Kilowatt Labs SIRIUS 1364-24-B-1C-TM-SD-A-G User manual

SIRIUS CAPACITOR MODULE
User Manual
Model number: 1364-24-B-1C-TM-SD-A-G
Version 1.0; Release Date: September 2020
Author:
Mamoona Khalid

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
2
Introduction
The Sirius Capacitor Module (“Sirius”) is supercapacitor-based storage that uses supercapacitors as
storage cells instead of chemical cells. Kilowatt Labs’ proprietary balancing, control and charge
retention algorithms control the operation of the supercapacitor-based modules, making Sirius a safe,
efficient and effective alternative to chemical batteries wherever chemical batteries are deployed.
Legal Provisions
No part of this User Manual (“Manual”) may be reproduced, or transmitted, in any form or by any
means, without the prior written permission of Kilowatt Labs, Inc. (“Kilowatt” or the “Company”).
Specifications in this Manual are subject to change without notice. While every attempt has been
made to make the Manual accurate and up-to-date, users are cautioned that product improvements
may cause the Company to make changes to specifications without advance notice. Users are
encouraged to consult the Company or its Resellers before using the Manual. Neither the Company
nor its Resellers shall be liable for any indirect, incidental, or consequential damages under any
circumstances caused by reliance on the material presented, including, but not limited to, omissions,
typographical errors, arithmetical errors or listing errors in the content material. The content of this
manual shall not be modified without the written authorization of the Company.
Trademarks
All trademarks are recognized, even if not explicitly identified as such. Kilowatt Labs® is a registered
trademark of the Company.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
3
Contents
1 Safety Instructions: ..............................................................................................................................5
1.1 Symbols Convention: ....................................................................................................................5
1.2 Safety Precautions: .......................................................................................................................5
1.3 Modules Connection Safety Precautions:.....................................................................................7
1.4 Shipping:........................................................................................................................................7
1.5 Qualified Installer:.........................................................................................................................7
2 Product Introduction:...........................................................................................................................8
2.1 Part Number:.................................................................................................................................8
2.2 Product Overview: ........................................................................................................................8
2.2.1 Appearance:...............................................................................................................................8
2.2.2 Mechanical Drawings:..............................................................................................................9
2.2.3 Dimensions and Weight:........................................................................................................10
2.3 Product Description: ...................................................................................................................11
3 Module Installation:...........................................................................................................................16
3.1 Inspection:...................................................................................................................................16
3.2 Safety Gear:.................................................................................................................................16
4 Electrical Installation:.........................................................................................................................18
4.1 Connecting Module to Power Supply: ............................................................................................18
4.2 Connecting Module to Load:...........................................................................................................19
4.3 Connecting Modules in Parallel: .....................................................................................................20
5 Operation Procedures:.......................................................................................................................21
5.1 Module Configuration:....................................................................................................................21
5.2 Software Configuration:..................................................................................................................22
6 Recovery Procedure:..........................................................................................................................24
7 Automatic Safety Shutdown: .............................................................................................................26
8 Trouble Shooting:...............................................................................................................................28
9 Features: ............................................................................................................................................29
9.1 Key Features:..............................................................................................................................29
9.2 Physical features: .......................................................................................................................29
9.3 Technical Features: ....................................................................................................................30
10 Shelf Life:.........................................................................................................................................31
11 Maintenance:...................................................................................................................................31
12 Disposal:...........................................................................................................................................31
13 Test Procedures: ..............................................................................................................................32

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
4
13.1 Round Trip Efficiency Test:........................................................................................................32
13.2 Test Method for Self-Discharge: ...............................................................................................33
14 FAQs:.............................................................................................................................................34

