Keysight Technologies U1282A Quick start guide

ADMINISTRATIVE INFORMATION
ACTION [X] ON SPECIFIED FAILURE
CATEGORY: [[]] AGREEABLE TIME
STANDARDS
LABOR: 0.1 Hours
LOCATION [X] CUSTOMER INSTALLABLE
CATEGORY: [[]] ON-SITE (active On-site contract required)
[[]] SERVICE CENTER
[[]] CHANNEL PARTNERS
SERVICE: [[]] RETURN
INVENTORY: [[]] SCRAP
[x] SEE TEXT
USED [[]] RETURN
PARTS: [[]] SCRAP
[x] SEE TEXT
AVAILABILITY: PRODUCT’S SUPPORT LIFE
NO CHARGE AVAILABLE UNTIL: 20 April 2017
[[]] Calibration Required
[X] Calibration NOT Required
PRODUCT LINE: WC
AUTHOR: SJ
ADDITIONAL INFORMATION:
© Keysight Technologies 2015-2016
Modification Recommended Service Note
Version 1.2 | April 25, 2016| Page 1of 3
Modification Recommended
Service Note
U1282A-01
U1282A Handheld Digit Multimeter
Serial Numbers: “See Appendix (A)"
The Problem –Capacitance measurement may be out of specification at 100nF range and below.
Parts Required:
P/N Description Qty.
Pomona 2BC-36 double banana plug both ends cable assembly
Supersedes:
NONE

© Keysight Technologies 2015-2016
Modification Recommended Service Note
Version 1.2 | April 25, 2016| Page 2of 3
Situation:
U1282A within the serial number range may not meet the specification for capacitance
measurement in 100nF range and below. This is due to improper open adjustment performed at
factory which the cable has been used to perform the open adjustment, has caused a negative
offset stored in the multimeter’s memory.
Solution/Action:
To verify whether the multimeter is impacted with capacitance measurement in 100nF range and
below:
1. Turn the knob to the Capacitance measurement position.
2. Manual set the range to 10 nF range.
3. Plug in one end of the Pomono 2BC-36 cable assembly across the capacitance measurement
terminal, leave the other end of the cable assembly open.
4. The U1282A should read between 0.8nF to 1.1nF, otherwise the “Open” calibration adjustment
was performed incorrectly.
To correct the multimeter capacitance measurement in 100nF range and below:
5. Unplug any cable from the multimeter’s terminal.
6. By referring to the service guide procedure
(http://literature.cdn.keysight.com/litweb/pdf/U1281-90002.pdf ), unsecure the meter to
enter into the calibration adjustment mode.
7. Turn the knob to the Capacitance measurement position.
8. Perform ONLY the “Open” adjustment in Capacitance measurement without any cable
connected to the multimeter.
9. Exit calibration adjustment mode after the “Open” adjustment is done.
10. Verify the “Open” adjustment has been performed correctly by repeating step 1 to step 4.
Customers who have purchased the U1282A Multimeter within the serial number range stated in this
service note will receive a complementary Pomona 2BC-36 cable assembly.
Each customer is entitled to one free Pomona 2BC-36 cable assembly.
To request a free Pomona 2BC-36 cable assembly, please click HERE
(http://www.keysight.com/find/pomona2BCcablerequest) and provide the following information on the
web form:
1. Instrument Model Number
2. Serial Number
3. Name of distributor who sold this unit
4. Date of purchase
5. Delivery details:
Receiver’s Name
Receiver’s Address
Receiver’s Telephone number
Keysight will arrange for the shipment of the free Pomona 2BC-36 cable assembly to the customer.

© Keysight Technologies 2015-2016
Modification Recommended Service Note
Version 1.2 | April 25, 2016| Page 3of 3
Revision History:
Date
Service
Note
Revision
Author
Reason for Change
20 April 2016
01
SJ
As Published
Appendix (A):
MY55270002
MY55300109
MY55420012
MY55440005
MY55460012
MY55280010
MY55310018
MY55420017
MY55440009
MY55460013
MY55280022
MY55320002
MY55420023
MY55440011
MY55460014
MY55280039
MY55410029
MY55420028
MY55440013
MY55470019
MY55280054
MY55410034
MY55420047
MY55440015
MY55280055
MY55410037
MY55420054
MY55440019
MY55290019
MY55410054
MY55420057
MY55440025
MY55290026
MY55410056
MY55420068
MY55440027
MY55300066
MY55410078
MY55430068
MY55440030
MY55300099
MY55420003
MY55440001
MY55440032
