1
DOOR AND PANEL PARTS
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
9−07 Litho in U.S.A. (els) Part No. W10163054 Rev. A
UNDERCOUNTER
DISHWASHER
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10078153 Instructions,
Installation
W10084091 Guide, Use & Care
Spanish
W10111124 Energy Guide
W10084169 Guide, Use & Care
English
W10082651 Tech Sheet
2 Arm, Hinge
8534854 Left
8534853 Right
3 8564886 Stiffener, Door
4 8542577 Insulation, Door
5 Access Panel
8573255 Black
6 Panel, Full Front
(Includes Items
4, 11 & 12)
W10077995 Black
W10137620 Stainless
7 Toe Panel
(Includes #13)
8573286 Black
8 302868 Screw
9 304392 Screw
10 3400071 Screw
11 Nameplate
W10021860 Black
W10021850 Stainless
12 2004333 Nut
13 8269016 Clip, Ground

CONTROL PANEL PARTS
2
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 Console Assembly
(Includes Insert)
W10084152 Black
2 8268540 Spring, Handle
3 8546546 Clip, BI−Metal
4 3400412 Screw
5 8524471 Actuator, Latch
6 661663 Bi−Metal
8 3369051 Screw
9 Handle, Latch
8269117 Black
10 8524476 Bolt, Latch
11
W10084142 Control,
Electronic
12 8269209 Switch, Door

DOOR AND LATCH PARTS
3
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3369051 Screw, Door
2 8281217 Screw
3
W10084288 Inner Door
Mastic Assembly
(Also Order
Item 6)
4
W10077883 Inlet, Air
5 8572583 Vent Assembly
(Also Order
Item 6)
6 8269259 Gasket, Vent
7
W10077877 Deflector, Vent
(Also Order
Item 6)
8
W10077882 Dispenser,
Assembly
9 8269258 Seal, Front
10 8545608 Harness, Vent
Motor
11 8574160 Seal, Side
12 8573176 Wiring Harness
13 8281154 Screw
14 8535660 Seal,
Console/door
15 8535637 Bracket,
Dispenser
16 8531865 Shield,
Dispenser
17
W10077881 Knob, Rinse Aid

LOWER WASHARM AND STRAINER PARTS
4
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 W10077965 Wash Arm Assembly
2
W10077899 Cap, Internal
Rear Feed
(Also Order
Item 3)
3 8268340 Seal, Sprayarm
4
W10077898 Hub, Lower
Sprayarm
(Also Order
Item 3)

HEATER PARTS
5
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 8537057 Heater Element
Assembly
(Also Includes
Item 2)
2 717273 Washer, Heater
Element
3 8268548 Nut, Heater
Element
4 3400931 Retainer, Spring
Grip
NOTE:
If heater element is
removed, it must be replaced.

FILL, DRAIN AND OVERFILL PARTS
6
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 8268892 Lever, Overfill
Switch
2 8531412 Hose, Inlet
3 8531325 Water Inlet
(Also Order
Item 4)
4 8531323 Gasket
5 8531327 Nut, Inlet
(Also Order
Item 4)
6 371505 Clamp, Hose
7 8563405 Fill Valve
Assembly
8 304392 Screw
9 8268909 Switch, Overfill
Control
10 8545946 Standpipe,
Overfill
(Includes Item 11)
11 8531743 Gasket, Flat
12 9741998 Nut, Standpipe
13
W10077871 Float & Retainer
Assembly
14 8269297 Miscellaneous
Parts Bag
(Includes 2 Screws
& 2 Hose Clamps)
15 356138 Clamp, Hose
16 8531022 Drain Loop
with Check Valve

