Keysight E8267D User manual

NOTE: For the latest revision of this installation note, go to the
website for your instrument:
http://www.keysight.com/find/psg or http://keysight.com/find/e8663b
Keysight E8257D/67D
PSG Signal Generators and
E8663B Analog Signal Generator
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz)
Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and
E8663BK-UNW
Installation Note

Notices
© Copyright 2004-2015 Keysight Technologies, Inc.
The information contained in this document is subject to change without notice.
Keysight Technologies makes no warranty of any kind with regard to this material, including but
not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Keysight Technologies shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
Manual Part Number
E8251-90381
Edition
Edition 1, August 2015
Printed in USA/Malaysia
Published by:
Keysight Technologies, Inc.
1400 Fountaingrove Parkway
Santa Rosa, CA 95403

Installation Note E8251-90381 3
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz)
Kit Part Numbers: E8257DK-UNW, E8267DK-UNW, and
E8663BK-UNW
Introduction
This upgrade kit adds Option UNW (Narrow Pulse Modulation) to the E8257D (Analog), E8267D
(Vector) PSG Signal Generators and the E8663B Analog Signal Generator.
Installation includes the following major steps, starting on page 5:
1. Check signal generator functionality.
2. Remove the outer and inner signal generator covers.
3. Install A12 Pulse Modulator.
4. Activate Option UNW.
5. Verify proper installation of Option UNW.
6. Re-assemble the signal generator.
7. Verify signal generator calibration.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . E8257D/67D and E8663B
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . Prefix US/MY/SG4928 and lower
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Keysight Technologies Service Center
(X) Personnel Qualified by Keysight Technologies
(X) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 2.0 hours
Estimated Verification Time: . . . . . . . . . . . . . . . 2.0 hours

4Installation Note E8251-90381
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Installation Kit Parts List
Tools Required
— TORX T-10 driver
— TORX T-15 driver
— TORX T-20 driver
— 5/16” open-ended wrench
— Needle-nose pliers
Item Quantity Description Part Number
1 1 Installation Note E8251-90381
2 2 Screw M3x0.5 8mm-LG 0515-0372
3 1 W120 Semi-Rigid Cable E8251-20342
4 1 W76 Semi-Rigid Cable E8251-20590
5 1 A12 Pulse Modulator E8251-60112
6 1 Cable Retainer Base E8251-40001
7 1 Cable Retainer Top E8251-40007
8 1 Entitlement Certificate 5964-5143
9 1 Entitlement Certificate Envelope 5967-7169

Installation Note E8251-90381 5
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Safety Considerations
Check Signal Generator Functionality
Use the following procedure to confirm that the signal generator powers up and the internal check
identifies no errors. The internal check evaluates the operation of the signal generator and returns
an error message if it detects a problem.
1. Turn on the signal generator and let it warm up for at least five minutes.
2. Run the signal generator self-test by pressing Utility > Instrument Info/Help Mode > Self
Test > Run Complete Self Test. Upon completion a summary of the self-test will be displayed.
Use the E8257D/67D PSG Service Guide or E8663B Analog Service Guide to troubleshoot any
failures detected by the test.
3. Check to see if the ERR annunciator is on.
—If the ERR annunciator is on, review the error messages in the error queue by pressing
Utility > Error Info. The first page of error messages in the error queue appears in the
display text area. (Refer to the signal generator error messages document for information
about each error message.)
After resolving all problems causing errors, press Clear Error Queue(s).
—If the ERR annunciator is off, the signal generator functionality check has passed.
Before you disassemble the signal generator, turn the power switch off and
unplug the power cord. Failure to unplug the signal generator can result in
personal injury.
Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
When the signal generator is first connected to ac line power, the error message
ERROR 514, Reference Oven Cold occurs which causes both the OVEN
COLD annunciator and the ERR annunciator to turn on.
After approximately five minutes, the OVEN COLD annunciator automatically
clears, but the ERR annunciator remains on until all errors are cleared from the
error queue.
Some circuits may require up to 50 minutes to warm up before passing the
self-test. If self-tests continue to fail after 50 minutes of warm up, troubleshoot
the instrument.

