King Pigeon BL280 User manual

Preface
BL280
User Manual
Version: V1.0
Issue Date: 2021-06-15
King Pigeon Communication Co., Ltd.
Website: www. iot-solution.com
LoRa Gateway BL280
Wireless Data Collection/
RS485 Transparent Transmission

Page 2 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
Thanks for choosing King Pigeon Wireless Data Acquisition System LoRa Gateway BL280.
Reading this manual with full attention will help you quickly learn device functions and operation
methods.
Copyright
This user manual is owned by King Pigeon Communication Co., Ltd. No one is authorized to copy,
distribute or forward any part of this document without written approval of King Pigeon. Any violation
will be subject to legal liability.
Disclaimer
This document is designed for assisting user to better understand the device. As the described
device BL280 is under continuous improvement, this manual may be updated or revised from time
to time without prior notice. Please follow the instructions in the manual. Any telecommunication
service network issues or damages caused by wrong operation will be beyond warranty.
Revision History
Revision Date
Version
Description
Owner
July 28, 2021
V1.0
Initial Release
HEX

Page 3 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
Contents
1 Product Introduction............................................................................................................................... 5
1.1 General Introduction........................................................................................................................5
1.2 Typical Application........................................................................................................................... 6
1.3 Safety Introduction.......................................................................................................................... 7
1.4 Packing List...................................................................................................................................... 7
1.5 Features............................................................................................................................................ 9
1.6 Technical Parameters..................................................................................................................... 9
2 Hardware Introduction..........................................................................................................................11
2.1 Outline Dimension......................................................................................................................... 11
2.2 LED Indicator..................................................................................................................................12
2.3 Interface Definition........................................................................................................................ 12
2.4 Ethernet Port.................................................................................................................................. 13
2.5 SIM Card Slot.................................................................................................................................13
2.6 Power Switch/Upgrading Switch................................................................................................. 13
2.7 External Antenna........................................................................................................................... 14
2.8 USB Port......................................................................................................................................... 14
3 Gateway Mounting................................................................................................................................15
3.1 Wall-Mounting................................................................................................................................ 15
3.2 DIN-Rail Mounting......................................................................................................................... 15
4 Parameter Configuration......................................................................................................................16
4.1 Preparation for Configuring the Gateway.................................................................................. 16
4.1.1 Install USB Driver...................................................................................................................16
4.1.2 Search for Port Number........................................................................................................ 16
4.1.3 Login to Configuration Software.......................................................................................... 17
4.2 Basic Settings................................................................................................................................ 18
4.3 Ethernet & Cellular Network Configuration................................................................................19
4.4 Cloud Platform............................................................................................................................... 19
4.5 Wireless Node Configuration.......................................................................................................23
4.6 Wireless Node Management....................................................................................................... 25
4.7 Historical Record........................................................................................................................... 26
4.8 Alarm Record..................................................................................................................................26
5 SMS Command..................................................................................................................................... 27

Page 4 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
6 Communication Protocol......................................................................................................................28
6.1 Modbus RTU Protocol.................................................................................................................. 28
6.2 Modbus TCP Protocol...................................................................................................................30
6.3 MQTT Protocol...............................................................................................................................33
7 Firmware Upgrading.............................................................................................................................33
8 Warranty Term...................................................................................................................................... 33
9 Technical Support.................................................................................................................................33
10 Appendix A SMS Command List......................................................................................................34
11 Appendix B Register Address...........................................................................................................36
12 Appendix C MQTT Application......................................................................................................... 39
13 Appendix D LoRa Node Introduction...............................................................................................43
WT100 (RS485 Transparent Transmission Node)......................................................................... 43
WT101(4 Digital Input Data Collection Node)..................................................................................44
WT102 (2 Relay Output Control Node)............................................................................................ 45
WT103 (AM2301 Temperature & Humidity Data Collection Node)..............................................46
WT104 (AM2401 Temperature & Humidity Data Collection Node)..............................................46
WT105 (DS18B20 Temperature Data Collection Node)................................................................47
WT106 (PT100 Temperature Data Collection Node)..................................................................... 48
WT107 (Multiple environmental Data Collection Node).................................................................49
WT108 (Soil PH Value Collection Node)..........................................................................................49
WT109 (Soil EC Data Collection Node)............................................................................................50
WT110 (Soil Moisture Content Data Collection Node)...................................................................51
WT111 (Multiple-Parameter Collection Node).................................................................................52

