Kingray FL3BPMH User manual

INSTALLATION MANUAL
FL3BPMH - A FULLY SHIELDED
BANDPASS FILTER AND TRIPLEXER
Ideal for broadband digital/analogue
applications
Drawing No: 41492-3
Part No: 310188
4
INSTALLATION cONTINUED – INPUT OPTIONS
By using the 2 switches on the PCB a number of input options are available to suit most requirements.
Standard Communications PTY. LTD. warrants this
Kingray product to be free from defects in material
and workmanship for a period of 3 years from the
date of installation and reserves the right to void
warranty if unit was misused, improperly installed or
damaged by claimant.
www.gme.net.au
SYDNEY
P: [phone]
F: [phone]
E: [email protected]
MELBOURNE
P: [phone]
F: [phone]
E: [email protected]
BRISBANE
P: [phone]
F: [phone]
E: [email protected]
ADELAIDE
P: [phone]
F: [phone]
E: [email protected]
PERTH
P: [phone]
F: [phone]
E: [email protected]
AUCKLAND
P: [phone]
F: [phone]
E: [email protected]
A Division of Standard Communications PTY. LTD.
Head Office: Locked Bag 2086, North Ryde N.S.W. 1670 P: [phone], F: [phone]
WARRANTY
Optimised for both Digital and
Analogue TV Signal Amplification
Thank you for selecting an Australian designed Bandpass Filter and Triplexer.
Mount with plastic securing strap on to mast or
mount to a wall with the four pre-drilled holes.
FM Trap
For maximum low band attenuation turn
control anti-clockwise.
Ensure weatherproof strips
remain in place.
Please see diagrams below for options.

SPEcIFIcATIONS INSTALLATION
3
The FL3BPMH is a passive bandpass filter/combiner
with 1,2 and/or 3 inputs. It is designed to pass
standard TV bands with an insertion loss of
< 2 dB, whilst rejecting unwanted out of band
signals, including AM, 27 MHz Radio, FM
(Switchable), paging, police radio, 477 MHz CB
Radio and mobile phones CDMA and GSM. There is
also a -12 dB low band attenuator included.
The FL3BPMH may also be used backwards as a low
insertion loss band separator.
Frequency Range VLF 44 - 108 MHz
VHF 174 - 230 MHz
UHF 520 - 820 MHz
FM Filter -30 dB @ 88 - 108 MHz
Pager Filter -30 dB @ 148 MHz
-20 dB @ 158 MHz (NZ)
Insertion Loss < 2 dB 477 MHz CB -40 dB
AM + 27 MHz -40 dB Mobile Phones -20 dB @ 860 MHz
-30 dB @ 940 MHz
Low Band
Attenuator
-12 dB max
2
FM TRAP OPTIONS
The FL3BPMH is designed to fit in the MHB02 for
outdoor use prior to a masthead amplifier or it can
be screwed to a wall in the plastic housing via the 4
pre-drilled holes.The unit can also be removed
from the plastic housing and mounted using the
KB001 bracket.
KB001 used for optional mounting of
FL3BPMH.
1. 2.
The diecast housing can pivot to
easily access Connectors.
Reversed KB001 for optional mounting
of FL3BPMH.
FM trap on FM trap off
The lid may be inserted into the plastic outer cover
whilst installing.
