KitchenAid 720-0733A Product information sheet

720-0733A(LP)730-0733A (NG) 19000385A0
FREESTANDING OUTDOORGRILL
InstallationInstructionsand Use&CareGuide
Forquestionsaboutfeatures,operation/performance, parts,accessoriesorservice, call: 1-877-373-2301
orvisit ourwebsiteat www.Kitchenaidgrills.com
ASADORAUT NOMOPARAEXTERIORES
Instrucciones deinstalaci nyManualdeusoycuidado
Paraconsultasrespectoacaracter sticas,funcionamiento,rendimiento,piezas,accesoriososerviciotécnico,llameal: 1-877-373-2301
ovisitenuestrositiodeinternet en www.Kitchenaidgrills.com
COMPTOIRPOURGRILD’EXTÉRIEUR
AUTOPORTANT
Instructionsd’installationet Guided’utilisationet d’entretien
Pourdesquestions àproposdescaractéristiques, dufonctionnement/rendement,despièces,desaccessoiresou du service,
composerle: 1-877-373-2301
ou visiternotresiteweb www.Kitchenaidgrills.com
Tableof Contents/Índice/Tabledesmatières.................................................................................2

OUTDOORGRILL SAFETY………………………………3
INSTALLATIONREQUIREMENTS………………………....5
Toolsand Parts……………...…………………………………5
Location requirements…………………………………..…….5
ProductDimensions……………………………….………….6
GasSupplyRequirements……………………………………7
GasConnectionRequirements………………………………7
REPLACEMENTPARTS……………………………………9
ALL PRE-ASSEMBLYLIST……………...………………….12
PACKAGECONTENTSLIST…………………...……………12
INSTALLATIONINSTRUCTIONS…………………….…...…13
Freestanding OutdoorGrill Installation…………………….13
MakeGasConnection…………………………...……..……15
GASCONVERSION………………………………….............18
Toolsand PartsforGasConversion …………………....18
Conversion fromLPGastoNaturalGas………………….18
Check and Adjusttheburners………………………….……21
TABLE OFCONTENTS
OUTDOORGRILLUSE …………………………………………22
UsingYourOutdoorGrill ………………………………..….…22
UsingYourSideBurner…………………………………..……24
TIPSFOROUTDOORGRILLING ……………………….…..25
Cooking Methods ………………….………………………...….25
GrillingChart ………………………….……………………....….26
OUTDOORGRILLCARE …………………………………..…28
ReplacingtheIgniterBattery …….………………….………....28
GeneralCleaning ………………………………………..........…28
TROUBLESHOOTING .........................................................30
ASSISTANCE ……………………………………………..……30
Accessories………………………………………………………..30
WARRANTY …………………………………………….…..…….31
2
SÉCURITÉDU GRILD'EXTÉRIEUR ………………….……63
EXIGENCESD’INSTALLATION …………………………..…65
Outilsetpièces ……………...……………………………...….65
Exigencesd'emplacement ……………………………………65
Dimensionsdu produit ……………………………………...…..66
Spécificationsdel'alimentation engaz ………………..……67
Exigencesconcernantleraccordementaugaz………………68
PIÈCES DERECHANGE …………………………………...…69
Contenu du colis…………………………………………...…….73
Touslespre-assemblylistevis……………………………..…..73
INSTRUCTIONSD’INSTALLATION ……………….……...….74
Installationdugrild’extérieurautoportant …………..………..74
Raccordementaugaz …………………………............…..….76
CONVERSIONSPOURCHANGEMENTDEGAZ …….…....79
Outilsetpiècespourconversiondegaz ………….……..…...79
Conversiondepropane àgaznaturel ……………….…...…...79
Contrôleet réglagedesbrûleurs ……………………….……...82
TABLE DES MATIÈRES
UTILISATIONDU GRILD’EXTÉRIEUR …….………………...83
Utilisationdugril d’extérieur …………………………………….83
Utilisationdevotrebrûleurlatéral……………………..………...85
CONSEILSPOUR L'UTILISATIONDUGRIL
D’EXTÉRIEUR……………………………………...……….….…86
Méthodesdecuisson ……………………………...………….…86
Tableau decuissonaugril ………………………...……...….….87
ENTRETIENDU GRILD’EXTÉRIEUR ……………………...…90
Remplacementdelapiledel’allumeur ………………………..90
Nettoyagegénéral …………………………………….……….…90
DÉPANNAGE........................................................................92
ASSISTANCE……………………………………………….……92
GARANTIE…………………………………………………...…....93
ÍNDICE
SEGURIDAD DELASADORPARAEXTERIORE….......33
REQUISITOSDEINSTALACIÓN…………..………………..35
Herramientasypiezas ……………...………………...……….35
Requisitosdeubicación ……………………………...……….35
Medidasdelproducto ……………………………….………36
Requisitosdelsuministrodegas ………………………….....37
Requisitosparalaconexióndegas …………………...…….38
PIEZASDEREPUESTO ……………………………...………39
ToolslosTornillospre-ensambladoslisto………………..….42
PaqueteListaDeContenido………………….............……42
INSTRUCCIONESDEINSTALACIÓN ……………….……..43
Instalacióndelasadorautónomoparaexteriores.........….43
Conexióndelsuministrodegas ………………………46
CONVERSIONESDEGAS ……………………………..….48
Herramientasypiezasparalaconversióndegas..........….48
ConversióndegasLPagasnatural …………………………48
Reviseyregulelosquemadores ……………………...……...50
USODELASADORPARA EXTERIORES …………………...52
Cómousarelasadorparaexteriores …………………………..52
Usodelmecherolateral…... …... …...……...………...54
CONSEJOSPARA ASARALAIRELIBRE …………………..55
Métodosdecocción ………………………………………...…...55
Cuadroparaasar ……………………………………………...….56
CUIDADODELASADORPARA EXTERIORES ………….….58
Cómoreemplazarlabater adelencendedor …………………58
Limpiezageneral ………………………………………………….58
SOLUCIÓNDEPROBLEMAS.................................................60
ASISTENCIA………………………………………………..……..60
GARANTÍA …………………………………………………..…....61