Page 5 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
1 Product Introduction
1.1 General Introduction
Wireless Data Acquisition System BL280 is based on LoRa RF technology. It’s mainly used for
collecting multiple environmental data distributed in different long range areas and transparent data
transmission from device to cloud. With LoRa modulation technology, it’s capable of realizing
multiple IO device monitoring, collecting data of temperature & humidity, light intensity, CO2, wind
direction & speed and soil conditions.
LoRa communication range is up to 2KM.Built-in LoRa chip SX1278 and GSM/GPRS/3G/4G/RJ45
module work together to achieve remote monitoring and control by sending sensor, PLC, smart
meter and other device data to cloud or mobile phone via SMS/2G/3G/4G/Ethernet. Huge field
wiring cost will be saved
This wireless data acquisition system comprised of 2 parts, LoRa Gateway BL280 and LoRa Nodes.
Nodes connect senor, PLC and other devices. The collected data is sent to gateway. Mutual
communication between PLC and cloud is done through wireless RF technology. Alarm threshold
can be set in gateway so that alarm events can be recorded.

Page 6 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
1.2 Typical Application
Smart greenhouse data collection and monitoring
Smart orchard data collection and monitoring
Smart crop land data collection and monitoring
Smart Breeding Temp& Humi data collection and monitoring
Smart factory temp & humi data collection and monitoring

Page 7 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
ATM, POS, PLC and DAQ device data transmission
Smart grid data transmission
Smart transportation data transmission
Industrial automation data transmission
Environmental protection data transmission
Weather station data collection and monitoring
Agriculture, Aquaculture and coal mine site data transmission
Smart agriculture, smart fire protection, smart city, smart building, etc
Other distributed site data collection and monitoring
1.3 Safety Introduction
Safety Notice:
Please don’t use this device in the place where mobile phone is prohibited.
Wireless Interference
Please avoid wireless interference to impact GSM/GPRS/3G/4G network.
1.4 Packing List
Please make sure below parts are included in the package before installing the device.
1x BL280 LoRa Gateway
1x 2 pin 3.5mm Female connector

Page 8 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
1x mini_USB cable
1x LoRa Antenna
1x 2G/3G/4G SMA Cellular Network Antenna (AT-25)
1x Power Adaptor (12VDC/2A)
1x User Manual (Soft Copy)

Page 9 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
Note: If any of the above parts are missing, please contact King Pigeon sales team.
Optional Part (Must order it separately)
35mm DIN Rail Mounting Bracket
1.5 Features
Embedded ARM®Cortex™-M 32-bit RISC core real-time operation system, software and
hardware watchdog to avoid false deadlock
Support 9~36VDC power supply with reverse wiring protection design
Modular design, only communication module change to upgrade GSM/3G/4G network
Support remote device restart and configuration with SMS
Device parameters can be set easily with local configuration software, SMS and APP
Support MQTT, Modbus TCP, Modbus RTU, transparent transmission and custom handshake
protocol to actively connect server & automatically re-connect server if network disconnected
Support Alibaba Cloud, HUAWEI Cloud, King Pigeon Cloud and other clouds with standard
Modbus MQTT protocols
Ethernet port has transformer isolator with 2KV electromagnetic isolation
Support long range wireless data transmission with data collection and device control nodes
Support multiple environmental data collection, max 12 types of different nodes can collect data
simultaneously
Automatic offline re-connection function ensure nodes and gateway are connected permanently
Support real-time monitoring node battery usage to avoid device data loss
1.6 Technical Parameters
Item
Parameter
Description
Power Supply
Power Voltage
9～36V DC
Power Consumption
Normal: 130mA@12V, Max 150mA@12V
Protection
Reverse wiring protection, ESD air: 15KV, surge:

Page 10 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
4KV
Backup Battery
3.7V/900mAh
USB
USB
1 x mini USB
Ethernet Port
Spec
1 x RJ45，10/100Mbps
Protection
ESD contact: 8KV , surge: 4KV (10/1000us)
Protocol
Modbus RTU, Modbus TCP, MQTT
LoRa Parameter
Communication frequency
402MHz-500MHz, optional 860-930MHz
City communication range
1km
Visible communication range
2km
Transmitting power
<24dBm
Receiving sensitivity
<-120dBm
Air communication speed
1.0Kbps
Cellular Network
2G
GSM/EDGE：850,900,1800,1900MHz
3G
GSM/EDGE：850,900,1800,1900MHz
UMTS：850,900,2100MHz
4G (E version)
GSM/EDGE：900,1800MHz
WCDMA：B1,B5,B8
FDD：B1,B3,B5,B7,B8,B20
TDD：B38,B40,B41
4G (AU version)
GSM/EDGE：850,900,1800MHz
WCDMA：B1,B2,B5,B8
FDD：B1,B2,B3,B4,B5,B7,B8,B28
TDD：B40
4G (A version)
WCDMA：B2,B4,B5
FDD：B2,B4,B12
4G (V version)
FDD：B4,B13
4G (J version)
WCDMA：B1,B3,B8,B18,B19，B26
FDD：B2,B4,B12
TDD: B41
4G (CE version)
GSM/EDGE：900,1800MHz
WCDMA：B1,B8
TD-SCDMA：B34,B39
FDD：B1,B3,B8
TDD：B38,B39,B40,B41
Protocol
Modbus RTU, Modbus TCP, MQTT
SIM/UIM Card slot
Standard flip cover, support 1.8V/3V SIM/UIM
card, built-in 15KV ESD protection
Software
Parameter
Network Protocol
IPV4, TCP/UDP, DHCP, DNS, Modbus RTU,
Modbus TCP, MQTT
Indicator
Cellular Network Signal, Status, Ethernet and
LoRa Radiao Frequency
User Configuration
PC software configuration, support WIN XP, WIN
7, WIN 8 and WIN 10
Node QTY
Support max 50 nodes
Node Type
Suport WT100-WT111, max 12 different types
Data Transmission
Support Transparent Transmission
SMS Command
Support SMS Commands
Login Package
Support custom login package
Heartbeat Package
Support custom heartbeat package

