KitchenAid KHLU162MSS User instructions

PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
CABINET DIMENSIONS
KHLU162M
KHLU182M
Electrical: 120-volt, 60-Hz, AC-only, 15-amp.
electrical supply. Use copper wire only. A time-
delay fuse or circuit breaker and separate circuit
is recommended.
This hood liner must be used with Exterior
Blower Models:
KPEC992M rated for 900 cfm
(25.5 cm/m) or,
KPEU722M rated for 1200 cfm
(34.0 cm/m).
36" and 48" Hood Liner
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 8285495
12-19-03
®
2-3/4"
(7.0 cm)
22"
(55.9 cm)
center line
of hood
14-3/16"
(36.0 cm)
3/4"
(1.9 cm)
2"
(5.1 cm)
2"
(5.1 cm)
5-15/16"
(15.1 cm) 10" (24.5 cm) dia.
vent collar
5-15/16"
(15.1 cm)
36" (91.4 cm) model:
35-13/16" (91.0 cm)
48" (121.9 cm) model:
47-13/16" (121.4 cm)
36" (91.4 cm) model:
15-23/32" (39.9 cm)
48" (121.9 cm) model:
21-23/32" (55.2 cm)
17-5/16"
(40.0 cm) 36" (91.4 cm) model:
31-7/16" (79.9 cm)
48" (121.9 cm) model:
43-7/16" (110.3 cm)
electrical
knockouts
30" (76.2 cm) min.
height above
cooking surface
hood support
must be capable
of supporting
50 lbs. (22.7 kg)
hood liner is
22" (55.9 cm)
deep
min. cabinet opening widths:
36" (91.4 cm) model, 36" (91.4 cm)
48" (121.9 cm) model, 48" (121.9 cm) determine hood support depth so
that front enclosure is flush with
adjoining enclosure.
hood liner
front
enclosure
