FT3010 (T-100) User Manual
Contents
Foreword 3
Declaration of Conformity 3
Important Safety Information 3
Product Characteristics 8
Technical Data 9
Intended Use 10
Parts Identification 11
Basic Components 11
Display Indicator 12
Operation and Setting Method 12
Installing and Replacing the Batteries 12
Setting Method 12
Advice for First Use 13
Correct Measurement 14
Troubleshooting 16
Care and Maintenance 16
Quality Promised and Service 18
Attachment List 18
Safety Classification of ME Equipment 19
EMC Precaution 19
Foreword
Thank you for purchasing product. FT3010 No-contact Electronic Forehead Infrared
Thermometer (here in after called the Forehead Thermometer for short) is a thermometer
which is used for measuring the temperature of human body at forehead by the principle of
receiving infrared. According to the human body skin difference, the measuring temperature
would be different. When changing the location from two different temperature location,
before use, please put the forehead thermometer in the same condition at least 30 minutes,
so that the forehead thermometer could be adapted to the ambient temperature. It is mainly
applied to household (consumer use). For your correctly use, please make sure you have read
this user manual. Please keep it carefully, in case you can refer again someday.
Declaration of Conformity
●This device fulfils the provisions of EC directive 93/42/EEC (Medical Device Directive).
●This forehead thermometer meets requirements established in ASTM Standard E1965-
98(2009). Full responsibility for the conformance of this product to the standard is
assumed by Zhongshan Jinli Electronic Weighing Equipment Co., Ltd
Add:283rd South Min’an Road Xiaolan Town, Zhongshan Ctiy,Guangdong China
●This device has been tested and homologated in accordance with EN60601-1-2:2015
for EMC. This does not guarantee in any way that the device will not be affected by
electromagnetic interference. Avoid using the device in high electromagnetic
environment.
Important Safety Information
●The warning symbol and cutline mentions in this user manual give guidance of safety
and correct method and avoid harm to your body.
Warning Symbols
Symbol
Meaning
Stop using the thermometer.
Prohibit operation.
Follow the operation manual.
Correct Disposal of This Product
Household users should contact either the
retailer where they purchased this product, or
local government for details of where and how
they can dispose of this item.
Business users should contact their supplier
and check the terms and conditions of the
purchase contract. This product should not be
mixed with other commercial wastes for
disposal.
This product does not contain any hazardous
substances.
•Please do not use a combination of old
and new batteries.
•Please use the same brand batteries.
•Remove the batteries if it is not in use
for a duration of time.
•Please set “+ and –“ correctly.
•By not following instructions, the
batteries may head and cause issues
with the product.
•If battery fluid should leak, please
contact the retailer which you bought
the item from.
Guidance
•The use of this thermometer is not
intended as a substitute for consulting
with a doctor.
•Please do not place this object close to
a charged object as there is possibility
of an electric shock.
•Disposal of discarded thermometer
should be in accordance with national
regulations.
•The user should contact the
manufacturer if you require further
advice and guidance on how to use and
maintain this device.
•It is not safe to modify the equipment.
•The materials used on this thermometer
have passed the biological performance
test. They are not potential for an
allergic reaction.
•Do not expose the thermometer to
extreme temperatures e.g.>50ºC or <-
20ºC.
•Do not use the device beyond intended
use.
•Keep the device away from water and
direct sunlight.
•Do not disassemble or try to repair the
unit.
•Please keep this user manual for further
guidance.
•Portable and mobile RF communication
equipment can effect this thermometer.
•Do not use a mobile phone or other
portable devices that emit
electromagnet fields, near the unit. This
may result in inaccurate readings.
Meanings of Symbols
Signs
Meaning
Type BF applied Part
Refer to the instruction manual
Manufacturer
European community
Specific batch code
CE mark
This marking indicates that the product
should not be disposed of with other
general household waste.
Product Characteristics
•Designed for measuring forehead temperature, with a dynamic offset for the ambient
temperature and forehead temperatures.
•Exclusive use German infrared probe for temperature measure with high accuracy
and stable performance.
•Providing the function and sound notification of high body temperature.
•With 32 sets of measurement memories.
•LCD digital display with backlight.
•Fahrenheit and Celsius operation modes.
•Auto-off function to save energy.
•Convenient and easy to use operation.
