Klarwind Air Purifier
USER MANUAL
Klarwind-100
r
C
U
ST
OM
ER SERVICE
TEL : 1-630-948-5004 Email : [email protected]
h^dKDZ^Zs/
d>ϭͲϲϯϬͲϵϰϴͲϱϬϬϰŵĂŝů><ƵƐƚŽŵĞƌ^ĞƌǀŝĐĞΛŐŵĂŝůĐŽŵ
Safety precautions
Product components
Product characteristics
Operational instructions
Key operation
Cleaning and Maintenance
7HFKQRORJ\DQGVSHFLƉFDWLRQV
Contents
5HSODFHPHQWRIƉOWHUV
Warranty
01
02
03
04
05
07
08
09
09
Prohibition
Warning
Notice
Any content with this mark must be prohibited, otherwise it may cause damage to the product
or endanger the personal safety of the user.
All contents with this mark must be strictly in accordance with the requirements, otherwise
it may cause damage to the product or endanger the personal safety of the user.
The content with this mark is the part that the user must pay attention to, otherwise it
will cause product damage or other loss due to improper operation.
Do not block the inlet / outlet.
Do not use this machine in wet places such as
fumes or bathrooms.
Regularly remove dust from fuselage and
power plugs.
Do not approach or place heat source objects
(such as fireplaces) when using this machine
or heaters or places that may be exposed to
flammable gases).
Do not unplug the power plug when the
hand is wet.
Do not clean and reuse efficient
composite nets.
Only randomly configured power adapters
can be used.
Be careful when cleaning the air purifier,
it is powerful corrosive cleaners can
damage the surface of the machine.
When cleaning or not using the machine,
unplug from the power outlet. Could cause
insulation Bad cause electric shock or fire
caused by short circuit.
This machine is not suitable for persons with
disabilities, persons with perceptual disabilities
and mental retardation people or children operate
on their own. If the person responsible for security
is present and provide guidance to assist in the
operation of this machine, is an exception.
01
Safety precautions
02 03
Before installing and using the product, please read this user manual carefully and keep
it properly for future use.
Decorative panels
Top cover
Shell
Lock
Base
Knob
Filter
Left Windward
Fan
Right Windward
DC 12V power adapter
1
2
3
4
5
6
7
8
9
10
11
Total Purification Function PURIFICATION FUNCTIONS
Dust removal,
mites and pollen
Effectively filter and remove indoor PM2.5Ƚ smoke, dust, pollen and so on; purify air, create fresh
space, purify harmful air State pollutants.
MAJOR FUNCTIONS
INITIAL FILTERφintercept hair, fiber velvet, large particles, dander and so on.
HEPA FILTERφcan remove air PM2.5, smoke, catkins, dander, pollen and other
particulate pollutants.
SPONGE WITH CARBON SPRAYINGφcan effectively purify harmful gases pollutants in the air.
3 IN 1
PRE
FILTER
HEPA
FILTER
CARBON
FILTER
1
2
3
4
5611
7
7
8
9
10
Compact design,
One-button start, simple operation.
Product characteristics
Product components
Removing fiber velvet,
animal dander, etc
Smoke removal
04
Please confirm that the purifier connects the power adapter (DC 12V) to
the socket that meets the requirements.
Please confirm that the power adapter is plugged in and tightly closed with
the power outlet.
Do not use when the power or plug is damaged, the body is damaged, or
the product is not working properly.
Do not touch the power cord with wet hands.
Use caution
3. Remove plastic bag
from filters.
6. plug the other end of
the adapter Into the right
electrical outlet,The purifier
enters the standby State.
7. light power on key
Turn it on.
8. the machine works
properly.
4. installed filter on the
machine and cover the
base.
5. input the power adapter
Insert the outlet into the
back of the machine
Interface.
2.Remove the machine
filter.
1.Twist the
machine base.
ȭStandby statusȮ
All indicator lights are lit when the purifier is connected to the DC 12V power supply and self-test is
extended for 0.5 seconds, that is, when the power is turned on, all lights are lit and extinguished after
0.5 seconds. The desktop air purifier enters standby state.