TUB AND FRAME PARTS
7
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054

TUB AND FRAME PARTS
8
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 W10084283 Tub Assembly
2 3400072 Screw
3
W10112096 Door Seal
4
W10082838 Plug Tub
5 9743002 Gasket, Bracket
Mounting
6 8269110 Seal, Cabinet
7 8573061 Strain Relief
8 8270021 Mount, Door
Balance
9 3367670 Screw
10 8269145 Bracket,
Undercounter
11 3400074 Screw
12 3370389 Screw
13 8268977 Wheel Leg
14 8524584 Leveler, Leg
15 8524474 Wheel, door
Balance
16 8270020 Spring, Door
Balance
17
W10078083 Wheel & Mount
Assembly
(Also Order #5)
18 3400892 Screw
19 8268991 Cover, Terminal
Box
20 8535568 Link, Door
Balance
21 304666 Retainer, Push
23 8573241 Shield, Sound
24 9742648 Bracket,
Thermostat
25 661566 Thermostat
26 8580309 Strike, Latch
27 3378128 Washer,
Pronged Cup
28 3400014 Screw

PUMP AND MOTOR PARTS
9
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054

PUMP AND MOTOR PARTS
10
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 8534952 Accumulator Assy
2 8283527 Shield, Motor
3 3400069 Screw
4 8572618 Sump With Seal
5 8268375 Check Valve, Sump
6
W10083957 Chopper Assembly
7 9741232 Screw
8 8531857 Protector, Inlet
9 8535760 Motor Assembly
10 3400217 Screw
11 8268391 Screen, Separation
12
W10084107 Sump & Motor
Assembly
(Includes
Item 13)
13 8269524 Tab, Sump
14 8533949 Nut
15 661662 Pump, Drain
16 8531019 Volute, Back
(Also Order
Items 21 & 26)
17 8269144 Hose, Drain
18 8535759 Motor
19 8268397 Seal, Volute
20 8531017 Impeller Kit
(Also Order
Item 26)
21 8268403 Face Seal Assembly
(Also Order
Item 26)
22 356138 Clamp, Hose
23
W10082647 Optical Water
Indicator
24 8535474 Capacitor
25 8534946 Shield,
Capacitor
26 8531018 Washer

UPPER RACK AND TRACK PARTS
11
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 8539234 Dishrack, Upper
2
W10077844 Clip, No−Flip
3
W10078214 Mount, Wheel
Stationary
4 3385089 Track, Rack
5
W10082860 Stop, Track
6 8539110 Handle, Dishrack

UPPER WASH AND RINSE PARTS
12
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 W10077896 Feed Tube
Assembly
(Also Includes
Item 3)
2 8533889 Screw
3 8557720 Sprayarm, 3rd
Level
4
W10118464 Cover, Screw
5
W10082867 Mount
6
W10082833 Manifold
7
W10082832 Hanger
8 8268433 Seal, Sprayarm
9
W10077923 Nozzle−Feed
10
W10082841 Sprayarm

LOWER RACK PARTS
13
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION
1 8539263 Lower Rack
3
W10082868 Wheel & Transport
Assembly
4 8562043 Basket,
Silverware
(Includes Item 5)
5 8519662 Lid, Basket
Center
6 8519589 Tinerow
7 8531314 Retainer, Tinerow

OPTIONAL PARTS (NOT INCLUDED)
14
For Models: KUDC03ITBL2, KUDC03ITBS2
(Black) (Stainless)
W10163054
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
ACCESSORIES
Side Panel Kits
8171656 White
8171657 Black
8171658 Biscuit
8171659 Stainless Steel
Custom Panel & Trim Kit
8212489 Black
Moisture Barrier Kit
4396277 Kit
Drain Hose
3385556 12 Ft.
Vinyl Touch−Up (4 oz.)
676453 White
676455 Grey
4396853 Silver Atlantis
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392899 Biscuit
4396603 Meteorite
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
285006 Superior Black
4392901 Biscuit
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit
POWER CORD KIT
4317824 Power Cord Kit
(Includes Power
Cord & Misc.
Hardware)
ANTI−TIP KIT
8171477 Floor Mount Kit
DISHRACK REPAIR
4396838 White
4396840 Grey
4396854 Silver Atlantis
