KitchenAid KERS807SBB02 User manual

COOKTOP PARTS
1
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
5−08 Litho in U.S.A. (amd) (eeb) Part No. W10206131 Rev. A
30" FREE STANDING
ELECTRIC OVEN
SELF CLEAN

COOKTOP PARTS
2
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10118260 Installation
Instructiions
W10162196 Use & Care Guide
W10112097 Tech Sheet
9763467 Easy Set Guide
9757680 Anti−Tip
Instructions
Safe Cooking Tips
9762761 English
W10065852 French
2 9762768 Clip, Retainer (3)
3 9761784 Frame, Cooktop
Side
4 Cooktop
W10110276 Black/Stainless
W10110274 White
W10110275 Biscuit
6 Trim, Cooktop
Right
W10110687 Black
W10110685 White
W10110686 Biscuit
W10140550 Stainless
Left
W10110682 Black
W10110680 White
W10110681 Biscuit
W10140549 Stainless
7
W10076030 Gasket (2)
8 8523739 Light, Indicator
9 9759944 Thermostat
10 9756821 Support, Wiring
11 9757825 Rail, Element
Center (1)
12 Element, Surface
8523696 RF
4456507 LR
4453909 LF, RR
13 9761423 Frame, Cooktop
Front
14 3196537 Screw
15 341196 Thermostat
16 3196160 Screw
17 9758799 Bracket, Indicator
Lamp
18 Backsplash
W10109750 Black
W10109740 White
W10109760 Biscuit
W10156267 Stainless
19 9759094 Spring, Locator
20 9761783 Frame, Cooktop
Rear
21 9763517 Rail, Element (3)
22 246119 Screw
23 9761724 Cover, Cooktop
Rear
24 Gasket, Backsplash
9763483BL Black/Stainless
9763483GY White/Biscuit
25 Glass, Backsplash
9761749BL Black/Stainless
9761749WH White
9761749BT Biscuit
26
W10153092 Panel, Backsplash

OVEN PARTS
3
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131

OVEN PARTS
4
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Side
Right
W10109540 Black
W10109570 White
W10109550 Biscuit
W10140548 Stainless
Left
W10109490 Black
W10109520 White
W10109500 Biscuit
W10140547 Stainless
2 3400832 Screw
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 3196537 Screw
6 3196160 Screw
7 8303099 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10067870 Lens, Light (2)
11
W10009930 Oven Light,
Assembly (2)
12 4452166 Bulb, Light (2)
13 4449154 Screw
14
W10130368 Frame, Front
15
W10074200 Gasket, Door
16 9757829 Bracket,
Transformer
17 4452152 Bracket, Mounting
18 9757685 Guide, Side Panel
19 4451478 Support, Insulation
20 Body, Side
9760723PB Black/Stainless
9760723PW White
9760723PC Biscuit
21 9757461 Bracket,Side Panel
22 9760888 Latch, Motorized
23 9759242 Thermostat
24 9757811 Brace, Side Panel
25 4455641 Side, Chassis
26 9759761 Back, Chassis
27 Liner, Oven
(Not Serviceable)
28 9759890 Clip, Side Panel
29
W10131825 Sensor
31 3196176 Screw
33 9759713 Base, Chassis
34 4448933 Retainer, Gasket
35 4448444 Grommet,
Mounting Rail
36 Vent, Bottom Upper
Assembly
W10116899 Black
W10116899 White
W10116898 Biscuit
W10160347 Stainless
37 Vent, Bottom Lower
W10153486 Black
W10153488 White
W10153487 Biscuit
W10154789 Stainless
38 4449743 Screw
41
W10111628 Transformer,
Control
43 3400080 Screw
44
W10165135 Box, Terminal
45 9757405 Cover, Termianl
Box
46 9759721 Insulator,
Termianl Box
47 9761958 Block, Terminal
48
W10181438 Appliance,
Manager
49
W10083460 Slide, GOC
50 9756454 Bracket, Appliance
Manager
51 9759884 Insulation
52 9759722 Insulation, Body
Side
53 9760481 Washer
54 9758583 Cover, Back
55 9759885 Pad,
Insulation(2)
56 9759945 Standoff, Rear
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
9756470 Insulation, Back

