Kinki Studio EX-P27 User manual

KINKI STUDIO
EX-P27 PREAMPLIFIER
INSTRUCTIONS
- We are from China -

Congratulations on your purchase!
Before you begin, you would need to have a CR2032 battery for the remote control.
Due to restriction of shipping the lithium ion battery via courier services, we have decided to exclude the
battery in the package. It should be easily available in the local hardware shop.
Insert the battery as the picture on the left. Please take note of the contact pin (A) & (B). Contact pin (B)
has to be resting on top of the battery.
In order to save on packaging materials to reduce environmental impact,
cheapo power cord is excluded.
- Enjoy the music -
THANK YOU!
KINKI STUDIO

KINKI STUDIO
IMPORTED NOTE
The design goal of the analog volume control was to accurately reproduce low noise, low distortion, detailed and
uncolored sound. The relay-controlled attenuator, can provide just that.
The design principle of the relay-controlled attenuator uses multiple relays and resistors to attenuate the volume.
The switching of the relays, at certain steps, may produce a low audible pop/click sound. It is completely normal
and does not harm the amplifier and loudspeakers.
KINKI STUDIO EX-P27 uses the highly acclaimed precision multistep relay-controlled attenuator. Combined with the
long endurance, precision hand-matched resistors, we achieved the design goal to reproduce highest transparency
sound quality.

PREFACE 前 言
Thank you for purchasing the KINKI STUDIO EX-P27 Pre-Amplifier.
Please take some time to read this manual. It can provide you with useful information to enjoy more fun while
listening music with the KINKI STUDIO EX-P27.
Introduction
Founded in 2008, KINKI STUDIO is dedicated to the design and manufacture of high-quality audio equipment. The
core design philosophy is to reproduce the sound to its original recording intent and avoid distortion caused by
excessive rendering. In order to obtain the best results, KINKI STUDIO insists on using the advanced technology in
the audio industry, continuous improvement and refinement over the years, created KINKI STUDIO today.
The high standards and concepts to reproduce sound that have been pursued in the design and manufacturing
process, technology and quality have become the core values of KINKI STUDIO.

WARNING 警 告
These instructions must be read before starting the connection or operation, otherwise the
amplifier may be risk to mis-operational damage.
Please read and understand the operation and application in detail below.
This is a very high quality amplifier, features with new technology. It is the industry leading audio
system for reproducing accurate sound. Only careful installation and correct operation can provide
you with the satisfaction you expected. The installation instructions and precautions must be
strictly followed to achieve the desired results without affecting the performance of the amplifier.

CONTENT 目 录
01 Unpacking---------------------------------------------------------------------------1
02 Placement & Cold Start---------------------------------------------------------------------2
03 Operational Voltage-------------------------------------------------------------------------2
04 Connections----------------------------------------------------------------------------3
05 Control--------------------------------------------------------------------------------4-6
06 Optimization---------------------------------------------------------------------------------7
07 Remote Control-----------------------------------------------------------------------------8
08 Product Care---------------------------------------------------------------------------------9
09 Technical Parameters-----------------------------------------------------------------------10
10 Block Diagram---------------------------------------------------------------------------11-12

KINKI STUDIO
01
1. Unpacking
KINKI STUDIO EX-P27 comes with：
- Preamplifier
- Remote Control
- Instruction Manual
-El cheapo Power Cord Excluded (Please use your own audiophile power cord for best sound)
Note:
If the preamplifier needs to be returned to the factory for servicing/warranty or secondary
transportation, please use the original packaging. The packaging is specially designed and manufactured
by KINKI STUDIO, which can better protect the amplifier during transportation, so please keep the
original after unpacking the package.

KINKI STUDIO
02
2. Placement & Cold Start
KINKI STUDIO EX-P27 preamplifier, like all high-quality amplifiers, generates a certain amount
of heat and must be properly dissipated. To ensure good heat dissipation and cooling, do not
place temperature sensitive equipment on top of the amplifier.
3. Operational Voltage
The normal working voltage of the EX-P27 is AC 100-120V for AC110 option, and AC
200V~245V for AC230 option. If your normal operating voltage is outside the above range,
please consult us.
The EX-P27 is protected by a fuse located at the IEC inlet, rated at 2A slow blow fuse.

KINKI STUDIO
03
4. Connections
Connect the power cord to the IEC inlet of the amplifier and plug it into the power plug socket.
For safety reasons, a 3-wire grounding (earth) plug must be used, whenever possible.
In order to get the best sound from the amplifier, avoid using any multiple plugs socket or
extension cords.
The signal input connections are located at the center of the rear panel with indication of
“LEFT IN” and “RIGHT IN” respectively.
You may use either RCA or XLR connection to source devices. The XLR Pinout is as follow:
-Pin 1 (Shield)
-Pin 2 (Hot)
-Pin 3 (Cold)
Note: The same set of inputs pair should be connected. For example, LEFT IN uses CH1, and
RIGHT IN must also use CH1.

