Kissingbaby KX112 User manual

WARNING
18.Do not use forward facing before the child is 15 months old and reached a size of 76cm .
Child height: 40-150CM
Model: KX112
CHILD SAFETY CAR SEAT
USER MANUAL

40-105cm
76-105cm
100-150cm
100-150cm
5-Point harness
5-Point harness
Height Body
restraint mode
Seat
fixing mode
Installation
direction
ISOFIX
+
Support leg
ISOFIX
+
Support leg
Rear facing
Forward facing
Forward facing
Forward facing
Three-point car
seat belt restraint
Three-point car
seat belt restraint
ISOFIX
attachments
+
Three-point
car seat belt
Three-point
car seat belt
Suitable for models with ISOFIX systems which pass ECE R14 and with three-point
seat belt/seat belt with a retractor which pass ECE R16.
It is not suitable for cars with only two point seat belts.
Rearward facing
40-105cm：ISOFIX+Support Leg+Five-point seatbelt
Forward facing
75-105cm:ISOFIX+Support Leg+Five-point seatbelt
100-150cm:ISOFIX+Three-point car seatbeltor
Three-point car seatbelt only.
Notice regarding i-Size category Enhanced Child Restraint Systems (40-105cm)
This is an i-Size Enhanced Child Restraint System.
It is approved according to UN Regulation No. 129, for use in, i-Size compatible vehicle
seating positions as indicated by vehicle manufacturers in the vehicle users' manual.
If in doubt, consult either the Enhanced Child Restraint System manufacturer or the retailer.
Notice regarding i-Size booster seat category Enhanced Child Restraint Systems (100-150cm)
This is a i-Size booster seat Enhanced Child Restraint System.
It is approved according to UN Regulation No. 129, for use primarily in " i-Size seating positions"
as indicated by vehicle manufacturers in the vehicle user’s manual.
If in doubt, consult either the Enhanced Child Restraint System manufacturer or the retailer.
NOT TO USE REARWARD FACING ECRS IN SEATING POSITIONS WHERE THERE IS AN ACTIVE FRONTAL
AIRBAG INSTALLED.
Do not use forward facing before the child is 15 months old and reached a size of 76cm .
IMPORTANT - DO NOT USE FORWARD FACING BEFORE THE CHILD'S AGE EXCEEDS 15 MONTHS
(Refer to instructions).
installation

5
Part name (front)
………………………………………………………
Support leg installation
………………………………………………………
…………………………………………………………
…………………………………………………
………………
……………………………
…………………………
……………
………………………………………
………………
……………………………………………………………
………………………………………………
5
6
7
7
8-9
10-11
12-13
14-15
16
19
19
17-18
Part name (front)
Part name (back)
Contents
Rotation function
(40-105cm) Seat installation mode (backward)
(40-105cm) Installation method for children (backward)
(76-105cm) Seat installation mode (forward)
(76-105cm) Installation method for children (forward)
Five-point safety belt concealment
(100-150cm) Seat installation mode and riding mode
Cloth removing
Cleaning and maintenance
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Press Release button to adjust
the length of support leg.
1
2
3
4
5
6
8
9
10
11
12
13
14
7
15
Headrest
Support leg indicator
Support leg button
Upper support leg
Lower support leg
Small headrest
(suitable for height less
than or equal to 75cm)
Harness cover
Buckle
Crotch pad
Harness adjuster button
Rotation handle
Vehicle belt guide
Vehicle belt guide
Shoulder strap
Inner cusion(suitable for
height less than or equal
to 75cm
Isofix button
16
17
Harness adjuster button

6 7
Part name (back)
19
18
20
18
19
20
Side impact protector (SIP)
Headrest adjustment handle
ISOFIX attachments
1.Support leg installation
2.Withdraw support leg
Support leg retract button
21
21
Bottom view
The support leg is improper installation
if with indicator show red color,
The support leg installation correct if with
indicator show green color.
Base , rotate the support leg in upright position after extend the support leg in max
position . press release button draw the lower support down to touch the car floor .
the support leg indicator show green color .
Retract the outrigger: press the button below the base (circled in red)Brace leg
Retracts brace leg.

