KitchenAid KCO124 User manual

Countertop Oven
Four grille-pain
Horno para mostrador
KCO124
W11407666E.indb 1W11407666E.indb 1 9/12/2023 11:39:47 AM9/12/2023 11:39:47 AM

2 |
PARTS AND FEATURES
3
8
4
5
6
7
1
2
13
13
9
10
11
17
18
19
20
21
22
15
1Toughened Glass Window
2Removable Crumb Tray
3Cool Down Surface for Removable
Oven Rack
4Chrome-plated Steel Broiling Rack
5Enamel-coated Pan
6Chrome-plated Steel Oven Rack
7Door Handle
8
Air Fry Basket
9Start: Start Selected Cooking Mode
10 Cancel: Stops Selected Cooking
Mode
11 Convection: Temperature Switch
Mode
12 Temperature/ Timer Knob
13 Mode Knob: Cooking Mode Selector
14 Preheating Icon
15 Shade Icon
16 Shade Number Graphic
17 Convection Icon
18 Fahrenheit Icon
19 Celsius Icon
20 Hours Icon
21 Minutes Icon
22 Slices Icon
14
16
NOTE: Press and hold the Convection button for 3 seconds to switch between the
temperature units Fahrenheit (°F) and Celsius (°C).
12
W11407666E.indb 2W11407666E.indb 2 9/12/2023 11:39:49 AM9/12/2023 11:39:49 AM

ENGLISH
| 3
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of electrical shock, do not put cord, plugs, or any parts of
the Air Fryer in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
6. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorized Service Facility for examination, repair, or
adjustment.
7. The use of accessories/attachments not recommended or sold by KitchenAid
may cause fire, electrical shock, or injury to persons.
8. Do not let cord hang over edge of table or counter, or touch hot surfaces.
9. Do not place on or near a hot gas or electric burner, or in a heated oven.
10. Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
11. Use extreme caution when removing Broiling Rack, Multipurpose Pan, Oven
Rack, or disposing of hot grease.
12. Oversize foods or metal utensils must not be inserted in a Air Fryer as they may
create a fire or risk of electric shock.
13. A fire may occur if Air Fryer is covered or touching flammable material, including
curtains, draperies, walls and the like, when in operation. Do not store any item
on top of the appliance when in operation.
W11407666E.indb 3W11407666E.indb 3 9/12/2023 11:39:49 AM9/12/2023 11:39:49 AM

4 |
14. Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts, creating a risk of electric shock.
15. Extreme caution should be exercised when using containers constructed of
materials other than metal or glass.
16. Do not store any materials, other than manufacturer’s recommended
accessories, in this Air Fry when not in use.
17. Do not place any of the following materials in the Air Fry: paper, cardboard,
plastic, or anything similar.
18. Do not cover crumb drawer or any part of the Air Fry with metal foil. This will
cause overheating of the oven.
19. To disconnect, turn the Air Fry “off” by pressing Cancel button, then remove plug
from wall outlet.
20. Do not use the appliance outdoors.
21. Do not use the appliance for other than intended use.
SAVE THESE INSTRUCTIONS
This product is designed for household use only.
PRODUCT SAFETY
ELECTRICAL REQUIREMENTS
Voltage: 120 V~
Frequency: 60 Hz
Power: 1800 W
NOTE: If the plug does not fit in the outlet,
contact a qualified electrician.
Do not modify the plug in any way.
Do not use an adapter.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or service technician to install an
outlet near the appliance.
The cord should be arranged so that it will
not drape over the countertop or tabletop
where it can be pulled on by children or
tripped over unintentionally.
W11407666E.indb 4W11407666E.indb 4 9/12/2023 11:39:49 AM9/12/2023 11:39:49 AM