OUTDOORGRILL SAFETY
IMPORTANT: Thisgrill ismanufacturedforoutdooruseonly.Forgrillsthataretobeusedatelevationsabove2,000ft(609.6m)
orificeconversionisrequired. See “GasSupplyRequirements”section.Itistheresponsibilityoftheinstallertocomplywiththe
minimuminstallationclearancesspecifiedonthemodel/serialrating plate. Themodel/serialratingplateforfreestandingmodelscan
befound ontheleft-handcabinetdoor.
3
DANGER
Ifyousmell gas:
1. Shutoff gastotheappliance.
2. Extinguishanyopenflame.
3. Openlid.
4.Ifodorcontinues, keepawayfrom
theappliance andimmediatelycall
yourgas supplieroryourfire
department.
WARNING
1.Donotstoreoruse gasolineorother
flammableliquidsorvaporsinthe
vicinityofthisoranyotherappliance.
2. AnLPcylindernotconnectedforuse
shall notbestoredinthevicinityofthis
oranyotherappliance.
StateofCaliforniaProposition65Warnings:
WARNING:ThisproductcontainsoneormorechemicalsknowntotheStateofCaliforniatocausecancer.
WARNING:ThisproductcontainsoneormorechemicalsknowntotheStateofCaliforniatocausebirthdefectsorother
reproductiveharm.
IntheStateofMassachusetts,thefollowinginstallationinstructionsapply:
nInstallationsandrepairsmustbeperformedbyaqualifiedorlicensedcontractor,plumber, orgasfitterqualifiedorlicensed
bytheStateofMassachusetts.
nIf using aballvalve,itshallbeaT-handletype.
nAflexiblegasconnector,whenused, mustnot exceed3feet.

