Performance Tool W4005DB User manual

1 YEAR LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These warranties give specific legal
rights. Except where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions and limitations of
warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal use and service. A
defective product may be returned for a free replacement within 90 days from the date of purchase, provided that product is returned to
place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL®
will replace at no charge any parts which our examination shall disclose to be defective and under warranty. These warranties shall be valid
only when a sales receipt showing the date of purchase accompanies the defective product or defective part(s) being returned. For part(s)
after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be replaced under normal
use and service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed, or which
has been repaired or altered in any way so as to affect adversely its performance or reliability, nor shall these warranties apply to any
product or part which has been subject to misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in connection with its
products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no express or implied
warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes no implied warranty of merchantability
and no implied warranty of fitness for any particular purpose, except that for goods purchased primarily for personal, family or household
use and not for commercial or business use, PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise
applicable, an implied warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above. The laws on limitation of implied warranties may differ from state to state, so the above limitations
may not apply in all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any manner related to any
product, or to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective product or part shall be
the repair, or replacement thereof as provided above. The laws on limitation of remedies or on consequential, incidental or special
damages may vary from state to state, so the above limitations may not apply in all cases.
© Copyright 2017 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
WARNING!
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO
MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND
WILL VOID WARRANTY.
Some dust created by power sanding contains chemicals known to the State of California to cause cancer, birth defects or other reproductive
harm. An example of this type of chemical is lead from lead based paints. Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure: work in a well ventilated area and work with approved safety equipment, such as dusk masks
that are specially designed to filter out microscopic particles.
1 TON CHAIN HOIST
OWNER’S MANUAL
Stock Number W4005DB

1 2
IMPORTANT SAFETY INFORMATION
WARNING: This is a lifting device only. Load must be supported immediately.
Do not overload chain hoist beyond rated capacity. Overloading can cause damage to or failure
of the hoist.
WARNING!
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO
SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY
DAMAGE AND WILL VOID WARRANTY.
Your Performance Tool chain hoist was constructed with quality materials and workmanship and
will give you many years of trouble free use when cared for as described in the "Care &
Maintenance" section on page 2. However, as with any mechanical device, periodic adjustments
are necessary to maintain a peak level of performance.
OPERATION
Before using your chain hoist, determine the approximate weight of the load to be lifted.
Be sure the load does not exceed the rated capacity of the chain block. NEVER
OVERLOAD THE CHAIN HOIST.
Check the parts of the chain hoist before each application. Inspect the hooks, load chain,
braking device, and other critical parts including the lubrication of the block.
All hooks must be securely attached to the chain hoist before using the equipment. Make sure
the load being lifted is not suspended from the tip of the hook, and the hook is not tilted. The
load chain should remain vertical without any twist in the chain to prevent tangling.
When lifting, the operator should stand in the plane of the hand wheel. Pull the hand chain, in
smooth and steady fashion, to rotate the hand wheel clockwise raising the load. Pulling the
hand chain in a counterclockwise direction will cause the hand wheel to separate from the
brake seat which will release the ratchet disc and gently lower the load.
To prevent tangling the chain and rotating the block, DO NOT pull the hand chain in a
direction diagonal to the hand wheel.
NEVER pass or work beneath a lifted load.
If the hand chain binds, STOP IMMEDIATELY.
Making sure that nothing is entangled with the load, inspect the chain hoist parts and
make sure the load is within the rated capacity.
CARE AND MAINTENANCE
1. Clean the chain hoist after each use. When hoist is not in use, store in a dry environment
to prevent corrosion and rusting.
2. Once a year, clean all the chains and hoist parts with kerosene. Lubricate the gears and
bearings with grease.
3. Align the “O” marks of the gears while assembling.
4. Previous to fitting the chain sprocket rollers into the outer race of the bearing on the
side plate, the rollers may be attached with grease to the journal of the chain sprocket.
5. Extra care must be taken when reassembling the brake mechanism. Align the diagonal
teeth of the ratchet disc and the pawl. Inspect the pawl to be sure that the springs are in
good, working condition. Turn the hand wheel clockwise after twisting it onto the driving
shaft, it must press the discs and plates onto the brake seat. When rotating
counterclockwise there should be clearance between the disc and the plates.
6. Do not dismantle the right side plate and stay.
7. Subject the block to a no-load test and a heavy load test after maintenance is complete.
The chain hoist may be returned to operational status after being found in good condition.
8. Inspect the braking mechanism regularly, and keep all friction surfaces clean and well lubricated.
Regularly check for loose, worn or damaged parts. Any hoist that appears damaged
in any way must be removed from service.
SPECIFICATIONS
Capacity ....................... 2,000 lbs.
Lift Range ...............................8 ft.
Specifications are subject
to change without notice.
