KitchenAid KICU465SBL0 User manual

HOOD PARTS
1
For Models: KICU465SWH0, KICU465SSS0, KICU465SBL0
(White) (Stainless) (Black)
1−08 Litho in U.S.A. (cre) Part No. W10138601 Rev. A
36" CANOPY HOOD

HOOD PARTS
2
For Models: KICU465SWH0, KICU465SSS0, KICU465SBL0
(White) (Stainless) (Black)
W10138601
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10094880 Use & Care Guide
2 Spacer
W10139307 Upper & Lower
W10139308 Center
3 Pipe, Fitting
(Upper)
W10139309 White
W10139310 Black
W10139311 S.Steel
4 Air−Outlet
4360316 LH White
W10138373 LH Black
4360330 LH S.Steel
4360323 RH White
W10138372 RH Black
4360332 RH S.Steel
5 Pipe Fitting
(Ducted)
W10139312 White
W10139313 Black
W10139314 S.Steel
6 Pipe Fitting
(Ductless)
W10139315 White
W10139316 Black
W10139317 S.Steel
7 Nameplate
W10138380 White
W10138381 Black
W10138382 S.Steel
11
W10138386 Board, Control
12 8190355 Duct, Air
13
W10139318 Duct, Air Spacer
15 8191005 Box, Control
16 8190358 Damper, Hood
17 Casing, Motor
(Not Serviced)
19 Hood
W10139304 White
W10139305 Black
W10139306 S.Steel
20 Support,Rear Lt
W10139301 White
W10139302 Black
W10139303 S.Steel
21 8189594 Filter
22 Support,Front Lt
W10139298 White
W10139299 Black
W10139300 S.Steel
23
W10138354 Socket,Light (4)
24
W10114395 Bulb, Light (4)
25
W10138395 Box, Control
26
W10138394 Knob, Control
27
W10138496 Control, Motor

MOTOR PARTS
3
For Models: KICU465SWH0, KICU465SSS0, KICU465SBL0
(White) (Stainless) (Black)
W10138601

MOTOR PARTS
4
For Models: KICU465SWH0, KICU465SSS0, KICU465SBL0
(White) (Stainless) (Black)
W10138601
Illus. Part
No. No. DESCRIPTION
1 8190389 Housing, Fan
(Upper)
2 8190388 Support, Motor LH
3
W10138388 Housing, Fan
(Lower)
4 8190384 Cover
5
W10136368 Capacitor
6
W10138387 Cover, Wiring
7
W10138389 Motor Assy
8 8190391 Support, Motor RH
9
W10138393 Screw
10
W10138390 Box, Electrical
11 8190393 Connector
12
W10138392 Connection, 6−Way
13
W10138391 Bracket
14 8190582 Screw