IMPORTANT SAFETYINSTRUCTIONS
WARNING: Toreducetheriskoffire, electricalshock,
Injurytopersons, ordamagewhenusingtheoutdoorcooking
gasappliance, followbasicprecautions,includingthefollowing:
nDonotinstallportableorbuilt-inoutdoorcookinggas
appliancesinoronarecreationalvehicle,portable
trailer, boatorinanyothermoving installation.
nAlwaysmaintainminimumclearancesfrom
combustibleconstruction, see “Location
Requirements”section.
nTheoutdoorcookinggasapplianceshallnotbelocated
underoverhead unprotectedcombustibleconstruction.
nThisoutdoorcooking gasapplianceshallbeusedonly
outdoorsandshallnotbeusedinabuilding, garage,or
anyotherenclosedarea.
nKeepanyelectricalsupplycordandfuelsupplyhose
awayfromanyheatedsurfaces.
nKeepoutdoorcookinggasapplianceareaclearand
free fromcombustiblematerial,gasolineandother
flammablevaporsandliquids.
nDonot obstructtheflowofcombustionand ventilation
air. Keeptheventilation openingsofthecylinder
enclosurefree and clearfromdebris.
nOpenthecabinet doorandinspectthegascylindersupply
hosebeforeeachuseoftheoutdoorcookinggasappliance.
Ifthehoseshowsexcessiveabrasionorwear,oriscut, it
MUSTbereplacedbeforeusingtheoutdoorcookinggas
appliance.Contactyourdealerand useonlyreplacement
hosesspecifiedforusewiththeoutdoorcookinggas
appliance.
nVisuallycheck theburnerflames.
Theyshouldbeblue.Slight
yellowtippingisnormalfor
LPgas. Theflamesshould
Beapproximately1"(2.5cm)high.
nCheck andcleanburner/venturitubeforinsectsand
insectnest.Acloggedtubecanlead tofireunderthe
outdoorcookinggasappliance.
nTheLPgassupplycylindertobeusedmustbe:
-constructedandmarkedinaccordancewiththe
Specification forLPGascylindersoftheU.S.
Department ofTransportation (DOT)orthe
NationalStandardof Canada, CAN/CSA-b339,
Cylinders, Spheres, andTubesforTransportation
ofDangerousGoods;andCommission.
-providedwithalistedoverfillingpreventiondevice.
-providedwithacylinderconnectiondevice
compatiblewiththeconnectionforoutdoorcooking
gasappliances.
nAlwayscheck connectionsforleaks eachtimeyou
connectanddisconnecttheLPgassupplycylinder.
See “Installation Instructions”section.
nWhentheoutdoorcookinggasapplianceisnot in
use,thegasmustbeturnedoffatthesupplycylinder.
nStorageofanoutdoorcookinggasapplianceindoors
ispermissibleonlyifthecylinderisdisconnected
andremovedfromtheoutdoorcooking gasappliance.
nCylindersmustbestoredoutdoorsandout of the
reachof childrenandmustnotbestoredina
building,garage, oranyotherenclosedarea.
nThepressureregulatorandhoseassemblysupplied
withtheoutdoorcooking gasappliancemustbe
used. Areplacementpressureregulatorand hose
assemblyspecifictoyourmodelisavailablefrom
youroutdoorcookinggasappliancedealer.
nGascylindermustincludeacollartoprotectthe
cylindervalve.
nForappliancesdesignedtouseaCGA791
Connection:Placeadustcapon cylindervalve
outletwheneverthecylinderisnot inuse.Only
installthetypeofdustcaponthecylindervalve
outletthatisprovidedwiththecylindervalve.Other
typesofcapsorplugsmayresultinleakageof
propane.
Ifthefollowinginformationisnot followed
exactly,afirecausingdeathorseriousinjurymayoccur.
nDonotstoreaspareLPgascylinderunderornear
thisoutdoorcookinggasappliance.
nNeverfillthecylinderbeyond80percentfull.
SAVE THESE INSTRUCTIONS
4

INSTALLATIONREQUIREMENTS
ToolsandParts
Gathertheserequiredtoolsand partsbeforestartinginstallation.
Read and followtheinstructionsprovidedwithanytoolslisted
here.
LocationRequirements
PartsSupplied
nGaspressureregulator/hoseassemblysetfor11”WCPLP
gas
nRightsideshelfwithsideburner
nLeftsideshelf
nSideburnercontrolknob
n“AA”Battery(1)
nWarming rack
nCooking grid
nSideburnercookinggrid
nNaturalgasorificeforsideburner
PartsNeeded
n20lbLPgasfueltank-approximately18”(45.7cm)height.
PartsNeededforConversion toNatural Gas
nNaturalgasconversionkitPartNumber710-0003. See
“Assistance”sectiontoorder.Theconversion kitincludes:
nNaturalgasregulator4" W.C.(marked “NaturalGas
Regulator”)
n10ft(3.0m)Naturalgashosewithquick connector
n5.9"(150mm)Naturalgasregulatorhose
n6mmnutdriver
n6mmwrench
nHexkey
nGaslineshutoffvalve
n1/2" malepipethread nippleforconnectiontopressure
regulator.
nLPgas-resistantpipe-jointcompound
nCSA design-certifiedoutdoorflexiblestainless steel
applianceconnector(4-5ft[1.2-1.5m])orrigidgassupply
lineasneeded.
Select alocationthatprovidesminimumexposuretowind
and trafficpaths. Thelocation shouldbeawayfromstrong
draftareas.
Donot obstruct flowof combustionandventilationair.
Clearancetocombustibleconstructionforgrill:
nAminimumof 24”(61cm)mustbemaintainedbetween
thefrontofthegrill hood,sidesandbackofthegrill
andanycombustibleconstruction.
nA24”(61cm)minimumclearancemustalsobe
maintainedbelowthecooking surface, andthegrill
shallnotbeusedunderoverhead combustible
construction.
5
Toolsneeded
nPhillipscrewdriver
nWrenchorpliers
nPipewrench
nScissorsorcutting pliers
(toremovetiedowns)
nNoncorrosiveleak-
detectionsolution
Rotisserie(accessory)*
If youequipyourgrillwitharotisserie,a6" (15.2cm)
minimumclearanceisneededfortherotisseriemotor.
Agrounded,3-prongoutletlocatedtotheleft ofthegrillis
required.
*See “Assistance”section toorder.

