Kingspan Aeromax Plus Assembly instructions

The Ultimate Air Source Heat Pump Package
Renewables
Homeowners Guide

The Ultimate Air Source Heat Pump Package
To optimise the entire range of benefits that Aeromax Plus heat
pumps have to offer, we provide the domestic and commercial
markets with a complete air source energy package that is
custom-made to suit the individual needs of each application.
This package is completely unique and includes the highest level
of customer support from initial advice, professional planning and
design, through to installation, technical and after sales support.
Aeromax & Aerocyl – The Perfect Package
Albion Aerocyl range offers Heat Pump Only cylinders and
combined Heat Pump & Solar Input cylinders, which have been
designed specifically for use in conjunction with a heat pump as the
main or additonal source of energy. Featuring a purpose-designed
coil, which allows maximum heat transfer of renewable energy into
the stored water, the cylinders are suitable for use with a wide range
of heat pumps available in the UK and are the perfect partners for
the Aeromax Plus Air Source Heat Pumps.
•Mains pressure hot water providing powerful showers.
•The cylinders high flow rates are ideal for multiple bathrooms
allowing baths to fill very quickly.
•Fast reheat and high efficiency makes hot water always available.
•Very well insulated resulting in low heat loss.
•Economical to run.
•Attractive white glossy finish case.
Usability
The ease of use of the Aeromax Plus provides homeowners with
confidence that their heating needs are being met efficiently.
Indeed they will notice very little difference between the use of this
renewable technology compared with traditional gas or oil boilers.
The user controls provided with the systems operate in the same
way to those found on a traditional domestic heating.
The main difference the homeowner will notice is in the savings on
their energy bills and in the reduction of their CO2footprint.
Combining the Best of Both Worlds
The package is suitable for both new and existing properties.
In new build homes Aeromax Plus will supply the home heating
and domestic hot water load. When fitting into existing dwellings
the present boiler can be retained as additional heating capacity,
making Aeromax the Ultimate Air Source Heat Pump Package.
The use of an Aeromax Plus Air Source Heat Pump can also
be combined with solar thermal water heating. In such systems
normally Aeromax will provide space heating whereas domestic
hot water will be heated by solar collectors, such as Thermomax
vacuum tube panels.
4
Solar thermal panels
Central heating radiators
Underfloor heating
Aeromax Plus heat pump
Domestic hot water
Domestic hot water cylinder
The Ultimate Air Source Heat Pump Package
To optimise the entire range of benefits that Aeromax Plus heat
pumps have to offer, we provide the domestic and commercial
markets with a complete air source energy package that is
custom-made to suit the individual needs of each application.
This package is completely unique and includes the highest level
of customer support from initial advice, professional planning and
design, through to installation, technical and after sales support.
Aeromax & Aerocyl – The Perfect Package
Albion Aerocyl range offers Heat Pump Only cylinders and
combined Heat Pump & Solar Input cylinders, which have been
designed specifically for use in conjunction with a heat pump as the
main or additonal source of energy. Featuring a purpose-designed
coil, which allows maximum heat transfer of renewable energy into
the stored water, the cylinders are suitable for use with a wide range
of heat pumps available in the UK and are the perfect partners for
the Aeromax Plus Air Source Heat Pumps.
•Mains pressure hot water providing powerful showers.
•The cylinders high flow rates are ideal for multiple bathrooms
allowing baths to fill very quickly.
•Fast reheat and high efficiency makes hot water always available.
•Very well insulated resulting in low heat loss.
•Economical to run.
•Attractive white glossy finish case.
Usability
The ease of use of the Aeromax Plus provides homeowners with
confidence that their heating needs are being met efficiently.
Indeed they will notice very little difference between the use of this
renewable technology compared with traditional gas or oil boilers.
The user controls provided with the systems operate in the same
way to those found on a traditional domestic heating.
The main difference the homeowner will notice is in the savings on
their energy bills and in the reduction of their CO2footprint.
Combining the Best of Both Worlds
The package is suitable for both new and existing properties.
In new build homes Aeromax Plus will supply the home heating
and domestic hot water load. When fitting into existing dwellings
the present boiler can be retained as additional heating capacity,
making Aeromax the Ultimate Air Source Heat Pump Package.
The use of an Aeromax Plus Air Source Heat Pump can also
be combined with solar thermal water heating. In such systems
normally Aeromax will provide space heating whereas domestic
hot water will be heated by solar collectors, such as Thermomax
vacuum tube panels.
4
Solar thermal panels
Central heating radiators
Underfloor heating
Aeromax Plus heat pump
Domestic hot water
Domestic hot water cylinder
A warm welcome
Congratulations!
Your home is tted with a unique renewable heating technology, allowing you to benet from lower running costs and a
more even temperature throughout your home.
An air source heat pump collects and utilises thermal energy from the outside air to heat the home and provide domestic hot
water. It does this in the same way that a fridge extracts heat from its inside. It can extract heat from the air even when the
outside temperature is as low as -20°C. The heat generated can be used to warm water for radiators, underoor heating
systems or provide domestic hot water in your home.
The process is simple, eective and entirely renewable and has been developed specically for use in the UK and Irish
domestic housing markets.
In this guide we’ll explain how Aeromax generates heat for your home and how to use your system in the most ecient way.
Your Aeromax Plus Air Source Heat Pump
Your Aeromax Plus air source heat pump is designed to heat your home and to provide domestic hot water (DHW). Normally
your installer will have ensured that your heat pump has sucient heating output to provide these services without any
supplementary heating being required.
You’ll nd your Aeromax Plus unit close to a wall outside your property. It can also be mounted o the ground.