Page 11 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
Storage
Max 2000 historical records & 500 alarm records
Certification
MTBF
≥100,000 hours
EMC
EN 55022: 2006/A1: 2007 (CE &RE) Class B
IEC 61000-4-2 (ESD) Level 4
IEC 61000-4-3 (RS) Level 4
IEC 61000-4-4 (EFT) Level 4
IEC 61000-4-5 (Surge)Level 3
IEC 61000-4-6 (CS)Level 4
IEC 61000-4-8 (M/S) Level 4
Others
CE, FCC, ROHS, 3C
Environment
Working Environment
-45～85℃, 5～95%RH
Storage Environment
-45～105℃, 5～95%RH
Others
Case Material
Metal
Size
88mm×75mm×30mm (L*W*H)
Protection Grade
IP30
Net Weight
235g
Mounting
Wall-Mounting, DIN Rail Mounting
2 Hardware Introduction
2.1 Outline Dimension
Front View Top View

Page 12 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
2.2 LED Indicator
LED Indicator
No.
Item
Color
Status
Description
1
Red
Fast
flickering
2G: No signal (0.8s off, 0.2s on)
3G/4G: No signal (1s off, 0.8s on)
Slow
flickering
2G: Normal (2s off, 0.2s on)
3G/4G: Normal (0.2s off, 1s on)
Off
Device fault
2
Status
Red
Stead On
External Power Supply is normal
Off
External power supply is lost
3
Ethernet
Red
Flickering
Ethernet port has data transmission
Off
Ethernet port has no data transmission
4
RF
Red
Flickering
LoRa RF has data transmission
Off
LoRa RF has no data transmission
2.3 Interface Definition
Power Supply
Power Supply
No.
Item
Description
1
In+
Positive Pole of Power Input
2
In-
Negative Pole of Power Input

Page 13 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
2.4 Ethernet Port
2.5 SIM Card Slot
BL280 support 1.8V/3V SIM card
2.6 Power Switch/Upgrading Switch
Make sure device is powered off before inserting SIM card. Follow Open direction to push SIM card
slot and then place the card into it.
Ethernet Port Introduction
No.
Color
Item
Description
1
Orange white
TX+
Positive of Transmitting
2
Orange
TX-
Negative of Transmitting
3
Green white
RX+
Positive of Receiving
4
Blue
Data+
Positive of two-way data
communication
5
Blue white
Data-
Negative of two-way data
communication
6
Green
RX-
Negative of Receiving
7
Brown white
Data+
Positive of two-way data
communication
8
Brown
Data-
Negative of two-way data
communication

Page 14 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
2.7 External Antenna
BL280 has 1 LoRa antenna and 1 GSM/3G/4G cellular network antenna
2.8 USB Port
mini USB port is used to connect BL280 to PC for configuring parameters and upgrading firmware
Power Switch
Upgrading Switch
GSM/3G/4G Antenna Port
LoRa Antenna Port

Page 15 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
3 Gateway Mounting
This gateway supports horizontal placement on the table, wall-mounting and DIN Rail mounting.
3.1 Wall-Mounting
3.2 DIN-Rail Mounting
Assembling clip buckle
Mounting on DIN Rail

Page 16 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
4 Parameter Configuration
BL280 configuration software has user-friendly interface. Just connect BL280 Gateway (hereafter
referred to as Gateway) to PC with USB cable to set parameters, export files and upgrade firmware.
4.1 Preparation for Configuring the Gateway
4.1.1 Install USB Driver
Skip this process if USB driver is installed already
Download BL280 configuration software and USB driver from King Pigeon website:
www.iot-solution.com
If any downloading issue, please contact King Pigeon sales team
4.1.2 Search for Port Number
Right click My Computer, then click Property-Device Manager-Port, if it’s connected normally and
USB driver is installed successfully, it will show as below:(Gateway port number is COM5)

Page 17 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
4.1.3 Login to Configuration Software
Click to execute it and enter below page:
Select connected serial port , input password (default is 1234 and it’s filled
automatically), click login to enter below main page. If login is not successful, please check USB
connection, password and port number.