8 9
Pull the rotation button one time by two finger ,meanwhile rotate main body till
heard "click" by another hand ,check the rotation indicator show green color .
一、Rotation function
Attention :the rotation function be Activated after the support leg full open.
Step 1.extend the support leg and installed
it till indicator show green color .
一、I-SIZE(40-105cm)（rearward facing）
1.Suitable for models with ISOFIX systems which pass ECE R14 .
2.This I-size seat is installed backward, suitable for 40-105cm children. Only one seat can be
adjusted in the five position.
3.i-size seats cannot be installed in places with airbags.
4.“IMPORTANT-DO NOT USE FORWARD FACING BEFORE THE CHILD’S AGEEXCEEDS 15
months(Refer to instructions)”
5.Important - The seat should not be used laterally in the driving condition.
Attention
1.i-size universal (40-105cm): ISOFIX+Support Leg+ five-point safety belt
Step 4: Push the baby car seat to the back
of the car seat to make them fit tightly.
Shake the seat from side to side to make
sure it is effectively fixed.
Step 2: Press the ISOFIX button at the bottom
of the seat forward and backward with your
hand, push the ISOFIX on both sides to the
maximum, press the end of the ISOFIX, and it
will not be retracted.
Push
click
Step 3: Insert the ISOFIX of the baby car seat
into the corresponding ISOFIX fixed point of
the car, and a click will be heard to display
green in the display window.It will display red
in the window before ISOFIX inserted correctly.

10 11
Step7: After installation, there is side protection
on the side of the door.
Step6:Adjust the body car seat on position 1
forward facing ,then rotate it on position 5
rearward facing .
1
5
Step5:Extend the support leg tube in max
position till the the green color show in top
of support leg .
PRESS
PRESS
i-size (40-105cm) Child mounting method (backward)
Step 1: Press and hold the central
regulator button while pulling the
shoulder strap outwards to relax
the shoulder strap.
Step 2: Press the red button to
open the buckle.
Step 3: Pull out the shoulder straps
and place them on both sides of
the seat.
Step 4: When i-size (40-105cm) is
used by children, please refer to
the above picture description for
the shoulder strap.
Step 5: Pull and adjust the safety
belt outward to make the shoulder
belt effectively restrain the children,
and reserve a certain space to prevent
the child seat belt from pressing the
children too much. The adult palm
can be inserted just between the safety
belt and the children's chest. It is better
not to be loose or tight, and ensure that
the pelvis area can be well restrained
when the belt is worn.Note: The bottom
of both sides of the shoulder shield
should be close to the same level and
pulled down to the bottom.

12 13
bottom insert
size range
40-75CM
size range
＞75CM
Model: KX111
only for height less than or equal to 75cm
Step 6: How to use the buckle: put the buckle insert around and together, and then
insert the buckle slot at the same time. The sound of clicking indicates that the
buckle has been stuck.Then pull up the clip insert to check whether the clip is
properly locked.To unfasten the clasp, press the red button and the clasp insert
will pop out automatically.
Step 7: Pull the headrest handle upward to adjust the height of the headrest. Adjust the
height to the right position according to the different heights of the child.
After the baby is seated, adjust the
head to the right position (note: the
lowest part of the head is 1-2 fingers
away from the shoulder is the best).
Pull
一、I-SIZE(76-105cm)（Forward facing）
Attention
2.i-size universal (40-105cm): ISOFIX+Support Leg+ five-point safety belt
Step 1.extend the support leg and installed
it till indicator show green color .
Step 2: Press the ISOFIX button at the bottom
of the seat forward and backward with your
hand, push the ISOFIX on both sides to the
maximum, press the end of the ISOFIX, and it
will not be retracted.
1.Suitable for models with ISOFIX systems which pass ECE R14 .
2.The i-size seat is installed forward, suitable for 76-105cm children. It has 4 adjustable
sitting positions, 1/2/3/4 gear respectively.
3.I-size seats cannot be installed in places with airbags.
4..“IMPORTANT-DO NOT USE FORWARD FACING BEFORE THE CHILD’S AGEEXCEEDS 15
months(Refer to instructions)”
5.Important - The seat should not be used laterally in the driving condition.
Step 4: Push the baby car seat to the back
of the car seat to make them fit tightly.
Shake the seat from side to side to make
sure it is effectively fixed.
Push
click
Step 3: Insert the ISOFIX of the baby car
seat into the corresponding ISOFIX fixed
point of the car, and a click will be heard
to display green in the display window.
It will display red in the window before
ISOFIX inserted correctly.