How does it work?
Aeromax Plus Air Source Heat Pumps provide thermodynamic heating by means of a vapour compression cycle. In the same
way that a fridge uses refrigerant to extract heat from the inside to keep the food cool, air source heat pump extracts heat
from the outside air, and uses it to heat the home through radiators, underoor system or provide domestic hot water. It can
extract heat from the air even when the outside temperature is as low as -20°C.
Every air source heat pump has four
main parts:
1. evaporator
2. compressor
3. condenser (heat exchanger)
4. expansion device
Although Aeromax Plus is powered by electricity, when it is installed and designed correctly can often result in the system
costing less to run than systems heated by oil, LPG, electricity or coal. Your heating costs will depend on how you use your
heating or hot water and the temperature of your radiators. Aeromax Plus is cost-eective to use all year round, but you can
ensure it is at its most ecient by running your radiators or underoor heating at lower temperatures.
How do I use it?
The Aeromax Plus heat pump is designed to operate with a standard heating time switch and programmable room
thermostat, providing space heating or DHW according to demand. The unit has two modes of operation: one for space
heating through underoor heating or radiators adjustable between 35°C and 55°C and a second for DHW preset at 60°C.
We recommend that you review the electricity taris from all suppliers in your area and select one that will give you the
optimum economy in relation to your lifestyle and heating demand. Timings appropriate to your heating and hot water
demand and to the selected tari should be programmed into the controller.
3
2
1
4
Heat
Pump
Internal Heating
Outside Air
(1) The evaporator collects heat from
the outside air, which is then drawn
into the unit by the fan through the
evaporator ns and expelled through
the front grille. The evaporator has
liquid refrigerant passing through
it, which is at a considerably lower
temperature than the outside air,
therefore the air gives up its heat to
the refrigerant, which then vaporises.
(2) This preheated vapour now
travels to the compressor where it
is compressed and upgraded to a
much higher temperature.
(3) The hot vapour now enters the
condenser where it is surrounded
by water from the heating system.
The heat is given up to the cooler
water and the now cooler refrigerant
returns to its former liquid state but
still under high pressure from the
compressor.
(4) This high pressure is then released
by passing the liquid through the
expansion device and from there it
returns to the evaporator and the
cycle starts again.

Heating and Domestic Hot Water system controls
Your heating system is controlled by a programmable room thermostat that allows you to choose when to have your heating
on and what temperature it should be when it is on. A time switch allows you to choose when you want to make hot water.
The programmable room thermostat controls the temperature of the main living area while thermostatic radiator valves
control the temperatures of the radiators in other rooms.
The Aeromax Plus radiator system works at a lower surface temperature than traditional central heating. This means that your
radiators will take a little longer to warm up your home but will give you a more even comfortable temperature.
Normally your installer will have ensured that your radiators are correctly sized for operation with a heat pump. The heat
pump supplies Domestic Hot Water at between 50ºC - 55ºC. This is stored in the special hot water cylinder provided with your
heat pump to ensure that you always have hot water on tap. The temperature of the stored hot water is controlled by the
cylinder thermostat and you should set this at a level which gives you hot water at a temperature which suits you.
Kingspan recommend that the hot water cylinder thermostat is set between 50/55 degrees C. This will save energy and limit
any unnecessary cycling of the heat pump. The cylinder immersion heater should be set at 60ºC and used to heat the stored
hot water to 60ºc once a week (see hot water table below for recommended timings).
Setting your heating
The programmable room thermostat lets you choose what times you want the heating to be on, and what temperature it
should reach while it is on. It will allow you to select dierent temperatures in your home at dierent times of the day (and
days of the week) to meet your particular needs. We recommend that you set your hot water time switch to heat the hot water
for 1½ to 2 hours before you require it rst thing in the morning, or later in the day. You should set the home heating to come
on after the hot water.
The hot water system and the radiator system cannot run at the same time. If the system requests hot water, the radiators will
turn o until the water heats up.
Typical winter settings for the programmable room thermostat and hot water time switch are illustrated below.
Heating
Weekdays (Mon-Fri) Weekend (Sat-Sun)
Event Time Temp. °C Event Time Temp. °C
1 06.00 20 1 07:00 20
2 09.00 15 2 10.00 20
3 11:30 20 3 11:30 20
4 13:30 15 4 13:30 20
5 16:30 21 5 16:30 21
6 22:30 18 6 22:30 18
During severe weather conditions where outside temperatures fall below zero it may be necessary to leave the heating
controls on for longer periods when utilising your air source heat pump. This is due to the lower ow temperatures used in
this style of system, which is dierent to that of a fossil fuel boiler.
Hot Water
Event No Hot water Mon - Fri Sat - Sun
1 1st ON 03:00 05:00
2 1st OFF 05.00 06:30*
3 2nd ON 15:00 15:00
4 2nd OFF 16:30 16:30
*Immersion heater: Please use your immersion heater for 1 hour per week after the suggested time indicated. It may be
necessary to utilise your hot water cylinder immersion heater more often in sever winter conditions.

