4K DisplayPort over HDBaseT Extender
UVX-DP-TP-100
Distributes uncompressed 4K @30 Hz UHD video,
audio, power, RS-232, and USB 2.0 up to 330 feet
(100 m) over a single CAT6a/7 cable.

877-877-2269 | blackbox.com
Page 2
FCC and IC RFI Statements/NOM Statement
FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY
CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if
not installed and used properly, that is, in strict accordance with the manufac-
turer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC
rules, which are designed to provide reasonable protection against such
interference when the equipment is operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference,
in which case the user at his own expense will be required to take whatever
measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emis-
sion from digital apparatus set out in the Radio Interference Regulation
of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de classe A prescrites
dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.
Normas Oficiales Mexicanas (NOM)
Electrical Safety Statement
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas
antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas
para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones
de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.

877-877-2269 | blackbox.com Page 3
NOM Statement
5. El aparato eléctrico no deberá ser usado cerca del agua — por ejemplo,
cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio— El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe
colocar en libreros o gabinetes que impidan el flujo de aire por los orificios
de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo
del tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.

877-877-2269 | blackbox.com
Page 4
NOM Statement
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

877-877-2269 | blackbox.com Page 5
Trademarks Used in this Manual
TRADEMARKS USED IN THIS MANUAL
Black Box and the Double Diamond logo are registered trademarks of
BB Technologies, Inc.
Blu-ray™is a trademark of Blu-ray Disc Association.
Any other trademarks mentioned in this manual are acknowledged to be
the property of the trademark owners.
Important Safety Instructions
1. Do not expose this apparatus to rain, moisture, dripping or splashing water
and do not place objects filled with liquids, such as vases, on the apparatus.
2. Do not install or place this unit in a bookcase, built-in cabinet or in another
confined space. Make sure the unit is well ventilated.
3. To prevent risk of electric shock or fire hazard caused by overheating, do not
obstruct the unit’s ventilation openings with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
5. Do not place sources of flames, such as lighted candles, on the unit.
6. Clean this apparatus only with a dry cloth.
7. Unplug this apparatus during lightning storms or when unused for long
periods of time.
8. Protect the power cord from being walked on or pinched particularly at
plugs.
9. Only use attachments/accessories specified by the manufacturer.
10. Refer all servicing to qualified service personnel.
Disclaimer
Black Box Network Services shall not be liable for damages of any kind,
including, but not limited to, punitive, consequential or cost of cover damages,
resulting from any errors in the product information or specifications set forth
in this document and Black Box Network Services may revise this document at
any time without notice.

877-877-2269 | blackbox.com
Page 6
Table of Contents
Table of Contents
1. Specifications........................................................................................ 7
2. Overview .............................................................................................. 9
2.1 Introduction ............................................................................... 9
2.2 Features...................................................................................... 9
2.3 What's Included ....................................................................... 10
2.4 Hardware Description.............................................................. 10
3. Connection and Installation............................................................... 12

877-877-2269 | blackbox.com Page 7
Chapter 1: Specifications
1. Specifications
Transmitter
Connectors (1) 12-VDC barrel connector,
(1) HDBaseT OUT,
(1) 3-pin Phoenix connector,
(1) DisplayPort IN,
(1) Audio IN,
(1) Audio OUT,
(1) USB Type B host connector
Input
Resolution
Support
Up to 3840 x 2160 @30 Hz (UHD)
Maximum
Data Rate
10.2 Gbps
Maximum
Distance
Via CAT6a/7 cables:
Up to 328 feet (100 m) at 3840 x 2160 @30 Hz, 4:2:0,
or 1080p @60 Hz output resolution;
Via CAT5e/6 cables:
Up to 224 feet (70 m) at 3840 x 2160 @30 Hz;
Up to 328 feet (100 m) at 1080p @30 Hz resolution
Receiver
Connectors (1) 12-VDC barrel connector,
(1) HDBaseT IN,
(1) 3-pin Phoenix connector,
(1) DisplayPort OUT,
(1) Audio IN,
(1) Audio OUT,
(2) USB Type A device connectors
Output
Resolution
Support
UHD30: 3840 x 2160 @30 Hz;
FHD: 1920 x 1080 @60 Hz;
HD: 1280 x 720 @60 Hz;
WUXGA: 1920 x 1200 @60 Hz;
WXGA: 1280 x 800 @60 Hz

