Kisai Blade User manual

Button
A
USB Port
Button
B
INSTRUCTION MANUAL

Blade has 2 time display modes [TURNING] & [FLASHING]
The default setting is [TURNING]
To change the time display mode, see section 4 “How to set the
time & display modes”.
Press button A to show the time.
Examples:
[12] [5] [9] = 12:59 [6] [3] [5] = 6:35 [10] [0] [8] = 10:08
In the image below the line at 3 o’clock is lit, indicating 3
The display will light up an blade which rotates around the face
3 times.
Each time it rotates it leaves 1 line lit, indicating in turn:
[hour] [group of 10 mins] [single mins]
This is known as the 12-5-9 method of time telling.
1. How to read the time
•
•
•
•
I. Turning Mode

Turning Mode - Full Example
Blade rotates
Blade rotates
Blade rotates
4 o’clock
20 minutes
7 minutes
First Spin
After pressing button A the blade rotates,
leaving the 4 o’clock line lit.
It is 4 o’clock.
Second Spin
On the second rotation the blade leaves the 2
o’clock line lit, indicating 20 minutes.
It is 4:20
Third Spin
On the third rotation the blade leaves the 7
o’clock line lit, indicating 7 minutes.
It is 4:27 exactly
Note:
If the blade rotates without leaving any line lit, it indicates ZERO

6 o’clock 10 o’clock
Time: 6:45 Time: 10:18
Time: 1:07
45 minutes
(flashing)
15 minutes
(flashing)
+3 minutes
(dots)
+2 minutes
(dots)
1 o’clock
(flashing rapidly)
Indicates 1:05 as 1 & 05
are the same position
The display will light up Hours & Minutes at the same time
similar to a regular clock.
One blade will light up to show the hour, one blade will flash to
show the minutes. Additional dots may appear to indicate the
exact minute.
II. Flashing Mode

Date icon
Alarm icon
Alarm ON
30 minutes
(flashing)
+3 minutesPM icon
8 o’clock
3. How to check the date & alarm
Press button A to change between [TIME] > [DATE] > [ALARM]
An icon will show to indicate date or alarm.
The date or alarm will be displayed in your chosen display
mode [TURNING] or [FLASHING]
•
•
•
Blade rotates
Date example [Turning Mode]
Alarm example [Flashing Mode]
June 24th
8:33 PM (Alarm ON)
Blade rotates Blade rotates
6 (June) 2 4
*You may choose to show [Month > Day] or [Day > Month]
See section 5 “How to set the date“

From the time display, press & HOLD button B to begin setting
the time.
You will be asked to set the following options in sequence.
4. How to set the time & display modes
•
•
Hours Minutes Mode Animation
The display will flash the current hour.
Press button A to change the hour
Press button B to accept.
•
•
•
I. Hours
*Setting mode will exit after 7 seconds of inactivity
Hour: 11 AM Hour: 7 PM

In the 12-5-9 time telling method, the “group of 10 mins” are
[00, 10, 20, 30, 40, 50]. So in this stage, if the exact minute is
34, you would set 30.
In the 12-5-9 time telling method, the “single mins” are [0-9]. So
in this stage, if the exact minute is 34, you would set 4.
The display will flash the current group of 10 minutes.
Press button A to change the minutes
Press button B to accept.
The display will flash the current single minutes.
Press button A to change the minutes
Press button B to accept.
•
•
•
•
•
•
II. Minutes (group of 10)
III. Minutes (single)
Group of 10 mins
30 mins
00
01
2
3
5
6
7
8
9
4
10
20
30
40
50
Single minutes
4 mins

Blade has 2 display modes [TURNING] & [FLASHING]
See section 1 “How to read the time” for an explaination of
each mode.
Two vertical blades are lit,
a blade rotates.
Two vertical blades are lit,
The top blade flashes.
The display will flash the current display mode.
Press button A to change the mode
Press button B to accept.
•
•
•
IV. Display Mode
Turning Mode Flashing Mode

