KICK ASS KATVANT5VOMNI User manual

Made in china
DIGITAL HDTV
CARAVAN/RV
ANTENNA
USER MANUAL
KATVANT5VOMNI

Screw x 6 (M5x60)
x 1 Plasc washer
Metal x 1washer
antenna x 1 HDTV Base x 1
F - F coaxial line (10M) x 1
Power supply x 1
User manual x 1
WHATS IN THE BOX
240v power source
INTRODUCTION
Thank you for purchasing the KickAss Digital HDTV Caravan / RV Antenna.
This product has been specially designed for outback condions. With its
light weight design and durable material choice this will connue to do the
job intended out in the harsh condions of the outback. Thats KickAss. Firstly
please read through the following instrucon before use.

Frequency range
VSWR
Impedance
Gain
Connector
Power supply
Cable Length
Polarizaon
Power Source
PRODUCT SPECIFICATIONS
FM 88-108Mhz; VHF 170-230Mhz, UHF 470-862Mhz
2.0
75
30 dBi
F Male or customized
USB port (5V/500mA)
10M
Horizontal
240v power adapter

ANTENNA INSTALLATION
Step 1: Install the antenna base to the roof of your
caravan or camper trailer.
Metal washer

Insert the screw into
the base.
Pass the plasc
washer through the
screw.
①
②
Antenna pedestal screw
inserted into roof of
Caravan or Camper Trailer.
①
Tighten nut.
Pass the metal
washer through the
screw.
①
②

Caravan or
Camper Trailer
Caravan or
Camper Trailer
Use silicon roof sealant
as required when mounng.
②
For the antenna cable a hole
may be made and sealed
separately at the most
convenient locaon
③

Step 2: Install the antenna to the antenna base.
Locang slot Locang slot
Insert the screw into
the hole posion of
antenna bracket.
Tighten the nuts and
the antenna is
installed.
①
②
Find the locang slot
of the bracket.
Aim at the locang
slots of the bracket
and base, then press
the antenna.
①
②
Note: Keep away from air condioning or other metal objects
when installing antennas.
Run the Antenna cable to the desired locaon and seal the roof entry
accordingly.

Power supply
Connect to a 5V USB charging port
(HDTV/Adapter)
Set Top Box
Power supply
Connect to a 5V USB charging port
(HDTV/Set Top Box/Adapter)
HOW TO CONNECT THE ANTENNA TO TV

(1) Connect the F male of antenna to the F female of the
power supply.
(2) Connect the F male of the power box to the ANT/IN
connector on Set Top Box or TV (Built-in tuner).
(3) Power the antenna by plugging the antenna power box’s
USB connector into an open USB port on the TV or the
set Top Box or into a wall outlet with one power adapter
(not included).
(4) If you find that the TV cannot receive any signals, please
check the following:
(1) Verify that the antenna, power supply, TV and set Top Box
are properly connected.
(2) Make sure your TV has a digital tuner, and if not, buy a Set
Top Box.
(3) Make sure the USB interface of the antenna power supply
is connected with the power charging port.
Note: Recepon quality and the number of channels
received are dependent on mulple factors like distance
from TV broadcast tower, broadcast power, line of sight,
terrain, metal construcon materials and other
environmental factors.

1. Please make sure your TV has a HDTV Tuner, if not, we suggest
you buy a Set Top Box.
2. Not all digital signals are high definion. Ensure your digital
receiver is a HD receiver, otherwise no HD channels can be
viewed.
3. Make sure you install the antenna and antenna power supply
correctly. The antenna power box comes with a USB cable and
this cable should be powered through a USB charging port, the
indicator light will be on when working.
4. TV recepon capacity depends on the distance among your
home, transming tower and surrounding environments.
5. Recepon will vary based on factors like geography and locaon
of the broadcast signal, antenna hills, buildings and even tall
trees can impact recepon.
6. When the antenna is installed on the caravan or camper trailer,
please try to install it as high as possible.
7. You need to retune your free view TV’s and digital receiver from
me to me to ensure you are receiving all available services.
Retuning only takes a few minutes and can be done via remote.
8. This digital HDTV antenna is intended for caravan and camper
trailer use.
Note: Keep away from air condioners or other metal objects
when installing antennas.
KickAss Tips for Best Recepon
Air Condioning Metal Fence and so on

THANK YOU FOR CHOOSING
KickAss® is committed to providing you with the
most up to date product information. As printed
material is harder to update we have created an online
user guide portal including videos, user guides and
product tips so you can view or download the latest
product information at any time. This also helps to save
our environment which we are committed to just as
much as we are committed to our customer service.
To get started with this product, please visit
and search for your SKU code
ONLINE USER GUIDES
SCAN QR CODE
USERGUIDES.KICKASS.COM.AU

In Australia, our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a
major failure.
Warranty does not cover products that have not been used in accordance with
the KickAss® user guide or are outside the warranty terms and conditions.
KICKASS PRODUCT QUALITY
This KickAss® product comes with a 12 month warranty
for your peace of mind. In the unlikely event this
product fails when used according to our user guide,
we will either repair or replace it. For full warranty
terms and conditions on this product, please see the
user guide at:
userguides.kickass.com.au
Customer Support
For any technical or warranty enquires
please visit our customer service
portal at:
warranty.kickass.com.au
QUESTIONS AND COMMENTS
Please visit us at kickass.com.au or
email us at [email protected]om.au

NOTES