ȭSLEEPȮ
In standby state (the key cycle indicator is not on), touch the key, the air purifier enters the working
state, the key cycle indicator light is blue, the fan runs in the sleep mode, the sleep indicator lights up,
No opera-tion after 5 seconds in sleep mode, all lights go out.
ȭLOWȮ
In sleep mode, touch the key to wake up sleep, touch the machine again within 5 seconds into the
low-grade operation, low-gear indicator light.
ȭHIGHȮ
In the low-grade state, touch the key, the machine into high-grade operation, high-grade indicator lights.
In the high-grade state, touch the key into standby state.
ON/OFF
05
Key operation
Operational instructions
Cleaning attention
1. turn off the machine and unplug the power.
Then rotate the base cover Turn on and remove
2 used old filters.
2. remove the new filter and remove all the
packaging film.
3. re-load 2 new filters in the direction of filter marking
and place the base The cover is reinstalled.
4. plug in adapter power and proceed on standby
Filter life reset or forced cleanout (refer to P6
page filter instructions Operations).
Applicable premises
Desk Study Hotel Baby room
06 07
Filter screen replacement instructions:
The filter life of the machine is set to 3000 hours (1 hour of low-grade operation ,1 hour of sleep opera-
tion ,0.5 hours of life deduction ,2 hours of high-grade operation). When the service life of the filter is
150 hours, the key cycle indicator lights flicker red to remind the user to replace the new filter. When
the service life of the filter expires, the key cycle indicator lights bright red, remind the user to replace
the new filter in time.
1. filter life zero reset: when the key cycle indicator lights in standby or working red flicker or red long
light, until the user in standby state long press key 3 seconds zero reset, red indicator lights out, Filter
life is reset.
2. filter life forced zero reset: when the filter life has not expired and the user needs to force zero in
midway to replace the filter, in standby state long press key 3 seconds to open key cycle indicator light
red, Then long press key 3 seconds red indicator lights out, complete filter life forced zero.
The filter net of the purifier shall not be washed with water ;
It is recommended that you replaced the filter in time when the filter life
reaches;
Please clean the body with a squishy wiper;
Do not use water or corrosive cleaner to clean the body;
The upper air outlet can be cleaned with a soft brush;
After cleaning, put all parts of the machine back in place, plug in the
power cord and continue using.
Replacement of filters
Product model KAFN010HF1P1USW
13W
Rated voltage
Rated power
Applicable area
CADR 40CFM
10-13m2
Noise
N.W
G.W
Product size
Packing Size
43dB
2kg
2.5kg
200*200*310mm
235*235*395mm
08 09
12V
The machine must be unplugged before maintenance
1. Clean the body
1) Remove stains with a soft wiper.
2) Stubborn stains that cannot be easily removed can be removed with a suitable amount of
neutral cleansers in a soft wiper.
Notes: do not scratch the machine enclosure with hard objects during maintenance when
removing the front cover, please follow the instructions to operate and do not damage any part
on the machine.
2. Cleaning and replacement of the filter net
1) According to the pollution degree of the actual application environment, the service period of
the filter net is also different, which can be based on the sound volume generated by the
machine and smell judgement to replace in time.
2) Soft cloth can be used to clean the dust on the surface of the primary filter to extend the
service life of the filter.
3) High efficiency composite filter net is recommended to be replaced upon expiration.
* According to the using place and the using method, the service period of filter replacement
may be shortened or extended, the resetting and replacement of filter life in special environment
can be improved.
* Please treat the waste filter as burnable trash.
Warranty
Warranty Information
1. This product has passed strict quality inspection.
2. In case of performance and function fault under the condition of normal use within warranty period of
the product, our company will be responsible for repairing it for free and for replacing it if the machine
cannot be repaired. In the event of failure for the following reasons, our company will provide paid
repair service.
1) Poor performance and machine fault which occurs after the warranty period expires.
2) Machine fault caused by consumer intentionally or due to negligence.
3) Fault that occurs when the machine is repaired in the sales service center or agent not designated by our
company.
4) Fault that is caused by power supply nonconformity or poor quality of power socket
(irrelevant to warranty period).
5) Product fault or defect caused by natural disaster.
Technology and specifications
