King Quest VQ4100 User manual

VQ4100 Quick Reference Guide
For DIRECTV®
This Quick Reference Guide will have you watching TV in minutes!
For additional information regarding the KING Quest,
see your Owner’s Manual.
IMPORTANT!
DO NOT apply feet if you will be roof
mounting the antenna unit.
IMPORTANT!
Antenna unit must have a clear view
of the southern sky. Any tall objects
can block the signal from reaching
the antenna.
2Place antenna unit in a location to scan for DIRECTV 101 satellite.
Place the KING Quest on a stable and reasonably level surface with a clear view of the southern sky.
When placing the KING Quest in position, be sure surface is dry and free of loose dirt or sand.
Lay the unit on a soft, non-scratching surface, and apply the (3) rubber feet.
1
TM

Place the power injector
in an accessible location.
3
4
Set up TV and receiver.
Make connections 1-3 in the order shown.
When all connections are made, the antenna unit will scan for the DIRECTV 101 satellite.
DO NOT MOVE THE ANTENNA UNIT WHILE IT IS SCANNING.
When the satellite is found, your programming will appear. Enjoy!
The antenna unit begins scanning when you plug in the power injector.
If you wish to start a new scan (for example, the unit gets moved and you lose reception): press the power injector’s
RESET button. This is the preferred method to start a new scan, but there are two alternate methods as well:
• Disconnect and reconnect the coax from the MAIN port on the antenna unit.
• Press the RESET button on the receiver (this option works for select receivers only, such as models D12, H24,
and HR24).
DIRECTV is a registered trademark of DIRECTV, L.L.C. KING Quest is a trademark, and KING is a registered trademark of Electronic Controlled Systems, Inc. which is not affiliated with DIRECTV, L.L.C. 21962 Rev A
Plug in power supply last.
Do not move antenna unit after
plugging in power supply as the
antenna has begun scanning.
Do not over tighten the coax connections.
Do not route the coax cable where it can be tripped on or run over by a vehicle.
Do not put sharp bends or kinks in the coax cable.
All components sold separately.
The KING Quest will not work with SWM only
receivers. For a list of compatible receivers,
see www.kingconnect.com/dtv-receivers.