14 15
Step7: After installation, there is side protection
on the side of the door.
Step 6: Rotate the baby car seat on forward
facing , pull the reclining button to adjust the
reclining position your desired.
Step 5: Extend the support leg tube in max
position till the the green color show in top
of support leg.
12 3 4
PRESS
PRESS
Step 1: Press and hold the central
regulator button while pulling the
shoulder strap outwards to relax
the shoulder strap.
Step 2: Press the red button to
open the buckle.
Step 3: Pull out the shoulder straps
and place them on both sides of
the seat.
Step 4: When i-size (40-105cm) is
used by children, please refer to
the above picture description for
the shoulder strap.
Step 5: Pull and adjust the safety belt
outward to make the shoulder belt
effectively restrain the children,and
reserve a certain space to prevent
the child seat belt from pressing the
children too much. The adult palm
can be inserted just between the safety
belt and the children's chest. It is better
not to be loose or tight, and ensure that
the pelvis area can be well restrained
when the belt is worn.Note: The bottom
of both sides of the shoulder shield
should be close to the same level and
pulled down to the bottom.
i-size (76-105cm) Child mounting method (forward)

16 17
bottom insert
size range
40-75CM
size range
＞75CM
Model: KX111
only for height less than or equal to 75cm
Step 6: How to use the buckle: put the buckle insert around and together, and then insert the
buckle slot at the same time. The sound of clicking indicates that the buckle has been stuck.
Then pull up the clip insert to check whether the clip is properly locked.To unfasten the clasp,
press the red button and the clasp insert will pop out automatically.
After the baby is seated, adjust the
head to the right position (note: the
lowest part of the head is 1-2 fingers
away from the shoulder is the best).
Step 7: Pull the headrest handle upward to adjust the height of the headrest. Adjust the
height to the right position according to the different heights of the child.
Pull
Five-point safety belt concealment
Press A-clok to pull up webbing max .Remove the shoulder protector from webbing . keep it
well for future use.
Press buckle button to disengage insert form buckle , Adjust
the headrest to expose the slots in backrest ,peel off the fabric ,
put two inserts into the slots of backrest . store the buckle into
the storage of seat .check the headrest move to the highest
position freely .settle the fabric smoothly.

18 19
Step 6: After installation, there is side protection
on the side of the door.
Step 1 :withdraw support leg into storage
of base .
一、I-SIZE(100-150cm)（Forward facing ）
Step 4: Push the baby car seat to the back
of the car seat to make them fit tightly.
Shake the seat from side to side to make
sure it is effectively fixed.
Step 2: Press the ISOFIX button at the bottom
of the seat forward and backward with your
hand, push the ISOFIX on both sides to the
maximum, press the end of the ISOFIX, and it
will not be retracted.
Step 3: Insert the ISOFIX of the baby car
seat into the corresponding ISOFIX fixed
point of the car, and a click will be heard
to display green in the display window.It
will display red in the window before
ISOFIX inserted correctly.
i-size universal(100-150cm): Option 1: ISOFIX attachments+Three-point car seat belt
Option 2: Three-point car seat belt
1.This ECRS seat is installed forward and suitable for children with height of 100-150cm. It has 1
adjustable sitting positions, 4 gear respectively.
2. Hide the five-point safety belt and pad before using the ECRS seat.
3. Suitable for models with ISOFIX systems which pass ECE R14 and with three-point seat belt/
seat belt with a retractor which pass ECE R16.
4.Don t use force-bearing points without marking.
Attention
click
bottom view
Push
Step 5: adjust the baby car seat on forward
facing , available to child's size 100-150cm ,
recline position 4 is available .
12 3 4
click
Don t use force-bearing points without marking
Step 7: put a child in baby car seat, adjust headrest to the right position, place the
upper end of the car seat belt diagonally through the guide hook slot at the bottom
of the head,the lower end of the diagonal band passes through the corresponding
guide mark,the cross band passes through two left and right guide barbs, finally, the
car latch is attached to the car buckle,when you hear "click," it means to lock correctly,
the pelvis should be properly restrained when the belt is worn.
Don't use support leg when use adult safety belt