6Installation Note E8251-90381
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Remove the Outer and Inner Signal Generator Covers
Remove the Outer Cover
Refer to Figure 1.
1. Disconnect the power cord.
2. Using a T-20 driver, loosen the two screws (1) and remove the strap handle (2).
3. Using a T-15 driver, remove the center screws (3) on the four rear-panel feet (4).
4. Remove the four bottom feet (5) from the cover by lifting the tab and sliding the foot toward
the tab.
5. Place the signal generator on its side.
6. Tilt the signal generator forward and slide the outer cover (6) back to remove it from the frame.

Installation Note E8251-90381 7
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Figure 1 Outer Cover Removal

8Installation Note E8251-90381
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Remove the Inner Top Cover
Refer to Figure 2.
1. Using a T-10 driver, remove the screws (1) from the inner-top cover (2). There are twelve
screws for the E8257D & E8663B and eleven screws for the E8267D.
2. Remove the inner-top cover.
Figure 2 Inner Top Cover Removal

Installation Note E8251-90381 9
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Install the A12 Pulse Modulator Assembly (For instruments with Option 1EH)
Refer to Figure 3.
1. Remove the A38 Lowband Switch Filter assembly.
2. Using needle-nose pliers, remove the cable retainer base for W119 (E8251-20333, not shown).
3. With the A31 Motherboard facing you, using a 5/16” open-ended wrench, remove the other
end of semi-rigid cable W119.
4. Using the T-10 driver, insert two screws (1) through the A12 Pulse Modulator bracket and into
the main chassis. Torque to 9 in-lbs.
5. Attach the loose end of the W69 ribbon cable (comes with the A12 Pulse Modulator assembly)
to the
A26 MID board, J14.
6. Install W76 (E8251-20590) from the A31 Motherboard (LB Output) to the A12 Pulse
Modulator. Torque to 8 in-lbs.
7. Install semi-rigid cable W75 (E8251-20033) from the A23 Lowband Coupler/Detector to the
A12 Pulse Modulator. Torque to 8 in-lbs.
8. Attach the loose end of flexible cable W16 (comes attached with the A12 Pulse Modulator
assembly) to A11J204.
W119 is connected to the A38 Lowband Switch Filter (OUT) and the A23
Lowband Coupler/Detector (IN).

10 Installation Note E8251-90381
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Figure 3 A12 Pulse Modulator Board
W76
1
W16
W69 W75 W120

Installation Note E8251-90381 11
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Install the A12 Pulse Modulator Assembly (For instruments without
Option 1EH)
Refer to Figure 4.
1. Remove A6 thru A8.
2. Using needle-nose pliers remove the cable retainer base for W37 (E8251-20225, not shown).
3. With the A31 Motherboard facing you, using a 5/16” open-ended wrench, remove the other
end of semi-rigid cable W37.
4. Using the T-10 driver, insert two screws (1) through the A12 Pulse Modulator bracket and into
the main chassis. Torque to 9 in-lbs.
5. Attach the loose end of the W69 ribbon cable (comes with the A12 Pulse Modulator assembly)
to the
A26 MID board, J14.
6. Install semi-rigid cable W120 (E8251-20342) from the A31 Motherboard (LB Output) to the
A23 Lowband Coupler Detector. Torque to 8 in-lbs.
7. Install semi-rigid cable W75 (E8251-20033) from the A23 Lowband Coupler/Detector to the
A12 Pulse Modulator. Torque to 8 in-lbs.
8. Attach the loose end of flexible cable W16 (comes attached with the A12 Pulse Modulator
assembly) to A11J204.
W37 is connected to the A31 Motherboard (LB Output) and the A23
Lowband Coupler/Detector (IN).

