CABINET PARTS
For Model: KSSS42MDX00
5−95 Litho In U.S.A. (RCG) Part No. 4379844
42" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Cabinet (Not A
Serviceable Part)
2 1112019 Leveler, Front (2)
4 1112023 Roller, Front &
Rear (4)
5 1112695 Leveler,
Adjustable (2)
6 2000670 Adjusting Rod (2)
7 1113250 Sleeve,
Retainer (2)
8 1112937 Bushing, Rod (2)
9 489359 Screw
10 1112939 Hole Plug, Leveler
11 1112849 Cap, Grommet
12 2002902 Stop Screw
13 1113122 Grommet, Wiring
14 2002804 Wiring Harness,
Cabinet
15 1112848 Drain Fitting
17 2001295 Shoulder Screw
18 Hinge (Top)
2001976 Left Side
2001975 Right Side
19 2000770 Shim, Hinge
Top
20 1112805 Guard, Wiring
21 487534 Screw (2)
22 2002903 Bushing
23 1112992 Door Closer
Assembly (2)
24 2000333 Bracket, Door
Closer
25 486194 Screw
26 1112973 Tap Plate,
Hinge Butt (2)
27 1113227 Fastener (3)
28 Gap, Cover
Assembly (Bottom)
2003386 Left Side
2003387 Right Side
29 Hinge (Bottom)
2001978 Left Side
2001977 Right Side
30 1112942 Shim, Hinge (1)
1112943 Shim, Hinge (2)
31 2000490 Screw
33 2001266 Tube clamp
34 2001963 Grille Base,
Front
35 489238 Screw (6)
36 2000684 Cover, Rear
37 1113123 Grommet, Wiring
38 1113079 Grommet, Flexible
39 2003472 Cup, Wiring
40 2003474 Seal
41 2001377 Screw
42 2003473 Grommet
43 2001415 Screw (4)
44 489359 Screw

3
CABINET TRIM PARTS
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2002194 Cabinet, Trim (2)
2 486194 Screw
3 2001297 Screw
4 2001189 Cabinet, Trim
(Bottom)
5 488649 Screw
6 2002229 Cabinet, Trim Top
7 2000007 Retainer, Unit
Base (2)
8 487944 Washer (2)
9 2002474 Retainer Clip

FREEZER LINER PARTS
4
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 1113649 Bracket, Light
3 1113650 Lens
4 1112613 Light, Socket
5 548049 Light, Bulb
6 538533 Support Clip,
Icemaker (2)
7 2000193 Grommet, Screw (2)
8 488552 Screw
12 486194 Screw
13 1112591 Spacer, Control
Panel (3)
14 842534 Clip, Air Duct (4)
16 1112260 Support,
Evaporator
17 658944 Stud, Shelf (8)
18 487559 Screw

5
REFRIGERATOR LINER PARTS
For Model: KSSS42MDX00
4379844

6
REFRIGERATOR LINER PARTS
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 LINER (Not A
Serviceable Part)
2 1112591 Spacer, Control
Panel (3)
5 2001117 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 488357 Screw
8 486194 Screw
9 1112257 Hole Plug
10 2000740 Meat Pan, Air
Duct Cover
11 2000337 Meat Pan, Air Duct
12 2003299 Inlay, Control
Meat Pan
13 2001326 Seal, Air Duct
14 1112218 Damper Control,
Meat Pan
15 2001735 Control Knob,
Meat Pan
16 837444 Retainer, Knob
17 2000343 Air Baffle
Assembly
20 2001073 Wiring Harness,
Air Baffle
21 2001146 Seal
22 1116793 Cover, Thermistor
23 1116959 Thermistor
25 2000736 Air Baffle Cover
26 2000527 Guard, Air Return