ENGLISH
| 5
GETTING STARTED
Make sure all sides are positioned with at
least 4” (10 cm) distance.
1
Toast
Bagel
Proof
Air Fry
Bake
Broil
Reheat
Dehydrate
Start
Cancel
Convection
Preheating
Shade Slices
Convection
F
C
Hrs
Min
Keep Warm
Toast
Bagel
Proof
Air Fry
Bake
Broil
Reheat
Start
Cancel
Convection
Preheating
Shade
Slices
Convection
F
C
Hrs
Min
Open the door and align the rack with the
grooves for desired positions
(see”Air Fryer rack position” section).
2
Before fi rst use, clean all parts and accessories (see “Care and Cleaning” section). Place the
Air Fryer on a dry and fl at level surface. Remove all packaging materials and labels, if present.
Plug into a grounded 3 prong outlet.
Your Air Fryer is now ready to use.
3
NOTE: Upon fi rst use, the Air Fryer may
produce light smoke. This is normal.
W11407666E.indb 5W11407666E.indb 5 9/12/2023 11:39:50 AM9/12/2023 11:39:50 AM

6 |
Food Portion Temperature Time
Chicken Nuggets 1 Layer 425°F (218°C) 8-10 minutes
Chicken Tenders 1 Layer 425°F (218°C) 13-15 minutes
Chicken Wings 1 Layer 425°F (218°C) 18-20 minutes
Fish Fillets 1 Layer 450°F (232°C) 12-14 minutes
Fish Sticks 1 Layer 450°F (232°C) 10-12 minutes
French Fries 1 Layer 425°F (218°C) 22-24 minutes
Mozarella Sticks 1 Layer 450°F (232°C) 5-7 minutes
Taquitos 1 Layer 400°F (204°C) 5-7 minutes
TIME RECOMMENDATION - AIR FRY FUNCTION
GETTING STARTED
PREHEATING
Preheating your Air Fryer is important for consistent and even results. Once you select your
desired cooking mode or any other settings, and press Start.
The light ring around the Start button will be on, and the Preheat indicator will show on the
LCD. Once the oven has reached the set temperature, a tone will sound to let you know that
you can insert food and begin cooking. Preheating is NOT necessary in all cooking modes.
To skip the Preheat and start the timer directly, push the Start button a second time.
The convection fan is controlled by the Convection button. Pushing the Convection button will
toggle the fan on or off for Bake, Broil, Keep Warm, and Reheat functions. A “Convection”
label and fan icon will appear on the display when the convection fan is on. The Air Fry
function uses a high speed convection fan that cannot be turned off. The Dehydrate function
uses the high speed convection fan as preset, but it may be turned off by pushing the
Convection button.
NOTE: Automatic Preheat is not programmed for Dehydrate, Keep Warm, Reheat, Toast and
Bagel functions.
CONVECTION
NOTE: Gently spray the basket with oil before each batch of food. No more oil is needed.
Results may vary with different food brands and sizes. Follow Toaster Oven instructions from
the back of the food package and reduce time.
TIP: When cooking fatty foods, such as non breaded poultry with skin, use the baking pan
instead of the Air Fry Basket to catch excess oil that may drip from the food.
COOKING FUNCTIONS
W11407666E.indb 6W11407666E.indb 6 9/12/2023 11:39:51 AM9/12/2023 11:39:51 AM

ENGLISH
| 7
Cooking
function Rack No.
Preset
Temp.
°C (°F)
Temperature
Range °C (°F)
Preset
Time
(Mins.)
Time
Range Elements Run
Dehydrate 1 - 2 150°F
(66°C) 80–180°F (27–82 °C) 6 hours 1 min–12
hours
2 bottom;
high speed
convect
Proof 1 90°F
(32°C) 75–90°F (24–32°C) 30 1 min–1
hours 2 bottom
Air Fry 2 400°F
(205°C) 150–450°F (66–232°C) 17 1 min–1
hours
2 top, 2 bottom,
high speed
convect
Bake 2 350°F
(176°C) 150–450°F (66–232°C) 30 1 min–2
hours 2 top, 2 bottom, convect available
Broil 2 450°F
(232°C) 350°F (176°C) 450°F (232°C) 81 min–30
mins 2 top, convect available
Reheat 2 300°F
(149°C) 150–450°F (66–232°C) 15 1 min–2
hours 2 top, 2 bottom, convect available
Keep Warm 2 170°F
(77 °C) 150–450°F (66–232°C) 1 hour 1 min–2
hours 2 bottom, convect available
COOKING FUNCTIONS
Cook all foods to minimum safe internal temperatures. Consuming raw or undercooked meats,
poultry, seafood, shellfish, or eggs may increase your risk of food borne illness.
Toasting
functions Rack No. Preset Shade Shade Range (Light to Dark) Preset Slices Range (# of slices) Elements Run
Toast 2 4 1-8 2 1-6 Runs 4
elements
Bagel 2 4 1-8 2 1-6 Runs 4
elements
W11407666E.indb 7W11407666E.indb 7 9/12/2023 11:39:51 AM9/12/2023 11:39:51 AM