20 21
Step3: After installation, there is side protection
on the side of the door.
2.、Three-point car seat belt
Step 1 :withdraw support leg into storage
of base .
bottom view
Removing cover
Step 1 Remove inner padded pillow and
shoulder protector (Picture 1)
Remove head rest cover (FIG. 2) : guide
the tension at the hook
When the belt is detached, take off the
cloth cover.
Remove the cloth cover of the chair body
(Figure 3) : buckle the latch of the chair
body Open, take off the cloth cover.
Maintenance
Washing instructions
1.When not using the baby car seat, keep it in a dry and ventilated place to avoid damp and mold.
2. If dust is found on the seat surface, clean the safety belt, fabric and plastic parts with a damp
sponge and then air dry.
3.If accidentally drip food or drink onto the safety belt, remove the safety belt and rinse it with
warm water, then air it to dry.
4.If clean the entire cover, refer to the washing instructions
5.During the first washing, slight fading may occur, which is a normal phenomenon
Do not use solvents, chemical cleaners or lubricants on any part of this product.
Hand washable,
water temperature
below 30℃
Do not bleach Do not dry Do not iron
click
Step 2: put a child in baby car seat, adjust
headrest to the right position, place the
upper end of the car seat belt diagonally
through the guide hook slot at the bottom
of the head,the lower end of the diagonal
band passes through the corresponding
guide mark,the cross band passes through
two left and right guide barbs, finally, the
car latch is attached to the car buckle,when
you hear "click," it means to lock correctly,
the pelvis should be properly restrained
when the belt is worn.
Don t use force-bearing points without marking
Don't use support leg when use adult safety belt