DOOR PARTS
5
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131

DOOR PARTS
6
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION
1 9759413 Panel, Door
2 9757706 Glass, Inner
3 4451722 Insulation, Door
4 4457132 Retainer, Glass
5 Hinge, Oven Door
9760579 Right
9760580 Left
6 9759225 Glass, Inner
7 4457114 Shield, Heat
Bottom
8 9759229 Bracket, Glass
Side
9 4457103 Shield, Heat Top
10 9759225 Glass, Inner Door
11 9759230 Bracket, Central
12 Bracket, Handle
9763497 Right
9763496 Left
13 Badge
8304603BL Black
8304603WH White
8304603BT Biscuit
8304603SS Stainless
14 Assembly, Door
Kit
W10131888 Black
W10131889 White
W10131890 Biscuit
W10155557 Stainless
15 Handle, Door
8303774BL Black
8303774WH White
8303774BT Biscuit
8303774SS Stainless
16 3196184 Screw
19 4448520 Bumper, Door

DRAWER PARTS
7
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Support, Drawer
Rail
9757687 Right
9757686 Left
2
9763501BL Support, Front
& Rear
3 Brace, Drawer
4453720 Right
4453721 Left
5 Side, Base
9759953 Right
9759954 Left
6
W10058460 Foot
7 8274149 Thermistor
8 3196037 Foot Assembly
10
W10144430 Drawer
11 Drawer Slide
W10019810 Right
W10019800 Left
12
W10144431 Panel, Drawer
13 Front, Drawer
9761747BL Black
9761747WH White
9761747BT Biscuit
W10203763 Stainless
14 Handle, Drawer
9761573BL Black
9761573WH White
9761573BT Biscuit
9761573SS Stainless
15 3196537 Screw
16
W10153100 Cover, Terminal
17 9758676 Support, Element
18 9760775 Element, Warming
Drawer
19 9763518 Enclosure, Warming
Drawer

CONTROL PANEL PARTS
8
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Control Panel
9761551BL Black
9761551WH White
9761551BT Biscuit
W10156268 Stainless
2 Switch, Infinite
9763761 RF
9763762 LR,LF,RR
3
W10181439 Control, Electric
4
W10105370 Shield, Console
Vent
5 3196068 Lens, Indictor (2)
6 3196160 Screw
7 9761745 Bracket,
Thermostat (2)
8
W10116195 Gasket, Vent
Shield
9 Knob
RF
W10130387 Black
W10130388 White
W10130389 Biscuit
W10156261 Stainless
LR,LF,RR
W10130391 Black
W10130392 White
W10130393 Biscuit
W10156260 Stainless
10 3196537 Screw
11 9780271 Screw
12
W10109430 Gasket, Console
13 9761566 Membrane, Switch

INTERNAL OVEN PARTS
9
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KERS807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9760774 Element, Broil
2 4449154 Screw
6 4448717 Rack, Oven
7 9760768 Element, Bake
8 9755542 Probe, Meat
9 9760769 Element,
Convection
10 9756690 Cover, Fan
11 4455037 Tray, Hidden Bake
12 4450039 Cover, Bake Tray
13
W10116228 Motor, Convection
14
W10116349 Nut
15
W10116351 Blade, Fan
16 9755543 Jack, Meat Probe
17 9755547 Lock Washer
18 9755546 Hex Nut

TOP VENTING PARTS
10
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION
1 4451759 Vent, Exhaust
2 4455178 Elbow, Vent Top
3 9759320 Blower
4 4451758 Block, Foam
5 4455177 Elbow, Vent Bottom
6
W10143041 Bracket, Terminal
Box
7 4449809 Screw (2)
10 4449040 Screw
11 4455352 Bracket, Blower

OPTIONAL PARTS
11
For Models: KERS807SBL02, KERS807SWW02, KERS807SBB02, KWES807SSS02
(Black) (Pure White) (Pure Biscuit) (Stainless)
W10206131
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242827 Wire (14 Ga.
150 c Yellow)
WIRING HARNESS PARTS
W10137680 Harness, Main
W10157935 Harness, Switch
9762921 Harness,
Communication
4452222 Spacer, Harness
9763481 Harness, Ground
Strap
W10137677 Cooktop, Electric
Switch
9757778 Bushing Snap
Split 1"
313660 Clip, Ground Wire
W10177363 Grommet, Flex 60mm
W10155291 Connector, Flex
4449809 Screw
112432 Nut
Edge Protector
W10123242 19mm
W10127413 38mm
4450800 Screw, Ground
3400015 Screw, Ground
Miscellaneous
9782676 Anti−Tip Assembly
