OVEN PARTS
1
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
6−10 Litho in U.S.A. (amd)(bay) Part No. W10269265 Rev. B
30" BUILT−IN ELECTRIC
DOUBLE OVEN
THERMAL CONVECTION

OVEN PARTS
2
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
W10269265
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8304336 Installation
Instructions
W10162180 Use & Care Guide
Tech Sheet
W10220954 English
W10220955 French
8304335 Easy Set Guide
Safer Cooking Tips
9762761 English
W10065852 French
2
W10153090 Bracket, Base
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 8303829 Exhaust,Vent Slope
6
W10181196 Divider, Vent
7
W10204470 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10169756 Lens, Light
11
W10307114 Oven Light
Assembly
12
W10307114 Bulb, Light
13 3400832 Screw (2)
14
W10115861 Frame, Front
15 8304493 Gasket, Door
16 3196176 Screw
17 4449040 Screw
18 4449154 Screw
19 4451478 Support, Insulation
21 Mounting Rail,Side
Right
8303677BL Black
8303677WH White
Left
8303678BL Black
8303678WH White
22
W10195935 Latch, Mortorized
23 4449743 Screw
24 8303972 Blower
25 4455641 Side, Chassis
26 8304303 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 8304452 Thermal Fuse 105C
29
W10131825 Sensor
30 8303685 Vent, Center
31 8303516 Base, Chassis
32 8304478 Retainer, Gasket
33 8303517 Cover, Back
34 Trim, Bottom Vent
8303705BL Black
8303705WH White
W10216230 Stainless
35 4449748 Screw
36 4448444 Mounting Grommet,
Rail
37
W10169348 Bracket,
Thermostat
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303965 Insulation, Wrap
8303967 Insulation, Back

CONTROL PANEL PARTS
3
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
W10269265
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8303716BL Black
8303716WH White
W10216219 Stainless
2 8303687 Support, Appliance
Manager
4 8303880 Control Panel,
Glass Touch
5
W10312205 User Inferface
6 8303719 Backer, Control
7 8303887 Bracket,Enclosure
8 4449154 Screw
9 3400832 Screw
10
W10119142 Appliance Manager
11 8304441 Resistor, Drop

OVEN DOOR PARTS
4
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
W10269265
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8303737BL Door Liner
2
W10174285 Hinge, Door (2)
3 3196183 Screw
4
8304581BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6 Cover, Hinge
W10137044 Right
W10137043 Left
7 8303731 Glass, Inner
8 4449743 Screw
9
W10143950 Screw
10 8304523 Seal
11
8304360BL Bracket, Handle
12 Door Glass, Assy
Lower Includes #17
8303993 Black
8303995 White
W10237350 Stainless
Door Glass, Assy
Upper No Nameplate
8303994 Black
8303996 White
W10237351 Stainless
13 Door Handle
W10292381 Black
W10292382 White
W10292380 Stainless
14
W10253472 Seal
15
8303745BL Frame,Door Side(2)
16 8303746 Door, Top
Bracket
17 Nameplate
(Lower Door)
8304603BL Black
8304603WH White
8304603SS Stainless
18 8304522 Bumper, Glass

INTERNAL OVEN PARTS
5
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
W10269265
Illus. Part
No. No. DESCRIPTION
1 9760774 Element, Broil
2 8304602 Shield, Broil
Element
3
W10284950 Rack, Oven
4
W10208155 Oven Rack
5
W10207398 Element, Bake
6 4455037 Tray, Bake
7 4449154 Screw
8 4450039 Cover, Bake Tray
9 4449809 Screw
10
8303962BU Cover, Fan
11 9760769 Element
Convection
12 9755543 Jack, Meat Probe
13 9755542 Probe, Meat
14
W10116351 Blade, Fan
15
W10116349 Nut
16
W10116228 Fan, Convection
17 9755547 Washer, Lock
18 9755546 Nut, Hidden

TOP VENTING PARTS
6
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
W10269265
Illus. Part
No. No. DESCRIPTION
1 9752759 Relay (2)
2 8304643 Duct, Air Outlet
3 4449809 Screw
6 8285593 Connector, Cover
7
W10111628 Transformer,
Control
9
7401P039−60 Block, Terminal
10 3400080 Screw
11 8303684 Vent, Control
Panel
12 Side, Control Top
8303518 Right
8304255 Left
13 8303520 Back, Control
14 8304219 Cover, Top
15
7103P027−60 Nut (3)

OPTIONAL PARTS
7
For Models:KEBS208SBL04, KEBS208SWH04, KEBS208SSS04
(Black) (White) (Stainless)
W10269265
Illus. Part
No. No. DESCRIPTION
OPTIONAL PARTS NOT INCLUDED
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
W10231531 Harness, Door
Latch
W10237644 Connector, Flex
W10171560 Harness, GOC
98997 Clip
8304051 Harness, Main
8304439 Conduit, Double
4450800 Screw,Ground
Miscellaneous
4448950 Screw, Install (4)
