OVEN PARTS
1
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
10−00 Litho In U.S.A. (RS) Part No. 8185596
30" BUILT−IN ELECTRIC
DOUBLE OVEN
THERMAL CONVECTION
SELF−CLEAN

OVEN PARTS
2
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
8185596
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Literature Parts
LIT4450411 Installation
Instructions
LIT4451952 Use & Care Guide
LIT4449066 Cookbook
(T/C Oven)
LIT4451879 Tech Sheet
LIT4449264 Easy Set Guide
LIT3191638 Safer Cooking Tips
2 Trim, Side
4450850 RH Black & BS Mdls
4450851 RH White Model
4452081 RH Stainless Steel
4450853 LH Black & BS Mdls
4450854 LH White Model
4452082 LH Stainless Steel
Screw
4449747 Black & BS Models
4449041 White Model
3 Hinge Receiver
4455722 Left Hand
4455723 Right Hand
4 4448520 Bumper, Door
5 4455509 Bracket, Support
6 4452201 Divider, Vent
4449809 Screw
7 4455286 Top Chassis
4449809 Screw
9 4452158 Tube, Vent
4449154 Screw
10 4452163 Lens, Light
11 4448972 Oven Light Assy
4449748 Screw
12 4452164 Bulb, Light
14 4451740 Frame, Front
4449040 Screw
4450118 Nut
15 4455382 Gasket, Door
19 4451478 Support, Insulation
4449809 Screw
20 4451605 Cap, Spacer
21 Rail, Side
4450581 Right Side
4450582 Left Side
4448444 Grommet
4449154 Screw
22 4451896 Latch Assy
4449154 Screw
23 4452224 Solenoid
24 4452312 Micro Switch N.C.
25 4454691 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26 4452234 Back, Chassis
4449809 Screw
27 Liner, Oven
(Not serviceable)
28 4451426 Micro Switch
29 4455636 Sensor
4449154 Screw
30 4451537 Spring, Latch
33 4451619 Deflector, Vent
4452489 Stainless Steel
Model
34 4452267 Vent, Center
37 4452223 Thermostat (TOD)
4449809 Screw
43 4455530 Base, Chassis
4449809 Screw
49 4448933 Retainer, Gasket
4449154 Screw
50 4451747 Cover, Back
4449809 Screw
51 Trim, Bottom
4448478 White Model
4448477 Black & BS Models
4452481 Stainless Steel
4452152 Bracket, Mounting
Stainlees Steel
53 4449845 Support, Bracket
4449809 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back

CONTROL PANEL PARTS
3
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
8185596
Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Control Panel Assy
W/Membrane, Switch
8300373 Black & Black
Stainless
8300372 White Model
4451791 S. Steel Model
2 4451034 Gasket,
Control Panel
3 4453165 Microcomputer
8281179 Screw
NOTE:
The following components are
used on the Stainless Steel Model.
4 4451791 Panel, Control
5 4452260 Spacer, Foam
6 4452379 Membrane Switch
7 4452248 Insulator, Board
8 4452249 Insulator, Board
Support
9 4455251 Insulator,
Dialectric

OVEN DOOR PARTS
4
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
8185596
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4451719 Door Liner
2 Hinge, Door
4455525 White, Black &
Black Stainless
4455526 Stainless Steel
4449743 Screw
3 4449259 Glass, Inner
5 4451671 Retainer, Glass
4449809 Screw
7 4449263 Glass, Inner
9 4451668 Retainer, Glass
4449809 Screw
12 Door Glass, Assy
4452074 Black Model
4452075 White Model
4452078 BS Model
4452316 Stainless Steel
13 Door Handle
4448414 Black & BS Models
4448415 White Model
4452088 Stainless Steel
14 4450813 Bracket, Handle
4451040 Screw
19 4450362 Shield, Heat
4449809 Screw
21 4451674 Seal, Door Top
23 Retainer, Clip
4450863 Black & BS Models
4450864 White Model
24 4455257 Glass, Inner
25 Bracket, Handle
Stainles Steel
4452959 Right Hand
4452960 Left Hand

INTERNAL OVEN PARTS
5
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
8185596
Illus. Part
No. No. DESCRIPTION
1 4448982 Plug, Button
2 4452156 Element, Broil
4449154 Screw
3 3147563 Grill, Broiler
4 3147845 Pan, Broiler
5 3181534 Rack, Roasting
6 4448717 Rack, Oven
7 4452155 Element, Bake
8 4448881 Nut, Hex
9 4451583 Fan, Convection
4449154 Screw
10 4452226 Blade, Fan
11 4448882 Washer, Lock
12 4452227 Nut
13 4451355 Jack, Meat Probe
14 4448948 Probe, Meat
15 4455037 Tray, Bake
17 4450039 Cover, Bake Tray
4449809 Screw
20 4452157 Element,
Convection
4449154 Screw
21 4448418 Cover, Fan
4449154 Screw

TOP VENTING PARTS
6
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
8185596
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 4451758 Foam, Block
2 4451759 Vent, Exhaust
4449809 Screw
3 Blower
6610168 Lower Oven 45MM
4455334 Upper Oven 60MM
4455352 Bracket, Blower
60MM
4455191 Plate, Service
5 6610122 Transformer,
(Lights)
4449809 Screw
7 4451891 Transformer
4449809 Screw
8 4455178 Elbow, Vent−Top
9 4455177 Elbow, Vent−Bottom
10 4451789 Plate, Mounting
11 4449868 Block, Terminal
3400080 Screw
13 4448552 Vent,
(Control Panel)
4450038 Screw
14 Side, Control Top
4451597 Right
4451598 Left
4449809 Screw
15 4452244 Back, Control
4449809 Screw
16 4450551 Cover, Top Rear
4449809 Screw
17 4448664 Clamp
4449809 Screw
112432 Nut
18 4452367 Cover, Top Front
4449809 Screw
4452260 Spacer, Foam
19 4451985 Suppressor

OPTIONAL PARTS
7
For Models:KEBS208DBL10, KEBS208DWH10, KEBS208DBS10, KEBS208DSS10
(Black) (White) (Black Stainless) (Stainless Steel)
8185596
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
4451926 Harness, Wire
(Latch)
4449809 Screw
4455727 Harness, Wire
(Main)
4450953 Conduit, Double
4450800 Screw
4448664 Clamp
4449809 Screw
112432 Nut
4452222 Spacer, Harness
4454835 Tie, Cable
4451761 Support, Wiring
4454842 Tie, Cable
313438 Clip, Harness
Miscellaneous
814381 Pin Hinge Kit
4448950 Screw, Install (4)
