Kill Shot Tree-Hoist User manual

Tree Mounted Game Hoist
Item #: Tree-Hoist

Part
Description
Qty
F
D-Shape Pin Clip
3
G
Pulley
1
H
M8 Bolt, Washer, Locknut
1 set
I
M10 Bolt, Washer, Locknut
2 sets
Parts List
Part
Description
Qty
A
Arm Support
1
B
Center Support(with
Chain)
1
C
Diagonal Support
1
D
Winch
1
E
Belt Stretcher
1
CAUTIONS AND WARNINGS
Confirm all parts are present before assembly. If any part is missing, cracked or
damaged, please contact Sportsman’s Guide customer service before assembly
Read and understand all warnings, cautions, assembly, installation and use
instructions prior to assembling, installing or using this product. Failure to follow all
warnings, cautions and instructions may result in serious injury or damage to personal
property.
The warnings, cautions, and instructions in this manual cannot cover all possible
conditions or situations that could occur. Exercise common sense and caution when
using this product. Always be aware of the environment and ensure that the product is
used in a safe and responsible manner.

• Do not exceed the working load limit of 300 pounds (136 kg). The manual crack is
rated to 660 pounds (299 kg). Be aware of dynamic loading! Sudden load movement
may briefly create excess load causing product failure.
• Do not install in a location that could pose a safety hazard.
• NEVER allow other persons to assemble, install or use this product until they have read
this manual and have developed a thorough understanding of how the product works.
• NEVER attempt to modify this product or subject it to an installation or use for which it
was not designed. Doing so may result in damage and/or serious injury.
• NEVER attempt to assemble, install, load or unload the rack while you are tired or
under the influence of drugs or alcohol.
• ALWAYS wear appropriate safety gear such as ANSI-approved safety goggles and
heavy-duty work gloves when assembling, installing, loading, unloading or removing/
storing the rack.
Step 1
Assembly Instructions
Pull out the Arm Support (A),
place it perpendicular to the
Center Support (B), and then
insert one D-Shape Pin Clip
(F).
Step 2
Connect the Arm Support (A)
and the Center Support (B)
with the Diagonal Support
(C), use two D-Shape Pin Clips
(F). There are 3 holes and it
could be inserted in any of
them according to actual
situation.

SG03.20
Step 3
Install the Winch (D) to the
bottom of the Center Support
(B), use the two bolt sets (I).
Assembly Tip:
Unwind all of the winch cable
from the spool when
installing the winch. This will
provide additional clearance
for your hand and/or wrench
making installation easier.
Step 4
Pull out some of the cable
from the spool and let it pass
through the groove of the
Arm Support (A). Then
assemble the Pulley (G) with
one bolt set (H).
Step 5
When you install the deer
hoist to the tree, you should
tie it with the chain and the
Belt Stretcher (E). Let the
Belt Stretcher (E) pass
through U-shape groove of
the Center Support (B), then
tie it in the tree. There are
two grooves on the Center
Support (B), upper and
bottom.