Product Dimension
523/8"(1330cm)
28"(71.12cm)
485/8"(123.5cm)
125/8"(32cm)
125/8"(32cm)
6
Themodel/serialnumberrating plateislocatedontheinsideofthe
left cabinetdoor.See thefollowingillustration.
A.Model/serialnumberplate
A

IMPORTANT: Grillmustbeconnectedtoaregulatedgassupply.
Refertothemodel/serialratingplateforinformationonthetype
of gasthatcanbeused.If thisinformationdoesnotagree with
thetypeofgasavailable,check withyourlocalgassupplier.
GasConversion:
Noattemptshallbemadetoconvert thegrillfromthegas
specifiedonthemodel/serialrating plateforusewithadifferent
gastypewithoutconsultingtheserving gassupplier. The
conversionkitsuppliedwithgrill mustbeused. See “Gas
Conversions”sectionforinstructions.
GasPressureRegulator
Thegaspressureregulatorsuppliedwiththisgrillmustbeused.
Theinlet(supply)pressuretotheregulatorshouldbeasfollows
forproperoperation:
LPGas:
Operatingpressure: 11"(27.9cm)WCP
Inlet(supply)pressure: 11" to14"(27.9cmto35.5cm)WCP
NaturalGas:
Operatingpressure: 4"(10.2cm)WCP
Inlet(supply)pressure: 7" to14"(17.8cmto35.5cm)WCP
maximum.
Contactlocalgassupplierifyou arenotsureabouttheinlet
(supply)pressure.
Observeallgoverningcodesandordinances.
IMPORTANT: Thisinstallationmustconformwithalllocalcodes
and ordinances.Intheabsenceoflocalcodes,installationmust
conformwitheithertheNationalFuelGasCode, ANSI
Z223.1/NFPA54, NaturalGasandPropaneInstallation Code,
CSA B149.1,PropaneStorageAndHandlingCode, B149.2, or
theStandardforRecreationalVehicles,ANSIA119.2/NFPA
1192 and CSAZ240RVSeriesRecreationalVehicleCodeas
applicable.
Gas SupplyRequirements BurnerRequirementsforHighAltitude
Inputratingsshownonthemodel/serialrating platearefor
elevationsupto2,000 ft (609.6m).
Forelevationsabove2,000 ft(609.6m),ratingsarereducedat a
rateof4%foreach1,000ft(304.8m)abovesealevel.Orifice
conversionisrequired.See “Assistance”sectiontoorder.
GasSupplyLinePressureTesting
Testing above1/2psi(3.5kPa)or14"(35.5cm)WCP(gauge):
Thegrill anditsindividualshutoffvalvemustbedisconnected
fromthegassupplypipingsystemduringanypressuretestingof
thatsystemattestpressuresgreaterthan1/2psi(3.5kPa).
Testing below1/2psi(3.5kPa)or14"(35.5cm)WCP(gauge)
orlower:
Thegrill mustbeisolatedfromthegassupplypipingsystemby
closingitsindividualmanualshutoffvalveduring anypressure
testingof thegassupplypipingsystemattestpressuresequalto
orless than1/2psi(3.5kPa).
Gas Connection Requirements
20lbLPGasFuel Tank
Thisgrillisequippedforusewitha20lbLPgasfueltank(fuel
tanknot supplied). Agaspressureregulator/hoseassemblyis
supplied.
Anybrand of20lbLPgasfueltankisacceptableforusewith
thegrill, providedthatitiscompatiblewiththegrill’sretention
means(tanktrayincluded).
Itisalsodesign-certifiedbyCSAInternationalforlocalLPgas
supplyorforNaturalgaswithappropriateconversion.
The20 lbLPgasfueltankmustbemountedandsecured.
DoorStyleTankTray
1.Opencabinet door.
2. Slidethetanktraylocking bracket counterclockwise90 º
and pull outthetray
A.Gaspressureregulator/hoseassembly
A
A. Tank tray locking bracket
A
7