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
5
1Safety Instructions:
This manual contains instructions for unpacking, mounting, installation and operation of a Sirius
Module. Please read this manual carefully before operating the system and follow all warnings and
safety instructions to prevent accidents. The Sirius Module must be installed by trained personnel.
1.1 Symbols Convention:
Safety instructions and general information that appears in this manual are described.
1.2 Safety Precautions:
The Sirius Modules are designed to provide years of trouble-free operation. Proper handling is
required to avoid damage to the Module. In particular the following precautions should be observed.
•Personal Safety:
→Always wear proper personal protective equipment (eyes protection, gloves and safety shoes).
Caution!
‘’Caution” indicates hazardous situation which, if not avoided could result in
minor or moderate injury.
Warning!
‘’Warning” indicates hazardous situation which, if not avoided could result
in major injury or death.
Danger!
‘’Danger” indicates hazardous situation which, if not avoided could result
in serious injury or death.
Note!
“Note” provides tip that are valuable for optimal operation of your
product.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
6
→Always make sure charger is set as recommended.
→Always make sure chargers are disconnected while working on Modules.
•Module Safety:
→Do not subject the Module to strong impact.
→Do not crush or puncture the Module.
→Do not dispose the Module in a fire.
→Do not charge the Module when the temperature is below -30oC.
→Do not charge the Module when temperature is above 80oC.
→Do not operate the Module above the specified voltage.
→Under no circumstances charge/discharge the Module at more than 60 A.
→Under no circumstance must the charging voltage exceed 27 Vdc for more than 60 seconds.
→Do not expose the Module to temperatures in excess of 80°C.
→Do not place the Module near a heat source, such as a fireplace.
→Do not disassemble the Module under any circumstances.
→Do not touch the Module with wet hands.
→Do not expose the Module to moisture or liquids.
→Keep the Module away from children and animals.
→Ensure precautions to prevent short-circuit under all circumstances.
→Do not connect or disconnect terminals from the Module without first disconnecting the load.
→Do not touch the terminals with conductors while the Module is charged. Serious burns, shock, or
material fusing may occur.
→Protect surrounding electrical components from incidental contact.
→When connecting to external devices ensure that galvanic isolation does not exceed 1000V.
→Do not use the Module in open-environment, in rain or in a place exposed to water and other
liquids.
→Do not subject the Module to high pressure.
→Do not step on the Module.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
7
→Do not drop the Module. Internal damage may occur that will not be visible.
→Do not stack Modules once they have been removed from the packaging, instead the Modules
should be placed on shelving.
→In case the Module is physically damaged due to any event, do not install and energize the Module
under any circumstances and immediately contact your Reseller.
1.3 Modules Connection Safety Precautions:
→All Modules must be at 100% SOC or same level of voltage before connecting in Series or in
Parallel.
→The maximum number of Modules that can be connected in series is 15 with Module Combiner.
→Do not connect more than 15 Modules in Series.
→Modules cannot be connected in Series-Parallel combination under any circumstance.
1.4 Shipping:
Sirius Capacitor Modules are shipped out via Air and Sea.
•If the Modules are shipped via Air, please follow the instructions given below:
•Carefully remove the nails from all the four sides of the wooden box and open it.
•Remove the foam and cling wrap and open the carton box and lift the Module manually.
•If the Modules are shipped via Sea, please follow the instructions below:
•Carefully remove the Module from the pallets after cutting the packing strip holding the
Modules to the shipping pallets.
•Open the carton box and lift the Module manually.
1.5 Qualified Installer:
Selling and installation of this Module is only through the Company’s Resellers who are trained on
installation, operation and maintenance of the Sirius Modules.
Note!
If you want to connect more than 15 Modules in Series, please contact your
Reseller.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
8
2Product Introduction:
2.1 Part Number:
1) Capacity of Module in WH
2) Nominal Voltage of the Module
3) Terminals are on the Front Side
4) Maximum Charge Rate of the Module
5) With Total Cell Monitoring
6) With Safety
7) With Alarm
8) General Module
2.2 Product Overview:
2.2.1 Appearance:
The appearance of the Sirius Module is shown below:

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
9
2.2.2 Mechanical Drawings:

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
10
2.2.3 Dimensions and Weight:
Width
230 mm
Depth
463 mm
Height
246 mm
Weight
30 kg

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
11
2.3 Product Description:
Object
Mark
Description
1
F08 Terminals
Terminals for Power Supply/ Load
Connections
2
LCD
(16×2) LCD
3
Fault Reset
Fault Reset Button