22 23
Vehicle list used as specific vehicle booster seat
Seat position in other car may also be suitable to accept this ECRS by installed
as specific vehicle booster seat. If you doubt, consult either the child restraint
manufacturer or the retailer.
CLA C 117 2,4
CLA shooting break 2,4
CLC 180 C 204 2,4
CLK CL 203 2,4
CLS C 219 2,4
E class W/S 211 2,4
E class W/S 212 2,4
GLA class 2,4
GLC class X253 2,4
GLK X 204 2,4
Maybach S class X222 2,4
M class W 163 2,4
M class W 164 2,4
M class W 166 2,4
ML class X 164 2,4
R class W/V 251 2,4
S class W/V 220 2,4
S class W/V 221 2,4
Vaneo W 414 2,4
Viano W 639 2,4
Vito W 639 2,4
ASX 2,4
Colt 2,4
Grandis 2,4
i-MiEV 2,4
Lancer 2,4
L200 2,4
L200D/cab (KK0T/KL0T) 2,4
Mirage / Space star 2,4
Outlander 2,4
Outlander PHEV 2,4
Pajero 2,4
Almera 2,4
Juke 2,4
Leaf 2,4
Micra 2,4
Murano 2,4
Note 2,4
Note 2,4
NV200 / Evalia 2,4
e-NV200 / e-Evalia
2,4
Path.nder 2,3,4
Pixo 2,4
Primastar 2,4
Primera 2,4
Pulsar 2,4
Qashqai 2,4
Qashqai 2,4
X-trial 2,4
X-trial 2,4
Adam 2,4
Agila 2,4
Ampera 2,4
Antara 2,4
Astra 2,4
Combo 2,4
Corsa 2,4
Insignia 2,4
Karl / Viva 2,4
Meriva 2,4
Mokka 2,4
Signum 2,4
Vectra 2,4
Vivaro 2,4
Zafira 2,4
Zafira Tourer 2,4
Car manufacturer Model Approved seats
Opel/Vauxhall
107 2,4
108 2,4
206 2,4
207 2,4
208 2,4
301 2,4
307 2,4
308 1,2,4
308 2,4
308 SW 2,4
407 2,4
508 2,4
607 2,4
807 2,3,4
1007 2,4
2008 2,4
3008 2,4
4007 2,4
5008 2,4
Expert 2,4
Partner Tepee 2,4
Partner Tepee 2,4
Cayenne 2,4
Macan P0146 2,4
Panamera 2,4
Qoros 3 2,4
Avantime 2,4
Captur 1,2,4
Clio II 2,4
Clio III 2,4
Clio IV 2,4
Clio Grandtour 2,4
Espace III 2,4
Espace IV 2,3,4
Espace V 2,3,4
Fluence 2,4
Kadjar 2,4
Kangoo I 3
Kangoo II 2,4
Koleos 2,4
Laguna II 2,4
Laguna III 2,4
Master Combi 2,4
Megane I 2,4
Megane II 2,4
Megane III 2,4
Megane Grandtour 2,4
Modus 2,4
Grand Modus 2,4
Scenic II 2,4
Scenic III 2,4
Grand Scenic II 2,4
Grand Scenic III 2,4
Talisman 2,4
Twingo I 2,4
Twingo II 2,4
Twingo III 2,4
Vel Satis 2,4
Zoe 1,2,4
Ghost 2,4
Phantom 2,4
9-Mar 2,4
40671 2,4
Alhambra 2,3,4
Altea 2,4
Arosa 2,4
Cordoba (Vario) 2,4
Exeo 2,4
Car manufacturer Model Approved seats
Mitsubishi
Nissan
Renault
Qoros
Porsche
Peugeot
Rolls-Royce
Saab
Seat
The seat could not fit all seating positions at a stature of 135cm
Ibiza 2,4
Leon 2,4
Mii 2,4
Toledo 2,4
Citigo 2,4
Fabia 2,4
Fabia 2,4
Octavia 2,4
Octavia 1,2,4
Rapid 2,4
Roomster 2,4
Roomster 2,4
Superb 2,4
Superb 2,4
Yeti 2,4
Forfour 2,4
Fortwo 1
Forester 2,4
Impreza 2,4
Legacy 2,4
Outback 2,4
Trezia 2,4
Tribecca 2,4
WRX STI/WRX 2,4
Alto 2,4
Celerio 2,4
Grand Vitara 2,4
Ignis 2,4
Kizashi 2,4
Liana 2,4
Splash 2,4
Swift 2,4
SX4 2,4
SX4 S-Cross 2,4
Vitara 2,4
Wagon R+ 2,4
Inica Vista 2,4
Model S 2,3,4
Model S 2,4
Auris 2,4
Auris 2,4
Avensis (Verso) 2,4
Avensis Sedan 2,4
Avensis Touring Sports 2,4
Aygo 2,4
Aygo 2,4
Camry 2,4
Corollo (Verso) 2,4
Corollo 2,4
Land Cruiser 2,4
Previa 2,4
Prius 2,4
RAV 4 2,4
RAV 4 2,4
Urban cruiser 2,4
Yaris (Verso) 2,4
Verso 2,4
Verso-S 2,4
Amarok 2010 2,4
Beetle 1998 2,4
Bora 1998 2,4
Caddy 2000 2*,4*
Caddy 4 2,4
EOS 2,4
Fox 2,4
Golf IV 2,4
Golf V 2,4
Golf VI 2,4
Golf VII 2,4
Golf Sportsvan 2,4
Jetta 2,4
Lupo 2,4
Passat 2,4
Passat B8 Saloon 2,4
Passat B8 Estate 2,4
Phaeton 2,4
Polo 2,4
Scirocco 2,4
Sharan 2,3,4
T4 Multivan/Caravelle 2,4
T5 Multivan/Caravelle 2,4
Tiguan 2,4
Touareg 2,4
Touran 2,4
Touran 2,3,4,5,7
Up 2,4
C 30 2,4
C 70 2,4
S 40 2,4
S 60 2,4
S 70 2,4
S 80 2,4
V 40 2,4
V 40 2,4
V 50 2,4
V 60 2,4
V 70 2,4
XC 60 2,4
XC 70 2,4
XC 90 2,4
XC 90 2,4
Car manufacturer Model Car manufacturer Model
Approved seats Approved seats
Volkswagen
Volvo
Skoda
Smart
Subaru
Suzuki
Tata
Tesla
Toyota