NaturalGasConversion
Conversion must bemadebyaqualifiedgastechnician.The
qualifiedNaturalgastechnicianshall providetheNaturalgas
supplytotheselectedgrilllocation inaccordancewiththe
NationalFuelGasCodeANSIZ223.1/NFPA 54-latest edition,
and localcodes.ForconversiontoNaturalgas,theNaturalGas
Conversion Kitsuppliedwiththegrill(onsomemodels)orthe
NaturalGasConversionKitPartNumber710-0003mustbe
used. See “Assistance”sectionforinformation on ordering.
IMPORTANT: Thegasinstallation must conformwithlocal
codes, orintheabsenceoflocalcodes,withtheNationalFuel
GasCode, ANSIZ223.1/NFPA54-latestedition.
FollowinstructionsforconvertingtoNaturalgasinthe “Gas
Conversions”sectionofthismanualortheinstructionssupplied
withNaturalGasConversion Kit Part Number710-0003.
Thegassupplylineshallbeequippedwithanapprovedshutoff
valve. Thisvalveshouldbelocatedinthesameareaasthegrill
and shouldbeinalocationthatallowseaseof openingand
closing. Donotblockaccesstotheshutoffvalve. Thevalveis
forturning onorshuttingoffgastothegrill.
A.Gassupplyline
B. Shutoffvalve open”position
C. Togrill
8
A
B
C
A. Locking screw
B. Bottomcollar
C.Mounting hole
5. Slidethedrawerwiththe20lbLPgasfueltankbackintothe
cabinet.Turnthetanktraylocking bracket clockwise90ºto
tighten.
A
A. Tanktraylocking bracket
3. Placethe20lbLPgasfueltankbottomcollarintothe
mounting holeinthetanktray.
4. Tightenthelockingscrewagainstthebottomcollarof
the20lbLPgasfueltanktosecure.

74
73
02
01
06
11 10
98
02
12
15 14 13
46
43
44
47
36
63
55
36
33
36
36
58
64
66
68
67
69
54
52
51
56
07
05
35
34 53
53
53
53
03
04
49
37
38
39
40
70
48
59
57
57
50
42
41
43
45
31
30
32
20
29
23
22
25
21
27
18
16
19
28
24
26
31
60
62
65
71
72
64
17
76b
76a
76c 76e
76f
76g
76d 76
61
75
75a
REPLACEMENT PARTS

No. Part(Description) Warranty coverage
(Year) QTY No. Part(Description) Warranty
coverage
(Year) QTY
1MainLid 3 1 35 Greasebox 1 1
2MainLidscrew 3 2 36 Doorhinge 1 4
3Temperaturegaugehousing 1 1 37 Doorhandleseat 1 4
4Temperaturegauge 1 1 38 Doorhandletube 1 2
5Mainlidhandleseat,left 1 1 39 Door, left 3 1
6Mainlidhandletube 1 1 40 Door,right 3 1
7Mainlidhandleseat,right 1 1 41 Lighting rod 1 1
8Warmingrack 1 1 42 Lighting rodcover 1 1
9Cookinggridwithhole 3 3 43 Gastanktrayslide 1 2
10 Flametamer 1 4 44 Tanktraybolt 1 1
11 Mainburner 10 4 45 Gastanktrayblockpiece 1 1
12 MainburnerigniterwireA 1 1 46 Gastanktrayslidebracket, left 1 1
13 MainburnerigniterwireB 1 1 47 Tanktray 1 1
14 MainburnerigniterwireC 1 1 48 Gastanktrayslidebracket,right 1 1
15 MainburnerigniterwireD 1 1 49 Electricignitermodule 1 1
16 Mainlidbracket,right 1 1 50 Bottompanel 1 1
17 Burnerpinassembly 1 4 51 Swivelcasterwithbrake 1 1
18 Mainlidbracket,left 1 1 52 Swivelcaster 1 1
19 Regulator,LP 1 1 53 Doorhingebracket 1 4
20 Frontbaffle 1 1 54 Sidepanel, left 1 1
21 Igniterjunction wire 1 1 55 Rubbergrommet 1 1
22 MainGasvalve 1 4 56 Back panel 1 1
23 Mainmanifold 1 1 57 Caster 1 2
24 Sideburnerorificebrass
connector 1 1 58 Sidepanel, right 1 1
25 SideburnerflexgaslineA 1 1 59 Sideburnercontrolpanel,right 1 1
26 Sidemanifold 1 1 60 Sideburnerigniterwire 1 1
27 Sideburnergasvalve 1 1 61 Mainburnerbowlassembly non-
replaceable 1
28 SideburnerflexgaslineB 1 1 62 Sideburner 1 1
29 Logo 1 1 63 Sideburnerbowl assembly 1 1
30 Maincontrolpanel 1 1 64 Hooks 1 6
31 Controlknob 1 5 65 Sideburnerend cap 1 1
32 Bezel 1 4 66 Sideburnercookinggrid 3 1
33 Cartframe,front 1 1 67 Sideburnerlid 1 1
34 Doormagnet 1 2 68 Sideburnerlidhingerodpin 1 4
10