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
12
4
Aux
Auxiliary USB
5
Comm Connector
Communication Connector USB
6
Comm Status
Communication Status LED
7
Terminal Status
Terminal Status LED
8
Circuit Breaker
125A 2P Circuit breakers for switch
ON/OFF Module.
9
F08 Bypass Terminals
Terminals for Series, Parallel Connection
and recovery purpose
10
14 Pin Connector
Parallel Cells Connector
1. F08 Terminals:
These are the output terminals of the Module having electronic switch protection that is limited to
100VDC only. F08 terminals are used to connect the load or charger to the Module. There are also
positive and negative cables in the jumper cable set. The red one is positive (+), the black one is
negative (-).
2. LCD Description:
Once the power is switched ON from the circuit breaker, the Module gets power and the LCD shows
the following message after 3 seconds under normal operation:
→After 1 second, the following two LCD screens get switched with each other.
Note:
Never connect the red cable to the negative terminal of the Module.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
13
3. Fault Reset:
Fault Reset is a push button which is used to turn ON the terminals manually after it turns OFF due to
any error.
The additional features of fault reset are as follows:
a) Hold fault reset for 5 seconds to toggle the terminals.
b) Hold fault reset for 3 seconds to reset fault if there is/are any.
c) Press fault reset button to check the state of charge and instantaneous power.
d) We can set the Current reading to zero.
•To make the current zero, follow the steps below:
→When current is not zero, the LCD will display the following message.
→To make the current zero, hold the fault reset button for 3 seconds and the LCD will display the
following message.
This means that the current is now zero.
To return back to the normal screen, press the fault reset button once more or leave the Module idle
for 5 seconds.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
14
4. Auxiliary USB:
This is an auxiliary connector with isolated UART or Serial Communication for wireless monitoring,
Module Combiner and future functions.
5. COMM Connector USB:
This is a COMM connector to monitor the Module using the Sirius software. FTDi chip is used for this
USB.
6. COMM Status LED:
COMM Status LED indicates the communication status.
•LED Status Indication:
Color
Status
Indication
Red
Blinking
Control Module is communicating with Sirius VIEW
Software.
Red
Steady
Control Module is not communicating with Sirius VIEW
Software.
Red
Dimming
Module is in power down state.
7. Terminal Status LED:
Terminal status LED indicates the F08 terminal status.
Color
Status
Indication
Green
ON
The F08 terminal is active
Green
OFF
The F08 terminal is not active.
Note!
Make sure that there is no external load or charger before setting the current
to zero.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
15
8. Circuit Breaker:
Circuit breaker is used to power ON the Module. It also acts as a second line of protection, if the circuit
fails to protect the Module from over current, the circuit breaker will trip.
9. F08 Bypass Terminals:
The Bypass terminals is used to bypass electronic switch. It is used for parallel/series connections and
recovery of the Module.
10. 14 Pin Connector:
Connector is used only when the Modules are connected in parallel. It is used to make the individual
cells of both Modules parallel.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
16
3Module Installation:
3.1 Inspection:
Inspect the shipping carton for visible damage including cracks, dents, deformation and other visible
abnormalities prior to unpacking the Module. Document (photograph) any damage and report this to
your Reseller as well as to the shipping agent immediately. Remove the Module from the shipping
carton and retain the shipping materials until the unit has been inspected and is determined to be
operational.
3.2 Safety Gear:
Installation must strictly follow the national safety regulations in compliance with the enclosure,
installation, creepage, clearance, casualty, markings and segregation requirements of the end-use
application. Installation must be performed by professional installers only. Switch OFF the system and
check for hazardous voltages before altering any connection! Sirius Modules must be handled only by
qualified and trained personnel. Installation should not exert bending or twisting torque to the Module
enclosure.
Note!
Read the safety Instruction section before installation.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
17
3.3 Unpacking and Contents Check:
Check the contents of the package.
1) Sirius Capacitor Module: 1364Wh24VDC
2) Bolts × 2
3) Washers × 4
4) Parallel Cells Connector
5) Remote Key
2
1
3
4
5

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
18
4Electrical Installation:
4.1 Connecting Module to Power Supply:
•Connect positive and negative terminals of charger to the positive and negative terminals of the
Sirius Module respectively.
•Turn ON the circuit breaker.
•Press the Module start button “A” of the remote key to turn ON the Module.
•Turn ON theCharger.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
19
4.2 Connecting Module to Load:
•Connect positive and negative terminals of discharger to the positive and negative terminals of the
Sirius Module respectively.
•Turn ON the circuit breaker.
•Press the Module start button “A” of the remote key to turn ON the Module.
•Turn ON thedischarger.

Sirius Capacitor Module –User Manual Model Number - 1364-24-B-1C-TM-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
20
4.3 Connecting Modules in Parallel:
Modules can be connected in parallel for capacity extension.
•Steps to Connect Modules in Parallel:
Refer to the parallel combination of the Sirius Modules as shown below and make your connection
accordingly.
•Connect the positive (+) of the F08 bypass terminals of both Modules.
•Connect the negative (-) of the F08 bypass terminals of both Modules.
•Connect the parallel cells connector as illustrated in the picture.
Caution!
Charge all the Modules to 100% SOC or same voltage level before
connecting them in parallel.