KINKI STUDIO
04
5. Control
Power Up
The power inlet IEC of the EX-P27 is located at the rear panel. After the power is supplied to the
amplifier, it will be in Operational state.
Press the front panel power button underneath once. The display indicator light flashes signify a
Start Up sequence. The input signal source (CH1-4) and volume display appear once the amplifier
is started in Operational state.
Under normal working conditions, press and hold the power button underneath the front panel for
five seconds, then release it, the amplifier will go into Standby. The indicator in the lower right
corner lights up.
Volume adjustment
Rotate the front panel right knob (VOLUME) to adjust the volume, to reduce volume, turn left; to
increase volume, turn right. Each step is in logarithm increment, there are total 95 steps.

KINKI STUDIO
05
5. Control – Con’t
Mute
Under normal working conditions, press the MUTE button on the remote control once, the display
will show MUTE, the input source number and volume display will disappear, the amplifier will be in
the Mute state. To un-mute, press the MUTE button again to return the amplifier to the Operational
state.
Input Source Selection
By turning the left knob（SELECT）to switch between Input CH1, CH2, CH3, CH4.
Output Source Selection (Mode)
By pressing the MODE button on remote control or press the front panel power button underneath
once to switch between Output 1 (RCA Output) , Output 2 (XLR Output) , Output 1+ 2 (RCA and XLR
Output operate simultaneously ).
Display
By pressing the DISPLAY button to brighten / dim / Off the display screen.

KINKI STUDIO
06
5. Control – Con’t
HT Bypass Input
HT Bypass Input is located at left rear panel. This feature enable users connecting an external
preamplifier to a same power amplifier such as AV preamplifier. This feature can be enabled by using
remote control. When it is in HT BYPASS mode, the EX-P27 preamplifier ‘s volume/gain controls are
bypassed, signal from the connected preamp at HT BYPASS terminal passthrough the EX-P27 directly
to the amplifier.

KINKI STUDIO
07
6. Optimization
Placement platform
The EX-P27 has extraordinary dynamic capabilities and sound transparency. To fully unleash its
performance, it must be placed on a rigid platform or proper HiFi rack. Please avoid the use of
any soft materials such as carpets underneath the amplifier.
Warm Up
When the preamplifier has not been used for a while, it will take 20 to 45 minutes to "warm-up".
In order to achieve the best operating temperature, the circuit must be warmed up to
approximately 40 degrees Celsius. It is advisable to keep the supply power on all the time for
optimal performance.
Note: The EX-P27 preamplifier takes about 300 hours to burn in. Please don't worry, the sound
will and can only be improved as it burns in.

7. Remote Control
The EX-P27 comes with full function remote control.
•POWER: On/Off EX-P27
•HT BYPASS: Enable HT Bypass Mode
•DISPLAY: Off/Dim/Brighten the Display
•INPUT + INPUT -: Input Source Selection
•V+ V- : Volume Control
•MUTE: Mute Speaker Output
•MODE: Output Mode Selection
➢Output 1 : RCA Output
➢Output 2 : XLR Output
➢Output 1 +2 : RCA and XLR Output Operate Simultaneously
KINKI STUDIO
08

KINKI STUDIO
09
8. Product Care
The EX-P27 usually requires no maintenance and requires only occasional cleaning of the physical
surface.
The power must be turned off and removed before cleaning the amplifier. Clean the surface of
the amplifier with a soft, slightly damp cloth. Wipe gently with a soft cloth dampened with water
or a mild detergent solution. Please avoid the use of harsh detergents (i.e. product containing
sodium carbonate).

KINKI STUDIO
10
9. Technical Parameters
Frequency Response: 0-50kHz (±0.1dB) ,0-150kHz (±1dB), 0-300kHz (±3dB)
THDN: 0.002% (-80dB)
S/N Ratio: >98dB, >100dB (A-Weighted)
Channel Separation: >106dB
Input Sensitivity: 2.25Vrms - 3.6Vrms
Input Impedance: 50kΩ
Input Connector: RCA x 4, XLR x 4, HT Bypass x 1
Output Voltage: 2.25Vrms - 3.6Vrms
Maximum Output Voltage : 16Vrms
Output Impedance: 75Ω
Output Connector: RCA x 1, XLR x 1
Power Consumption: 80W Max Output
Dimension: 430W x 120H x 330D
Weight: 15KG

KINKI STUDIO
11
Input Selection Display Volume Control
Front Panel
Power/Mode
431 2

KINKI STUDIO
12
Rear Panel
1
5
2 3 4
678
1Preout 1/2 (Right) 23HT Bypass Signal Input 4On/Off Switch
5Fuse Holder
(2A 5x20mm)
Preout 1/2 (Left)
6Input Signal Channel 1-4 (Left) 712V Trigger 8Input Signal Channel 1-4 (Right)