877-877-2269 | blackbox.com
Page 8
Chapter 1: Specifications
1. Specifications (continued)
Receiver (continued)
Maximum
Distance
Via CAT6a/7 cables:
Up to 328 feet (100 m) at 3840 x 2160 @30 Hz, 4:2:0,
or 1080p @60 Hz output resolution;
Via CAT5e/6 cables:
Up to 224 feet (70 m) at 3840 x 2160 @30 Hz;
Up to 328 feet (100 m) at 1080p @30 Hz resolution
General (Transmitter and Receiver)
ESD Protection Human-body model:
±8 kV (air-gap discharge)/
±4 kV (contact discharge)
Operating
Temperature
32 to 113° F (0 to 45° C)
Storage
Temperature
-4 to +158° F (-20 to +70° C)
Humidity 10 to 90%, noncondensing
Power Input 100–240 VAC, 50/60 Hz, 1.5 A
Input Connector
Type
IEC320, C14
Power Output Each unit: (1) 12-VDC, 2-A power supply
Consumption 14.2 W (max.)
Power Supply
Cord Length
6 ft. (1.8 m)
Dimensions Each unit: 0.99"H x 7.91"W x 3.95"D
(2.51 x 20.09 x 10.03 cm)
Weight Each unit: 1.1 lb. (0.5 kg)

877-877-2269 | blackbox.com Page 9
Chapter 2: Overview
2. Overview
2.1 Introduction
The UVX-DP-TP-100 is a 4K DisplayPort over HDBaseT Extender with USB 2.0
and audio passthrough. It distributes uncompressed 4K @30 Hz UHD video,
audio, power, RS-232, and USB 2.0 together up to 330 feet (100 m) over a sin-
gle CAT6a/7 cable. The extender has a transmitter unit and a receiver unit.
With USB 2.0 passthrough, the extender enables users to control or monitor
a remote server from a harsh environment, or operate a physically inaccessible
PC, server, or workstation remotely. Bidirectional audio passthrough enables
audio distribution in both directions.
The extender units have 48 V PoH and only need one power supply at the
transmitter end to power both transmitter and receiver units. Secure the
transmitter's 12 V power supply with a screw-in connector to prevent the power
from being accidentally disconnected. Power LEDs on both units light when
power is applied to the unit. Signal status LEDs show connections between
devices.
2.2 Features
• Via CAT6a/7 cables, the extenders support 4K @30 Hz up to 330 feet
(100 meters) and 1080p @60 Hz up to 330 feet (100 meters).
• Via CAT5e/6 cables, the extenders support 4K x 2K @30 Hz output
up to 224 feet (70 meters).
• Supports DisplayPort 1.2 up to 4K @30 Hz.
• Provides USB 2.0 passthorugh over HDBaseT, with USB-HOST built-in TX and
USB-DEVICE built-in RX.
• Supports bidirectional stereo line audio passthrough over HDBaseT.
• Provides RS-232 and EDID passthrough over HDBaseT
• All connectors are on one side of each unit for easy installation.
2.3 What's Included
Your package should include the following items. If anything is missing
or damaged, contact Black Box Technical Support at 877-877-2269
or [e-mail].
• (1) DisplayPort Extender Transmitter
• (1) DisplayPort Extender Receiver
• (1) 12-VDC, 2-A power supply with US, EU, UK, and AU power clips
• (2) 3.5-mm, 2-pin male Phoenix connectors

877-877-2269 | blackbox.com
Page 10
Chapter 2: Overview
• (2) mounting brackets
• This user manual
2.4 Hardware Description
Figures 2-1 and 2-2 show the front and back panels of the receiver. Tables 2-1
and 2-2 describe their components.
1 2 3 4 5
Transmitter
(bottom
photo)
Receiver
(top photo)
1 2 3 4 5
Figure 2-1. Receiver and Transmitter front panels.
6 7 8 9 10 11 12
Transmitter
(bottom
photo)
Receiver
(top photo)
13 14 15 16 17 18 19
Figure 2-2. Receiver and Transmitter back panels.

877-877-2269 | blackbox.com Page 11
Chapter 2: Overview
Table 2-1. Transmitter front- and back-panel components.
Number Component Description
1Mode Switches the Mode for the RS-232 port.
Normal: RS-232 HDBaseT passthrough.
Update: RS-232 firmware update.
2Power LED ON: The transmitter is powered on.
OFF: The transmitter is powered off.
3Status LED Blinking: The transmitter is working properly.
OFF: The transmitter is not working properly.
4HDCP LED ON: HDCP video is being transmitted.
Flashing quickly: Non-HDCP video is being
transmitted.
OFF: No audio and video signal.
5Link LED ON: HDBaseT link is normal.
OFF/Blinking: No HDBaseT link.
6Barrel connector. 12-VDC power input
7HDBaseT OUT Connects to HDBaseT IN port of receiver
83-pin Phoenix
connector
RS-232 passthrough or firmware update
9DP IN Connects to a DisplayPort source
10 Audio IN Connects to an audio source such as a PC
11 Audio OUT Connects to an audio device such as an
amplifier.
12 USB Type B
connector
Connects to a device to be controlled, such as
a server, computer, etc.

