KING EXTEND GO KX3000 User manual

KX3000
MULTI-USE PORTABLE
CELLULAR SIGNAL BOOSTER
User Manual
EXTENDGO

Page 2
BEFORE YOU START
Read through this manual before installing
or operating the KING Extend Go.
If you have any questions,
call KING Customer Service at [phone].
! !
TABLE OF CONTENTS
PACKAGE CONTENTS .............................................................................. 2
OVERVIEW ................................................................................................. 3
VEHICLE ANTENNA SET 1 .................................................................... 4-5
PORTABLE/MOUNTABLE ANTENNA SET 2 ......................................... 6-9
SIGNAL BOOSTER LIGHT ...................................................................... 10
TROUBLESHOOTING .............................................................................. 11
SAFETY GUIDELINES ............................................................................. 12
SPECIFICATIONS .................................................................................... 13
WARRANTY .............................................................................................. 14
PACKAGE CONTENTS

Page 3
OVERVIEW
The KING Extend Go comes with two sets of antennas.
Set 1 can be used on a vehicle, utilizing the magnetic base for easy mounting.
Set 2 can be: • Mounted to a vehicle roof with included bracket.
• Mounted to a pole or ladder with included bracket
• Set up temporarily using the tripod.
The KING Extend Go is a cellular signal booster. It requires no additional
activation or service plan. You simply set it up or install it as desired, connect
power, and register it with your provider. It’s now ready to use!
For more information on registering your booster with your provider, see:
Sprint & T-Mobile: https://www.t-mobile.com/support/coverage/register-a-signal-booster
Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html
AT&T: https://securec45.securewebsession.com/attsignalbooster.com/
U.S. Cellular: https://www.uscellular.com/support/fcc-booster-registration
Antenna Set 2 Antenna Set 1
OR
Use outdoor antenna 2 either as a mounted antenna
or as a temporary antenna using the included tripod.
Example: Use the temporary tripod setup when at
Tripod use: Attach the tripod bracket to the antenna
with the supplied hardware.
Attach bracket to tripod using the threaded knob.
TIP
therefore only one antenna set can be used at a time.
TIP

Page 4
VEHICLE ANTENNA SET 1
Antennas connected to a booster create spheres of signal.
When these spheres overlap, interference may occur and cause the booster to
scale down its power or shut down to prevent damage.
• Near center of the roof.
• At least 12 inches away from other antennas.
• At least 12 inches away from any window
(including sun roofs.
OUTSIDE ANTENNA LOCATION
INSIDE ANTENNA LOCATION
• Side of the seat or on the dash.
• At least 18 inches but no more than 36 inches from
where the cellular device will be used.
• DO NOT MOUNT WHERE AIR BAGS WILL DEPLOY.
• Keep booster as far away from antennas as possible.
• The included bracket can be used to fasten booster in a
bracket can also be used to keep booster from sliding around.
• The booster can be oriented in any direction.
SIGNAL BOOSTER LOCATION
The cable is strong enough that it may be routed
under weather stripping and shut in most vehicle
doors without damaging the cable.
TIP
• Car/sedan: cable routed into rear side door.
• Truck: cable routed into side door.
CABLE ROUTING OPTIONS
MAXIMIZE
HORIZONTAL AND VERTICAL
ANTENNA SEPARATION
TO MINIMIZE
SIGNAL OVERLAP.

Page 5
MOUNT OUTSIDE ANTENNA
1. Clean the surface where you will place the antenna.
2. Place antenna. The magnetic base will hold the antenna in place.
MOUNT INSIDE ANTENNA
attach to the side of the antenna labeled “MOUNTING SIDE.”
2. Mount the antenna.
MAKE CONNECTIONS
1. Connect cable from outside antenna to port labeled “Outside Antenna” on
the booster.
2. Connect cable from inside antenna to port labeled “Inside Antenna” on the
booster.
3. Connect power adapter to booster.
4. Plug power adapter into vehicle power.
The booster will automatically power on when plugged in. If your booster is
working correctly, the light on the power adapter will be red, and the light on the
booster will be green.
For aluminum roofs, use the included
adhesive disk to secure the antenna in place.
TIP
or by unplugging the booster This will prevent the booster from
draining the battery in your vehicle.
POWER LAST.
Only use power adapter provided with this product.
1
1
2
2
3
3
4
4

Page 6
chosen locations, completing the setup instructions, and verifying the system
works as desired.
TIP
PORTABLE / MOUNTABLE ANTENNA SET 2
OR
• Must be completely above roof line.
• Must not exceed maximum vehicle height
restrictions.
• Locate as far from metal obstructions as possible.
• Mount directly to roof, pole or ladder using
included bracket .
OUTSIDE ANTENNA LOCATION
INSIDE ANTENNA LOCATION
• Best when used within 4-10’ of cellular device.
• Must be at least 36” from all active users.
• Keep booster as far away from antennas as possible.
• The included bracket can be used to fasten booster
on bottom of the bracket can also be used to keep
booster from sliding around.
power source.
• Booster can be oriented in any direction.
SIGNAL BOOSTER LOCATION
Ladder
Mount
Roof
Mount
Antennas connected to a booster create spheres of signal.
When these spheres overlap, interference may occur and cause the booster to
scale down its power or shut down to prevent damage.
MAXIMIZE
HORIZONTAL AND VERTICAL
ANTENNA SEPARATION
TO MINIMIZE
SIGNAL OVERLAP.