8 |
AIR FRY RACK POSITION
Rack position for Air Fry
Rack position for Bake, Reheat,
Dehydrate, Proof, Bagel, Toast,
Keep Warm, Broil
Rack position for Baking large
items or items that are sensitive
to over browning on top
W11407666E.indb 8W11407666E.indb 8 9/12/2023 11:39:54 AM9/12/2023 11:39:54 AM

ENGLISH
| 9
USING THE DEHYDRATE FUNCTION
Dehydrate option is to remove moisture content from veggies or fruits to dry and preserve
them.
Set the function knob to Dehydrate.
The preset temperature 150°F will be
shown. If desired, rotate knob to adjust.
Press the knob to show preset time. The
preset time is 6 hours. If desired, rotate
knob to adjust.
1
Open the door and place the food on the
center of the rack. Close the door.
Press Start to start the cycle.
2
When the time has elapsed, the end
signal will sound and the Air Fryer will
shut off automatically.
3IMPORTANT: Always use oven mitts when
removing pans or racks.
USING THE PROOF FUNCTION
Dehydrate
Bagel
Proof
Toast
Air Fry
Bake
Broil
Reheat
Keep Warm
Set the function knob to Proof.
The preset temperature 90 °F will be
shown. If desired, rotate knob to adjust.
Press the knob to show preset time. The
preset time is 30 minutes. If desired,
rotate knob to adjust.
1
The Proof function maintains a warm
environment useful for rising yeast.
Use for dough. To speed up bread proofi ng.
With a range of 75–90°F temperature and
lower heating elements, this setting can be
used to accelerate bread proofi ng (rising).
W11407666E.indb 9W11407666E.indb 9 9/12/2023 11:39:56 AM9/12/2023 11:39:56 AM

10 |
USING THE PROOF FUNCTION
Open the door and place the food on the
center of the rack. Close the door.
Press Start to start the cycle.
2
When the time has elapsed, the end
signal will sound and the Air Fryer will
shut off automatically.
3
USING THE BAGEL FUNCTION
Set the function knob to Bagel. Shade and
slices will be shown.
1
In Bagel mode, the oven distributes power between the top and bottom heating elements to
nicely brown the top of cut bagels while gently warming the outside.
Open the door and place the food on the
center of the rack. Close the door.
2
Toast
Bagel
Proof
Air Fry
Bake
Broil
Reheat
Dehydrate
Start
Cancel
Convection
Preheating
Shade Slices
Convection
F
C
Hrs
Min
Keep Warm
When the time has elapsed, the end
signal will sound and the Air Fryer will
shut off automatically.
4
Start
Cancel
Convection
Preheating
Shade Slices
Convection
F
C
Hrs
Min
Toast
Bagel
Proof
Air Fry
Bake
Broil
Reheat
Dehydrate
Start
Cancel
Convection
Preheating
Shade Slices
Convection
F
C
Hrs
Min
Keep Warm
The Shade Icon starts flashing. Rotate the
knob to adjust shade. Press knob to select
slices. The Slices Icon will starts flashing.
If desired, rotate knob to adjust number
of slices.
Press Start to start the cycle.
3