877-877-2269 | blackbox.com
Page 12
Chapter 2: Overview
Table 2-2. Receiver front- and back-panel components.
Number Component Description
1Mode Switches the Mode for the RS-232 port.
Normal: RS-232 HDBaseT passthrough.
Update: RS-232 firmware update.
2Power LED ON: The receiver is powered on.
OFF: The receiver is powered off.
3Status LED Blinking: The receiver is working properly.
OFF: The receiver is not working properly.
4HDCP LED ON: HDCP video is being received.
Flashing quickly: Non-HDCP video is being
received.
OFF: No audio and video signal.
5Link LED ON: HDBaseT link is normal.
OFF/Blinking: No HDBaseT link.
13 Barrel connector. 12-VDC power input
14 HDBT IN Connects to HDBaseT OUT port of HDBaseT
transmitter.
15 3-pin Phoenix
connector
RS-232 passthrough or firmware update
16 DP OUT Connects to a DisplayPort display device
17 Audio IN Connects to an audio source such as a PC
18 Audio OUT Connects to an audio device such as an
earphone.
19 (2) USB Type A
connectors
Connect to USB devices (mouse, keyboard,
USB disk, etc.)

877-877-2269 | blackbox.com Page 13
Chapter 3: Connnection and Installation
3. Connection and Installation
1. Using quality DisplayPort cables, connect a DisplayPort source (Blu-ray™,
games console, satellite/cable TV, media server, etc.) to the DisplayPort IN
port of the transmitter.
NOTE: Make sure that the source and display are 4K compatible if you are
attempting to transmit an Ultra HD signal—check that all devices are
correctly configured for input/output compatibility.
2. Connect a good quality, well-terminated CAT5e or higher cable between
the HDBaseT OUT of the transmitter to the HDBaseT IN of the receiver.
NOTE: The maximum transmission distances for the extenders are 230 feet
(70 meters) with CAT5e/CAT6 or 328 feet (100 meters) with
CAT6a/CAT7. This value applies to perfect transmission conditions—
including straight cable runs with no electrical interference, bends, kinks,
patch panels, or wall outlets.
If any of the above is a factor in your installation, transmission range may be
affected—avoid this where possible.
3. Connect the DisplayPort display device (LED/LCD display or projector) to the
DP OUT of the receiver.
NOTE: We strongly recommend using the supplied mounting brackets to secure
the receiver to a flat surface behind/near the display device.
Sudden movement of these devices could lead to loss of picture/sound
if connections loosen or strain, resulting in unnecessary service call-backs.
4. Connect the included 12-VDC power supply to the transmitter and power it
on. The PoH function carries power along the length of the cable one way to
power the receiver. No additional power supply is required at the display end
of the cable run.

877-877-2269 | blackbox.com
Page 14
Chapter 3: Connnection and Installation
PC
USB
Audio
DP IN
CATx cable
USB
Audio
DP OUT
Monitor
4K DisplayPort over
HDBaseT Extender
Transmitter
(UVX-DP-TP-100)
4K DisplayPort over
HDBaseT Extender
Receiver
(UVX-DP-TP-100)
Earphone
Figure 3-1. Installation diagram.

877-877-2269 | blackbox.com Page 15
NOTES

Chapter
877-877-2269 | blackbox.com
Great tech support is just 60 seconds away
at 877-877-2269 or blackbox.com.
Black Box Tech Support: FREE! Live. 24/7.
Tech support the
way it should be.
uvx-dp-tp-100_user_rev1
About Black Box
Black Box provides an extensive range of networking and infrastructure
products. You’ll find everything from cabinets and racks and power and surge
protection products to media converters and Ethernet switches all supported by
free, live 24/7 Tech support available in 60 seconds or less.
© Copyright 2016. Black Box Corporation. All rights reserved. Black Box®and the Double Diamond
logo are registered trademarks of BB Technologies, Inc. Any third-party trademarks appearing in
this white paper are acknowledged to be the property of their respective owners.