24 25
LISTA DE AUTOMÓVILES:
Algunos asientos de otros vehículos pueden ser
ATENCIÓN: Infórmese de la legislación de tráfico
vigente en el país por el que circule. Puede restringir
el uso de su sistema de retención infantil.
E
1
1
3
3
2
2
4
4
3
5
7
147 2,4
156 2,4
159 2,4
Giulietta 2,4
Mito 2,4
A1 2,4
A2 2,4
A3,S3 2,4
A3,S3 2,4
A3 sportback 2,4
A3 cabrio 2,4
A4,S4,RS4 1,2,4
A4 avant 2,4
A4,S4,RS4 1,2,4
A4 avant 1,2,4
A4 cabrio 1,2,4
A4 imo 1,2,4
A4 avant 1,2,4
A5,S5 1,2,4
A5 sportback 1,2,4
A5 cabrio 2,4
A6.S6,RS6 2,4
A6,S6,RS6 1,2,4
A7 2,4
A8,S8 2,4
Q3 1,2,4
Q5 1,2,4
Q7 1,2,4
Q7 1,2,4
TT 1,2,4
1 serie 2,4
2 serie active tourer 2,4
2 serie gran tourer 2,4
3 serie 2,4
4 serie gran coupe 2,4
5 serie 2,4
6-serie 2,4
7 serie 2,4
7 serie 2,4
i3 2,4
Mini 2,4
Mini Clubman 2,4
Mini Clubman 1,2,4
Mini Countryman 2,4
X1 2,4
X1 2,4
X3 2,4
X5 2,4
X5 2,4
X6 2,4
Z4 2015 1Aveo 2,4
Aveo 2,4
Captiva 2,4
Cruze 2,4
Epica 2,4
Kalos 2,4
Lacetti 2,4
Malibu 2,4
Matiz 2,4
Nubira 2,4
Orlando 2,4
Alfa Romeo
BMW
Audi
Chrevolet
Car manufacturer Model Approved seats
B-max 2,4
C-max 2,4
Ecosport 2,4
Fiesta 2,4
Focus 2,4
Focus 2,4
Fusion 2,4
Galaxy 2,4
Galaxy 2,4
Galaxy 2,4
Grand C-max 2,4
Ka 2,4
Kuga 2,4
Mondeo 2,4
Mondeo 2,4
S-max 2,4
S-max 2,4
Tourneo Connect 2,4
Tourneo Courier 2,4
Transit 2,4
Accord 2,4
City 2,4
Civic 2,4
CR-V 2,4
CR-V 2,3,4
CR-Z 2,4
FR-V 2,4
Insight 2,4
Jazz 2,4
Legend 2,4
Stream 2,4
Accent 2,4
Coupe 2,4
Elantra 2,4
Getz 2,4
H1/iMax/i800/H300 2,4
i10 2,4
i20 2,4
i20 2,4
i30 2,4
i40 2,4
iX20 2,4
iX35 2,4
iX55 2,4
Matrix 2,4
Santa Fe 2,4
Sonata 2,4
Terracan 2,4
Tucson 2,4
Tucson 2,4
Veloster 2 2,4
S-type 2,4
X-type 2,4
XE 2,4
XF 2,4
XJ 2,4
Cherokee 2,4
Renegade 2,4
Car manufacturer Model
Approved seats
Honda
Hyundai
Jaguar
Jeep
Spark 2,4
Trax 2,4
300 CC 2,4
Dodge Caliber 2,4
Dodge Nitro 2,4
Dodge RAM 2,4
Jeep Commander 2,4
Jeep Grand Cherokee 2,4
Jeep Wrangler 2,4
PT cruiser 2,4
Sebring 2,4
Voyager 2,4
Berlingo 1,2,4
Berlingo Multispace 2,4
C1 2,4
C1 2,4
C2 2,4
C3 2,4
C3 Picasso 2,4
C4 2,4
C4 Aircross 2,4
C4 Cactus 2,4
C4 Picasso 1,2,3,4
C4 Picasso 2,3,4
C4 Grande Picasso 1,2,3,4
C4 Grande Picasso 2,3,4
C5 1,2,4
C6 2,4
C8 2,3,4
C-Elysée 2,4
DS3 2,4
DS4 2,4
DS5 2,4
Jumpy 2,4
Nemo 2,4
Xsara Picasso 2,4
Dokker 2,4
Duster 2,4
Lodgy 2,3,4
Logan MCV 2,4
Logan 2 MCV 2,4
Sandero 2,4
Sandero 2 2,4
Sirion 2,4
500 2,4
500 L 2,4
500 X 2,4
Bravo 2,4
Croma 2,4
Doblò 2,4
Fiorno / Qubo 2,4
Freemont 2,4
Grande Punto 2,4
Idea 2,4
Linea 2,4
Multipla 2,4
Panda 2,4
Punto 2,4
Scudo 2,4
Sedici 2,4
Stilo 2,4
Ulysse 2,4
Car manufacturer Model
Approved seats
Citroën
Dacia
Ford
Daihatsu
Fiat
Chrysler