*Naturalgasconversionkit soldseparately
11
No. Part(Description) Warranty
coverage(Year) QTY No. Part(Description) Warranty coverage(Year) QTY
69 Sideburnerlidhingerod 1 2 76b NG Regulator assembly
soldseparatelyas
set with#76
1
70 Sideshelfcontrolpanel 1 1 76c Truss Head Screw
withlock 2
71 Sideshelf endcap 1 1 76d Flat washer 2
72 Sideshelf 1 1 76e 6 mmNut driver 1
73 Cartbasket 1 1 76f Hexwrench 1
74 Tankheatshield 1 1 76g 6mmwrench 1
75 NG orificepack 1 1 77 Preassembly
hardwarepack 1 1
75a SideburnerNG orifice
(1.7) 1 1 78 Grillcover 1 1
76 NGconversionkit(710-
0003) soldseparatelyas set 179 Manual 1 1
76a NGGasHosewithQuick
Connectorassembly
soldseparatelyas
set with#76 1

Controlknob
PackageContentsList
Sideburnerassembly SideShelf Assembly
Cookinggridwithhole Warmingrack
All Pre-AssembledScrewsList
12
Sort Description Size Quantity
11/4-inTrussHead Screw 1/4*12mm 10
2 5/32-inTrussHead Screw 5/32*10mm 2
35/32-inTrussHead Screw 5/32*12mm 4
4 Locking nuts 5/32 2
5 3/16-inFlat washer 4
6M4TrussHead Screwwithlocking
washer M4*8mm 2
7 1/4-inflatwasher 2

INSTALLATIONINSTRUCTIONS
FreestandingOutdoorGrill Installations
4.Loosen2screwson thegrillsidepanelbut notremovethem
completelyandremove1screwonthegrill controlpanel.
C
13
Unpack Grill
1. Removeallpackagingmaterialsand removegrillfromthe
shipping base.
2.Movegrillclosetodesiredoutdoorlocation.
3.Openthegrillhood.
Remove Packaging MaterialInsidetheGrill
1. Useautilityknifetocutyellowstrapsandpackingtapeto
openboxfromtop and removetheboxes
2. Removethewarmingshelfandgrillgratesfrominsidethe
grill andremovethepackageinsidethefirebox.
3. Removefoamblockandwrapfrominsidethegrill.
AttachRightSideShelfwithSideBurner
1. Unpackrightsideshelfwithsideburner.
2.Opengrilllid.
3. Remove3screwsfromthesideofthesideburnershelf.
A
A. Side burnerscrews
A
B
A. Grillcontrolpanelscrews
B. Grillside panelscrew
B
A
5.Attachthetop of sideshelftothegrill(A)byinsertingthe3
screwsremovedinStep3intothesideshelf frominsidethe
grillhood andtighten. See illustrationinStep7.
6.Attachthebottomof sideshelf tothesidepanel(B)of the grill
bytightenthe2screwsloosenon thegrillsidepanelin
Step4.Tightenthescrews. See illustrationinStep7.
7.Attachthesideshelftothecontrolpanel(C)byinserting the
screwremovedfromthegrillcontrolpanelinstep4.Tighten
thescrew.

11.Attachsideburnerorificebrassconnectortosideburner
tubewithpreassembledbrass screwthentightenby
wrench.
12.Connectelectricalplugsonundersideofsideburner.
13.Insertthevalvestemintotheknobandpushknobinto
place.
14
A. Side burnerorificebrassconnector
B. Side burnertube
A. Controlknob
A.Electricalplug fromgrill
B.Sideburnerignition pin
14.Theigniterbatteryisnotfactoryinstalled. A’’AA’’
sizealkalinebatteryislocatedintheaccessory
boxon thegrillgrate.Installbatteryatthistime
following theinstructionsin “Replacingthe
igniterBattery’’ section.
A
A. Controlknob
8. Removethe2screwsfromsideburnervalveassembly. See
illustrationstep10.
9. Pushthevalvestemout throughtheopening inthefront ofthe
sideburnershelf, lininguptheholesinthesideburnervalve
assemblywiththeopeningsonthesideburnershelf.See
illustrationinstep10.
10.Attachthesideburnervalveassemblytothesideburnershelf
withthescrewsremovedinstep8.
BA
A
B
A

6.Attachthebottomofthesideshelftothesidepanel(A)of
thegrill bytightenthe2screwsloosenonthegrillside
panelinstep4. See illustrationinstep7.
7.Attachthesideshelftothecontrolpanel(C)byinserting
thescrewremovedfromthegrillcontrolpanelinstep4.
Tightenthescrew.
MakeGas Connection
B
C
A
1.Replacethegrill grates.
2.Placewarmingshelfonbracketsasshown.
15
A
B
AttachLeftSideShelf
1.Unpack left sideshelf.
2.Opengrilllid.
3.Remove3screwsfromthesideofthesideshelf.
4.Loosen2screwsonthegrill sidepanelbutnotremove
themcompletelyand remove1screwonthegrillcontrol
panel.
A. Grillcontrolpanelscrews
B. Grillside panelscrew
5.Attachthetop ofthesideshelftothegrill(B)byinserting
the3screwsremovedinStep3intothesideshelffrom
insidethegrillhoodandtighten. See illustrationinStep7.
CompleteAssembly
A. Warming shelfbracket
B. Warming rack
AttachCartBasket
1.Remove2screwsonthesidepaneland 2screwson
thebottompanel.
2.Attachbaskettothesidepanelandbottompanelby
usingthescrewsremovedinstep1.
NOTE:IfgrillistobeconvertedtoNaturalgas,follow
instructionsinthe “GasConversions”section.
20 lbLPGasFuelTank
AB