Thermostatic radiator valves (TRV’s)
Some of your radiators have thermostatic valves which allow you to vary the temperature in dierent areas of your home.
You may, for example, prefer to keep your bedrooms cooler than your living room. With underoor heating, the house
temperature is normally controlled by the room thermostat alone. The Aeromax Plus system typically requires at least one
radiator (usually located in the same location as the room thermostat) to remain “open loop” with no thermostatic radiator
valve tted.
Automatic defrost
When moist air comes into contact with the Aeromax Plus’s evaporator, it will ice up in much the same way as ice builds up in
your refrigerator. Defrosting the evaporator is a normal part of the Aeromax Plus operation in colder weather and normally
takes place for about 4 minutes per hour. When defrosting, the fan will stop and water vapour may be seen rising from the
heat exchanger. This is normal and is not a cause for concern.
Safety precautions
1. Do not stand on the heat pump for any reason.
2. Do not allow children to poke sticks or other objects through the front grille into the fan as this could cause
injury and will damage the fan.
3. Outer panels should only be removed by a qualied service engineer.
Servicing
We recommend that an annual service of the Aeromax Plus air source heat pump is carried out, should you require further
details on service packages please contact us. You are advised to check occasionally that there is no debris around the heat
pump which may get drawn into, or obstruct, the fan unit.
Trouble shooting
The diagnostic indicator for the air source heat pump will be located indoors in a visible place. The green lights shows that
the power is on to the heat pump. The red alarm light will ash in the event of a problem. If this occurs count the number of
ashes between pauses and use the fault code table to determine the fault.

System test
The error code can be identied from the ashing LED using the following table. In the case of more than one error, the error
with the highest priority will be displayed until it is resolved. In the case of an error the LED ashes a numbers times equal
to the error code at a frequency of 1Hz and then remains o again for 6 seconds. If the error code has 2 digits, the ashing is
interrupted for 2 seconds between the rst and second digits.
Example: error 23: 2 ashes of 1 second each. O for 2 seconds. 3 ashes of 1 second each. O for 6 seconds. The cycle repeats
until the LED turns o because the problem is resolved or if an error with higher priority occurs.
To reset the unit after an error has been cleared turn o the mains supply for 10 seconds and turn on again.
Fault Code Code Description
3 Enter Water Temperature Thermistor (EWT) Failure/Out of Range
4 Actual Refrigerant Temperature Thermistor BPHE (TR) Failure/Out of Range
5 Air Thermistor of GMC
6 Loss communication to NUI control
7 NUI control Room Thermistor
8 Unit Capacity Mismatch
9 Flow Switch error / Water Pump
10 EEProm Corrupt
11 Air temperature higher than Stop Heat
12 Air temperature lower than Stop Cool
13 Loss Communication to RS485 (system conguration type 6)
14 Loss of Signal From inverter board / High Temperature Release (Thermostat on compressor: 120° ± 4° C)
15 Exit water Temperature Thermistor (LWT) Failure/Out of Range
17 Inverter Air Thermistor (TO) Failure/Out of Range
18 G-Tr inverter short circuit protection
20 Compressor position Detection Circuit error
21 Inverter Current Sensor error
22 Heat Exchanger Sensors (TE) / (TS) Failure/Out of Range
23 Discharge Temperature Sensor (TD) (TD > 100° ± 4° C)
24 Outdoor Fan motor error
26 Other inverter board error
27 Compressor Lock
28 Discharge Temperature error Failure/Out of Range
29 Compressor Breakdown
30 Other inverter board error

