KITIDEA M601A User manual

Belgian Waffle Maker
Model No ： M601A
For your safety and continued enjoyment of this product, always read
the Instruction Book carefully before using.

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be taken, including
the following:
1. READ ALL INSTRUCTIONS.
2. Do not touch hot surfaces. Use handles and knobs.
3. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on
or taking off parts, and before cleaning appliance.
4. To protect against fire, electrical shock, and injury to persons, DO NOT IMMERSE
CORD, PLUG, OR UNIT in water or other liquids.
5. Close supervision is necessary when any appliance is used by or near children or
individual with certain disabilities.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest Kitidea®
Authorized Service Facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by Kitidea®may result in fire,
electric shock, or injury to persons.
8. Do not use outdoors, or use appliance for other than its intended use.
9. Do not let power cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Unplug the unit when finished baking waffles.
12. Always begin by plugging appliance into wall outlet. To disconnect, turn control to
setting OFF, then remove plug from wall outlet.
13. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REPAIR
SHOULD BE DONE ONLY BY AUTHORIZED PERSONNEL. DO NOT REMOVE THE
BASE PANEL. NO USER-SERVICEABLE PARTS ARE INSIDE.
14. Extreme caution must be used when moving an appliance contain hot oil or other hot
liquids.
15. Do not operate your appliance in an appliance garage or under a wall cabinet. When
storing in an appliance garage, always unplug the unit from the electrical outlet. Not doing so
could create a risk of fire, especially if the appliance touches the walls of the garage or the
door touches the unit as it closes.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY

2
POLARIZATION INSTRUCTIONS
For your protection, the Kitidea®Belgian Waffle Maker is supplied with a polarized plug
(one blade is wider than the other). To reduce the risk of fire, this plug will fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does
not ft, contact a qualified electrician for assistance. Do not modify the plug in any way.
Parts and Features
1. Waffle Plates-Bake extra-thick,1-inch Belgian waffles for even baking.
2. Lid Handle-Used to rotate waffle plates 180°.
3. Stainless Steel Cover.
4. Indicator Lights:
4a.Power light-illuminates when the waffle maker is plugged in.
4b.Heating lights -illuminate when the waffle plates are preheated and when the baking cycle
is complete.
5. Measuring Cup- Filled to the specified value for perfectly measured waffles.
6. Control Panel and knob - Adjustable from temperature settings 1-6 for different batters
you're desired.
7. Drip Tray- Catches any excess batter and is removable for easy cleaning.
8. Non-Skid Feet: Fix the entire product, make the product placed firmly.
9. BPA-Free (not shown)
All materials that come in contact with food or liquid are BPA free.

BEFORE FIRST USE
Before using your Kitidea®Belgian Waffle Maker for the first time, remove any dust from
shipping by wiping the plates with a damp cloth.
Remove all packaging and any promotional labels or stickers from your waffle maker. Be
sure that all parts (listed in Parts and Features) of your new waffle maker have been
included before discarding any packing materials. You may want to keep the box and
packing materials for use at a later date.
NOTE: The waffle plates have been treated with a special nonstick coating. The first time
you use your waffle maker, it may have a slight odor and may smoke a bit. This is normal
and common to appliances with a nonstick surface.

4
OPERATING INSTRUCTIONS
1. Place the Kitidea®Belgian waffle Maker on a clean, flat surface.
2. Plug the power cord into a standard electrical outlet
3.To preheat your Kitidea®Belgian waffle Maker, turn the control knob dial to your preferred
setting. The ready indicator light located on the in the control panel of the waffle maker will
light up when fully heated. (Heat-uptime should take approximately 4 minutes for the first
waffle of each baking session.)
4. After waffle maker is preheated, season waffle plates with cooking spray or brush with a
flavorless oil to thoroughly coat all surfaces. If s important that you preheat the waffle maker
before seasoning with cooking spray or oil. Your waffle maker is now ready to bake.
5. After the waffle maker is preheated and ready for baking, open the waffle maker lid.
6. Fill the provided batter cup with batter.Pour the batter evenly across the waffle plates. Use a
heatproof spatula to spread the batter evenly over the grids.
7. Close the lid and rotate the handle 180° to the right. The Heating indicator light will turn off.
NOTE: Baking time is determined by the browning setting chosen. It may take up to 4 minutes
longer to bake your waffles on a higher setting.
8. When the waffle is baked, the unit will beep three times, the Heating light indicator will
turn on.
Note: The browning and baking time of the waffle according to your perference. If you think
the waffle is not cooked enough after 1 baking cycle (the first buzzer and the heating indicator
light ON), please wait 1-2 more cycles of baking. Once the waffle maker is heated for the first
time, the cooking cycle time will be faster. It will take approx. 5-8mins to reach the optimal
temperature.
Rotate the handle 180° to the left and open the lid. To remove the waffle, gently loosen the
edges with a heatproof spatula. Never use stainless steel utensils, as they may damage the
nonstick coating.
9. Repeat the above process if making additional waffles. It is not necessary to spray the
waffle grids before each new waffle.
When you are finished baking, always unplug the power cord from the wall outlet Allow the
waffle maker to cool down completely before handling. The waffle plates have been treated
with a special nonstick PTFE coating. Before the first use, we suggest you season the grids
with cooking spray or flavorless vegetable oil. If using oil, apply oil with a paper towel or
pastry brush.
For Protection
1. When the circuit board cannot collect any temperature in 2 minutes, the buzzer alarm for a
long time (very rapid noise), the entire circuit will be powered off, no power.
2. When the whole machine continues to bum empty for 1 hour, not in use, the entire circuit
board will automatically lose power. No power, stop heating.