REFRIGERATOR CONTROL PANEL PARTS
7
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 1112641 Control Panel
2 2003302 Inlay, Control
Panel
3 2000789 Circuit Board
4 2001738 Control Knob
5 837444 Retainer, Knob
6 1118894 Switch, Rocker Arm
7 1113135 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113774 Shield, Control
Panel
11 1112613 Socket, Light (2)
12 548049 Light Bulb (2)
13 486194 Screw
14 2001074 Control, Harness
15 2001141 Channel, Wiring
16 1115375 Clip, Wiring (2)

8
FREEZER CONTROL PANEL PARTS
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 1113626 Control Panel
2 2003308 Inlay, Control
Panel
3 1113466 Thermostat &
Barrier Assembly
4 488974 Screw (2)
5 1115373 Switch, Rocker Arm
6 1113134 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113768 Shield, Control
Panel
11 1112613 Socket, Light
12 486194 Screw
13 548049 Light Bulb
14 2001973 Channel, Wiring
16 2001737 Knob, Thermostat
17 1115375 Clip, Wiring

REFRIGERATOR SHELF PARTS
9
For Model: KSSS42MDX00
4379844

REFRIGERATOR SHELF PARTS
10
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2174403 Frame, Shelf
2 2003376 Glass, Shelf
3 1113547 Reflector, Shelf
4 1113791 Gasket, Glass (2)
5 2179375 Rack, Wine
6 2164372 Egg Bin
7 2003326 Frame, Assembly
Meat Pan
8 2164373 Egg Carrier
9 1113894 Cover, Crisper
10 2003379 Glass, Crisper
(Includes #9)
11 2000742 Meat Pan,
Connector
12 2164374 Cover
13 489212 Screw
14 2003316 Crisper Pan (2)
15 2174388 Roller
16 1113871 Eyelet, Roller
17 489211 Screw
18 488307 Washer
20 2003321 Meat Pan
23 2002181 Retainer, Glass
25 2003411 Crisper Spacer,
Right Side (2)
27 1113169 Stop, Roller
28 2003410 Crisper Spacer,
Left Side (2)
29 486194 Screw

FREEZER SHELF PARTS
11
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2003143 Solid Shelf
2 2003134 Front, Ice
Compartment
3 1113637 Shelf, Fixed (2)
1113565 Shelf, Fixed−Deep
4 2001625 Basket (2)
5 2002726 Ice Container
6 2003044 Front Cover
7 Slide, Container
2002720 Right Side
2002721 Left Side
8 2003046 Hole Plug, Front
9 2003047 Hole Plug, Rear
13 2003113 Trim, Basket
15 2174388 Roller
16 1113871 Eyelet, Roller
17 489211 Screw
18 488886 Screw
22 Basket Slide
2000061 Right Side
2000062 Left Side
Right Side (2)
24 1113169 Stop, Roller
25 486194 Screw

TOP GRILLE AND UNIT COVER PARTS
12
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2002583 Top Grille
Assembly
2 2003267 Cover, Unit
3 486194 Screw
4 2002484 Grille, Bracket
5 2001415 Screw
6 2002955 Decortive Panel
Assembly
7 2003480 Guard, Compressor
Wiring
8 2003482 Guard, Water
Valve Wiring

REFRIGERATOR DOOR PARTS
13
For Model: KSSS42MDX00
4379844

REFRIGERATOR DOOR PARTS
14
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2002833 Refrigerator
Door Panel
(Includes
Insulation)
2 939101 Screw Anchor (8)
3 2001983 Hinge Assembly,
Top
5 489282 Screw
6 2002073 Hinge Assembly,
Bottom
7 1112533 Gasket Retainer,
Side (2)
8 1112541 Gasket Retainer,
Top & Bottom
9 2000880 Door Gasket,
Magnetic
10 489089 Screw (38)
11 2002224 Handle, Door
12 2001230 Washer
13 2002007 Door, Spacer
Bottom
15 487052 Screw
16 2002201 Trim (Top)
17 489112 Screw
18 2002196 Trim (Side)
19 2002842 Trim (Bottom)
20 1113953 Panel, Interior
Door
21 1113951 Ladder, Shelf (2)
22 1112530 Retainer, Shelf
Ladder (2)
23 1112514 Back Up Plate (8)
24 486194 Screw
25 1112721 Bin, Utility
26 2003464 Door, Utility Bin
27 2003131 Door Shelf (4)
28 1125936 Butter Tray