12 Installation Note E8251-90381
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Figure 4 A12 Pulse Modulator Board
W76
1
W16
W69 W75 W120

Installation Note E8251-90381 13
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
Activate Option UNW
1. Turn the signal generator on and allow it to warm up for 5 minutes.
2. Connect the instrument to the LAN, using the instructions in the Keysight Signal Generator
Programming Guide.
3. Load the IP address into the instrument, by pressing Utility > GPIB/RS-232/LAN > LAN Setup
> IP Address. Enter the IP address.
4. Using the web browser on your PC enter the following URL, replacing <ip-address> with the
actual IP address you entered into the instrument in step 3: http://<ip-address>/update.
5. Scroll to “Update optional PULSE MODULATOR”, select “add:E8251-60064”, enter the
modulators serial number and click Execute.
6. Check Firmware Version and Update if <C.04.71
a. Press Utility > Instrument Info/Help Mode > Diagnostic Info.
b. If the firmware is <C.04.71, upgrade the firmware.
7. Update the Arrays
a. Connect the instrument to the LAN and write down the IP address.
b. Load the IP address into the instrument, by pressing: Utility > GPIB/RS-232/LAN > LAN
Setup >IP Address.
c. Open a web browser on your PC.
d. Enter the following URL, replacing <ip-address> with the actual IP address of your
instrument, http://<ip-address>/update.
e. Type in or, if using the web to view this installation note, copy the script from below and
paste it into the text area on the update page.
cd "ALC FED PULSE DELAY", 0, 9
cd "ALC FED PULSE DELAY", 1, 9
cd "ALC FED PULSE DELAY", 2, 9
cd "ALC FED PULSE DELAY", 3, 9
cc "ALC FED PULSE DELAY"
cd "ALC RED PULSE DELAY", 0, 245
cd "ALC RED PULSE DELAY", 1, 180
cd "ALC RED PULSE DELAY", 2, 180
cd "ALC RED PULSE DELAY", 3, 180
cd "ALC RED PULSE DELAY", 4, 230
cd "ALC RED PULSE DELAY", 5, 190
cd "ALC RED PULSE DELAY", 6, 170
cd "ALC RED PULSE DELAY", 7, 170
cd "ALC RED PULSE DELAY", 8, 230
cd "ALC RED PULSE DELAY", 9, 190
cd "ALC RED PULSE DELAY", 10, 180
cd "ALC RED PULSE DELAY", 11, 180
cd "ALC RED PULSE DELAY", 12, 195

14 Installation Note E8251-90381
Add Option UNW (Narrow Pulse Modulation 10 MHz-3.2 GHz) Kit Part Numbers: E8257DK-UNW,
E8267DK-UNW, and E8663BK-UNW
cd "ALC RED PULSE DELAY", 13, 180
cd "ALC RED PULSE DELAY", 14, 180
cd "ALC RED PULSE DELAY", 15, 180
cc "ALC RED PULSE DELAY"
ky 42718
f. Press Execute, to update the arrays.
g. Cycle the instrument power.
8. Follow the instructions on the Entitlement Certificate.
Verify Proper Installation of Option UNW
1. Press: Utility > Instrument Info > Help Info > Options Info.
2. Make sure Option UNW is listed.
Re-Assemble the Signal Generator
Refer to Figure 1 and Figure 2.
1. Reinstall the inner and outer instrument covers by reversing the order for removal.
2. Torque all T-10 screws to 9 in-lbs.
3. Torque all T-15 and T-20 screws to 21 in-lbs.
Verify Signal Generator Calibration
1. Turn the signal generator on and allow it to warm up for 30 minutes.
2. Perform the following adjustment and performance tests to verify signal generator calibration.
Refer to the PSG Family Signal Generators Service Software or the E8663B Analog Signal
Generator Service Software:
—ADC Calibration
—ALC Dynamic Calibration
—Power Flatness Calibration
—Pulse Width Calibration
—Self Tests
—Internal Pulse Modulation Level Accuracy
—Internal Pulse Modulation Rise/Fall Time
—External Pulse Modulation ON/OFF Ratio
If you enable an option that does not have the required hardware installed, the
menus for that option will be activated but the option cannot operate.

This information is subject to change
without notice.
© Keysight Technologies 2004-2015
Edition 1, August 2015
E8251-90381
www.keysight.com