Guarantee
During the period of guarantee we will, at our option, repair or replace your Aeromax Plus heat pump free of charge where it suers a
mechanical or electrical breakdown resulting from defective workmanship or materials, subject to the following conditions and exclusions:
1. The guarantee period commences from the date of commissioning. This must be recorded by the installer on the commissioning sheet.
Without proof of purchase, i.e. an invoice or completed commissioning sheet, the guarantee period will be taken to commence from the
date of manufacture, as detailed by the serial number on the appliance data plate.
2. The guarantee period for your heat pump is 2 years.
3. If the heating system fails, you should call the installer who will identify whether the problem lies with the heat pump or some other
part of the system. They may be able to resolve the problem on the spot. If the problem is found to lie with the heat pump, they should
telephone our Service Department on 0845 260 7260 in the UK and Northern Ireland or 1800 812718 for ROI. If the problem cannot be
solved over the phone, they will arrange a visit by an authorised Aeromax Plus service agent to inspect and repair or, where in our sole
opinion repair is not economic, arrange to replace the heat pump.
4. Your Aeromax Plus heat pump must not be removed from its place of installation at your property without our prior consent.
5. We reserve the right to charge a call-out fee:
a. Where the problem is found not to lie with the heat pump.
b. Failure to notify us of cancellation of an agreed appointment prior to our engineer’s visit.
c. The heat pump is outside the guarantee period.
6. The guarantee does not cover other costs or expenses caused or arising as a result of the failure of your heat pump.
7. The guarantee does not apply to any costs incurred during delays in xing reported faults.
8. The guarantee applies to Aeromax Plus heat pumps installed in the UK and the Republic of Ireland.
The Guarantee does not apply if:
1. The heat pump and associated equipment has been incorrectly sized for the application.
2. The heat pump and associated equipment has not been installed and commissioned in complete accordance with the procedures dened
in the Aeromax Plus Installation Manual.
3. The heat pump and associated equipment has been worked upon or has been adjusted by anyone other than a person authorized to do
so by Kingspan Renewables.
4. The heat pump and associated equipment has suered frost, ood or malicious damage.
IMPORTANT: Kingspan Renewables guarantee is subject to the homeowner registering with the Kingspan Renewables Customer Service
Department within 30 days of commissioning / occupation if new build to conrm:
 • ProductMake/Model
 • Detailsofinstallation
Please complete the registration card provided with the unit and return to:
CustomerServiceDepartment,KingspanRenewables,TadmanStreet,Wakeeld,WF15QU,UK
For product registration or further information we can be we can be contacted in the following ways.
Email. [email protected]
Tel: [phone] (UK)
Tel: [phone] (ROI)
If you do not register the Product then Kingspan Renewables Guarantee is limited to twelve months from the date of commissioning.
The product must be maintained by a competent person* within 12 months after commissioning, and thereafter at 12 monthly intervals.
Kingspan Renewables reserves the right to seek evidence of this maintenance to our reasonable satisfaction before approving any
guarantee servicing / repairs.
Please note: this guarantee excludes all pipework and connections and excludes any ancillary equipment that may be connected to the
product. (Ex: descaling equipment, water softeners).
*A competent person is a business that has been adjudged by an accredited body (examples of which are NICEIC and BPEC) to be
suciently competent to self-certify that its work complies with Document (G) Part 3 of the Building Regulations of England and Wales.
* May Include SEI registered installers and/or FAS trained plumbers who have completed the renewables technology module.

Guarantee
The Aeromax Plus Heat Pump Package is designed for a long
operational life. All components of the package carry a guarantee
against faulty materials or manufacture:
• 2 years on Aeromax Plus Air Source Heat Pump.
• 5 years on the Albion Aerocyl Unvented Copper cylinder.
• 2 years on the parts associated with the cylinder.
For the guarantee to be valid it is necessary that the system has
been correctly installed in line with Installation Manual, Operating
Instructions and all the relevant standards, regulations and codes
of practice in force at the time.
Other terms & conditions apply - see overleaf
Kingspan Renewables have a policy of continuous product development and may introduce product modications from time to time.
As a consequence details given in this brochure are subject to alteration without notice.
B9417A.02
AUG 11
Kingspan Renewables: A trading name of Kingspan Hot Water Systems Ltd. Registered Oce: Tadman Street, Wakeeld WF1 5QU Registered in England, No. 04357772
Kingspan Renewables Limited
180 Gilford Road, Portadown, Co. Armagh, Northern Ireland,
BT63 5LF, United Kingdom.
Tel: [phone] Fax: [phone]
E-mail: [e-mail]
www.kingspansolar.com
Kingspan Renewables
Tadman Street, Wakefield, WF1 5QU.
Tel: [phone] Fax: [phone]
E-mail: [e-mail]
www.kingspan-renewables.co.uk
SAP
Appendix
Q
Certicate Number MCS HP0050
Heat Pumps