LPGas:
IMPORTANT: A20lbLPgasfueltankmust bepurchased
separately.
IMPORTANT: Thegaspressureregulator/hoseassembly
suppliedwiththegrillmustbeused.Replacement gaspressure
regulator/hoseassemblyspecifictoyourmodelisavailablefrom
youroutdoorgrilldealer.
DoorStyleTankTray
1.Opencabinet doors.
2. Slidethetanktraylocking bracket counterclockwise90º
and pull outthetray.
To Connectthe20lbLPGasFuelTank:
1.Check that the20 lbLPgasfueltankisinthe “Off”
position.Ifnot, turnthevalveclockwiseuntil itstops.
2. Checkthatthe20lbLPgasfueltankvalvehastheproper
type-1externalmalethread connectionsperANSI Z21.81.
3. Checkthattheburnercontrolknobsareinthe “Off”
position.
4. Removeanydebrisandinspectthevalveconnections,
port,andgaspressureregulator/hoseassemblyfor
damage.
NOTE: AlwayskeeptheLPcylinderat90°(upright)
orientationtoprovidevaporwithdrawal.
5. Usingyourhand,turnthegaspressureregulator/hose
assemblyclockwisetoconnect tothe20lbLPgasfuel
tankasshown.
Hand tightenonly. Useof awrenchcoulddamagethe
quick coupling nut.
A.Gaspressureregulator/hoseassembly
B. 20lbLPgasfueltank
A
B
Makesurethatthecylindervalveconnectiondevice
properlymateswiththeconnectiondeviceattachedto
theinlet of thepressureregulator.
6.Openthetankvalvefullybyturningthevalve
counterclockwise.Waitafewminutesforgastomove
through thegasline.
7.Beforelighting thegrill,testallconnectionsbybrushing
onanapprovednoncorrosiveleak-detection solution.
Bubbleswillshowaleak.
8.If aleakisfound,turnthetankvalveoff and do notuse
thegrill. Contactaqualifiedgastechniciantomake
repairs.
9.Goto “CheckandAdjusttheBurners”section.
A. Tanktraylocking bracket
3. Placethe20lbLPgasfueltankbottomcollarintothe
mounting holeinthetanktray.
4. Tightenthelockingscrewagainstthebottomcollarof
the20 lbLPgasfueltanktosecure.
A
B
C
A. Locking screw
B. Bottomcollar
C.Mounting hole
5.Slidethetanktraywiththe20lbLPgasfueltankbackinto
thecabinetandlockthelockingbracket.
A
16

To Disconnectthe20 lbLPGasFuelTank:
1. Checkthattheburnercontrolknobsareinthe “Off”position
and thegrilliscool.
2. Checkthatthe20lbLPgasfueltankisinthe “Off”position.
Ifnot, turnthevalveclockwiseuntil itstops.
3. Usingyourhand,turnthegaspressureregulator/hose
assemblycounterclockwisetodisconnect tothe20lbLPgas
fueltankasshown.
Hand loosenonly. Useof awrenchcoulddamagethequick
coupling nut.
A.Gaspressureregulator/hoseassembly
B. 20lbLPgasfueltank
AB
4. Placedustcaponcylindervalveoutlet wheneverthe
cylinderisnotinuse.Onlyinstallthetypeofdustcapon
thevalveoutletthat isprovidedwiththecylindervalve.
Othertypesofcapsorplugsmayresult inleakageof
propane.
17