FREEZER DOOR PARTS
15
For Model: KSSS42MDX00
4379844

FREEZER DOOR PARTS
16
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2002866 Freezer Door
Panel (Includes
Insulation)
3 2002074 Hinge, Bottom
4 489282 Screw
5 2001984 Hinge, Top
7 1112533 Gasket Retainer,
Side (2)
8 1112540 Gasket Retainer,
Top & Bottom
9 2000879 Door Gasket,
Magnetic
10 489089 Screw (36)
11 2002226 Handle, Door
12 2001230 Washer
13 2002007 Door, Spacer
14 487052 Screw
15 2002207 Trim (Top)
16 489112 Screw
17 2002949 Trim (Bottom)
18 2002198 Trim (Side)
19 2000178 Interior Door
Panel
20 2003128 Shelf Bin (4)
21 939101 Screw Anchor

UPPER UNIT PARTS
17
For Model: KSSS42MDX00
4379844

UPPER UNIT PARTS
18
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2003398 Assembly, Unit
Base
2 2163787 Clip, Compressor
Mounting (4)
3 2169443 Compressor
(Includes Items
7, 8, 9, 11,
12 & 21)
(Also Order
876765 Tube Kit)
4 680975 Washer
5 2003389 Bushing, Foam
6 2163786 Grommet, Mounting
7 2172890 Wire Assembly
8 2154697 Overload
(Includes Relay)
9 2162358 Terminal Cover
11 Relay
(See Overload)
12 2169137 Capacitor
14 486899 Screw
15 487869 Screw
16 2003392 Condenser
17 943447 Grommet (4)
18 1113019 Clamp (4)
19 487522 Screw
20 851095 Wire Tie (2)
21 2164492 Drier
23 2169135 Motor, Fan
24 1108179 Blade, Fan
25 2003169 Orifice, Fan
27 489099 Screw (3)
29 486692 Speed Nut
30 2162044 Defrost Timer
31 488911 Screw
32 2000645 Sleeve,
Condenser
34 2003011 Process, Tube
35 486194 Screw
36 2003174 Cover, Fan
37 2003355 Cover, Condenser
38 2003263 Air Vane
39 2003381 Service Cord
41 1113162 Clamp, Cord (2)
42 1113229 Switch, Power
Disconnect
43 488879 Screw, Ground
44 653035 Clip, Cord Plug
45 2003356 Wiring Harness,
Unit Compartment
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
6.75 oz.
(R−134A)

LOWER UNIT AND TUBE PARTS
19
For Model: KSSS42MDX00
4379844

LOWER UNIT AND TUBE PARTS
20
For Model: KSSS42MDX00
4379844
Illus. Part
No. No. DESCRIPTION
1 2000528 Defrost Bi−Metal
2 1113043 Clamp, Bi−Metal
3 486194 Screw
4 2003271 Sleeve
5 2002171 Sleeve
6 2002999 Condenser
Inlet Tube
8 2003015 Tube, Connect
(Drier)
9 2002993 Heater, Drain Pan
10 1113062 Hanger, Heater
11 1113105 Bracket, Heater
12 487534 Screw
13 2002995 Tube, Discharge
14 2003272 Sleeve
15 2003002 Heat Exchanger
16 2002965 Evaporator
17 2000631 Heater, Defrost
18 1113048 Clamp, Heater (2)
19 1108431 Clamp, Heater (2)
20 1112844 Gasket, Evaporator
21 857547 Wire Tie
23 851095 Strap
25 2001264 Drain Pan
26 Bracket, Drain Pan
1113206 Left
1113207 Right
27 513942 Dampener
