kim lighting Micro-Flood User manual

Part No. 955008/30/13 EC 130822022 Status 17
Micro-Flood®Installation Instructions
Make certain electrical supply is OFF before starting fixture installation.
!
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS!
WARNING: Fixtures must be grounded in accordance with local codes or the National Electrical
Code. Portable spear mounts using a cord and plug must be plugged into a receptacle protected by
a Ground Fault Circuit Interrupter in accordance with the National Electrical Code. Failure to do so
may result in serious personal injury. DO NOT operate luminaire with missing or damaged lens.
SAFETY WARNING: Fixtures can become very hot depending on the lamp wattage used. Glass
lenses
and metal areas above and around the lamp can become hot enough to blister hands.
Particular care should be taken not to locate fixtures where small children can reach them if higher
wattages are used.
CAUTION: When relamping fixture avoid touching the lamp envelope with bare hands. Lighted lamp is HOT!
If touching the lamp is necessary during installation, clean the envelope with alcohol and dry with a clean,
soft cloth before burning. Contamination of the quartz envelope may reduce lamp performance. Fixtures
are approved for above ground installation only.
NOTE: Keep the lamp free from impact while burning, as this may deform the filament and shorten life for
Halogen/Metal Halide lamps
KEEP THIS SHEET FOR FUTURE REFERENCE.
!
!
EL215
16555 East Gale Ave.
City of Industry, California 91716-0080
626/968-5666 • FAX [phone]
Tools Required: qF" Allen Wrench qB" Allen Wrench qPhillips Head Screwdriver
qFlat Head Screwdriver qAdjustable Wrench qThread Sealant
2. Coat coupling threads with
a good sealant and tighten
coupling onto mounting
device*. Re-tighten set screw.
1. Loosen set screw at bottom
of mounting device* with
Phillips Head screwdriver.
3. Install fixture onto coupling
and attach fixture leads
observing polarity …
4. white-to-common, black-
to-voltage. Screw on Junction
box cover, making sure gasket
is securely in place.
*Consult KIM Landscape Lighting Collection Catalog for mounting device options.

Page 2 Kim Lighting • 16555 E. Gale Ave. • P.O. Box 60080 • City of Industry, CA 91716-0080 • 626/968-5666 • FAX [phone]
LAMP INFORMATION
CATALOG NO. LAMP TYPE MAX. WATTS
EL215
Quartz Halogen
Mini-Can Base
by others
150W Hal.
175W MH
WARNING! HID /Fluorescent fixtures utilize a
lamp that may contain mercury. For information on
disposal, go to website: www.lamprecycle.org
How may we serve you better? Please let us know.
Visit our website at: www.kimlighting.com
Your concerns are important to us
Micro-Flood®Installation Instructions
KIM LIGHTING LIMITED WARRANTY
When installed in accordance with Kim Installation Instructions and accepted trade practices, the following shall apply:
General Product Limited Warranty Coverage
All material and component parts used in the manufacture of Kim Products, are warranted to be free from defects of material and/or
workmanship for a period of 1 year from date of sale, with the following exceptions:
Auxiliary Equipment:
All auxiliary equipment (such as lamps, ballasts, and transformers) provided by and/or included in Kim Products shall carry the
components manufacturer’s warranty.
Copper, Bronze and Brass Landscape Components
Copper and Bronze Landscape fixture components shall be warranted against defects of material and/or workmanship, and failure
due to corrosion, for a period of 25 years from date of sale.
Kim Lighting’s brass components are constructed from several brass parts that are manufactured by various methods at various
times. Since brass naturally deepens in color as it ages through the normal oxidation process, these parts may exhibit subtle
differences in coloration when the product is new. This is normal and expected. These color differences will be eliminated shortly
after installation through the normal brass oxidation process.
Composite In-Grade Components
Composite In-Grade fixture components installed below grade, shall be warranted against defects of material and/or workmanship,
and failure due to corrosion, for a period of 7 years from date of sale.
Aluminum Landscape Components
Aluminum Landscape fixture components not in direct contact with soil, shall be warranted against defects of material and/or
workmanship for a period of 3 years from date of sale. Aluminum fixture components in direct contact with soil shall be warranted
from defects of material and failure from corrosion for a period of 1 year from date of sale.
Limit of Liability and General Conditions
Only products which are installed, used and maintained in accordance with applicable Kim instructions, specifications and accepted
trade practices, are covered by the Kim Warranty. During the warranty period, with proof of purchase, Kim will repair or replace
with the same or similar product, at Kim’s option without charge. Labor costs are the owner’s responsibility and are excluded from
this warranty. This warranty is void if the product is modified, tampered with, misapplied, poorly installed, improperly maintained, or
subjected to abnormal conditions.
Repair or replacement as provided under this warranty is the exclusive remedy of the purchaser. This warranty is in lieu of all other
warranties, expressed, or implied, including any implied warranty of fitness for a particular application. Kim Lighting shall not be
liable to the purchaser for indirect or consequential damages.
Note: Swivel stem must be
installed with the mounting
threads facing down or
horizontal. Fixtures may not be
installed with mounting threads
facing up unless shielded from
moisture.
6. To adjust backtilt, loosen
swivel screw being careful not
to disengage threads. Hold
fixture at desired angle and
firmly tighten swivel screw.
5. Loosen screws and install
lamp type listed on fixture
label. Replace lens frame
and tighten screws for proper
sealing.
7. Loosen set screw to adjust
fixture rotation and tighten set
screw.
