DOOR AND PANEL PARTS
1
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
3−11 Litho in U.S.A. (ELS) (psw) Part No. W10405137 Rev. A
UNDERCOUNTER
DISHWASHER
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10321585
Instructions,
Installation
W10395349
Energy Guide
W10300929
Guide, Use & Care
English/French
W10300597
Guide, Use & Care
Spanish
W10195613
Tech Sheet/English
W10195614
Tech Sheet/French
2 Arm, Hinge
8534854 Left
8534853 Right
3
W10321449
Vapor Barrier
Assembly
4
W10316572
Screw
5 Access Panel
W10369024
Black
W10369026
White
6 Panel, Full Front
(Includes Items
4, 10, 16 & 17)
W10195873
Black
W10195872
White
W10195870
Stainless
7
W10307614
Screw
8
W10073540
Insulation
Access Panel
9 Handle Assembly
(Includes Item 7)
W10195735
Black
W10195736
White
W10195738
Stainless
10
W10195726
Stud, Mounting
11
W10319007
Light Pipe
12 Screw
W10331789
Black
W10331793
White
13 304392 Screw
14
W10194911
Bracket, Panel
Control
15 3400071 Screw
16 Nameplate
W10243392
Black
W10243393
White
W10243391
Stainless
17
W10315897
Insulation,
Front Panel
CONTROL PANEL AND LATCH PARTS
2
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION
1 Console Assembly
W10195788
Black
W10195791
White
W10195795
Stainless
2
W10195237
Clip, Control
3
W10195528
Bi−Metal
4 3369051 Screw
5
W10195093
Latch Assembly
(Includes Switch)
6
W10195343
Control,
Electronic
7
W10194937
Brace, Connector
8
W10195836
Light, Status
INNER DOOR PARTS
3
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 3369051 Screw, Door
2 8281217 Screw
3
W10195604
Inner Door &
Mastic Assembly
(Also Order
Item 6)
4
W10195543
Seal−Door
Bottom
5
W10195031
Vent Assembly
(Also Order
Item 6)
6 8269259 Gasket, Vent
7
W10195032
Deflector, Vent
(Also Order
Item 6)
8
W10195174
Dispenser,
Assembly
9
W10077881
Knob, Rinse Aid
10
W10195007
Seal,
Console/Door
11
W10195290
Wiring Harness
12
W10177098
Screw
13 8535637 Bracket
Dispenser
14
W10195837
Barrier, Vapor
Door
15 3400071 Screw
16
W10319030
Shield, Dispenser
FILL, DRAIN AND OVERFILL PARTS
4
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION
1
W10195037
Lever, Overfill
Switch
2 8531412 Hose, Inlet
3
W10195536
Water Inlet
(Also Order
Items 4)
4 8531323 Gasket
5
W10213826
Nut, Inlet
(Also Order
Item 4)
6 371505 Clamp, Hose
7
W10195047
Fill Valve
Assembly
8 304392 Screw
9
W10195039
Switch, Overfill
Control
10
W10195035
Standpipe,
Overfill
(Also Order #11)
11 8531743 Gasket, Flat
12
W10195038
Nut, Standpipe
13
W10195036
Float & Retainer
Assembly
14
W10292152
Miscellaneous
Parts Bag
(Contains 2 Hose
Clamps, Screws &
2 Under Counter
Brackets)
15 356138 Clamp, Hose
16
W10195751
Drain Loop
with Check Valve
Assembly
TUB AND FRAME PARTS
5
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
TUB AND FRAME PARTS
6
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION
1
W10194904
Tub Assembly
(Also Includes
Heater Assembly)
2 3400924 Retainer, Push
3
W10300924
Seal, Door
4
W10082838
Plug, Tub
5
W10300779
Strike, Plate
6 3400014 Screw
7
W10179427
Seal, Cabinet
8 8573061 Strain Relief
9
W10084086
Door, Balance
Assembly
10 3367670 Screw
11 8269145 Bracket,
Undercounter
12 3400074 Screw
13
W10195368
Insulation,
Bottom
14 3370389 Screw
15 8268977 Wheel Leg
16 8524584 Leveler, Leg
17 3378128 Washer
Pronged Cup
18 8270020 Spring, Door
Balance
19 3400892 Screw
20 8268991 Cover, Terminal
Box
21
W10158291
Cable, Door
Assembly
22
W10292870
Protector
23 304666 Retainer, Push
24 8573240 Shield, Sound
Tub
25
W10195090
Bracket,
Thermostat
26
W10195091
Thermostat
27 Spacer, Tub/Brace
W10195630
Left
W10195631
Right
PUMP, WASHARM AND MOTOR PARTS
7
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
PUMP, WASHARM AND MOTOR PARTS
8
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION
1 8579241 Cover, Sieve
2
W10348405
Screw
3
W10311176
Cover, Outlet
4
W10208687
Sump With Seal
(Includes Items
12, 13 and
2 Hose Clamps)
5 8579298 Retainer,
Feed Tube
6 8579253 Screen
7
W10320512
Wash Arm Assembly
8
W10056426
Filter Cup,
Assembly
9 8579311 Hose, Inlet
(Includes 3 Hose
Clamps)
10
W10328224
Motor & Sump Assy.
11 8579272 Shield, Motor
12
W10348407
Screw
13 8579289 Tab, Sump
14
W10158351
Pump, Drain
15 8269144 Hose, Drain
16 8579251 Disc−Valve
Diverter
17
W10056349
Motor, Diverter
Valve
18 8269146 Hose Clamp
19
W10134017
Optical Water
Indicator
20 9741232 Screw
21
W10179455
De−Coupled Drain
Assembly
22
W10179454
Block, Mounting
UPPER WASH AND RINSE PARTS
9
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION
1 8579262 Feed Tube
Assembly
(Also Includes
Item 2)
2 8557720 Sprayarm, 3rd
Level
3 8579242 Mount
4 8579259 Manifold
5
W10324452
Sprayarm
6
W10084221
Manifold,
Turbozone
HEATER PARTS
10
For Models: KUDE48FXBL0, KUDE48FXWH0, KUDE48FXSS0
(Black) (White) (Stainless)
W10405137
Illus. Part
No. No. DESCRIPTION
1
W10195052
Heater Element
Assembly
(Also Includes
Item 2)
2 717273 Washer, Heater
Element
3 8268548 Nut, Heater
Element
4 3400931 Retainer, Spring
Grip
5
W10343251
Shield, Heater Nut
NOTE:
If heater element is
removed, it must be replaced.
