USB High Speed Serial Adapter
Product Fact Sheet
No Serial Port? No Problem!
Our USB “High Speed” Serial Adapter is a simple, inexpensive, and
reliable way to connect a serial device to a USB port.
Features
• Cable (detachable) plugs into a USB port on a PC or Mac
• Provides one male DB9 port for connection to serial device
• Supports data rates up to 230 Kbps
• Draws its power from the USB connection
• Includes line monitor, date trace and con guration utilities
• Microsoft WHQL certi ed
Requirements
Windows :
At least one available USB port; Windows 98/Me/2000/XP
Macintosh :
At least one available USB port; Mac OS 8.6 or greater;
Mac OS X v10.1.3 or greater
Linux :
At least one available USB port; Linux 2.4.22 or greater
Specifications
Serial Communications
• Serial Interface: RS-232
• Serial Connector DB-9 Male
• Max Data Rate: 230 Kbps
USB Specifications
• Host Interface: USB 1.1
• USB Connector: USB Type B
• Complies with USB 1.1 DC Power Specifications
Environmental
• Temperature Range: 0C - 40C
Keyspan is America’s favorite USB Connectivity Provider !
www.keyspan.com
1 510 222 0131
Connections for your Computer
Part #: USA-19HS MSRP: $39
Pin Assignments
DB-9
Signal
Type
1
DCD
Input
2
RxDATA Input
3
TxDATA
Output
4
DTR
Output
5
Ground Ground
6
DSR
Input
7
RTS
Output
8
CTS
Input
9
RI
Input