Technical Data
Normal operating
conditions
Temperature: 16ºC - 40ºC
Relative humidity: 15% ~ 95%RH
Atmospheric pressure: 860 –1060 hPa
Power supply: DC 3V (2 x AA LR6)
Transport condition and
storage
Ambient temperature: -20ºC ~ 50ºC
Relative humidity (RH): 15% - 95%
Atmospheric pressure: 860 –1060 hPa
Dimensions
90mm x 43mm x 148mm
Weight
100g (not including batteries)
LCD display resolution
0.1ºC (0.1ºF)
Range of measurements
Body temperature: 22ºC ~ 43ºC
Surface temperature: 0ºC ~ 100ºC
Measurement accuracy
1) 22ºC - 42ºC: ± 0.3ºC
2) < 22ºC : ±0.5ºC
3) > 42ºC: ±0.5ºC
Repeatability
<±0.2ºC
Power
<50mW
Measurement time
1 second
Measurement distance
30mm –50mm
Auto-time off time
10 seconds
Measurement data
capacity
32 sets
Warning
This unit has been thoroughly tested and inspected to assure accurate readings and easy
operation. The performance of the instrument may be adversely affected by the following:
•Operation outside of normal operating conditions
•Shock may cause adversely altered performance.
•
Intended Use
The forehead thermometer is designed for body surface and forehead temperature
measurement for infant and adults without contact to the human body.
The forehead thermometer can also be used to measure the temperature of a baby’s bottle,
bath and room temperature (by using the surface mode).
Normal Temperatures According to Measurement Method:
Measurement Method
Normal Temp Range ºC
Normal Temp Range ºF
Rectal
36.6 to 38
97.8 to 100.4
Oral
35.5 to 37.5
95.9 to 99.5
Axillary
34.7 to 37.3
94.4 to 99.1
Ear
35.8 to 38
96.4 to 100.4
The temperature of the human body can vary throughout the day. It can also be influenced
by numerous external factors.
Normal Temperature According to Age
Age Method
Normal Temp Range ºC
Normal Temp Range ºF
0 –2 years
36.4 to 38.0
97.5 to 100.4
3 –10 years
36.1 to 37.8
97.0 to 100.0
11 –65 years
35.9 to 37.6
96.6 to 99.7
>65 years
35.8 to 37.5
96.4 to 99.5
Attention: ASTM laboratory accuracy requirements in the display of 37 to 39℃(98 to 102℉)
for Skin IR thermometers is ±0.3℃(± 0.5℉) ，whereas for mercury in-glass and electronic
thermometers, the requirement per ASTM Standards E667-86 and 1112-86 is ±0.1℃(± 0.2℉)
Manufacturer will make available upon request specific instructions for tests to determine
the laboratory error, clinical bias and clinical repeatability.
When you need to clinical accuracy characteristics and procedures, please contact with the
local distributors obtain from our company
Parts Identification
Basic Components
Display
Installing and Replacing the Batteries
1) Push the battery cover back, open the cover from the
body.
2) Insert two AA batteries as indicated and then replace the
battery cover.
Setting Method
Keep pressing “SET” key and hold for 3 seconds into the setting mode.
Select measurement unit ---Menu F1
Enter into setting mode, the LCD displays “F1”, press “+” key to select “℉” unit, press “-”key to select
“℃” unit.
Warning value setting ---Menu F2
【Default 37.8 ℃(100.4℉)】Enter into setting mode, short press “SET” key twice, the LCD displays
“F2”, then press “+” key to increase the setting value 0.1℃(0.1℉), press“-” key to reduce the setting
value0.1℃(0.1℉).
Offset value setting ---Menu F3
【Default 0.0 ℃(0.0℉)】Enter into setting mode, press “SET” key triple, the LCD display “ F3”, then
press “+” key to increase the setting value 0.1 ℃(0.1℉), press “-”key to reduce the setting value
0.1℃(0.1℉).
Sound notification setting
Enter into setting mode, press “SET” key four times, the LCD display “ F4”, then press “+” key to turn
on the sound notification function, press “-”key to turn off the sound notification function.
Backlight setting
---Menu F5
Enter into setting mode, press “SET” key five times, the LCD display “ F5”, then press “+” key to turn on
the backlight function, press “-” key to turn offthe backlight function.
Exit setting mode
Press “SET” key until shutdown.
Advice for the 1st Use
For stable and reliable results, it is essential to check the forehead thermometer and change as
needed, as follows:
•Take the temperature of the same person using a conventional thermometer; you will get
37.0℃ (98.6℉) for instance.