Page 7
OUTSIDE ANTENNA MOUNTING OPTIONS

Page 8
1. Fasten the outside antenna to the mounting bracket with the supplied
2. Connect the separate cable to the antenna (LARGE CONNECTOR
3. Apply roof-compatible sealant around the areas where the bracket fasteners
will penetrate the roof.
4. Fasten bracket to roof. Make sure fastener holes and fastener heads are
properly sealed.
INSTALLATION
It is up to the installer to determine the best component locations and fasteners.
AVOID SHARP BENDS WHEN ROUTING COAX!

Page 9
If using the included booster
mounting bracket, remove
the booster from the bracket.
Fasten bracket to wall, then
snap booster back into bracket.
TIP
5. Route the cable to where it will enter the vehicle.
6. Drill an appropriately sized hole and feed the cable into the vehicle.
Fasten cable to roof every 12-18 inches.
8. Inside, place the booster in desired location or install the booster to a wall.
Connect cable to the booster.
9. Connect inside antenna cable to booster. Place inside antenna in position
as far from outside antenna and booster as possible.
10. Plug booster into power source.
Make sure to avoid any cabling, pipes, etc. that may be
damaged by drilling.

Page 10
SIGNAL BOOSTER LIGHT
SOLID GREEN
This indicates your booster is functioning properly and there are no issues
with installation.
BLINKING RED, THEN SOLID GREEN
This indicates one or more of the booster bands has reduced power due to
a minor feedback loop condition called oscillation. This is a built-in safety
feature to prevent harmful interference with a nearby cell tower. If you are
already experiencing the desired signal boost, then no further adjustments
are necessary. If you are not experiencing the desired boost in coverage,
then refer to the troubleshooting section on the next page.
SOLID RED
nearby cell tower. Refer to the troubleshooting section on the next page.
LIGHT OFF
antenna set 1 and the cigarette power adapter, make sure it is turned on and
the light is red.
After making all connections, the signal booster will automatically power on and
the signal booster light will be green. If using the power adapter with antenna set
1, the power adapter light will be red.
TIP

Page 11
TROUBLESHOOTING
Need help? KING Customer Service: [phone]
FIXING BLINKING OR SOLID RED BOOSTER LIGHT ISSUES
This section is only applicable if the signal booster light is red or blinking
red and you are not experiencing the desired signal boost.
1. Unplug the signal booster’s power supply/power adapter.
2. Relocate the inside and outside antennas further away from each other.
The objective is to increase the separation between them so their spheres
of signal will not overlap and cause interference as discussed on page 4.
3. Plug power supply/power adapter back in.
4. Monitor the indicator light on your signal booster. If after a few seconds of
“power on”, a solid blinking red light appears, repeat steps 1 through 3.
Increase the separation distance until the condition is corrected and/or
desired coverage area is achieved.
TIP
Increasing vertical separation between antennas
typically improves isolation better than increasing
horizontal separation.

Page 12
SAFETY GUIDELINES
Use only the power supply and power adapter provided with this product.
Use of any other power supply/adapters may damage your equipment.
Connecting the signal booster directly to the cell phone with use of an adapter
will damage the cell phone.
RF Safety Warning: Any antenna used with this device must be located at least 8
inches from all persons.
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless
provider and have your provider’s consent. Most wireless providers consent
to the use of signal boosters. Some providers may not consent to the use of
this device on their network. If you are unsure, contact your provider.
You MUST operate this device with approved antennas and cables as
MUST be installed at least 8 inches
from any person.
You MUST cease operating this device immediately if requested by the FCC
or licensed service provider.
WARNING: E911 location information may not be provided or may be
inaccurate for calls served by using this device.

Page 13
Each signal booster is individually tested and factory set to ensure FCC
compliance. The signal booster cannot be adjusted without factory
reprogramming or disabling the hardware. The signal booster will amplify, but not
alter incoming and outgoing signals in order to increase coverage of authorized
will reduce gain until a signal is detected. If a detected signal is too high in a
frequency band, or if the signal booster detects an oscillation, the signal booster
the signal booster will automatically resume normal operation after a minimum
momentarily removing power from the signal booster. Noise power, gain, and
linearity are maintained by the signal booster’s microprocessor.
This device complies with Part 15 of FCC rules. Operation is subject to two
device must accept any interference received, including interference that may
weBoost could void the authority to operate this equipment.
SPECIFICATIONS

Page 14
LIMITED WARRANTY
8147. You must contact KING before the warranty period expires. The customer must supply proof
cannot supply proof of purchase, warranty period shall start 30 days after date of manufacture.
according to the warranty policy outlined below.
Warranty cases may be resolved by returning the product directly to the reseller
with a dated proof of purchase. Signal Boosters may also be returned directly to
the manufacturer at the consumer’s expense, with a dated proof of purchase and a
shall, at their option, either repair or replace the product.
This warranty does not apply to any Signal Boosters determined by KING or Wilson to
have been subjected to misuse, abuse, neglect, or mishandling that alters or damages
physical or electronic properties. Replacement products may include refurbished Wilson
In no event shall KING or Wilson be liable for any indirect, incidental, or consequential damages
from the sale or use of the product. This disclaimer applies both during and after the term of this
warranty.
KING disclaims liability for any implied warranties, including implied warranties of “merchantability”
state to state. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
DISCLAIMER: The information provided is believed to be complete and accurate. However, no
responsibility is assumed by KING or Wilson for any business or personal losses arising from its
use, or for any infringements of patents or other rights of third parties that may result from its use.

Simply better, by design.
™
23697 Rev A © 2020 KING
For patents go to: weboost.com/us/patents.
NOT AFFILIATED WITH WILSON ANTENNA
All trademarks are the sole property of their respective owners.