5
CLEANING AND CARE
Once you have finished baking, remove plug from electrical outlet. Leave the top lid open and
allow grids to cool before cleaning. Never take your Belgian waffle maker apart for cleaning.
Simply brush crumbs from grooves, and absorb any excess cooking oil by wiping with a dry
cloth or paper towel. You may clean the grids by wiping with a damp cloth to prevent staining
and sticking from batter or oil buildup.
Be certain grids have cooled completely before cleaning. If batter adheres to plates, simply
pour a little cooking oil onto the baked-on batter and let stand about 5 minutes.
This will soften the batter for easy removal.
To clean exterior, wipe with a soft, dry cloth. Never use an abrasive cleanser or harsh pad.
NEVER IMMERSE CORD, PLUG OR UNIT IN WATER OR OTHER LIQUIDS.
Hand-wash drip tray.
Care: Any other servicing should be performed by an authorized service representative.
TIPS
•Packaged Belgian waffle mixes found in most supermarkets may be used with this unit.
•For best results, we recommend filling the supplied measuring cup to the top so it will fill the
waffle plates.
•For evenly filled waffles, pour the batter into the center of the lower plate and spread out
evenly to the edges. The entire waffle plate should be filled.
•For added convenience while baking waffles, rest the measuring cup on the Lip of the bowl
containing the batter until the next baking cycle.
•We recommend turning the browning control dial to setting #4 when using commercial
pancake/waffle mixes and for the included recipes. If you prefer crisper, darker Belgian
waffles, set the browning control higher. If you prefer lighter waffles, turn the browning
control dial down.
•If waffles tend to stick to waffle plates, add slightly more oil or butter to the batter.
•Belgian waffles taste best when made to order, but baked Belgian waffles may be kept warm
in a 200°F oven. Place them in a baking pan or wrap them in foil while in the oven, waffles
wrapped in foil may lose their crispness.
•Baked waffles may be frozen. Allow them to cool completely, and then place them in a
plastic food storage bag. Use waxed paper to keep waffles separated. Reheat in an oven,
toaster or toaster oven when ready to serve.

10
LIMITED TWO-YEAR WARRANTY
This warranty is available to consumers only. You are a consumer if you own a Kitidea®
Belgian waffle Maker that was purchased at retail for personal, family or household use.
Except as otherwise required under applicable law, this warranty is not available to retailers or
other commercial purchasers or owners.
We warrant that your Kitidea®Belgian waffle Maker will be free of defects in materials and
workmanship under normal home use for 2 years from the date of original purchase. If your
Kitidea®Belgian Waffle Maker should prove to be defective within the warranty period, we
will repair it, or if we think necessary to replace it.
Classic Belgian Waffles
Classic Belgian waffles have a crispy outside and are soft and moist on the inside. Try these
waffles with your favorite syrup or a topping such as sliced fresh strawberries and freshly
whipped cream.
Makes approx. 10 waffles
11/2cups water, divided
21/4teaspoons active dry yeast (one packet)
3 cups sifted all-purpose flour
1/4teaspoon salt
3 large eggs, separated +1 egg white
1/3cup sugar
1/2cups whole milk
8 tablespoons unsalted butter, melted and cooled
2 teaspoons vegetable oil
2 teaspoons pure vanilla extract