•Take the temperature of the same person using the forehead thermometer keeping the 50 to
150 mm distance between the thermometer and the forehead (Take care to remove any
obstacle which could alter the measurement (hair, perspiration…). If you get 37.0 ℃(98.6 ℉),
the Non-contact body infrared Thermometer is properly set and ready for use.
•If you get a lower temperature, 36.4℃ (97.4℉) for example, your difference is 0.6℃(1.2℉), you
should adjust the temperature on the forehead Thermometer Body infrared Thermometer and
add the difference, i.e. 0.6℃1.2℉) .
•To do it, press the “SET “button for 3 seconds, the screen displays F1, press “SET “button again
until you get F3, press “+”button in order to add the difference (in our example, 0.6℃( 1.2℉)
•8.3.3 To check, take the temperature again using the Non-contact body infrared
Thermometer.
Caution：This setting applies only to Body mode.
Measurement body temperature
Hold the forehead thermometer, leave one finger in front of the button, keep
transducer window at human’s forehead, leaving a distance of 30 - 50mm from the
forehead. Press the button, and the thermometer will start up automatically and
display the measurement result, as shown in the figure below:
Troubleshooting
Error Symbol
Cause
Processing Method
Low battery
Replace the batteries
System fault
Speak to the dealer in which you
purchased the device.
Ambient temperature too high
Please follow the guidance in the user
manual regarding ambient
temperature.
Ambient temperature too low
Measuring temperature too high
Stop measuring
Measuring temperature too low
Care and Maintenance
•The protective glass over the lens is the most important and fragile part of the
thermometer, please take great care of it.
•Do not recharge non rechargeable batteries, do not throw in fire.
•Do not expose the thermometer to sunlight or water.
•The Infrared Sensor is the most precise part, must be protected carefully.
•Clean and Disinfect the device with a cotton bud lightly moistened with 70% alcohol.
•Do not clean the device with corrosive detergent.
•Keep the device in a dry environment and keep it away from dust and direct sunlight.
•The main unit is not waterproof. Be careful when handling this unit so that no liquid
(alcohol, water, or hot water) will get into the main unit.
•If the infrared sensor becomes dirty, lightly wipe it with a soft dry cloth.
•It is regular recommended to do the recalibration every two years to ensure
functioning correct.
Expected Serviced Life: 2 Years.
The typical service life of the new and unused batteries is 10000 measurements for the
operation time is 10s.
WARNING: Do not modify this equipment without authorization from manufacturer.
Manufacturer will provide circuit diagrams, component part lists, descriptions, calibration
instructions to assist to service personnel in parts repair.
Quality Promised and Service
The guarantee time is two years after you buy the device.
Notice: If the device is broken by the non-formal used or disassemble by you, the device
cannot be in the guarantee range.
Tips: Please keep the guarantee card and the buying receipt, which is very useful when you
need to amend it.
Attachment List
One set of Electronic Forehead Infrared Thermometer.
One set of user manual.
One set of the Warranty certificate.
2x1.5 AA Batteries(optional).
Safety Classification of ME Equipment
Protection against electric shock
Internally powered ME equipment
Applied part
Type BF applied part, including whole
forehead thermometer
Protection against harmful ingress of water
or particulate matter
IP22
Mode of operation
Continuous operation
Note: Not intended to be sterilised. Not for use in oxygen rich environments.
Manufacturer
Zhongshan JinLi Electronic Welghing
EquipmentCO.,LTD.
283rd South Min’an Road, Xiaolan Town,
Zhongshan City，Guangdong, China
Contact Tel.:+86(760)28133810
Fax:+86(760)28133778
EU-Representative
Wellkang Ltd
Suite B,29 Harley Street
LONDON,W1G 9QR,U.K.
www.CE-Marking.EU
EMC Precaution
•MEDICAL ELECTRICAL EQUIPMENT needs special precautions regarding EMC and
needs to be installed and put into service according to the EMC information provided
in the ACCOMPANYING DOCUMENTS
•Wireless communications equipment such as wireless home network devices, mobile
phones, cordless telephones and their base stations, walkie-talkies can affect this
equipment and should be kept at least a distance d = 3,3 m away from the
equipment.
(Note. As indicated in Table 6 of IEC 60601-1-2:2015 for ME EQUIPMENT, a typical cell phone
with a maximum output power of 2 W yields d = 3,3 m at an IMMUNITY LEVEL of 3 V/m).
Table of contents
Other KINLEE Thermometer manuals