Change the way you think about time

Blade has an animation mode which causes the watch to animate
the display every 15 mins between 6pm & midnight.
You may set the animation mode ON or OFF.
A flashing “X”Display spinning
The display will flash the current animation setting.
Press button A to change the setting
Press button B to accept & finish.
•
•
•
V. Animation
Animation ON Animation OFF

In the 12-5-9 date telling method, the “group of 10 days” are
[00, 10, 20, 30]. So in this stage, if the exact day is 24, you
would set 20.
The display will flash the current month (1-12).
Press button A to change the month
Press button B to accept.
The display will flash the current “group of 10” days (0-30).
Press button A to change the “group of 10” days
Press button B to accept.
•
•
•
•
•
•
Press button A twice to show the date.
Press & HOLD button B to begin setting the date.
The icon will be lit. (date)
5. How to set the date
•
•
•
I. Month
II. Day (groups of 10)
*Setting mode will exit after 7 seconds of inactivity
Group of 10 days
20 days
00 10
20
30

In the 12-5-9 date telling method, the single days are [0-9].
So in this stage, if the exact day is 24, you would set 4.
You may set the date to display [Month > Day] or [Day > Month]
The display will flash the current single days (0-9).
Press button A to change the “group of 10” days
Press button B to accept.
The display will flash the current date format setting.
Press button A to change the setting
Press button B to accept & finish.
•
•
•
•
•
•
III. Day (single days)
IV. Date format
01
2
3
5
6
7
8
9
4
Single days
4 days
Month / Day
Day / Month

Press button A three times to show the alarm.
Press & HOLD button B to begin setting the alarm.
The icon will be lit. (alarm)
The icon will be flashing.
Press button A to turn the alarm buzzer ON or OFF
Press button B to accept.
6. How to set the alarm
•
•
•
•
•
•
I. Alarm buzzer
II. Alarm hours
*Setting mode will exit after 7 seconds of inactivity
The display will flash the current alarm hour.
Press button A to change the alarm hour
Press button B to accept.
•
•
•
Alarm icon (flashing)
Alarm ON
Alarm hour
6AM
No PM marker = AM

In the 12-5-9 time telling method, the “group of 10 mins” are
[00, 10, 20, 30, 40, 50]. So in this stage, if the exact minute is
09, you would set 0.
In the 12-5-9 time telling method, the “single mins” are [0-9]. So
in this stage, if the exact minute is 09, you would set 9.
III. Alarm minutes (groups of 10)
IV. Alarm minutes (single minutes)
The display will flash the current group of 10 minutes.
Press button A to change the minutes.
Press button B to accept.
The display will flash the current single minutes.
Press button A to change the minutes
Press button B to accept & finish.
•
•
•
•
•
•
Group of 10 mins
0 mins
00 10
20
30
40
50
01
2
3
5
6
7
8
9
4
Single minutes
9 mins

7. Charging the watch
The watch battery can be recharged by connecting the USB
charging cable provided to the watch USB port and the other
end to your computer’s USB port.
To open the watch USB port, use the screw driver included.
When charging, the charging light will animate.
When the charging light stops animating, the watch is 90%
charged.
It is advised that you continue to charge the watch for the full 3.5
hours to ensure the battery is 100% charged.
Included in the box
• Watch
• USB cable
• Screw driver
• Spare USB cap
• Watch manual
• Link USB Cable
•
•
•
•
•
USB charging port screw Charging light

8. User information
This watch is covered by a 1 year warranty. This warranty
does not cover water damage, accidental damage, neglect
or unauthorized repair.
II. Warranty
Blade uses a PL301517 rechargable watch battery.
The battery should last about 1 month between charges.
The battery lifetime is expected to be 300 charges.
Only use the cable provided with the watch for
recharging, as it is designed specifically for this watch.
This watch has limited resistance to water. Please do not
use the watch in the shower, for swimming or for other
water related activities.
I. Battery
III. Caution
•
•
•
•
•
•

Case Materials
Case Dimensions
Maximum Fit
Wrist Size
Display
Strap Materials
Finish
Weight
Battery
Wood
Wood
45mm x 53mm x 12mm
210mm (approx.)
LED Digital Tube
Clear Coatng
60g
PL301517 Rechargable
SPECIFICATIONS