5
Heat half of the water to lukewarm, 105°F-110°F (40°C-45°C). Dissolve the yeast in the water
with a pinch of the sugar from the recipe; let stand 5 to 10 minutes, until the mixture begins to
foam.
Put the flour and salt into a large bowl; stir to blend and reserve. Add the egg yolks, one of the
egg whites, and remaining sugar to the yeast mixture; stir to blend. Add the remaining water,
milk, melted butter, oil, and vanilla; stir until the mixture is smooth. Stir the Liquid mixture
into the flour mixture and beat until the mixture is smooth.
Beat the egg whites until stiff peaks form. Fold the egg whites gently into the batter. Let the
batter stand for 1 hour, stirring every 15 minutes. Preheat your Kitidea®Belgian Waffle
Maker on setting #4 or preferred setting* (indicator light will illuminate when preheated). For
best results, do not open waffle maker during cooking process. Doing so will offset the timing
mechanism.
When the waffle grids are preheated, open the lid. Fill the provided batter cup to the top with
batter. If using a standard measuring cup, fill to 3/4cup. Use a heatproof spatula to spread the
batter evenly over the grids. Close lid and rotate waffle maker 180° to the right. Bake the
waffles until the Ready light illuminates, indicating the waffle is done. Rotate waffle maker
180° to the left. Remove waffle and repeat until all batter is used.
Waffles may be kept warm in a low (200°F) oven. Place waffles arranged on a cookie sheet on
a rack in the warm oven. Serve with whipped cream, fruit, jam, powdered sugar, or a warm
fruit syrup. *We recommend using setting #4 to achieve agolden-brown, baked Belgian
waffle. Adjust the browning control if you prefer lighter or darker waffles.
Nutritional information per waffle: Calories 300 (40% from fat) • carb.
37g • pro. 8g fat 13g • sat. fat 7g ・chol. 94mg • sod. 104mg
calc. 61mg• fiber lg
Gingerbread Belgian Waffles
These waffles have the flavor of just-baked gingerbread, and are delicious served with fresh
fruit or caramelized apples and pears.
Makes approx. 6 waffles
1/2cup warm water
1 teaspoon granulated sugar
1/4teaspoons active dry yeast (one packet)
1/2cups all-purpose flour
1 cup graham cracker crumbs
1/4cup granulated sugar

5
1/4teaspoon salt
1 teaspoon ground ginger
1/2teaspoon finely chopped lemon zest
2 cups warm milk (about 105°F)
3 large eggs, separated
1/2cup unsalted butter, melted and cooled
1 teaspoon pure vanilla extract
Measure water into a large bowl. Add 1 teaspoon granulated sugar and yeast; stir to dissolve.
Let stand 10 minutes. In a separate bowl, combine the flour, graham cracker crumbs, 1/4cup
sugar, salt, ginger, and lemon zest; stir to combine. Add the milk, egg yolks, melted and
cooled butter, and vanilla to the yeast mixture. Stir until smooth. Add the dry ingredients and
beat until smooth, using a hand mixer on low speed. Cover with waxed paper and let stand to
rise in a warm, draft-free place for 30 minutes.
Beat the egg whites until stiff, but not dry. Gently fold into the batter. Preheat your Kitidea®
Belgian Waffle Maker on setting #4 or preferred setting* (indicator light will be illuminated
when preheated).
For best results, do not open waffle maker during cooking process. Doing so will offset the
timing mechanism.
When the waffle grids are preheated, open the lid. Fill the provided batter cup to the top with
batter. If using a standard measuring cup, fill to
3/4cup. Use a heatproof spatula to spread the batter evenly across the grids. Close lid and
rotate 180° to the right and bake the waffles until the Ready light illuminates, indicating the
waffle is done. Remove waffle and repeat with remaining batter.
Waffles may be kept warm in a low (200°F) oven. Place waffles arranged on a cookie sheet on
a rack in the warm oven. Serve with lemon curd, fruit jam, powdered sugar, a warm fruit syrup,
or whipped cream.
*We recommend using setting #4 to achieve a golden-brown, baked Belgian waffle. Adjust
the browning control if you prefer lighter or darker waffles.
Nutritional information per waffle: Calories 458 (44% from fat) • carb. 23g • pro. llg fat 23g •
sat. fat 12g ・chol. 159mg ・sod. 279mg calc, 120mg• fiber lg
Good-Night Waffles
Most of the mixing for these waffles is done the night before. In the morning, just mix in the
eggs, vanilla extract and baking soda while the waffle maker is heating. Leftover batter may
be covered and kept in the refrigerator for up to 3 days. Heat your waffle maker in the morning,
stir the batter and have a freshly baked waffle for breakfast.