26
Carens/Rondo 2,4
Carens 2,4
Carnival/Sedona 2,4
Cee’d 2,4
Cerato/Spectra 2,4
Magentis/Optima 2,4
Opirus/Amanti 2,4
Picanto/Morning 2,4
Rio/Pride 2,4
Sorento XM 2,4
Sorento UM 2,4
Sportage 2,4
Soul AM 2,4
Soul PS 2,4
Soul EV 2,4
Venga 2,4
Delta 2,4
Musa 2,4
Phedra 2,4
Thema 2,4
Ypsilon 2,4
Discovery 2,4
Discovery Sport 2,4
Freelander 2,4
Range Rover 2,4
Range Rover Evoque 2,4
Range Rover Sport 2,4
CT 2,4
GS 2,4
IS 2,4
IS 2,4
LS 2,4
LX 2,4
NX 2,4
RX 2,4
Ghibli 2,4
2 2,4
2 2,4
3 2,4
3 2,4
5 2,4
6 2,4
6 2,4
CX-3 2,4
CX-5 2,4
CX-7 2,4
CX-9 2,4
Premacy 1 2,4
A class W 168 2,4
A class W/C 169 2,4
A class W 176 2,4
B class T 245 2,4
B class W 246 2,4
C class C 205 2,4
C class W/S 203 2,4
C class W/S 204 2,4
C class W 205 2,4
Citan 2,4
CL C 215 2,4
CL C 216 2,4
Car manufacturer Model
Lexus
Maserati
Mazda
Mercedes
Approved seats
Kia
Lancia
Land Rover
The car models listed on the list do not fully
guarantee that your car has an ISOFIX
configuration.Before purchasing this product,
please check if your car is equipped with the
ISOFIX .If your car is small, such as a convertible
or two-door car, the head space will be relatively
limited, which may prevent the product from
fully extending.
this child seat.
legislation of the country in which you are driving. The use
of your child restraint system may be restricted.
Certains sièges d’autres véhicules peuvent également
ATTENTION : Renseignez-vous sur la législation de la
circulation en vigueur dans le pays où vous circulez. Elle
pourrait restreindre l’utilisation du système de retenue
pour enfants.
altri veicoli.
ATTENZIONE: Iinformati riguardo il codice della strada
vigente nel paese in cui circoli. Potrebbe prevedere
restrizioni sull’uso del sistema di trattenuta per bambini.
Alguns assentos de outros veículos podem ser também
ATENÇÃO: Informe-se sobre o código da estrada vigente
no país onde circular. Pode restringir o uso do seu sistema
de retenção infantil.
GB
FR
IT
PT
Kissingbaby
Meihu Village, Henghe Town,Cixi City, Ningbo,China
NINGBO KANGXIN CHILDREN PRODUCT CO.,LTD