GASCONVERSIONS
ToolsandPartsforGas Conversion
Gathertherequiredtoolsandpartsbeforestartinginstallation.
Read and followtheinstructionsprovidedwithanytoolslisted
here.
Partssupplied
nNaturalgasorifices
Partsneeded
nNaturalgasconversion kit Part Number710-0003.See
n“Assistance”sectiontoorder.Theconversionkitincludes:
nNaturalgasregulator4" W.C.(marked “NaturalGas
nRegulator”)
n10 ft(3.0m)Naturalgashosewithquickconnector
n5.9"(150mm)Naturalgasregulatorhose
n6mmnutdriver
n6mmwrench
nHexkey
IMPORTANT:Gasconversionsmustbedonebyaqualified
installer.Beforeproceeding withconversion,shutoff thegas
supplytotheappliance.
1. Turnoff themaingassupplyvalve.
2. Disconnect20 lbLPgasfueltank(ifpresent).
3. Turnoff allburnercontrolvalves.
4. Removethe20lbLPgasfueltank(if present)fromthe
grill cart.
5. UseanadjustablewrenchtoremovetheLPregulator
fromthemanifold.
ConversionfromLPGas toNaturalGas
Installationoftheregulator
6. UseanadjustablewrenchtoinstalltheNaturalgas
regulatorhosetothemanifoldandsecure.Attachthe
Naturalgasregulatortothesidepanelinsidethegrill
cartwiththetwoscrewsthatarepreassembledonthe
regulator.
Toolsneeded
nPhillipscrewdriver
nPipeWrench
nAdjustablewrench
n6mmsocketand
wrenchor6mmnut
driver
nThinflat-blade
screwdriver
nPliers
nPipethread sealant
certifiedforLPgas
18

ChangeGrillMain Burner ValveOrifices
3.Usea6mmsocketandwrenchor6mmnutdriverto
removethebrassorificefromtheend ofgasvalve. The
mainburnerNGorificeislocatedbehindtheLPorifice,so
noadditionalorificeneedstobeinstalled.
1.Removethegratesandflametamers.
2.Removethe2screwsandcotterclipthatholdtheburnerin
place. Setthescrewandclipaside.Removetheburner
fromthegrillbyliftingtheburnerout.
A
A.Mainburnerorifice
IMPORTANT: Check thattheorificeisproperlyinstalled
insideoftheburneropening.
4.Reinserttheburnerandreattachusingthe2screwsand
cotterclippreviouslyremoved. Repeattheprocedurefor
eachmainburner.
5.Positiontheigniterssotheyare1/8" (3.2mm)awayfrom
eachburner.
1.Acombinationofpipefittingsmustbeusedtoconnectthe
grilltotheexistinggasline.
nThe10ft(3.0m)PVCflexiblegassupplyhosedesign
ncertifiedbyCSAmustbeused.
nPipe-jointcompoundssuitableforusewithNaturalgas
mustbeused. DonotuseTeflon®+tape.
nTheremustbeacertifiedmanualshut-offvalveinthegas
supplylinenearthegrillforeasyaccess.
2. Connectthebrassconnectorononeend ofthe10ft(3.0m)
PVCflexiblegassupplyhosetotheNaturalgaspressure
regulator.
3. Connectthequickconnectorontheotherendofthe
10ft(3.0m)PVCflexiblegassupplyhosetotherigidNatural
gassupplypipe.
B
A
Make Gas Connection
C
D
A. Left side panel
B.Manifold
C.10 ft.(3.0m) PVCgashose
D. Naturalgaspressureregulator/hoseassembly
19
†®TEFLONisaregisteredtrademarkofE.I.DuPont DeNemours
and Company.
A.Screws
B.CotterClip
B
A

2. Useaflat-bladescrewdrivertoturnthehigh flame
setscrewcounterclockwiseapproximate90º.
3. Checkthatburneroperatesat thenewhighflamesetting.
It maybenecessarytoadjust thescrewsettingslightly
moretogettheidealburnerflameheight.
WhenconvertingfromLPtoNaturalgas, youwill needto
adjustthehigh flamesetting screwforidealburnerflame
height.
1.Removeeachcontrolknobforthemainburnersandside
burner
ChangetheSideburnerOrifices
1.Useawrenchtoremovethesideburnerorificebrass
connectorwithflexlineend tosideburnertube.
A.Side burnerflexend
2.Use6mmsocketwrenchor6mmnutdrivertoremovethe
orifice. ReplacewiththeNaturalgasorifice.
A.Orifice
IMPORTANT: Checkthattheorificeisproperlyinstalledinside of
thevalve.
3.Reinstall sideburner,tightenthesideburnerorificebrass
connectorandsideburnertubebyusingawrench.
4.Openthemanualshutoff valveinthegassupply.Thenvalveis
openwhenthehandleisparalleltothegaspipe.
A
A
20
5.Testall connectionsusing anapprovednoncorrosiveleak-
detectionsolution.Bubbleswillshowaleak.Correctany
leakfound
InthelastpageoftheUseandCareGuide,writer “Convertedto
NaturalGas.”Alsorecordtheconversiondateandthe
technician/companythatperformedtheconversion.
Note: PlaceLPgaspartsinplasticpartsbagforfutureuseand
keepwithpackcontainingliterature.
AdjustHighFlameSetting Screw
1.Theappliancenameplateislocatedinsidethegrillcabineton
theleft –handcabinetside.Withapermanentmarker,check
theboxnextto “Naturalgas”andmarkthrough “LP-Propane.”
RecordConversion
A. Closed valve
B.Openvalve
