KitchenAid KIRD801XSS0 User manual

1 Cover, Capacitor
4360060 L.H.
4360056 R.H.
2 4360175 Capacitor
3 4360176 Terminal
4 4360177 Guide, Exhaust
5 4360178 Damper
6 Cover, Blower
4360179 R.H.
4360188 L.H.
7 4360180 Nut
8 Blower Wheel
4360181 R.H.
4360187 L.H.
9 4360182 Box, Blower
10 4360183 Support, Blower (2)
11 4360184 Housing, Blower
12 4360185 Plate, Motor
13 4360186 Motor
14 4360114 Screw
15 4360154 Motor, Gear
16 4360035 Micro Switch (3)
17 4360155 Bracket, Motor Gear
18 4360059 Bracket, Capacitor
19 4360189 Cover, Blower Box
20 4360190 Cover, Exhaust Outlet

1 Cover, Controls (Top)
4360130 KIRD801XXS0
4360131 KIRD861XSS0
2 4360132 Button, Push
3 4360134 Housing, Switch
4 4360135 Switch, Fan
5 4360136 Shield, Suppport Bracket (2)
6 4360137 Knob
7 4360138 Panel, Control
8 4360139 End Cap (2)
9 4360140 Plate, Support (Upper) (2)
10 Housing, Non-Serviceable
11 Bracket, Support
4360141 Lower R.H.
4360170 Lower L.H.
12 4360142 Nut
13 4360143 Arm, Gear Motor
14 4360144 Arm, Cavity
15 4360145 Bolt
16 4360062 Strain Relief
17 4360006 Screw
18 4360146 Nut
19 4360147 Strain Relief
20 4360148 Screw
21 Cover, Housing Non-Serviceable
22 4360149 Cover, Wiring Box
23 4360150 Nut
24 Guide, Housing Non-Serviceable
25 4360152 Box, Wiring
26 4360153 Clamp
27 4360156 Nut
28 4360157 Spring
29 4360158 Washer
30 4360159 Bolt
31 4360160 Trim, R.H.
32 Cavity Non-Serviceable
33 Filter, Grease
4360193 KIRD801XSS0
4360194 KIRD861XSS0
34 4360005 Washer
35 4360165 Terminal
36 4360196 Micro Switch (2)
37 4360166 Actuator, Micro Switch (2)
38 4360167 Spring (2)
39 4360168 Cover, Switch
40 4360169 Housing, Switch
41 Support
4360171 L.H.
4360172 R.H.
42 4360173 Guide, Housing (Back)
43 4360174 Spacer, Cavity (2)
44 4360044 Clamp, Cable
45 4360133 Switch
47 4360163 Bolt
48 4360164 Nut
49 4360211 Nut, Wire

Following Parts Not Illustrated and Optional Parts Not Included
4360198 Installation Kit
LITERATURE PARTS
LIT4174172 Installation Instructions/Use and Care Guide
OPTIONAL PARTS NOT INCLUDED
4360205 Trim Kit-White (KIRD801)
4360207 Trim Kit-Black (KIRD801)
4360206 Trim Kit-White (KIRD861)
4360208 Trim Kit-Black (KIRD861)