Page 18 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
4.2 Basic Settings
In this page, user can quickly configure and get basic device information, including device model,
version,password, time, ID,description,etc
Basic Information
Item
Description
Default
Device ID
Range: 1~247, device ID is used to identify the
gateway in monitoring center
1
Gateway Device
Input custom device name
Null
Read Device Time
Read current gateway time
--
Write Local Time
Write local compute time to gateway
--
Change Password
Click it to change password
--
Original Password
Original device password
Null
New Password
Input new password
Null
Confirm Password
Confirm new password
Null
Gateway Device Version
Click it to read device model, version, IMEI, cellular
network signal strength
--
Model No.
Device Model
--
Version
Firmware version
--
IMEI
Unique IMEI number of the communication module
--
Battery Voltage
Backup battery voltage
--
Cellular Network Signal
Strength
Cellular network signal strength, range 0-31, If the
value is 0, please make sure SIM card is inserted
properly and charged.
--
Working Frequency Range
Range: 1~99, gateway and node must be in the same
communication frequency range.
1
Node Reporting Cycle
Node data uploading cycle, Range: 2~50(minute)
1

Page 19 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
4.3 Ethernet & Cellular Network Configuration
Set Ethernet and cellular network parameter in below page
Network Configuration
Item
Description
Default
APN
(Acess Point Name)
Mobile service provider APN access point
(not necessary in China)
Null
User Name
APN user name (not necessary in China)
Null
Password
APN password (not necessary in China)
Null
IP Mode
Set static / dynamic IP
Static
Device IP
Gateway BL280 IP Address
Null
Local Listening Port
Device port number as TCP/UDP server, can be custom,
range 0-65536
Null
Subnet Mask
Current Subnet Mask
Null
Router IP
Current Router IP Address
Null
DNS server 1
Current DNS server 1 IP address
Null
DNS server 2
Current DNS server 2 IP address
Null
Note: this gateway can be used as TCP server and TCP client.
4.4 Cloud Platform
This page is to configure the parameters for connecting device to internet. With rich automatic
handshake login packages, custom heartbeat packages and logout function, it can be connected to

Page 20 of 52 King Pigeon Communication Co., Ltd.
www.iot-solution.com
Wireless Data Acquisition System - LoRa Gateway BL280
monitoring software or cloud for two-way communication through GPRS/3G/4G and Ethernet.
Below are the options:
1) Modbus RTU Protocol, i.e. Modbus RTU over TCP, transfer Modbus RTU protocol in TCP link to
realize two-way communication between gateway and host computer. For example, input cloud
platform WWW.MY-M2M.COM, Domain name: modbus.dtuip.com, port: 6651
2) Modbus TCP protocol, i.e.add TCP to the beginning and end of standard RTU protocol message
to realize two-way communication between gateway and host computer. For example, input cloud
platform WWW.MY-M2M.COM, Domain name: mbtcp.dtuip.com, port: 6655
3) MQTT protocol, i.e. execute MQTT protocol in TCP link to realize two-way communication
between gateway and host computer. The advantage of MQTT is data will be saved in cache if
network is lost and re-transmitted once network recovers. For example, input cloud platform:
WWW.MY-M2M.COM, Domain name: mqtt.dtuip.com, port: 1883
Communication Protocol @Cloud Platform
Item
Description
Default
Priority
Set network priority, include Ethernet first, Cellular network
first and both of them
Ethernet
first
King Pigeon Cloud V2.0
(Modbus)
Set parameters for server 1 to connect King Pigeon cloud
V2.0 (Modbus RTU Over TCP)
--
King Pigeon Cloud V2.0
(MQTT)
Set parameters for server 1 to connect King Pigeon cloud
V2.0 (MQTT)
--
King Pigeon Cloud V3.0
Set parameters for server 1 to connect King Pigeon cloud
V3.0 (Modbus RTU Over TCP)
--
Alibaba Cloud
Set parameters for server 1 to connect Alibaba Cloud(via
private key)
--
HUAWEI Cloud
Set parameters for server 1 to connect HUAWEI Cloud(via
private key)
--
Other Cloud Platform
Custom parameters for connecting to required servers
--
Note:
