636C and 11636D power dividers respectively.
Table 2-1 11636C Environmental Conditions
Environmental condition Requirement
Temperature
–Operating
–Storage
–Cycling
-45 °C to +70°C
–65 °C to +85°C
–65°C to+85°C,10 cyclesat 20°Cper minuteramprate,20
minutes dwell time per MIL-STD-833F, Method 1010.8,
Condition C (modified)
Humidity
–Operating
–Storage 50% to 95% RH at 40 °C, 24 hours cycling, 5 cycles 90% RH at 65 °C, 24 hours
Shock
– End-user handling
– Mechanical Survival
– Transportation
Delta-V: 3m/s ±5%, Duration <3ms at 6 faces
Half Sine: 1000g, 0.5ms at 6 faces
50g, delta-V: 8m/s at 6 faces
Vibration
– Operating (Random) 2.41 Grms, 10 min/axis
Altitude
–Operating
– Non-operating 4,600 meters (15,092 feet) 4,600 meters (15,092 feet)
ESD immunity
– Contact Discharge
– Air Discharge 4 kV (to center conductor) 15 kV (to outer conductor)

Characteristics and Specifications 2
Keysight 11636C/D Power Divider Operating and Service Manual 17
Table 2-2 11636D Environmental Conditions
Environmental condition Requirement
Temperature
–Operating
–Storage
–Cycling
-45°C to +70°C
–65 °C to +85°C
–65°Cto+85°C,10cyclesat 20°Cperminuteramprate,20
minutes dwell time per MIL-STD-833F, Method 1010.8,
Condition C (modified)
Humidity
–Operating
–Condensation
– Resistance
95% RH at 40°C, 24 hours cycling, 5 cycles
95% RH at -10°C to 25°C, Method 2
95% RH at 65°C, 10 Days per JEDEC HAST Standard
Shock
– End-user handling
– Mechanical Survival
– Transportation
Delta-V: 3m/s ±5%, Duration <3ms at 6 faces
Half Sine: 1000g, 0.5ms at 6 faces
50g, delta-V: 8m/s at 6 faces
Vibration
– Operating (Random) 0.3 Grms, 5-500 Hz
Altitude
–Operating
– Non-operating 4,600 meters (15,092 feet) 4,600 meters (15,092 feet)
ESD immunity
– Contact Discharge
– Air Discharge 4 kV (to center conductor) 15 kV (to outer conductor)

2 Characteristics and Specifications
18 Keysight 11636C/D Power Divider Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11636C/D Power Divider
Operating and Service Manual
19
3 Installation and
Verification
Installation 20
Operating Instructions 21
Performance Tests 22
Service Instructions 27
This chapter mainly focuses on the installation of the power divider and operating
instructions to walk you through the quick-check procedure to ensure that the
power divider is working before its implementation in the system. There are also
the performance tests and service instructions available in this chapter.

3 Installation and Verification
20 Keysight 11636C/D Power Divider Operating and Service Manual
Installation
Initial inspection
1Inspect the shipping container for damage. If the shipping container or
cushioning material is damaged, it should be kept until the contents of the
shipment have been checked for completeness and the instrument has been
checked both mechanically and electrically.
– Check for mechanical damage such as scratches or dents.
– Procedures for checking electrical performance are given under “Operator’s
Check” on page 21 or “Performance Tests” on page 22.
2If the contents are incomplete, if there is mechanical damage or defect, or if
the instrument does not pass the electrical performance test, contact the
nearest Keysight Technologies Sales and Service office (refer to “Sales and
Technical Support” on page 3). Keysight will arrange for repair or replacement
of the damaged or defective equipment. Keep the shipping materials for the
carrier’s inspection.
3If you are returning the instrument under warranty or for service, repackaging
the instrument requires original shipping containers and materials or their
equivalents. Keysight Technologies can provide packaging materials identical
to the original materials. Refer to “Sales and Technical Support” on page 3 for
the Keysight office nearest to you. Attach a tag indicating the type of service
required, return address, model number and serial number. Mark the container
FRAGILE to insure careful handling. In any correspondence, refer to the
instrument by model number and serial number.