5
Makes approx. 6 waffles
1/2cup lukewarm (105°F) water
l tablespoon granulated sugar
21/4teaspoons active dry yeast (one packet)
2cups whole milk, warmed (about 105°F)
1/2cup unsalted butter, melted and cooled
1 teaspoon salt
2 cups all-purpose flour
2 large eggs, lightly beaten
2 teaspoons pure vanilla extract
1/4teaspoon baking soda
The night before, or at least 8 hours before baking, combine the warm water, granulated sugar
and yeast. Let stand 10 minutes, until foamy. Stir in the warm milk, melted butter and salt.
Beat in the flour until smooth (this may be done using a hand mixer on low speed).
Wrap bowl tightly with plastic wrap and let stand overnight (or for 8 hours) on the countertop;
do not refrigerate.
When ready to bake, preheat your Kitidea®Belgian Waffle Maker on setting #4 or preferred
setting* (indicator light will be illuminated when preheated).
For best results, do not open waffle maker during cooking process. Doing so will offset the
timing mechanism.
While the waffle maker is heating, stir the eggs, vanilla extract and baking soda into the batter.
When the waffle grids are preheated, open the lid. Fill the provided batter cup to the top with
batter. If using a standard measuring cup, fill to 3/4cup. Pour into waffle grids. Use a heatproof
spatula to spread the batter evenly over the grids. Close cover and rotate 180° to the right.
Bake the waffles until the Ready light illuminates, indicating the waffle is done.
Rotate 180° to the left. Remove waffle and repeat with remaining batter. Waffles may be kept
warm in a low (200°F) oven. Place waffles arranged on a cookie sheet on a rack in the oven.
Serve with sliced fresh fruit jam, powdered sugar, a warm fruit syrup, or whipped cream.
*We recommend using setting #4 to achieve a golden-brown, baked Belgian waffle. Adjust
the browning control if you prefer lighter or darker waffles.
Nutritional information per waffle: Calories 373 (49% from fat) • carb. 38g • pro. 10g fat
20g • sat. fat 12g • chol. 123mg • sod. 501mg calc, 117mg • fiber lg
Pumpkin-Nut Belgian Waffles
These waffles taste like freshly baked pumpkin muffins and are delicious served with warm
maple syrup.
Makes approx. 6 waffles
1/2cups all-purpose flour

5
1 ounce finely chopped walnuts or pecans (best if toasted first)
1 tablespoon cornstarch
1 tablespoon baking powder
1 teaspoon salt
1 teaspoon ground cinnamon
1/2teaspoon ground ginger
1/4teaspoon freshly ground nutmeg
3/4cup pumpkin puree (canned solid-pack pumpkin)
2 large eggs, separated
1 cup whole milk
1/4cup real maple syrup (do not use pancake syrup)
3 tablespoons unsalted butter, melted and cooled
1 teaspoon pure vanilla extract
3 large egg whites
In a large bowl, combine the flour, chopped nuts, cornstarch, baking powder, salt, cinnamon,
ginger, and nutmeg. Stir to blend and reserve.
In a second bowl, combine the pumpkin puree, egg yolks, milk, maple syrup, melted butter,
and vanilla extract; stir until smooth. Add the liquid ingredients to the dry ingredients and stir
to blend until smooth, using a whisk.
In a clean, dry bowl, beat the egg whites until stiff peaks form. Gently fold the beaten egg
whites into the batter.
Preheat your Kitidea®Belgian Waffle Maker on setting #4 or preferred setting* (indicator
light will be illuminated when preheated).
For best results, do not open waffle maker during cooking process. Doing so will offset the
timing mechanism.
When the waffle grids are preheated, open the lid. Fill the provided batter cup to the top with
batter. If using a standard measuring cup, fill to 3/4cup. Pour into waffle grids. Use a heatproof
spatula to spread the batter evenly over the grids. Close cover and rotate 180° to the right.
Bake the waffles until the Ready light illuminates, indicating the waffle is done. Rotate 180°
to the left. Remove waffle and repeat with remaining batter. Waffles may be kept warm in a
low (200°F) oven. Place waffles arranged on a cookie sheet on a rack in the oven. Serve with
warm maple syrup, powdered sugar, or whipped cream.*We recommend using setting #4 to
achieve a golden-brown, baked Belgian waffle. Adjust the browning control if you prefer
lighter or darker waffles.
Nutritional information per waffle: Calories 303 (35% from fat) • carb. 40g • pro. 10g fat 12g
• sat. fat 5g • chol. 92mg • sod. 579mg calc. 94mg • fiber 2g

2
